SifWeld Evolution MTS200 SYN User manual

Operation Manual
www.sifweld.com
Peters House
The Orbital Centre
Icknield Way
Letchworth Garden City
Hertfordshire
SG6 1ET
Tel. [phone]
MIG
Approved
TIG MMA
TSXE1D200MTS
SifWeld Evolution MTS200 SYN

2
DECLARATION OF CONFORMITY
The Low voltage Directive 2006/95/EC of 12 December 2006, entering into force 16 January 2007
The EMC Directive 2004/108/EC, entering into force 20 July 2007
The RoSH Directive 2011/65/EC, entering into force 2 January 2013
Type of Equipment
Welding power source for MIG/MAG, TIG/TAG, MMA welding
Brand name or trade mark
SifWeld® Evolution
Type designation etc.
MTS200 SYN
Manufacturer or his authorised representative established within the EEA
Name, address, telephone no, fax no
Weldability Sif
Peters House, The Orbital Centre
Icknield Way, Letchworth
Hertfordshire, SG6 1ET
United Kindom
Phone: [phone] Fax: [phone]
The following harmonised standard in force with the EEA has been used in the design:
EN60974-1- Arc welding equipment- Part 1: Welding power sources
EN60974-10 Arc welding equipment - Part 10: Electromagnetic Compatibility (EMC) requirements
Additional information: restrictive use, Class A equipment, intended for use in locations other than residential
By signing this document, the undersigned declares as manufacturer, or the manufacturer’s authorised
representative established within the EEA, that the equipment in question complies with the safety
requirements stated above.
WEEE Directive & Product Disposal
At the end of its serviceable life, this product should not be treated as household
or general waste. It should be handed over to the applicable collection point for
the recycling of electrical and electronic equipment, or returned to the supplier for
disposal.
Place and Date
Letchworth, UK
01-04-2015
Position
Quality Manager
Weldability Sif
Signiture
Keith Mullan

3
Safety Guidelines
These general safety norms cover both arc welding machines and plasma cutting machines unless
otherwise noted. The equipment must only be used for the purpose it was designed for. Using it in any
other way could result in damage or injury and in breach of the safety rules. Only suitably trained and
competent persons should use the equipment. Operators should respect the safety of other persons.
Prevention against electric shock
The equipment should be installed by a qualified person and in accordance with current standards in
operation. It is the user’s responsibility to ensure that the equipment is connected to a suitable power
supply. Consult with your utility supplier if required. If earth grounding of the work piece is required,
ground it directly with a separate cable. Do not use the equipment with the covers removed. Do not
touch live electrical parts or parts which are electrically charged. Turn off all equipment when not in use.
Cables (both primary supply and welding) should be regularly checked for damage and overheating. Do
not use worn, damaged, under sized or poorly jointed cables. Ensure that you wear the correct protec-
tive clothing, gloves, head and eye protection. Insulate yourself from work and ground using dry insulat-
ing mats or covers big enough to prevent any physical contact with the work ground. Never touch the
electrode if you are in contact with the work ground, or another electrode from a different machine.
Do not wrap cables over your body. Ensure that you take additional safety precautions when you are
welding in electrically hazardous conditions such as damp environments, wearing wet clothing, and
metal structures. Try to avoid welding in cramped or restricted positions. Ensure that the equipment is
well maintained. Repair or replace damaged or defective parts immediately. Carry out any regular main-
tenance in accordance with the manufacturer’s instructions.
Safety against fumes and welding gases
Locate the equipment in a well-ventilated position. Keep your head out of the fumes. Do not breathe
the fumes. Ensure the welding zone is in a well-ventilated area. If this is not possible provision should be
made for suitable fume extraction. If ventilation is poor, wear an approved respirator. Read and under-
stand the Material Safety Data Sheets (MSDS’s) and the manufacturer’s instructions for metals, consum-
able, coatings, cleaners, and de-greasers. Do not weld in locations near any de-greasing, cleaning, or
spraying operations. Be aware that heat and rays of the arc can react with vapours to form highly toxic
and irritating gases. Do not weld on coated metals, unless the coating is removed from the weld area,
the area is well ventilated, and while wearing an air-supplied respirator. The coatings on many metals
can give off toxic fumes if welded.
Prevention against burns and radiation
Arc rays from the welding process produce intense, visible and invisible (ultraviolet and infrared) rays
that can burn eyes and skin. Wear an approved welding helmet fitted with a proper shade of filter lens
to protect your face and eyes when welding or watching. Wear approved safety glasses with side shields
under your helmet. Never use broken or faulty welding helmets. Always ensure there are adequate
protective screens or barriers to protect others from flash, glare and sparks from the welding area. Ensure
that there are adequate warnings that welding or cutting is taking place.

