Silvercrest KH 2450 User manual

SilverCrest KH 2450
DIGITAL VOICE RECORDER
Operating Instructions
ID-Nr.: KH2450 10/2008 V2
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
www.kompernass.com
A
Bedienungsanleitung KH 2450 EN.indd 78-2 23.12.2008 23:11:29

4
Contents
Contents ................................................................................................................. 4
1. Intended use ....................................................................................................... 6
2. Technical Data.................................................................................................... 6
Power supply.....................................................................................................................6
Memory .............................................................................................................................6
3. Safety Instructions ............................................................................................. 6
4. Items supplied .................................................................................................... 9
5. Operating elements, connections and displays................................................. 9
5.1 Front.............................................................................................................................9
5.2 Le ...............................................................................................................................9
5.3 Top ............................................................................................................................ 10
5.4 Right.......................................................................................................................... 10
5.5 Bottom...................................................................................................................... 10
5.6 Bottom...................................................................................................................... 10
6. Preparing the voice recorder for use ............................................................... 10
7. Using the voice recorder................................................................................... 14
7.1 Switching the voice recorder on ........................................................................... 14
7.2 Switching the voice recorder o .......................................................................... 16
7.3 Recording dictation................................................................................................ 16
7.4 Playback of recorded dictation ............................................................................. 18
7.5 Options during playback ....................................................................................... 19
7.5.1 Stopping the playback..................................................................................... 19
7.5.2 Adjusting the playback sound volume ......................................................... 19
7.5.3 Adjusting the playback speed ........................................................................ 20
7.5.4 Fast forward/rewind........................................................................................ 20
7.6 Handling recorded dictations ............................................................................... 22
7.6.1 Overwriting passages in a recorded dictation............................................. 22
7.6.2 Inserting a passage into a recorded dictation.............................................. 22
7.7 Deleting recorded dictations................................................................................. 23
7.7.1 Completely deleting recorded dictations ..................................................... 24
7.7.2 Partially deleting recorded dictations........................................................... 25
8. Further functions and adjustments of the voice recorder .............................. 27
8.1 Activating/deactivating the key lock.................................................................... 27
8.2 Selecting a folder for saving dictation recordings.............................................. 27
8.3 Provide dictation recordings with references ..................................................... 29
8.4 Using memory cards instead of the device internal storage system................ 33
8.5 Switching voice activation on/o ......................................................................... 34
g
h
j
k
l
q
r e wt
y
u
i
o
asdf
;
Warranty
Digital Voice Recorder
KH 2450
Fill in this section and submit it with the device!
To ensure you receive a free repair pro-
cedure, please contact us via our Service-
Hotline. Ensure that you have your sales
slip handy.
DES Ltd
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Irish Connection
Tel: 00353 (0) 87 99 62 077
Fax: [phone]
e-mail: [email protected]
www.mysilvercrest.de
Description of the defect:
✄
Sender, please write clearly:
Last Name:
First Name:
Street Address:
Postal Code/City:
Country:
Telephone:
Date/Signature:
Bedienungsanleitung KH 2450 EN.indd 3-77 23.12.2008 23:12:06

