STOVE USER GUIDE
EN
MODELS
CS5404B01 - CS5405B01 - CS5405W01

1, en_US
MANUFACTURER
Merzifon OSB AMASYA, Silverline Endüstri ve Ticaret A.Ş
IMPORTER
Via Carlo Porta 4 20813 Bovisio Masciago (MB) - Italy
01.03.2021STOVE USER GUIDE EN2

Table of contents
1 PREFACE............................................................................. 4
2 IMPORTANT INFORMATION REGARDING SAFETY......... 5
3 ROOM VENTILATION.......................................................... 9
3.1 Recommendations for Appliance Installation ............... 9
4 INSTALLATION OF APPLIANCE...................................... 11
5 MODELS............................................................................. 13
6 INTRODUCTION OF APPLIANCE .................................... 14
7 PREPARATION AND INSTALLATION............................... 16
7.1 Rules To Observe When Connecting Gas.................. 17
7.2 Connecting The Gas Hose......................................... 17
8 GAS CONVERSION........................................................... 19
8.1 Injector Change in Gas Hobs...................................... 19
9 USING THE HOB............................................................... 21
9.1 Gas burner control knob............................................. 21
9.2 Gas Cutter Safety Assembly....................................... 21
9.3 Recommendations for Energy Saving........................ 23
10 CLEANING AND MAINTENANCE..................................... 24
10.1 Removing the Hob Components............................... 24
11 10 INFORMATION REGARDING TRANSPORTATION..... 26
12 POWER CONNECTION SCHEME..................................... 27
13 PRODUCT INFORMATION SLIP....................................... 28
Table of contents
01.03.2021 STOVE USER GUIDE EN 3

1 PREFACE
DEAR CUSTOMER,
We sincerely thank you for purchasing our product. Please read all
instructions and warnings in this user manual carefully. This
manual includes important information for safe installation, use and
maintenance of your product and necessary warnings to get the
most out of your appliance. Please keep this manual in a safe and
easily accessible location for future reference. Manufacturer cannot
be held responsible for the damages that may be caused to nature,
people, the appliance's surroundings or other materials due to the
translation or printing of this manual, from incorrect use of the
appliance. As a result of its development and improvement policy,
the manufacturer reserves the right to change the product charac-
teristics and performance or the contents of the user manual
without prior notice.
PREFACE
01.03.2021STOVE USER GUIDE EN4

2 IMPORTANT INFORMATION REGARDING SAFETY
nThis section includes the safety instructions necessary to pre-
vent the risk of personal injury or material damage. Not
observing these instructions may void any warranty and our
company shall not be responsible for any damage that may
occur.
General Safety
CAUTION!
Device and its accessible parts are hot during
operation. Touching the heating elements should
be avoided. Children under 8 years of age should
be kept away, if they cannot be monitored continu-
ously. This device can be used by children over 8
years of age, people with physical, hearing or
mental challenges or people with lack of experi-
ence or knowledge; as long as control is ensured
or information is provided regarding the dangers.
Children must not play with the appliance.
Cleaning and user maintenance should not be car-
ried out by children without supervision.
CAUTION!
Appliance is intended for cooking. It should not be
used for other purposes like heating a room.
nThis product is designed for home use. Commercial use is not
permitted.
nIt cannot be used for any purpose other than cooking or
heating food.
nIt is dangerous and inappropriate to use it for any other pur-
pose (example; to heat the room it is in).
nManufacturer cannot be held responsible for damages that
may be occur on people, surroundings or other materials due
to unsuitable, incorrect or impractical uses of the product.
nEnsure you remove all packaging material before you use your
product.
nThe accessible parts may be hot during use.
nThe appliance is not designed to be operated by an external
timer or a separate remote control system.
nNever clean your stove with a steam cleaner
CAUTION!
If the stove glass breaks, turn off all burners imme-
diately, do not touch the appliance surface and do
not operate the appliance.
IMPORTANT INFORMATION REGARDING SAFETY
01.03.2021 STOVE USER GUIDE EN 5