4
Wear suitable protective flame resistant clothing. The sparks and spatter from welding, hot work pieces,
and hot equipment can cause fires and burns. Welding on closed containers, such as tanks, drums, or
pipes, can cause them to explode. Accidental contact of electrode to metal objects can cause arcs,
explosion, overheating, or fire. Check and be sure the area is safe and clear of inflammable material
before carrying out any welding.
Protection against noise
Some welding and cutting operations may produce noise. Wear safety ear protection to protect your
hearing.
Protection from moving parts
When the machine is in operation, keep away from moving parts such as motors and fans. Moving
parts, such as the fan, may cut fingers and hands and snag garments. Protections and coverings may
be removed for maintenance and controls only by qualified personnel, after first disconnecting the
power supply cable. Replace the coverings and protections and close all doors when the intervention
is finished, and before starting the equipment. Take care to avoid getting fingers trapped when loading
and feeding wire during set up and operation. When feeding wire be careful to avoid pointing it at other
people or toward your body. Always ensure machine covers and protective devices are in operation.
Precautions against fire and explosion
Avoid causing fires due to sparks and hot waste or molten metal. Ensure that appropriate fire safety
devices are available near the cutting / welding area. Remove all flammable and combustible materials
from the cutting / welding zone and surrounding areas. Do not cut/weld fuel and lubricant containers,
even if empty. These must be carefully cleaned before they can be cut/welded. Always allow the cut/
welded material to cool before touching it or placing it in contact with combustible or flammable
material. Do not work in atmospheres with high concentrations of combustible fumes, flammable gases
and dust. Always check the work area half an hour after cutting to make sure that no fires have begun.
Risks due to magnetic fields
The magnetic fields created by high currents may affect the operation of pacemakers or electronically
controlled medical equipment. Wearers of vital electronic equipment should consult their physician
before beginning any arc welding, cutting, gouging or spot welding operations. Do not go near welding
equipment with any sensitive electronic equipment as the magnetic fields may cause damage.
RF Declaration
Equipment that complies with directive 2004/108/EC concerning electromagnetic compatibility (EMC)
and the technical requirements of EN60974-10 is designed for use in industrial buildings and not those
for domestic use where electricity is provided via the low voltage public distribution system. Difficulties
may arise in assuring class A electromagnetic compatibility for systems installed in domestic locations
due to conducted and radiated emissions. In the case of electromagnetic problems, it is the
responsibility of the user to resolve the situation. It may be necessary to shield the equipment and fit
suitable filters on the mains supply.

5
LF Declaration
Consult the data plate on the equipment for the power supply requirements. Due to the elevated
absorbency of the primary current from the power supply network, high power systems affect the
quality of power provided by the network. Consequently, connection restrictions or maximum
impedance requirements permitted by the network at the public network connection point must be
applied to these systems. In this case the installer or the user is responsible for ensuring the equipment
can be connected, consulting the electricity provider if necessary.
Materials and their disposal
The equipment is manufactured with materials, which do not contain any toxic or poisonous
materials dangerous to the operator. When the equipment is scrapped, it should be dismantled
separating components according to the type of materials. Do not dispose of the equipment with
normal waste. The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment states
the electrical equipment that has reached its end of life must be collected separately and returned to an
environmentally compatible recycling facility.
Handling of Compressed gas cylinders and regulators
All cylinders and pressure regulators used in welding operations should be handled with care.
Never allow the electrode, electrode holder or any other electrically “hot” parts to touch a cylinder.
Keep your head and face away from the cylinder valve outlet when opening the cylinder valve.
Always secure the cylinder safely. Never deface or alter any cylinder.
The following signs and explanations are to remind the user of the potential
risks involved and the dangers of misuse or mistreatment of the welding
machine.
!
RUNNING PARTS MAY BE DANGEROUS!
Keep away from running components,
including the fan.
BE AWARE OF SPARKS AND SPATTER
Wear protective clothing, such as leather
gloves, Flame retardant overalls, boots and
eyewear.
DO NOT TOUCH THERMAL COMPONENTS!
Thermal components may cause severe burns
when in contact with unprotected skin.
ELECTRIC SHOCKS CAN KILL!
Never touch electrical parts. Keep the
equipment in good condition, replace
damaged parts, undertake regular
maintenance according to the instructions.

