Silvercrest PS2-WLC User manual

PS2-WLC Controller
- 1 -
Playstation®, PS2, PSone and PSX are registered trademarks of Sony Computer
Entertainment, Inc. This product is not sponsored, endorsed or approved by Sony Features
and/or specifications subject to change without notice.
User guide
We hope you enjoy using our PS2™ 2.4 GHz wireless controller. Please read this guide
thoroughly before using the unit.
4-WAY button
TURBO button
SELECT button
PROGRAM button
START button
CONNECT button
button
Ubutton
{button
Xbutton
RIGHT ANALOGUE JOY-
STICK (when pressed:
R3)
RX-LED
ANALOGUE button
MODE-LED
LEFT ANALOGUE JOY-
STICK (when pressed: L3)
X button
R1 button
ON/OFF switch
Battery compartment
L1 button
L2 button
Connection plug
RX-LED
CONNECT button
POWER-LED
1. Product description
This device is a wireless controller specifically for use with PlayStation2™. It can also be used
with PSONE™ and PSX™. The controller works at a frequency of 2.4 GHz, has a double
vibration feature as well as all other functions of the original SONY units. The controller also
has Turbo and Program functions.
2. Included
1 Controller; 1 receiver; 1 user manual
3. Product features
Power Supply: 3 x 1.5 V AAA batteries
Operating time: More than 6 hours
Transmission: 2.4 GHz multi-channel transmission
Range of action: 10 m
Special functions: Turbo function, programmable buttons with memory,
forced connection
4. Connecting the receiver
Insert the receiver plug into the appropriate slot on the PlayStation™ console and then
switch on the PlayStation™. The POWER-LED on the receiver will come on. The RX-
LED will remain on as soon as the receiver is connected to the controller.
5. Inserting / replacing the batteries
Before using the controller insert the batteries into the battery compartment on the back of the
unit. To do this, open the battery compartment , insert the new batteries according to the
polarity and close the compartment. Please ensure the controller has been switched off before
you replace the batteries. Please also read the information on safe disposal of batteries.

PS2-WLC Controller
- 2 -
Note:
Please only use batteries or rechargeable batteries with a nominal voltage of 1.5 V.
Please ensure the batteries are always inserted according to the correct polarity. Replace
the batteries with the same brand or similar batteries.
There is a risk of explosion if the batteries are not replaced correctly.
Do not attempt to recharge a non-rechargeable battery. There is a risk of explosion.
Batteries / rechargeable batteries can be fatal if swallowed. Please store batteries out of
reach of small children. Seek medical help immediately if a battery has been swallowed.
Do not expose the batteries to heat or flames. Never short-circuit batteries; never try to
force open batteries; never attempt to recharge non-rechargeable batteries. Batteries may
otherwise explode and cause serious injury.
Never replace the batteries in a potentially explosive area. Sparks may be generated
while the batteries are being inserted or replaced which could cause an explosion.
Potentially explosive areas are often signposted as such, but not always. These include
filling stations, such as under below-deck areas on boats, fuel transmission stations, fuel
depots, areas in which the air may contain chemicals or particles such as grain, dust or
metallic powder, as well as all other areas in which you would normally be asked to switch
off the engine of your car.
6. Switching on and off
The on/off switch is on the back of the device. To switch the unit off move the
switch to the “OFF” position and to the “ON” position to switch it on.
7. Connecting the controller
The connection mode will initiate as soon as the On/Off switch on the underside of
the unit is switched to the ON position. The RX-LED and MODE-LED lights will
light up briefly at the same time. If the RX-LED comes on, the device is trying to establish a
connection with the receiver. The RX LED goes out as soon as a connection has been
established.
8. Force connection
If several wireless controllers are connected at the same time, you can use the force
connection method to select a single controller.
Press the CONNECT button on the hand-held unit and then press the CONNECT button
on the receiver within 15 seconds to establish a connection. Now press the L3 button
and the SELECT button on the hand-held unit and the CONNECT button on the
receiver at the same time for 15 seconds.
9. Mode selection
Many games support an analogue controller which permit more precise input than with digital
controllers.
There must be a connection to the receiver before you can switch between the digital and
analogue modes. To do this, press the ANALOGUE button . The MODE-LED lights
up in analogue mode. The MODE-LED is off in digital mode.
Note:
The default mode is digital.
Not all games support digital mode.
You may have to finish the game before switching between modes.
10. Energy-saving mode
The unit is equipped with an energy-saving mode to conserve energy and prolong battery life.
This mode is activated in the following situations:
where no connection has been established between the unit and the receiver after 3
seconds
where the unit and receiver are connected but the unit has not been used for 3 minutes
where the connection between controller and receiver has been interrupted and no
connection has been established within 6 seconds
where you press the CONNECT button on the hand-held unit without pressing the
CONNECT button on the receiver within 15 seconds.
If your unit is in the energy-saving mode, press either the START , L3 , or R3
buttons to reactivate the controller.
11. TURBO functions
With the TURBO function you can switch the U, {, X, , R1, R2, L1 and L2 buttons
to the TURBO/rapid fire function. The controller must be connected to the receiver to activate
or deactivate the TURBO function.
To activate: Press and hold the TURBO button until the RX-LED comes on.
Then press the button for which you want to activate the rapid fire function.
To deactivate: First press the button which you want to reset. Press and hold the TURBO
button until the RX-LED goes out.