If the surface is cracked, open the device circuit to
avoid risk of electric shock.
nDo not perform any repairs, maintenance or modifications on
the product.
nBut you can troubleshoot for some problems.
nAll maintenance and repair must be performed only by author-
ized service and only original spare parts shall be used.
The appliance plug is grounded, therefore ensure that the
socket is grounded as well.
nNever try to unplug the plug by pulling on the cord.
Unplug the product during transportation, cleaning or when
maintaining it.
Take care not to take your appliance's power cord through hot
areas.
Ensure that the gas hose or pipe you shall use does not pass
through hot areas and make sure that check is made against
gas leaks with soap bubbles.
After you plug the gas hose you shall use with your appliance
on the hose nipple, tighten with clamp. Check for gas leaks
with soap bubbles.
The product sides become hot during operation, so flammable
materials should not be placed near.
Do not place empty pots and pans on burning burners. They
may get damaged.
After every use, check that the knobs of the product are in off
position.
Do not use the product in states like medicated and/or under
influence of alcohol which may affect your ability of judgement.
Be careful when using alcohol in your foods. Alcohol will evap-
orate at high temperatures and may catch fire to cause a fire if
it comes in contact with hot surfaces.
DANGER!
Never try to put out the fire with water, only shut
down the device circuit and then cover the flame
with a cover and a fire blanket.
DANGER!
Do not store the material on cooking surface.
nDo not subject the gas hose or pipe to extra weight or impact.
nDo not slam the pots on the product.
nPlace pots proportional to the size of the burner. Do not use
small diameter pans on large burners and large diameter pans
on small burners.
IMPORTANT INFORMATION REGARDING SAFETY
01.03.2021STOVE USER GUIDE EN6

nPlace the pan on the centre of the burner.
nDo not leave your product to run on its own, check it regularly.
Safety for Children
nThe open parts of the product shall get warm while it is in use
and after it is used; children should be kept away.
nDo not put objects that children may reach on the appliance.
nKeep packaging materials like nylon and Styrofoam from
places children can reach due to safety reasons; otherwise
they may be dangerous.
CAUTION!
If you do not want to use your appliance any more,
unplug the appliance and disconnect the electrical
contact and the gas connection. Unused devices
pose a safety risk for children. Thus, keep the
appliance away from places that children can
reach.
Safety in Gas Works
nAll kinds of operations to be performed on gas equipment and
systems must be performed by authorized service.
nBefore installation, check that the local distribution conditions
(gas type and pressure) conform to the product settings.
nProduct must be installed and connected according to the
installation regulations in force.
nVentilation requirements must be paid special attention.
nGas products and systems should be checked regularly for cor-
rect operation. Please have annual maintenance performed.
nClean the gas hob burners regularly. Flames should be blue
and burn properly.
nGas should burn well in gas products. If there is not enough
gas burn, Carbon monoxide (CO) may be formed. Carbon
monoxide is a colourless, odourless and very toxic gas; even
small amounts have lethal effect.
nAsk your local gas supplies about the phone numbers for
emergencies related to gas and the measures to be taken
upon smelling gas.
CAUTION!
When a gas cooking appliance is used;
humidity, heat and burning products are gener-
ated in the room. Make sure that the kitchen is
well ventilated while the appliance is in use.
Preserve natural ventilation holes or have a
mechanical ventilation equipment (kitchen
hood, extractor) installed. Long term intense
use of the appliance may require extra ventila-
tion, for example, opening a window, or a better
ventilation, such as increasing the mechanical
ventilation level.
IMPORTANT INFORMATION REGARDING SAFETY
01.03.2021 STOVE USER GUIDE EN 7

What To Do Upon Smelling Gas
nTurn off all valves on the gas products and gas counters.
nDo not use naked flame, and do not smoke.
nDo not operate any electrical switch. (Eg.: Lamp switch or
doorbell)
nOpen the doors and windows.
nCheck all hoses and their connections against leaks. If you still
smell gas, leave the house.
Safety in Electrical Operation
nAll kinds of operations to be performed on electrical equipment
and systems must be performed by authorized and competent
people.
nIn case of any damage, turn off the product and disconnect the
electrical connection. To do this, switch off the circuit breaker of
your house.
nEnsure that the breaker current is compatible with the product
current.
CAUTION!
Turn off all burners and any other electrical heating
element and disconnect the appliance from the
power source. Do not touch the appliance surface.
Do not use the appliance.
nDo not let the cooking pots to heat up empty; the heat accumu-
lation on the base may damage the glass surface.
nIn glass hob models; if the glass of your hob cracks and/or
breaks, unplug the appliance and do not tamper with it.
nDo not use pots that conduct excess heat down to the glass.
nDo not heat closed cans and glass jars. The pressure accumu-
lation in jars may lead to an explosion.
nDo not place empty pans or pots over hobs. The glass surface
may be damaged.
nDo not place sharp objects on the oven.
CAUTION!
Do not use empty pots/pans, metal / ceramic
cooking accessories etc. and products that may
cause the glass to overheat due to heat accumula-
tion between the glass and the cooking surface.
Excess heat may damage the glass surface and
may cause the glass to explode.
IMPORTANT INFORMATION REGARDING SAFETY
01.03.2021STOVE USER GUIDE EN8

