Sigtronics SE-18P User manual

…when it counts!
Model SE-18P
Headset Instructions
The SE-18P series headset is adjusted at the factory for immediate use. The head-
set is equipped with a single plug and a coiled cord.
The headband is adjustable through a full range of motion, and the locking nuts
may be tightened to allow you to custom t the headphone. Place the head-
phone over your head and adjust the slides up until minimum pressure is felt on
the top of your head. For maximum noise attenuation, the clamping pressure of
the headband has been set at the factory. Releasing the clamping pressure by
bending the headband is not advised, because loss of attenuation will result.
The microphone boom is fully adjustable and will rotate 180 degrees for use on
the left or right side of the head.
Make sure you are speaking into the side of the mic labeled “Talk” or substan-
tial loss of gain will occur. Microphone placement should be at the corner of
the mouth, approximately ” from the lips.
Your SE-18P headset has a push to talk switch located on the mic side ear cup. The
mic is operative only when the switch is depressed. For intercom and radio func-
tion, depress the switch to talk.
When you rst connect the headset, turn the volume control on the headset up
to the full clockwise position, then adjust the listening volume with the audio
control of either your radio or intercom as appropriate. If applicable, crew mem-
bers should also turn their individual headset volumes up fully. Doing this allows
for a full range of adjustment for each passenger, since those with the most acute
hearing can turn their headset volume down, if necessary.
continued on back…
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in
water or any other liquid. Be especially careful not to allow the microphone to
become wet! Exposure to moisture may cause internal corrosion and failure and
will void your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thor-
oughly and make sure it is completely dry before putting it back on.
To remove the windscreen, carefully grasp the windscreen lightly along its entire
length and remove from the microphone element being careful not to twist the
element itself.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited one-year parts and labor warranty. Please
see the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: [phone]
E-mail: [e-mail]
Web Site: www.sigtronics.com









 




 





















SIGTRONICS SE-18P HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1800192 PREAMP 13 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 25 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC
2100063 KNOB, 3/8 INCH, BLACK, VOLUME 14 100367 YOKE, EAR CUP MOUNT, METAL 26 100257 HEADBAND, METAL, LARGE
3100077 POTENTIOMETER 15 100384 BRACKET, YOKE SUPPORT WITH TANG 27 800035 CABLE, HEADSET, STEREO, COILED
4100079 RECEIVER, 300 OHM, MONO 16 100369 EAR SEAL, FOAM FILLED 28 800118 HEADPAD ASSEMBLY, SIDE, WITH CUSHION, SE-18
5100108 SCREW, 4-40 X 1/4, THREAD FORMING 17 100370 RECEIVER MOUNT, HEADSET 29 100612 O-RING, WINDSCREEN RETAINER, SE-18
6800193 MICROPHONE & FLEX BOOM ASSEMBLY 18 800198 HEADPAD WITH CUSHION, TOP, SE-18 30 100232 SWITCH, SPDT, MOMENTARY
7100251 E-RING, EAR CUP TO YOKE RETAINER 19 100373 SLIDE, YOKE BRACKET, LONG, NYLON 31 100625 O -RING, PTT, HEADSET
8100252 NUT, HEX, 8-32, LOCKING 20 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 32 100428 SWITCHGUARD, PTT, BLACK
9100361 EAR CUP, PRINTED AND DRILLED 21 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 33 100317 BUTTON, SWITCH, PTT, RED
10 100221 WIRE, #22, 19 STRAND, 4 INCH 22 100568 STRAIN RELIEF, CABLE 34 900111 WINDSCREEN, MICROPHONE, FOAM, PACKAGED
11 100363 SCREW, 8-32 X 1/2, PHILLIPS HEAD 23 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH 35 100611 WINDSCREEN, MICROPHONE, FOAM, BULK
12 100364 SCREW, 8-32 X 3/8, PHILLIPS HEAD 24 100258 CLIP, HEADBAND GUIDE, PLASTIC 36 100402 OPTIONAL – EAR SEAL, GEL FILLED