6
1. Preface 7
1.1 General 7
1.2 Introduction 8
1.3 Technical Specications 9
1.4 Overview of Machine 10
2. Control Panels 11
2.1 MMA Display 12
2.2 Lift TIG Display 13
2.3 MIG Manual Display 16
2.4 MIG SYN Display 18
2.5 Spool Gun Display 20
2.6 System Setting Panel 21
3. Installation MMA, MIG, TIG 22
3.1 Wire Feed Roller 29
3.2 Wire Intallation and setup 30
3.3 MIG Totch liner Types 32
4. Operation 33
4.1 Spool Gun 34
5. Troubleshooting 37
6. Maintenance 38
7. Warranty 39
Contents

7
1. Preface
Congratulations on choosing your SifWeld Evolution MTS200 welding machine.
Used correctly, SifWeld products can signicantly increase the productivity of your welding, and provide
years of economical service. This operating manual contains important information on the use,
maintenance and safety of your SifWeld product. Please read the manual carefully before using the
equipment for the rst time. For your own safety and that of your working environment, pay particular
attention to the safety instructions in the manual.
For more information on SifWeld products, consult an authorised SifWeld dealer, or visit the SifWeld web
site at www.sifweld.com. The specications presented in this manual are subject to change without prior
notice.
Important notes
Items in the manual that require particular attention in order to minimise damage and personal harm
are indicated with the ’NOTE!’ notation. Read these sections carefully and follow their instructions.
Disclaimer
While every effort has been made to ensure that the information contained in this guide is accurate and
complete, no liability can be accepted for any errors or omissions. We reserve the right to change the
specication of the product described at any time without prior notice. Do not copy, record, reproduce
or transmit the contents of this guide without prior permission.
1.1 General

8
The SifWELD MTS200SYN is a professional, digital controlled inverter welding powersource
for MIG, MMA & Lift-TIG applications.
Using the built in Synergic facility the machine will automatically give the optimum welding
parameters for the specic material, wire size and shielding gas. featuring IGBT technology and providing a
lightweight, multi-process machine. An integral wire feed system accommodates 5kg wire spools.
Features
• Full Digital Control with large Colour LCD Screen for showing and changing all welding parameters
• Active PFC technology for increased duty cycle and energy efficiency.
• Multi voltage input, can use with long extension lead, 230V or 110V
• MIG/MAG with Synergic programs for aluminum, mill steel, stainless steel and CuSi
- 2T /4T/S4T/Spot Weld welding mode
- function parameter adjustment
• MMA function (Stick electrode)
- Hot start (improves electrode starting)
- Adjustable Arc Force
• DC TIG
- Lift Arc ignition (prevents tungsten sticking during arc ignition)
- 2T /4T Trigger Control
- Adjustable Down slope
-Gas/air cooling mode
• Internal wire feeder, gear driven for up to 5kg Ø spool.
• Euro style MIG torch connection.
• IP21S rating for environmental/safety protection.
• Spool Gun Connection.
1.2 Introduction

9
Duty cycle (40oC)
No-load Voltage (V)
Welding Current (A)
Input Power (KW)
Input Current (A)
67.5 66.7 67.5 66.7 67.467.4
Frequency (HZ)
1.3 Technical Specications
SifWeldEvolution MTS200 SYN
Input Voltage (V) 1~110/120/130±10%
Diameter (mm)
50/60
36.6 27.6
40% 140A
60% 115A
100% 90A
Fe: 0.6/0.8/0.9/1.0
SS: 0.8/1.0
Flux-Cored: 0.6/0.8/0.9/1.0
MIG
1~220/230/240±10%
25.6 20.2 30.4
40% 100A
60% 85A
100% 65A
Al: 1.2
0.99
TIG MIG MIG TIG MIG
27.9
4.0 3.0 5.9 4.6 7.0 3.1
25~140 10~140 25-20010~100
40% 200A
60% 165A
100% 130A
Protection class
Circuit breaker
Dimensions (mm)
Weight (Kg)
Power Factor
IP21S
JD03-A1 30A
540*245*390
17.8
10~200