3 ROOM VENTILATION
1- Window
2- Cooker Hood
3- Air Exit
The air required for burning is acquired from the room air and the
resulting gases are given directly into the room. Good ventilation of
the room is a must for safe operation of your product. If there are
no windows or doors to be used for room ventilation, additional
ventilation must be installed (Fig. 1).
Room Size Ventilation Opening
Smaller than 5 m³ min. 100 cm2
5 m³ to 10 m³ min. 50 cm2
Larger than 10 m³ Not needed
In basement or cellar min. 65 cm2
This appliance is not connected to burning prod-
ucts evacuation setup. This appliance must be
connected and installed according to the installa-
tion regulations in force. Conditions regarding ven-
tilation must be specially considered.
3.1 Recommendations for Appliance Installation
These operations should be exclusively performed by an author-
ized technician.
nThe appliance must be installed in accordance with the regula-
tions in force.
nAuthorized service technician must observe the laws in force
regarding the discharge of waste gases.
nAppliance's gas connection must be disconnected before
starting maintenance or repair works.
nAppliance must be placed in units resistant to heat.
nThe working surface of the hob must be higher than the sur-
face of the unit it shall be placed on, and must be able to with-
stand 60° higher than the room temperature.
nAppliance must be installed away (at least 20 cm.) from easily
flammable materials (curtains etc.)
nAfter the appliance's connection is completed, it should be
checked for gas leaks. This check should be made by gas leak
detector. After the application, there must not be any observed
leaks around the connection. Otherwise, the connection should
be checked again.
nAll gas connection parts and gas distribution components used
for the gas connections of the appliance must be ensured to
conform to the national and international requirements.
Fig. 1
ROOM VENTILATION
Recommendations for Appliance Installation
01.03.2021 STOVE USER GUIDE EN 9

DANGER!
Do not check gas connections with flame.
LOCATION
nYour appliance is designed and approved for home use only. It
should not be installed and used in commercial or semi-com-
mercial locations. Appliance malfunctions caused by such use
are outside the warranty.
nThe working surface of the hob must be higher than the sur-
face of the unit it shall be placed on, and must be able to with-
stand 60°C higher than the room temperature. Do not leave
your plastic etc. items near the appliance when your appliance
is in use.
ROOM VENTILATION
Recommendations for Appliance Installation
01.03.2021STOVE USER GUIDE EN10

4 INSTALLATION OF APPLIANCE
nThis appliance must be used only in well ventilated locations in
accordance with the regulations in force. Please read the
manual before installing or using this product. Installation must
be performed by an authorized service according to the instruc-
tions. Our company cannot be held responsible for damages
that may be occur on people, surroundings or other materials
due to incorrect installation.
CAUTION!
ENVIRONMENTAL WARNING:
Please dispose of the packaging materials of
the appliance in accordance with safety and
environment conditions after the installation.
Please dispose of the waste packages
according to their properties (folio, cardboard,
Styrofoam) for recycling. Before disposing of
the product, cut the power cord to render it
unusable to prevent children from being
exposed to danger.
Installation Warnings
nEnsure that the electrical and/or gas utilities are suitable before
calling the authorized service to have the product ready If not,
call an electrician or plumber to arrange the utilities as neces-
sary. Then call authorized service.
nIt is customer's responsibility to prepare the location the
product shall be placed on and also have power and/or gas
utility prepared.
n
nThe rules about electrical and/or gas in local standards must
be adhered to during product installation. The product's con-
nection to the gas distribution system can only be performed by
an authorized and qualified person.
nGas pressure and type coming from the local gas distribution
centre must be the same as the data specified on the product
type label or gas display label.
nThe electrical cable should not be crushed, folded or pinched,
or come into contact with hot parts of the product. Plug must be
in an easily accessible location after installation. But it should
not rest on somewhere on the burners.
nHob is designed to be installed on commercially available
counters. A safe distance must be left between the product and
kitchen walls or furniture. Please install according to the meas-
urements shown in the figure.
nSurfaces used, synthetic laminates and adhesives must be
resistant to heat ( minimum 100 ºC). These materials such as
synthetic laminated material and adhesives, plastic or materials
containing adhasives may get damaged. Real resistance
against temperature increase depends on the performance of
the kitchen units or the surface finish.
INSTALLATION OF APPLIANCE
01.03.2021 STOVE USER GUIDE EN 11