5
8.6 Microphone sensitivity........................................................................................... 36
8.7 Using the voice recorder as a PC microphone.................................................... 38
8.8 Switch-o options................................................................................................... 40
8.9 Switching audio signals on/o.............................................................................. 42
8.10 Adjusting the illumination .................................................................................. 44
8.11 Selecting the recording mode ............................................................................. 46
8.12 Setting the date and time..................................................................................... 47
8.13 Resetting the internal dictation counter............................................................ 49
8.14 Returning the voice recorder to factory settings.............................................. 51
8.15 Formatting the internal memory of the voice recorder .................................. 52
8.16 Changing the display language........................................................................... 54
8.17 Display the version number of the Firmware................................................... 56
9. Maintenance ..................................................................................................... 58
9.1 Changing the batteries/cells .................................................................................. 58
9.2 Recharging cells in the battery compartment of the voice recorder ............... 58
10. Copying dictation recording from the voice recorder to a PC ..................... 60
10.1 Installing the soware »Convert« onto a PC.................................................... 61
10.2 Using the soware »Convert«............................................................................. 63
10.3 Deinstalling the soware »Convert« from a PC .............................................. 67
11. Connecting ancillaries to the voice recorder................................................. 68
11.1 Connecting headphones to the voice recorder................................................. 68
11.2 Connecting an external microphone to the voice recorder............................ 69
12. Cleaning the voice recorder ........................................................................... 69
13. Troubleshooting ............................................................................................. 69
13.1 e voice recorder indicates no functions ....................................................... 69
13.1.1 With cell/battery operation.......................................................................... 69
13.1.2 With mains power operation....................................................................... 70
13.1.3 With connection of the voice recorder to a PC via a USB-cable (USB
operation) .................................................................................................................. 70
13.2 Voice recorder has crashed/input not possible................................................. 70
13.3 Error messages ...................................................................................................... 71
13.4 Other Malfunctions.............................................................................................. 71
14. Disposal .......................................................................................................... 72
14.1 Device..................................................................................................................... 72
14.2 Batteries/Cells........................................................................................................ 72
14.3 Packaging materials.............................................................................................. 72
15. Warranty and Service..................................................................................... 72
16. Importer ......................................................................................................... 73
Bedienungsanleitung KH 2450 EN.indd 5 23.12.2008 23:09:38

6
. Intended use
e digital voice recorder SilverCrest KH  is intended exclusively for the recording,
storage and playback of dictations. is dictation device is not intended for utilisation
in commercial or industrial applications. No warranty claims will be approved for
damage resulting from improper use!
. Technical Data
Power supply
Battery operation:  Batteries of Type AA/LR
Mignon . V or  Cell Type AA/Mignon . V
Mains operation:  V DC, . A, Polarity:
Memory
Internal memory:  MB
Expandable memory: SD and MMC memory cards up to a capacity of  GB
. Safety Instructions
Read the operating instructions carefully before using the device for the rst time
and preserve this booklet for later reference. Pass this booklet on to whoever might ac-
quire the device at a future date.
‹†DANGER! ›
Should moisture/water penetrate into the voice recorder, …
Úthere is the risk of receiving an electric shock!
Úit could be irreparably damaged!
Bedienungsanleitung KH 2450 EN.indd 6 23.12.2008 23:09:39

7
Thus: Do not use or store the voice recorder …
Úin moist environments!
Úin close proximity to water! Additionally, never expose the voice recorder to spray water or rain.
ÚNEVER place water-lled receptacles on the voice recorder!
Exposure to extreme heat sources can lead to an overheating of the voice recorder and to the melting of plastic
parts. This could irreparably damage the voice recorder, and there is the additional risk of a re!Thus:
ÚNever place the voice recorder directly adjacent to sources of heat.
ÚDo not place any open re sources – e.g. burning candles – on the voice recorder!
ÚDo not leave the voice recorder in a vehicle when the outdoor temperature is high.
Especially in summer the temperature inside a vehicle can become extremely high.
ÚDo not subject the voice recorder to direct sunlight or strong articial light.
When operating the voice recorder on mains power use only a suitable and undamaged power adapter;
Output voltage: V DC, Output current:  mA, DC-Plug (Barrel plug) ,/, mm (Inner/Outer diameter),
Polarity DC-Plug: . Suitable power adapters are available in electronic and audio/video specialist
shops. Should the voice recorder be used with an unsuitable or damaged power adapter there is the risk of you
receiving an electric shock! Additionally, the voice recorder could be irreparably damaged!
Never attempt to recharge standard batteries in the battery compartment of the voice recorder! Essentially, only
cells can be recharged. Never throw batteries/rechargeable cells into a re! NEVER open batteries or cells, never
solder or weld them! Should you do so, there is a risk of re or explosion! Additionally, the voice recorder
could become irreparably damaged.
Keep batteries and cells well away from children. Children could put batteries and cells into their mouth and
swallow them. Should a battery or a cell be swallowed, seek medical assistance IMMEDIATELY!
In the event of a defect, NEVER attempt to repair the voice recorder or a power adapter yourself! There is a risk of
receiving an electric shock! Instead, consult our service partner responsible for your country. The contact information
for our service hotline can be found on the warranty card at the end of this operating manual.
Do not leave packaging material lying unattended. Plastic foils and bags and pieces of styropor etc. are not
toys, they can be dangerous for small children.There is a risk of suocation!
‹™CAUTION! ›
Equipment connected to a power supply can be damaged during a thunderstorm.Thus:
ÚIf working with mains power, always withdraw the plug from the power socket in the event of a thun-
derstorm.
Bedienungsanleitung KH 2450 EN.indd 7 23.12.2008 23:09:39