10
1.4 Overview of Machine
Front View
Power Source Front Panel Layout
1. Positive (+) welding power output
connection socket.
2. MIG torch euro connector.
3. Remote connection plug.
4. Negative (-) welding power output
connection socket.
5. TIG torch gas connector.
6. Power switch.
7. Gas inlet connector.
8. Input power cable.
Rear View
6. Power switch.
7. Gas inlet connector.
8. Input power cable.
Wire Feeder of machine
9. Spool holder.
10. Spool Gun Switch.
11. MIG Torch Polarity Change Power Connection.
12. Wire feed tension adjustment.
13. Wire feed tension arm.
14. Wire feeder inlet guide.
15. Wire drive roller.

11
2. Control Panels
1. Screen
It displays welding current and welding voltage or other parameters, error codes.
2. Welding mode button
Press it to select MMA/ TIG Lift/ MIG Manual/ MIG Synergic and Spool Gun welding mode.
3. Gas check button
Press it to check whether the machine isn’t air-connected or the gas passage isn’t smooth.
4. Left parameter knob
Press it to select parameters and rotate it to adjust values, such as welding current. In function
interface, rotate it to select parameters.
5. Function button
Press it to select parameters or enter the function interface.
6. Right parameter knob
Press it to select parameters and rotate it to adjust values.
7. Manual wire feed button.

12
2.1 MMA Display
1. Welding mode button
Press it to enter MMA welding mode.
2. Left parameter knob
Rotate it to welding current.
3. Right parameter knob
Press it to select Hot Start or Arc Force and rotate it to adjust values.
Hot start
Hot start provides extra power when the weld starts to counteract the high resistance of the electrode
and workpiece as the arc is started. Setting range: 0~10.
Arc force
An MMA welding power source is designed to produce constant output current. This means with
different types of electrode and arc length; the welding voltage varies to keep the current constant.
This can cause instability in some welding conditions as MMA welding electrodes will have a minimum
voltage they can operate with and still have a stable arc.
Arc Force control boosts the welding power if its senses the welding voltage is getting too low. The
higher the arc force adjustment, the higher the minimum voltage that the power source will allow. This
effect will also cause the welding current to increase. 0 is Arc Force off, 10 is maximum Arc Force. This is
practically useful for electrode types that have a higher operating voltage requirement or joint types that
require a short arc length such as out of position welds.

13
2.2 LIFT TIG display
1. Welding mode button
Press it to enter Lift TIG welding mode.
2. Left parameter knob
Rotate it to adjust welding current. In function interface, rotate it to select parameters, such as
trigger mode and Post Flow time.
3. Right parameter knob
Rotate it to adjust Down Slope time or other parameters.
4. Function button
Press it to enter the function interface.that require a short arc length such as out of position welds.
FUNCTION INTERFACE
1. Motion: Trigger mode 2T/ 4T/ Spot weld.
2. Post Flow 0-10s.