PS2-WLC Controller
- 3 -
The RX-LED comes when on you are setting the TURBO function; the RX-LED
flashes when performing the TURBO function.
12. Button programming function:
You can program and save the button sequence using the PROGRAM function.
Setting the PROGRAM functions: Press the PROGRAM button . The RX-LED
light will come on. Now press the button which you want to programme with a combined
function. Then press the desired button sequence (a maximum of 15 buttons) finish by
pressing the PROGRAM button.
The RX-LED light will go out.
Clearing the PROGRAM functions: Press the PROGRAM button once. The
RX-LED light will come on. Press the button which you previously programmed and want
to clear. Press the PROGRAM button once again. The RX-LED goes out, i.e. the
PROGRAM function has been cleared.
The following buttons can be programmed with combined functions: L2, L3, R2, R3. The
following buttons can be used for programming: U, {, X, , all 4 directional buttons, L1,
L2, L3, R1, R2 and R3. When you switch off the unit the controller retains the last
PROGRAM function setting. The RX-LED remains on when you are setting the
PROGRAM function; the RX-LED flashes when you are using the PROGRAM function.
Note:
Not every game supports button sequence programming.
13. Vibration mode
The unit vibrates once briefly to confirm when you press the R3 and SELECT buttons. This
is to indicate that all vibrations (strong and weak) have been deactivated. Press the same
button again to reactivate the vibration mode. This is confirmed by two short vibrations.
14. Safety advice
Do not attempt to dismantle, modify or repair the unit yourself.
Do not use this unit together with other electronic equipment of the same operating
frequency to avoid damaging both units.
Please ensure no fluids or small pieces of metal can get inside the unit. Avoid knocks to
the unit and do not place heavy objects on the device. Do not place containers of liquid like
vases or drinking glasses on or near the unit and never immerse the unit in fluid.
Do not use or store the unit in high-temperature areas, or in steamy, smoky or dusty areas.
Never mix battery types and never mix old and new batteries. Replace the batteries as
soon as they become too weak or where the unit has not been used for some time.
There is a risk of explosion if the batteries are not replaced in the proper manner. Please
ensure the batteries are always inserted according to the correct polarity. Replace the
batteries with the same brand or similar batteries. Risk of explosion when batteries are
replaced incorrectly.
Do not attempt to recharge a non-rechargeable battery. There is a risk of explosion.
Batteries / rechargeable batteries can be fatal if swallowed. Please store batteries out of
reach of small children. Seek medical help immediately if a battery has been swallowed.
Do not expose the batteries to heat or flames. Never short-circuit batteries; never try to
force open batteries; never attempt to recharge non-rechargeable batteries. Batteries may
otherwise explode and cause serious injury.
15. Disposing of batteries
Please note that you, as the end user, are required to return used batteries to a public
or privately run battery disposal unit.
16. Disposing of the unit
Please note that this device is subject to European Directive 2002/96/EC on the
reduction of electronic waste.
You are not permitted to dispose of this unit together with household
waste.
Information on safe disposal of all devices is available from your local
council, waste disposal unit and the shop in which you purchased this
product.
You may deposit this product free of charge in your community collection
facility.
Correct disposal of used goods protects the environment as well as your
health.
17. Guarantee
This product comes with a three-year guarantee starting on the day of purchase. If this product
is faulty send it, together with the receipt and a stamped-addressed envelope, to:
JNC Datum Tech GmbH, Support Center,
Maltschachstrasse 32, D - 72144 Dusslingen, Germany.
Manufacturer:
JNC Datum Tech GmbH
Benzstraße 33
D - 71083 Herrenberg
Germany
More information can also be found at:
www.mysilvercrest.de