8
ÚThe power socket should be close to the appliance and easily accessible at all times, so that the plug can
be quickly removed in the event of danger.
The voice recorder could be irreparably damaged after a fall! Therefore, place the voice recorder only on rm,
level and non-slip surfaces.
The voice recorder can be irreparably damaged by leaking battery acids.
Thus: Remove all batteries and cells from the battery compartment if you are not planning to use the voice
recorder for an extended period.. Regularly check the inserted batteries/cells. In the event of a leaking battery/cell:
Put on a pair of protective gloves. Then clean the battery compartment and the contacts for the batteries/cells
with a dry cloth.
This device is not intended for use by individuals (including children) with restricted physical, physiological
or intellectual abilities or deciencies in experience and/or knowledge unless they are supervised by a person
responsible for their safety or receive from this person instruction in how the device is to be used. Children
should be supervised to ensure that they do not play with the device. Otherwise, there is a risk of injury!
The voice recorder should not be used or stored in dusty environments. Dust particles could penetrate into the
appliance. If large quantities of dust penetrate the voice recorder it could overheat and be irreparably damaged.
There is also the risk of a re!
‹]NOTICE: ›
NEVER open the housing of the voice recorder!The voice recorder does not contain any user-serviceable components!
If the housing of the voice recorder is opened, the warranty will become void!
Thus: In the event of a defect with your voice recorder contact our service hotline responsible for your locality!
The contact information for our service hotline can be found on the warranty card at the end of this operat-
ing manual.
The voice recorder becomes warm when it is switched on. This is no cause for concern and does not indicate
a technical problem.
For damage to the voice recorder that is a result of...
Úimproper use of the voice recorder,
Úimpact caused by falls,
Úthe eects of moisture, resp.
Úwater that has permeated into the voice recorder,
Úthe eects of heat/overheating,
Úthe utilisation of power adapters that do not conform to the specications given in this operating
manual,
Bedienungsanleitung KH 2450 EN.indd 8 23.12.2008 23:09:39

9
Úan attempt to recharge standard (non-rechargeable) batteries in the battery compartment of the voice
recorder,
Úopening of the voice recorder housing, and
Úattempts at repair eected by non-qualied personnel,
no liability/warranty will be accepted!
. Items supplied
•Digital Voice Recorder SilverCrest KH 
• × Batteries (Type AA/Mignon . V )
•Storage case
•USB-Cable for connection of the voice recorder to a PC
•CD-ROM with the soware »Convert«, for data transfer from the voice re-
corder to a PC
. Operating elements, connections and displays
5.1 Front
qDisplay
wFunction button A (for diverse adjustments; the respective function is shown
in the display qabove the function button)
eFunction button B (as function button A)
rFunction button C (as function button A)
tFunction button D (as function button A)
yLoudspeaker
5.2 Left
uJack socket »DC V . A« for a power adapter (not supplied)
iHeadphone jack »EAR « (for connecting headphones with a . mm jack
plug to the voice recorder)
Bedienungsanleitung KH 2450 EN.indd 9 23.12.2008 23:09:39

10
5.3 Top
oMemory card slot » SD/MMC« (for SD/MMC memory cards)
aButton »ON/OFF« (for switching the voice recorder on and o)
sMicrophone jack socket »MIC « (for connecting an external microphone
with a . mm jack plug)
dStatus lamp »DICT «
fMicrophone »MIC « (internal microphone of the voice recorder for dictation
recording)
5.4 Right
gButton » DICT«
hMulti-function slider for the functions
Ú» FFWD« (fast forward at playback)
Ú» STOP« (stop dictation recording/playback)
Ú» START« (start dictation recording/playback)
Ú» REW« (fast rewind at playback )
jSlider » HOLD« (Activate/Deactivate the key lock)
5.5 Bottom
kUSB interface » « (to connect the voice recorder to a PC)
5.6 Bottom
lBattery compartment »OPEN/BATT «
;Button »RESET«
. Preparing the voice recorder for use
1Carefully remove the voice recorder from the packaging.
2Only for battery/cell operation: Open the battery compartment lat the rear
of the voice recorder. Insert …
Úthe two supplied cells, resp.,
Útwo batteries of the type AA Mignon . V or
Úbatteries of the type AA/LR . V.
Be sure to insert the batteries/cells with their correct polarities. The correct
polarity is indicated inside the battery compartment. When done, close and
secure the battery compartment.
Bedienungsanleitung KH 2450 EN.indd 10 23.12.2008 23:09:39