14
2T MODE
The trigger is pulled and held on to activate the welding circuit, when the trigger is released, the
welding circuit stops. This function without the adjustment of start current and crater current is suitable
for the Re-tack welding, transient welding, thin plate welding and so on.
PANEL FUNCTIONS & DESCRIPTIONS
1
released, the welding circuit stops.
This function without the adjustment of start current and crater current is suitable for the
Re-tack welding、transient welding、thin plate welding and so on.
Introduction:
(1) 0: Press the gun switch and hold it. Electromagnetic gas valve is turned on. The
shielding gas stars to flow.
(2) 0～t1: Pre-gas time (0.1~2.0s)
(3) t1～t2: Arc is ignited and the output current rises to the setting welding current (Iwor
Ib) from the min welding current.
(4) t2～t3: During the whole welding process, the gun switch is pressed and held without
releasing.
Note: Select the pulsed output, the base current and welding current will be outputted
alternately; otherwise, output the setting value of welding current;
(5) t3: Release the gun switch, the welding current will drop in accordance with the
selected down-slope time.
(6) t3～t4: The current drops to the minimum welding current from the setting current (Iw
or Ib), and then arc is turned off.
(7) t4～t5: Post-gas time, after the arc is turned off. You can adjust it (0.0~10s) through
turnning the knob on the front panel.
(8) t5: Electromagnetic gas valve turned off, the shield gas stops to flow, and welding is
finished.
4T Mode
This is known as ’latching’ mode. The trigger is pulled once and released to activate the
Introduction
1. 0: Press the gun switch and hold it. Electromagnetic gas valve is turned on. The shielding gas stars to
ow.
2. 0~t1: Pre-gas time (0.1~2.0s)
3. t1~t2: Arc is ignited and the output current rises to the setting welding current (Iw or Ib) from the
min welding current.
4. t2~t3: During the whole welding process, the gun switch is pressed and held without releasing.
Note: Select the pulsed output, the base current and welding current will be outputted alternately;
otherwise, output the setting value of welding current.
5. t3: Release the gun switch, the welding current will drop in accordance with the selected down-slope
time.
6. t3~t4: The current drops to the minimum welding current from the setting current (Iw or Ib), and
then arc is turned off.
7. t4~t5: Post-gas time, after the arc is turned off. You can adjust it (0.0~10s) through turnning the knob
on the front panel.
8. t5: Electromagnetic gas valve turned off, the shield gas stops to ow, and welding is nished.

15
4T MODE
This is known as ’latching’mode. The trigger is pulled once and released to activate the welding circuit,
pulled and released again to stops the welding circuit. This function is useful to longer welds as the
trigger is not required to be held on continuously. TIG series of welding machines also has more current
control options that can be used in 4T mode.
The start current and crater current can be pre-set. This function can compensate the possible crater
that appears at the beginning and end of the welding. Thus, 4T is suitable for the welding of medium
thickness plates.
PANEL FUNCTIONS & DESCRIPTIONS
1
welding circuit, pulled and released again to stops the welding circuit. This function is
useful to longer welds as the trigger is not required to be held on continuously. TIG series
of welding machines also has more current control options that can be used in 4T mode.
The start current and crater current can be pre-set. This function can compensate the
possible crater that appears at the beginning and end of the welding. Thus, 4T is suitable
for the welding of medium thickness plates.
Introduction:
(1) 0: Press and hold the gun switch, Electromagnetic gas valve is turned on. The
shielding gas stars to flow;
(2) 0～t1: Pre-gas time (0.1~2.0S);
(3) t1～t2: Arc is ignited at t1 and then output the setting value of start current;
(4) t2: Loosen the gun switch, the output current slopes up from the start current;
(5) t2～t3: The output current rises to the setting value (Iwor Ib), the upslope time can be
adjusted;
(6) t3～t4: Welding process. During this period, the gun switch is loosen;
Note: Select the pulsed output, the base current and welding current will be outputted
alternately; otherwise, output the setting value of welding current;
(7) t4: Press the torch switch again, the welding current will drop in accordance with the
selected down-slope time.
(8) t4～t5: The output current slopes down to the crater current. The downslope time
can be adjusted;
(9) t5～t6: The crater current time;
(10) t6: Loosen the gun switch, stop arc and keep on argon flowing;
(11) t6～t7: Post-gas time can be set by the post-gas time adjustment knob on the front
Introduction
1. 0: Press and hold the gun switch, Electromagnetic gas valve is turned on. The shielding gas stars to ow.
2. 0~t1: Pre-gas time (0.1~2.0S);
3. t1~t2: Arc is ignited at t1 and then output the setting value of start current;
4. t2: Loosen the gun switch, the output current slopes up from the start current;
5. t2~t3: The output current rises to the setting value (Iw or Ib), the upslope time can be adjusted;
6. t3~t4: Welding process. During this period, the gun switch is loosen;
Note: Select the pulsed output, the base current and welding current will be outputted alternately;
otherwise, output the setting value of welding current;
7. t4: Press the torch switch again, the welding current will drop in accordance with the selected down-
slope time.
8. t4~t5: The output current slopes down to the crater current. The downslope time can be adjusted;
9. t5~t6: The crater current time;
10. t6: Loosen the gun switch, stop arc and keep on argon owing;
11. t6~t7: Post-gas time can be set by the post-gas time adjustment knob on the front

