Moman H2 User manual

Thank you for choosing MOMAN product. Please read this manual carefully
before use and follow all instructions mentioned herein.
User Manual
MOMAN
H2
Headset Helmet Intercom
2-Rider Kit
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Caring For Your MOMAN Product
Intercom x2
Screw Driver x2
Back Clip x2
USB Cable x2 Headphone Velcro x8
1 Pair of Speakers with
Microphone x2
Hook and Loop
Fasteners x2
Manual x1
Velcro Clip x2
Package List
MOMAN
Product Introduction
① On/Off Key
② Indicator Light
③ Function Key
④ Charging Interface
⑤ Knob
⑥ Headset Interface
⑦ Buckle Flap
⑧ Speaker
⑨ Headset Plug
⑩ Butterfly
sticker
⑪ Microphone
Operation
1. Power On/Off
2. Pairing & Disconnection 3. Phone Control
4. Music
8. Language
7. Multi-Mode Switch
5. Volume Adjustment
6. FM Radio
ON: Press the On/Off Key for 2 seconds. When you
hear voice prompt, the blue indicator flashes twice.
The system enters the standby mode.
OFF: Press the On/Off Key for 2 seconds. When you
hear voice prompt, the red indicator flashes twice.
2.1 with Two Intercoms
Pairing:
(1)Power on two intercoms and the blue indicators flash twice. The red and
blue indicators flash alternatively, which means two intercoms wait to be
Bluetooth paired.
(2)Then, press the On/Off Key of any one of them while the blue indicator
flashes quickly with voice prompting “Intercom Search”; the red and blue
indicator of the other keeps flashing alternatively. After few minutes, they are
paired automatically with blue indicator flashing slowly.
Disconnect:
Press the Function Key for 2 seconds to disconnect the intercoms. Press it
again to reconnect.
※ The distance between intercom and mobile phone should be within 1 meter.
※ When two intercoms are paired successfully, there is no need to pair them
repeatedly. Under standby mode, they will be paired automatically after a few
seconds.
※ The automatic connection function is available within five minutes after
disconnection. If the connection fails again, you can manually press the
Function Key once for searching and matching.
2.2 with Mobile Phone
(1) After power on, the blue indicator flashes twice. The red and blue indicator
flashes alternatively, which means the intercom waits to be Bluetooth paired.
(2) Turn on the Bluetooth function of the mobile phone, search and select
“MOMAN H2” to connect and pair. The voice will prompt “Bluetooth
connected”.
※ The distance between intercom and mobile phone should be within 1 meter.
※ If the intercom has pairing record with the mobile phone, they will be
connected after power on, provided that the Bluetooth is turned on.
Answer the call: press the Function Key
Automatic answer: When the phone calls and there
is no operation after 8 seconds, it will answer the call
automatically.
Reject the call: press and hole the Function Key for 3
seconds until you hear the “beep” sound.
(1) Under Bluetooth connection mode, press the
Function Key to play/pause music.
(2) Next Music: turn the Knob counterclockwise.
(3) Previous Music: turn the Knob clockwise.
When it is on, press On/Off Key and rotate the Knob to
change the language of voice prompt.
7.1 Between Intercom and Music/FM Radio:
(1)In intercom mode, press the Function Key for 2 seconds and you hear “beep”,
indicating the intercom mode exits, and enter the switch between Music/FM
radio;
(2) Turn on/off FM Radio: Press the Function Key twice;
Turn on/off Music: short press the Function Key;
Back to Intercom: long press the Function Key.
7.2 Between Intercom and Mobile Phone:
(1) If the machine is connected with mobile phone, the intercom will disconnect
when there is call. When the call ends, it will get back to the intercom mode,
which takes 5 seconds.
7.3 Function Priority
Level 1: Mobile Phone
Level 2: Intercom
Level 3: Music/FM Radio
(1) Decrease: continuously turn the Knob
counterclockwise.
(2) Increase: continuously turn the Knob clockwise.
※ There is voice alarm for two high or two low volume.
(1) Turn on: under standby mode, press the Function
Key twice to switch to the FM radio.
(2) Select Channels: quickly rotate the Knob and
release to adjust and select channels. Continuously
rotate the Knob to select different channels. Rotate
the Knob continuously to enter volume adjustment.
(3) Turn off: press the Function Key twice to get back
End the call: press the Function Key.
Redial: In standby mode, press the On/Off Key twice to dial the last call number.
to the previous mode.
※ If the signal is weak indoor, you could try to turn on the FM radio near
window or in the open area.
※ When FM radio is turned on and there is a phone calling, the machine will
cut off FM radio automatically and connect to the mobile phone. It gets back to
the FM radio when the call ends.