11
2Only for mains power operation: Insert the DC plug (barrel plug) of a suit-
able power adapter into the socket »DC V .A« uon the voice recorder.
A power adapter is not supplied. Pay heed to the correct polarity of the DC
plug. For this voice recorder, a suitable power adapter must have a positive po-
larity. Insert the plug of the power adapter into a mains power socket.
‹†DANGER! ›
For mains power operation of the voice recorder use exclusively a suitable power adapter; Output voltage:
 V DC, Output current:  mA, DC-Plug (Barrel plug) ,/, mm (Inner/Outer diameter), Polarity DC-Plug:
. Suitable power adapters are available in electronic and audio/video specialist shops. Should the
voice recorder be used with an unsuitable power adapter, there is the risk of you receiving an electric shock!
Additionally, the voice recorder could be irreparably damaged!
2Only for USB operation: Check to ensure the PC is switched on. Insert the
small plug of the supplied USB cable into the USB interface » « kon the
voice recorder. Insert the large plug of the USB cable into a free USB interface
on your PC. If batteries/cells have not been inserted into the battery com-
partment of the voice recorder: Immediately switch the voice recorder on by
pressing the button "On/O" a. If batteries/cells have been inserted into the
battery compartment: Switch the voice recorder on before connecting it to
the PC. If you do not, the voice recorder will switch over to PC operation and
will be identied by the PC as a removable media. In PC operation, dictations
from the voice recorder can be copied onto the PC; for this, see also chapter .
»Copying dictation recording from the voice recorder to a PC«. However, in
PC operation the voice recorder cannot be used for dictations. Additionally, in
PC operation you cannot utilise the menu or any of the other adjustments for
the voice recorder.
3Switch the voice recorder on by pressing the button "On/O" a.
In the display qthe battery selection screen appears:
OK ESC
Type of battery
Non-rechargeable
battery
Bedienungsanleitung KH 2450 EN.indd 11 23.12.2008 23:09:39

12
4Aer pressing function button B e/C r, choose between the settings:
ÚRechargeable battery
ÚNon-rechargeable battery
Select »Rechargeable battery« if you have inserted rechargeable batteries into
the battery compartment.
Select »Non-rechargeable battery« if you have inserted standard non-recharge-
able batteries into the battery compartment.
Also select »Non-rechargeable battery« if you wish to use the voice recorder …
Úwith a power adapter (not supplied) connected to a mains socket.
Úvia a USB cable (supplied) connected to the USB interface.
On completion, and by pressing the function button D t, select »OK« to con-
rm the adjustment. If you do not, the voice recorder will automatically
select the adjustment »Non-rechargeable battery«.
‹†DANGER! ›
Ensure absolutely that the correct adjustment has been selected. Otherwise, there is the risk that standard
batteries, ones not suitable for recharging, could be recharged. In this case, there is the real risk of re or an
explosion!
In cases of doubt: Remove the batteries/cells from the battery compartment; check to conrm if they are
standard batteries or rechargeable batteries.Then reinsert the batteries/cells into the battery compartment.
Switch the voice recorder on then select the correct adjustment in the battery selection screen.
Alternatively, you can remove the batteries/cells from the battery compartment if you wish to use the voice
recorder …
Úwith a power adapter connected to a mains power socket
Úvia a USB cable connected to the USB interface on a PC.
‹]NOTICE: ›
To carry out the steps  to  you have ca.  seconds for each. Otherwise, the adjustment of the time and
date indicator breaks o. In this case, you can reach the adjustment data for the time and date indicators via
the main menu.This is explained in chapter . »Setting the date and time«.
Bedienungsanleitung KH 2450 EN.indd 12 23.12.2008 23:09:39