nCertain kitchen unit surface finishes (for example, vinyl) is
especially vulnerable to damage and discolouration in tempera-
tures lower than those specified above.
nCounter must be levelled and fixed horizontally.
nHave the gap for the hob on the counter cut according to the
installation dimensions of the hob.
nWhen installing the hob on a cabinet, a rack must be mounted
to separated the cabinet and the hob. If mounting on a flush
oven, the distance between must be at least 30 mm. Before
placing the appliance, ensure of the local distribution require-
ments (gas type and pressure) and that the appliance setting is
suitable.
nThese device setting conditions are specified on the label.
nFor example, if it can touch the lower side of the product due to
installing on a drawer, this section should be closed with a
wooden plate.
nIt is not recommended to install the product near a refrigerator
or a deep freezer, otherwise the emanating heat shall
adversely affect the performance of the said appliances.
Fig. 2: Installation Min. 30 mm
INSTALLATION OF APPLIANCE
01.03.2021STOVE USER GUIDE EN12

5 MODELS
Fig. 3: CS5404B01
Fig. 4: CS5405B01 - CS5405W01
MODELS
01.03.2021 STOVE USER GUIDE EN 13

6 INTRODUCTION OF APPLIANCE
Fig. 5
1- Pot Carriers
2- Burner Housing
3- Gas Cutter Thermal Component
4- Strong Burner
5- Glass Table
6- Spark Plug
7- Gas burner control knobs
8- Wok Burner
CS5404B01 CS5405B01 - CS5405W01
Width 590 mm 750 mm
Depth 520 mm 520 mm
Height 55 mm 55 mm
CS5404B01 - CS5405B01 - CS5405W01
Wok Burner 3.8 KW
Strong burner 2.9 KW
Normal burner 1.75 KW
Auxiliary Burner 1 KW
Supply voltage 220 - 240 V AC
Ignition Electrical
Safety Gas Cutter Thermal Component
Feed Frequency 50 - 60 Hz
Cable Section 3G x 0,75 mm² 16 A 250 V
Gas Product Category II 2H3+ / II 2H3B/P / I3+
Gas Type / Pressure G20 / 20 mbar
INTRODUCTION OF APPLIANCE
01.03.2021STOVE USER GUIDE EN14

Gas Type / Pressure Conversion G30 / 30 mbar
Electrical Power 1.2 W
The values provided with the appliance or its
accompanying documents are laboratory readings
in accordance with the respective standards.
These values may differ depending on the use and
ambient conditions.
Wok Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters (mm) 0.98 1.35
Rated Power (kW) 3.8 3.8
Flow rate 277 g/h 0.362 m³/h
Large Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters (mm) 0.85 1.15
Rated Power (kW) 2.9 2.9
Flow rate 218 g/h 0.276 m³/h
Middle Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters (mm) 0.65 0.97
Rated Power (kW) 1.75 1.75
Flow rate 127 g/h 0.166 g/h
Small Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters (mm) 0.50 0.72
Rated Power (kW) 1 1
Flow rate 73 g/h 0.095 g/h
INTRODUCTION OF APPLIANCE
01.03.2021 STOVE USER GUIDE EN 15

7 PREPARATION AND INSTALLATION
Fig. 6
The measurements specified above are applicable for 60 and 75
cm stoves (Fig. 6).
Fig. 7
The measurements specified above are applicable for 90 cm
stoves (Fig. 7).
Have the installation surface cut with the provided dimensions. Hob
placed on counter must be placed with the hob band provided with
the product. Stick so that it doesnt overlap. Place the hob inside
the gap previously opened on the kitchen counter. Fix the stove
with mounting plates
PREPARATION AND INSTALLATION
01.03.2021STOVE USER GUIDE EN16