16
2.3 MIG Manual Display
PANEL FUNCTIONS & DESCRIPTIONS
1
panel (0.0～10S);
(12) t7: Electromagnetic valve is closed and stop argon flowing. Welding is finished.
§3.2.4 MIG Manual display introduction
1. Welding mode button: Press it to enter MIG Manual welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In function interface,
rotate it to select parameters.
3. R parameter knob: rotate it to adjust Inductance or other parameters.
4. Function button: Press it to enter the function interface.
5. Air check button.
6. Manual wire button.
Function interface:
1. Welding mode button
Press it to enter MIG Manual welding mode.
2. Left parameter knob
Rotate it to adjust wire feeding speed. In function interface, rotate it to select parameters.
3. Right parameter knob
rotate it to adjust Inductance or other parameters.
4. Function button
Press it to enter the function interface.
5. Gas check button.
6. Manual wire feed button.
PANEL FUNCTIONS & DESCRIPTIONS
1
panel (0.0～10S);
(12) t7: Electromagnetic valve is closed and stop argon flowing. Welding is finished.
§3.2.4 MIG Manual display introduction
1. Welding mode button: Press it to enter MIG Manual welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In function interface,
rotate it to select parameters.
3. R parameter knob: rotate it to adjust Inductance or other parameters.
4. Function button: Press it to enter the function interface.
5. Air check button.
6. Manual wire button.
Function interface:
FUNCTION INTERFACE
1. Motion: Trigger mode: 2T/ 4T/ Spot weld.
2. Pre Flow: 0-10s.
3. Post Flow: 0-10s.
4. Burnback: 0-10.
5. Slow Feed: 0-10s.

17
Burnback
Short-circuit between welding wire and molten pool leads to the increase of current, which leads to the
melting speed of welding wire too fast, and the wire feeding speed cannot keep up with, which makes
the welding wire and workpiece disconnected. This phenomenon is called “burn back”. This function is
to ensure the welding seam is not constant after welding. Range: 0-10.
Slow feed
This function is used to regulate the start speed of wire feeding increasing. Range: 0-10s.
Spot Weld trigger mode
PANEL FUNCTIONS & DESCRIPTIONS
1
1. Motion: Trigger mode: 2T/ 4T/ Spot weld.
2. Pre Flow: 0-10s.
3. Post Flow: 0-10s.
4. Burnback: 0-10.
5. Slow Feed: 0-10s.
Burnback
Short-circuit between welding wire and molten pool leads to the increase of current,
which leads to the melting speed of welding wire too fast, and the wire feeding speed
cannot keep up with, which makes the welding wire and workpiece disconnected. This
phenomenon is called “burn back”. This function is to ensure the welding seam is not
beautiful after welding. Range: 0-10.
Slow feed
This function is used to regulate the speed of wire feeding increasing. Range: 0-10s.
Spot Weld trigger mode:
Gun Switch
Gas Supply
Wire Feed
Output Voltage
Output Current
Spot Weld Time
Spot weld

18
2.4 MIG SYN Display
PANEL FUNCTIONS & DESCRIPTIONS
1
§3.2.5 MIG SYN display introduction
The operator simply sets the welding current like MIG welding and the machine
calculates the optimal voltage and wire speed for the material type, wire type and size
and shielding gas being used. Obviously other variables such as welding joint type and
thickness, air temperature affect the optimal voltage and wire feed setting, so the
program provides a voltage fine tuning function for the synergic program selected. Once
the voltage is adjusted in a synergic program, it will stay fixed at this variation when the
current setting is changed. To reset the voltage for a synergic program back to factory
default, change to another program and back again.
1. Welding mode button: Press it to select MIG SYN welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In functional parameter
interface, rotate it to select parameters.
3. R parameter knob: Rotate it to adjust parameters.
4. Functional button.
5. Manual shield gas check button.
6. Manual wire feed button.
The operator simply sets the welding current like MIG welding and the machine calculates the optimal
voltage and wire speed for the material type, wire type and size and shielding gas being used. Obviously
other variables such as welding joint type and thickness, air temperature affect the optimal voltage
and wire feed setting, so the program provides a voltage ne tuning function for the synergic program
selected. Once the voltage is adjusted in a synergic program, it will stay xed at this variation when the
current setting is changed. To reset the voltage for a synergic program back to factory default, change to
another program and back again.
1. Welding mode button
Press it to select MIG SYN welding mode.
2. Left parameter knob
Rotate it to adjust wire feeding speed. In functional parameter interface, rotate it to select parameters.
3. Right parameter knob
Rotate it to adjust parameters.
4. Functional button.
5. Manual shield gas check button.
6. Manual wire feed button.