13
5In the display qthe date/time setting screen is now indicated. First of all the
hour indicator is marked. Adjust the hour indicator by selecting » «/» « with
the function buttons B e/C r.
6On completion, and by pressing the function button D t, select »OK« to con-
rm the adjustment. e marking changes to the minute indicator.
7Adjust the minute indicator by selecting » «/» « with the function
buttons B e/C r.
8On completion, and by pressing the function button D t, select »OK« to con-
rm the adjustment. e marking changes to the date indicator.
9Adjust the day indicator by selecting » «/» « with the function buttons
B e/C r.
10 On completion, and by pressing the function button D t, select »OK« to
conrm the adjustment. e marking changes to the month indicator.
11 Adjust the month indicator by selecting » «/» « with the function buttons
B e/C r.
12 On completion, and by pressing the function button D t, select »OK« to
conrm the adjustment. e marking changes to the year indicator.
13 Adjust the year indicator by selecting » «/» « with the function buttons
B e/C r.
14 Should you decide to once again change one of the settings: By pressing the func-
tion button D tselect »OK«. e marking then changes back to the hour in-
dicator.
Alternatively: Subsequently select with the function button A w»End«, to
conrm all of the settings. Appearing briey in the display q…
Úthe SilverCrest logo
Ú»INT«, should there not be a memory card inserted into the memory card slot
o; then the internal memory of the voice recorder is used for dictations.
Ú»EXT«, should there be an SD/MMC memory card inserted into the memory
card slot oand this is being used for dictations.
As the soware of the voice recorder is loading, the hourglass symbol is blended in
briey. Subsequently, the start screen is displayed. In the upper right corner of the
display qappears …
Bedienungsanleitung KH 2450 EN.indd 13 23.12.2008 23:09:40

14
Úin battery/cell operation, the battery symbol ; the beams in the battery
symbol indicate the current full resp. charged condition of the batteries.
Úin mains power/USB operation the symbol .
e voice recorder is now ready for use.
. Using the voice recorder
7.1 Switching the voice recorder on
1To switch the voice recorder on: Press the button »ON/OFF« aonce. e sta-
tus lamp »DICT « dbriey lights up once. In the display qthe SilverCrest
logo is briey shown; indicated subsequently are:
Úshould the batteries/cells have been exchanged before switching on: the battery
selection screen (see chapter  »Preparing the voice recorder for use«, step );
the battery selection screen is not indicated if …
Úthe batteries/cells were not exchanged before switching on
Úthe switched-o voice recorder is connected to a PC via a USB cable
(PC operation)
Úsubsequently the SilverCrest logo
Ú»INT«, should there not be a memory card inserted into the memory card slot
o; in this case the internal memory of the voice recorder is used for dicta-
tions.
Ú»EXT«, should there be an SD/MMC memory card inserted into the memory
card slot o; in this case the memory card is used exclusively as an external
memory for dictation recording.
During soware loading phases the hourglass symbol in blended in briey.
Consequently, a short signal tone sounds and the start screen appears with the
following indicators/menu choices:
Should it be that no dictations have yet been saved:
Bedienungsanleitung KH 2450 EN.indd 14 23.12.2008 23:09:40

15
Menu NEW
Free 11:43h
no dictations
q w
e
r t
qe amount of recording time currently available for dictations, e.g. »Free
:h«
wWith battery/cell operation: the battery symbol ; the beams in the battery
symbol indicate the current full resp. charged condition of the batteries.
With mains power/USB operation: the symbol
e»no dictations«, insofar as no dictations have yet been saved
r»MENU« (Selection of the main menu of the voice recorder, by using function
button D t, for adjusting the various functions of the voice recorder)
t»NEW« (for eecting a new dictation)
Should dictations have already been saved:
Menu DICT± NEW
Free 9:15h
DICT006 01:40
y
u
yName and length of the last saved dictation, e.g. »DICT :«
u»DICT ±« (for selection of previously saved dictations by means of the
function buttons B eand C r)
Bedienungsanleitung KH 2450 EN.indd 15 23.12.2008 23:09:40

