Sigtronics S-58Y User manual

igtronics
®
Sigtronics
®
S
…when it counts!
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: [phone]
E-mail: [e-mail]
Web Site: www.sigtronics.com
Model S-58Y
Headset Instructions
The S-58Y series headsets are adjusted at the factory for immediate use with all
current standard radio systems in general aviation aircraft. Headsets equipped
with two plugs are the standard conguration. The headphone plug is the larger
diameter plug and should be inserted into the headphone jack (.250” standard
monaural jack). The mic plug is the smaller diameter plug and should be inserted
into the microphone jack (.206” standard microphone jack).
The headband is adjustable through a full range of motion, or the locking nuts
may be tightened to allow you to custom t the headset. Place the headset over
your head, adjust the slides up until minimum pressure is felt on the top of your
head. The headset is now properly adjusted. For maximum noise attenuation, the
clamping pressure has been set at the factory. Releasing the clamping pressure
by bending the headband is not advised, because loss of attenuation will result.
Note: If an especially large headband is needed, it may be ordered from Sigtronics.
The microphone boom is fully adjustable and will rotate 180 degrees for use on
the left or right side of the head. Make sure you are speaking into the side of the
mic labeled “Talk” or substantial loss of gain will occur. Microphone placement
should be at the corner of the mouth, approximately ¼” from the lips.
When you rst connect the headset, turn the volume control on the headset up
to the full clockwise position, then adjust the listening volume with the audio
control of either your radio or intercom as appropriate. Passengers should also
turn their individual headset volumes up fully. Doing this allows for a full range of
adjustment for each passenger, since those with the most acute hearing can turn
their headset volume down, if necessary.
continued on back…
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in water
or any other liquid. Be especially careful not to allow the microphone to become
wet! Exposure to moisture may cause internal corrosion and failure and will void
your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thoroughly
and make sure it is completely dry before putting it back on.
To remove the windscreen, carefully grasp the windscreen lightly along its entire
length and remove from the microphone element being careful not to twist the
element itself.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited ve-year parts and labor warranty. Please see
the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.

SIGTRONICS S-58Y HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1100671 HEAD BAND EXTRUSION, 6.25 IN., S-58Y 13 100108 SCREW, 4-40 X 1/4, THREAD FORMING 25 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH
2100610 CUSHION, HEADBAND, FOAM FILLED 14 100251 E-RING, EAR CUP TO YOKE RETAINER 26 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH
3100672 HEADBAND, METAL, BLACK, YOUTH 15 100252 NUT, HEX, 8-32, LOCKING 27 800036 CABLE, HEADSET, MONAURAL
4100602 HEADBAND, METAL, BLACK, STANDARD 16 100941 EAR CUP, PRINTED AND DRILLED, MICROPHONE SIDE 28 100933 WIRE, CROSSOVER, OVER THE HEAD, 28 INCH
5100603 YOKE, EAR CUP MOUNT, METAL, BLACK 17 100938 EAR CUP, PRINTED AND DRILLED, VOLUME CONTROL SIDE 29 100935 WIRE, #22, JUMPER, HEADSET, 4 INCH
6100604 BRACKET, YOKE SUPPORT WITH TANG, BLACK 18 100049 GROMMET, 5/16 INCH, RUBBER 30 100569 STRAIN RELIEF, CABLE
7100373 SLIDE, YOKE BRACKET, LONG, NYLON 19 800044 MICROPHONE & FLEX BOOM ASSEMBLY 31 100579 CLIP, CLOTHING, HEADSET CABLE
8100258 CLIP, HEADBAND GUIDE, PLASTIC 20 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 32 100360 KNOB, BLACK, VOLUME
9100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC 21 90 0111 WINDSCREEN, MIC, 8 SERIES 33 100365 POTENTIOMETER, 2K
10 100362 CLIP, CROSS-OVER, WIRE, PLASTIC 22 800250 PREAMP 34 100858 RECEIVER AND MOUNT, 300 OHM, MONO
11 100363 SCREW, 8-32 X 1/2, PHILLIPS HEAD 23 100402 EAR SEAL, GEL FILLED 35 100613 OPTIONAL – HEADBAND, METAL, BLACK, LARGE
12 100364 SCREW, 8-32 X 3/8, PHILLIPS HEAD 24 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 36 100369 OPTIONAL – EAR SEAL, FOAM FILLED


 







 

























10-5-2021
s-58y.pdf