Have the installation surface cut with the provided dimensions. Hob
placed on counter must be placed with the hob band provided with
the product. Stick so that it doesnt overlap. Place the hob inside
the gap previously opened on the kitchen counter. Fix the stove
with mounting plates
7.1 Rules To Observe When Connecting Gas
1- Hob
2- Hose End
3- Hose
4- Clamp
5- Oven
nGas (Lpg and natural gas) connection must be made by tech-
nical service.
nIf you use the gas hose as plastic type, make sure it conforms
to the TSE standard "TS_EN_14800".
nEnsure that the gas hose does not touch the hob above.
nIf you are using a flush type oven under the hob, make sure
that the gas hose does not touch the oven below.
nGas hose should not be pulled, bent or twisted.
nGas hose should not touch sharp edges and corners.
nEnsure the gas hose and hose end's gas leak-tightness.
nGas hose should be changed at least once a year.
nThe total length of the gas hose should not be longer than 125
cm.
nAfter gas connection is done and leak tightness is achieved,
the hose must not be touched.
nIf your are making the natural gas connection with metal flex-
ible pipe, check for whether the collar is suitable; it must be
1/2.
nEnsure that the metal flexible pipe is TSE approved.
nUse a leak-tightness gasket in metal connection.
7.2 Connecting The Gas Hose
1- LPG connection end
2- Plastic hose (internal diameter max 8 mm)
Slide the clamp on the hose. Then make the hob connection with
the hose. Finally, tighten the clamp well using screwdriver (Fig. 9).
nRepeat the same operations with the other end of the hose and
perform the gas bottle connection.
nDefinitely check for leak-tightness.
nIf later you have to use your product with a gas type different
than the one it is set for, you have to apply to authorized
service for the conversion.
Fig. 8
Fig. 9: GAS CONNECTION
PREPARATION AND INSTALLATION
Connecting The Gas Hose
01.03.2021 STOVE USER GUIDE EN 17

CAUTION!
LPG bottles should not be kept inside the
house.
Connecting Metal Flexible Pipe
1- Main gas pipe bend
2- Main gas pipe bend gasket
3- Gas pipe collar
CAUTION!
The flexible hose to be installed shall not come to
contact with the moving sections of the location
that is reserved for the unit (such as a drawer) or
shall not be installed through a section that may
cause clogging in the hose.
CAUTION!
When performing installation or gas conversion, fix
the main gas pipe with a second wrench. Take
care not to twist the main gas pipe (Fig. 11).
Your Hob Is Set For Natural Gas.
nYour natural gas utility must be prepared before placing your
hob.
nAt the end of your utility, there must be a flexible pipe that is
closed with a blind flange for natural gas connection.
nWhen the service is making the connection, they will remove
the blind flange and connect to your hob directly or using a
direct connection apparatus (coupling).
Natural gas valve must be in an easily accessible
location.
DANGER!
Do not use lighter or match fire to check the gas
leak.
Leak-tightness Check: Ensure that the knobs are
in off position and bottle / natural gas is not on
during the check. Foam up soap and apply the
foam to the connection end of the hose for gas
leak check. If there is a leak, the foam shall
bubble. If so, check the gas connection again.
Fig. 10: METAL PIPE CONNEC-
TIONS
Fig. 11
PREPARATION AND INSTALLATION
Connecting The Gas Hose
01.03.2021STOVE USER GUIDE EN18

8 GAS CONVERSION
8.1 Injector Change in Gas Hobs
The diameter of the injector used in your appliance is provided on
the injector in hundredths of millimetre. To change injectors:
nRemove the hob grating and the hob burners.
nRemove the injector with a suitable socket wrench (Fig. 12)
and install the new injector suitable for the gas type to be used
in the appliance in its place.
nCheck gas leakproofness with foam after the injectors are
installed. To do this, apply foam to the bases of the injectors.
Press on the injector with your finger to prevent gas exit and
check whether bubbles form where the injector is connected.
The chart below provides the injector diameters to be used in con-
versions between gases.
Wok Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters
(mm)
0.98 1.35
Large Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters
(mm)
0.85 1.15
Middle Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters
(mm)
0.65 0.97
Small Burner LPG (G30-30 mbar) NG (G20)
Injector Diameters
(mm)
0.50 0.72
Fig. 12
GAS CONVERSION
Injector Change in Gas Hobs
01.03.2021 STOVE USER GUIDE EN 19

Setting Low Flame Position
1- Idle Screw
For low flame position, the idle screw should be loosened during
conversion from LPG to natural gas. The same screw should be
tightened when converting from natural gas to LPG. Ensure that
the appliance is plugged in, the gas feed is on, and hob cooker and
cap adapters are in place. Ignite the hobs and bring them into low
flame position. Remove the knobs by pulling. The idle screw is
located on the tap body ( Fig. 13/1 ). Tighten/loosen the screw
using a small flat screwdriver. This enables the flame of the hob to
increase or decrease in low flame position. Tighten/loosen the
screw so that the flame length is 4 mm.
1 - Small burner should be turned 1/4 (quarter) turn in clockwise
direction.
2 - Middle burner should be turned 1/4 (quarter) turn in clockwise
direction.
3 - Large burner should be turned 1/2 (quarter) turn in clockwise
direction.
Replace the knob and ensure that the burner does not turn off
when it is adjusted from full flame to low flame in a time frame of
one second. Repeat the process above for each hob.
Fig. 13
GAS CONVERSION
Injector Change in Gas Hobs
01.03.2021STOVE USER GUIDE EN20