16
7.2 Switching the voice recorder o
Hold the button »ON/OFF« apressed down until »O« appears in the display q.
e voice recorder then switches itself o.
7.3 Recording dictation
1Switch the voice recorder on by pressing the button »ON/OFF« once.
As soon as the start screen is shown in the display q:
2Place the multi-function slider hat » STOP«.
3en select, by pressing the function button A w, »NEW«. e voice recorder
now allocates a new dictation reference with a successive number.
‹]NOTICE: ›
Every new dictation recording is saved under a new, successive number. However, take note:The numbering
of saved dictations does not subsequently change when you delete individual dictations.
‹ÚEXAMPLE: ›
You start a new dictation recording.This is automatically assigned the number »DICT«. At a later date you
delete dictation recording »DICT«. When you start a new dictation recording, this one is automatically as-
signed the next following number, »DICT«, although the dictation with the prior number, »DICT«, has
been deleted.
You can however reset the dictate counter back to null. After the resetting of the counter, the subsequent dic-
tations will again be automatically successively numbered, beginning at »DICT«. The resetting of the in-
ternal counter for dictations is explained in chapter . » Resetting the internal dictation counter«.
However, the dictation recording does not start immediately, instead, at rst it is in
a pause-mode. e status lamp »DICT « dblinks; in the display qis indicated:
Bedienungsanleitung KH 2450 EN.indd 16 23.12.2008 23:09:40

17
Free 9:15h
DICT008 00:00
q w
e
Record Pause
qe successive number of the new dictation recording, e.g. »DICT«
we current length of the dictation recording (for new dictations that have not
yet been started, always »:«)
e»Record Pause«
4To start the dictation recording: Place the multi-function slider hat »
START«. In the display q»Record« is indicated, then the dictation recording
is started. During the dictation recording the lapsed period of the dictation re-
cording is continuously indicated in the display q. e status lamp »DICT
« dglows permanently during the dictation recording.
‹]NOTICE: ›
Every individual dictation recording can be up to three hours long (insofar as sucient memory space is avail-
able). After three hours a new dictation recording is automatically initiated; thereby, the running dictation
recording is not interrupted.The newly initiated dictation recording receives the same number as the original,
but expanded by a letter. Example After a period of three hours of the dictation recording »DICT«, the new
dictation recording »DICTA« is automatically initiated. In the display qis indicated:
Free 14:38h
DICT001A 01:15
Record
Bedienungsanleitung KH 2450 EN.indd 17 23.12.2008 23:09:40

18
In accord with this pattern, after every further three hours additional dictations are automatically initiated
(e.g. »DICTB«, »DICTC« etc.). For each of these an acoustic signal sounds.
5When you wish to interrupt the dictation recording: Place the multi-function
slider hat » STOP«. In the display q»Record Pause« is indicated, the hith-
erto period of the dictation recording remains shown. For as long as the dicta-
tion recording is interrupted, the status lamp »DICT « blinks.
To continue the dictation recording: Place the multi-function slider hback at
»START«.
6When you wish to terminate the dictation recording: Press the button
»DICT« gonce. e status lamp »DICT « dgoes out. In the display
qis indicated:
Free 16:38h
DICT009 01:00
play-back end
1.5 VOL± HOME
Now you can…
Úplay back the saved dictation recording. is is explained in the following
chapter . »Playback of recorded dictation«.
Úwork on the saved dictation recording. is is explained in the following chap-
ter . »Handling recorded dictations«.
Údelete the dictation recording, either completely or partially. is is explained
in the following chapter . »Deleting recorded dictations«.
7.4 Playback of recorded dictation
To play back saved dictations:
1Switch the voice recorder on by pressing the button »ON/OFF« a.
As soon as the start screen is shown in the display q:
2Place the multi-function slider hat » STOP«.
Bedienungsanleitung KH 2450 EN.indd 18 23.12.2008 23:09:40

19
3Should there be several dictations extant: Select the one you want by pressing
the function buttons B e/C r»DICT ±« to switch between the saved dicta-
tions. When the desired dictation recording is shown in the display q:
4Place the multi-function slider hat » START«. e selected dictation re-
cording is now played back. In the display qis indicated:
Free 16:38h
DICT005 01:00
playback
1.5 VOL± END
q w
e
r yt
qe designation of the dictation recording being played back, e.g. »DICT«
we current playback time of the dictation recording
e»play-back«
r».«: by pressing the function button D t, change the playback speed by .
t»VOL ±« to adjust the playback sound volume
y»END« to end the playback
7.5 Options during playback
.. Stopping the playback
To stop playback of a saved dictation recording: Place the multi-function slider h
at » STOP«. Playback is stopped; in the display q»play-back« is faded out. To
continue playback: Place the multi-function slider hback at » START«; playback is
continued from the point where it had been stopped.
.. Adjusting the playback sound volume
During playback you can adjust the playback sound volume between the
values of  (muted) and  (maximum volume).
Bedienungsanleitung KH 2450 EN.indd 19 23.12.2008 23:09:40