19
PANEL FUNCTIONS & DESCRIPTIONS
1
§3.2.5 MIG SYN display introduction
The operator simply sets the welding current like MIG welding and the machine
calculates the optimal voltage and wire speed for the material type, wire type and size
and shielding gas being used. Obviously other variables such as welding joint type and
thickness, air temperature affect the optimal voltage and wire feed setting, so the
program provides a voltage fine tuning function for the synergic program selected. Once
the voltage is adjusted in a synergic program, it will stay fixed at this variation when the
current setting is changed. To reset the voltage for a synergic program back to factory
default, change to another program and back again.
1. Welding mode button: Press it to select MIG SYN welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In functional parameter
interface, rotate it to select parameters.
3. R parameter knob: Rotate it to adjust parameters.
4. Functional button.
5. Manual shield gas check button.
6. Manual wire feed button.
FUNCTION INTERFACE
1. Trigger mode: 2T/ 4T/ S4T/ Spot weld. (No Spot weld in MIG Dual Pulse.)
2. Wire material: SS solid-cored/ Fe solid-cored/ Fe ux-cored/ Al-Mg solid-cored/ CuSi.
3. Wire diameter: 0.6~1.6mm.
4. Shield gas: CO2 and Ar+CO2 20%.
5. Pre ow time: 0~10s.
PANEL FUNCTIONS & DESCRIPTIONS
1
Function interface:
1. Trigger mode: 2T/ 4T/ S4T/ Spot weld. (No Spot weld in MIG Dual Pulse.)
2. Wire material: SS solid-cored/ Fe solid-cored/ Fe flux-cored/ Al-Mg solid-cored/
CuSi.
3. Wire diameter: 0.6~1.6mm.
4. Shield gas: CO2and Ar+CO220%.
5. Pre flow time: 0~10s.
S4T trigger mode:
Gun Switch
Gas Supply
Wire Feed
Output Voltage
Output Current
Welding condition
Initial condition
End Current condition
Transition Time
Burnback Time
S4T mode

20
2.5 Spool Gun Display
1. Welding mode button
Press it to select Spool Gun welding mode.
2. Left parameter knob
Rotate it to adjust wire feeding speed. In functional parameter interface, rotate it to select parameters.
3. Right parameter knob
Rotate it to adjust parameters.
4. Functional parameter button.
5. Manual shield gas check button.
6. Manual wire feed button.
PANEL FUNCTIONS & DESCRIPTIONS
1
§3.2.6 Spool Gun display introduction
1. Welding mode button: Press it to select Spool Gun welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In functional parameter
interface, rotate it to select parameters.
3. R parameter knob: Rotate it to adjust parameters.
4. Functional parameter button.
5. Manual shield gas check button.
6. Manual wire feed button.
Function interface:
PANEL FUNCTIONS & DESCRIPTIONS
1
§3.2.6 Spool Gun display introduction
1. Welding mode button: Press it to select Spool Gun welding mode.
2. L parameter knob: Rotate it to adjust wire feeding speed. In functional parameter
interface, rotate it to select parameters.
3. R parameter knob: Rotate it to adjust parameters.
4. Functional parameter button.
5. Manual shield gas check button.
6. Manual wire feed button.
Function interface:
FUNCTION INTERFACE
1. Trigger mode: 2T/ 4T/ Spot weld.
2. Pre ow time: 0~10s.
3. Post ow time: 0~10s.
4. Burnback: 0~10.
5. Slow feed time: 0~10s.