20
To increase the playback sound volume: Press the function button B e.:
With each press of the button you raise the playback sound volume by a step.
For a faster raising of the playback sound volume you can also hold down the
function button B e.
To reduce the playback sound volume: Press the function button C r. With each
press ofthe button youreduce the playback sound volume bya step.For afaster reduction
of the playback sound volume you can also hold down the function button C r.
e currently adjusted volume level is indicated for a few seconds in the display q.
.. Adjusting the playback speed
e playback of saved dictation recordings can take place at two speeds:
Únormal speed
Úone and a half times speed
e standard factory setting is normal playback speed.
1To switch to a one and a half times playback speed: Select it during playback
by pressing the function button D t» .«. Playback now takes place at one
and a half times normal speed.
2To switch back to normal playback speed: Select it by pressing the function
button D t» .«. Playback now takes place again at normal speed.
.. Fast forward/rewind
‹]NOTICE: ›
During fast forward/rewind there is no sound playback.
To select passages of the dictation recording in fast forward during playback:
1Place the multi-function slider hat » FFWD« and hold it in this position;
in the display qis indicated:
Bedienungsanleitung KH 2450 EN.indd 20 23.12.2008 23:09:41

21
Free 03:37h
DICT013 1:13:06
Fast forward
During fast forward the actual playback period of the dictation recording is
continuously indicated in the display q.
2As soon as you have reached the desired passage in the dictation recording:
Release the multi-function slider h.
3Should you wish to continue playback from the selected passage: Place the
multi-function slider hback at » START«.
To select passages of the dictation recording in fast rewind during playback:
4Place the multi-function slider hat » REW« and hold it in this position;
in the display qis indicated:
Free 03:37h
DICT013 34:30
Rewind
During fast rewind the actual playback period of the dictation recording is
continuously indicated in the display q.
5As soon as you have reached the desired passage in the dictation recording:
Release the multi-function slider h. Playback is now automatically continued
from the selected passage.
Bedienungsanleitung KH 2450 EN.indd 21 23.12.2008 23:09:41

22
7.6 Handling recorded dictations
.. Overwriting passages in a recorded dictation
You can amend saved dictations at any point; for this, simply start a new dictation
recording at the desired point:
1Switch the voice recorder on by pressing the button »ON/OFF« a.
As soon as the start screen is shown in the display q:
2Place the multi-function slider hat » STOP«.
3Should there be several dictations extant: Select the one you want by press-
ing the function buttons B e/C r»DICT ±« to switch between the saved
dictations. When the designation of the dictation recording to be amended is
shown in the display q:
4Place the multi-function slider hat » START«. e selected dictation re-
cording is now played back. As soon as the point is played back at which you
wish to amend the dictation recording:
5Press the button » DICT« g; as soon as »Record« is indicated in the display
qyou can start your new dictation recording. During the dictation recording
the lapsed period of the dictation recording is continuously indicated in the
display q. e status lamp »DICT « dglows permanently during the dic-
tation recording.
6When you wish to interrupt the dictation recording: Place the multi-function
slider hat » STOP«. In the display q»Record Pause« is indicated, the hith-
erto period of the dictation recording remains shown. For as long as the dicta-
tion recording is interrupted, the status lamp »DICT « blinks.
To continue the dictation recording: Place the multi-function slider hback at
»START«.
7When you wish to terminate the dictation recording:
Press the button » DICT« gonce. e status lamp »DICT « dgoes out.
.. Inserting a passage into a recorded dictation
1Switch the voice recorder on by pressing the button »ON/OFF« a.
As soon as the start screen is shown in the display q:
Bedienungsanleitung KH 2450 EN.indd 22 23.12.2008 23:09:41
