Sima SUP-60 User manual

Introduction
Congratulations on your purchase of the Sima SUP-60 Universal Power Adapter. It
canpowerdigitalcamerasandotherportableelectronicdevicesrequiring3.3/4.2/5.0
/6.5/8.4or9.5V DC power.Itis fully regulatedusinghigh efficiency switchingtechnology
and features overload and short circuit protection. The SUP-60 comes with seven
connectors to fit different digital cameras and other electronic devices. Additional
connectors are available from Sima.
This package Includes:
1 AC adapter 7 Center pin positive connectors
1 SUP-60 Manual
Operation
1. Set the output voltage switch, as illustrated in Fig. 1, to the
desired output for your device. Choose from the following
settings: 3.3 / 4.2 / 5.0 / 6.5 / 8.4 or 9.5 V.
The SUP-60 comes with seven standard connectors. The
connectors allow you to match the size of your device’s DC
inputjack.Ifyourdevicerequiresother types of connectors,
visit Sima’s customer service at www.simacorp.com.
The connectors supplied with the SUP-60 are all set in a
center pin positive alignment ( Fig. A) If your device
requires a center pin negative power source (Fig. B) do
not use this adapter. To determine the required current
and correct polarity for your device, refer to the
manufacturer’s instruction manual or specifications
2. Select the appropriate connector and attach it to the output socket at the end of the
output cord. To identify the correct connector for your device, see the list of digital
cameras on the reverse side of this sheet. If unsure, use the connector that fits the
power jack of your camera. The two-pin connectors can fit into the socket only one
way. Align the pins as shown at right in Fig. 2. One pin is larger
than the other. Do not force.
3. Inserttheconnectorintothepowerjackonyourportable device.
4. Plug the AC adapter into the SUP-60’s input power jack
located at the top of the unit. Note: Do not plug the AC
adapter directly into anything except the SUP-60. Next,
plug the AC adapter into a standard AC wall outlet. The red
power light on the SUP-60 should turn on. You can now
operate your device.
IMPORTANT:Your portable device must be rated between 3 - 10V
DC and no more than 2100 mA of current to use the SUP-60. If
theexactvoltageforyourdeviceisnotlistedbelowandislessthan10V,youcantry
setting the voltage switch to the nearest voltage – use the lower setting first. If the
devicedoesnot operate, disconnect the connector from thedevice,resetthe voltage
switch to the next higher setting and re-connect. Do not continue trying higher
settings as they may result in damage to your device or the adapter.
The SUP-60’s current (mA) must be equal to or greater than the current your portable
device requires. Remember 1A = 1000mA, 0.5A = 500mA. Use the following chart
to determine the output current from the SUP-60:
Output Max. Output Max.
Voltage Current Voltage Current
3.3V = 2.1A 6.5V = 1.7A
4.2V = 2.0A 8.4V = 1.6A
5.0V = 1.9 A 9.5V = 1.5A
Resetting the Adapter
CAUTION: If the power light turns off, check the power source. If on, the output current
may be beyond the AC adapter’s specifications and overload protection has been activated.
To reset the adapter:
1. Remove the SUP-60 from the AC outlet and the device you are powering. Wait 10 sec.
2. Plug the SUP-60 into the AC outlet again. If the indicator remains off, there may be a
problem with the AC adapter. Contact Sima’s customer service for assistance.
Model SUP-60
For use with
digital cameras and camcorders.
Fig. 1
Output
Voltage
Switch
Power
light
120 VAC
Output
socket
Fig. 2
Connector
Output
socket
90-day Limited Warranty
Sima Products Corporation warrants this
product against defects in materials and
workmanship for a period of 90 days from the
date of purchase. During the warranty period,
the product will be repaired or replaced at
Sima’s option. Mail the enclosed product
registration card within ten days of the original
purchase.
Conditions: Ship your unit, freight pre-paid,
including reasonable proof of date and place
of purchase and description of problem to:
Sima Products Corporation
Attn: Customer Service
140 Pennsylvania Ave.
Bldg. #5
Oakmont, PA 15139
This warranty is void if any defects are caused
by abuse, misuse, negligence or unauthorized
repairs.All liability for incidental or
consequential damages is specifically
excluded. Some states do not allow for the
exclusion or limitation of incidental or
consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights
and you may have other rights, which vary
from state to state.
Universal Power Adapter
Input
+ -
Fig. A OK - + Fig. B No
Can’t find your plug?
Visit our website
2
www.simacorp.com

Safety warnings and Cautions
WARNING: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture.
CAUTION: To reduce the risk of electric shock, do not remove cover or back. No user serviceable parts
inside. Refer servicing to qualified personnel.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
Thismanualcontains importantsafetyandoperating instructionsforyourAC poweradapter. Beforeusing
your adapter, read all instructions and cautionary markings on the product.
DANGER: To reduce the risk of fire or electric shock, follow these instructions.
FCC Statement Thisdevice complieswith Part15 ofthe FCCRules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interferencereceived, includinginterference that maycause undesiredoperation. Youradapter isETL listedto
UL standards and meets all applicable FCC standards.
WARNING: Changes or modifications to this unit may cause interference and void the user’s authority to
operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception, which can be determined
byturning the equipmentoff andon, the user is encouragedto try to correct theinterference by one or moreof
thefollowingmeasures:1. Re-orient orrelocatethereceiving antenna. 2.Increasetheseparation betweenthe
equipment and receiver. 3. Consult Sima customer service atwww.simacorp.com if the problem still exists.
CAUTIONS: The adapter must attach to the power supply source with a built-in over-current protective
device(Max. 15A), suchas a 15Afuse and branchcircuit. Make surethe adapter isdisconnected from theAC
outlet and device before adjusting the voltage setting. Do not use the adapter to power a device that exceeds
the maximum power rating.
Note:TheSUP-60’svoltagemustbethesame as thevoltageyourportabledevicerequires.The SUP-60’s
current (mA) must be equal to or greater than the current your portable device requires.
Specifications:
AC adapter input: 120V AC, 60 Hz
AC adapter output: 13.5V DC, 1.2A
SUP-60 input: 12-15V DC,
Output rating: 3.3 / 4.2 / 5 / 6.5 / 8.4 or 9.5V DC
DC cord length: 1 m
Operation Temp: 32 to 113 degrees F
Storage temp.: -4 to 140 degrees F
Dimensions: 4” x 2.1” x 1.4”
Plug # & Size (diameter)
4.0 mm x 1.7 mm
4.75 mm x 1.7 mm
3.5 mm x 1.35 mm
3.0 mm x 1.0 mm
Sony L/M
Sony S/C
Sony F/C
Brand Model #Voltage Plug size
AGFA ePHOTO CL-30/34/50/307/780/ 780C/1280/1680 6.5V 4.0 x 1.7
CANON IXUS,IXUSV,V2,V3,100/110/230/300/330,/350, 4.2V 3.5 x 1.35
CANON A10/20/30/40 4.2V 4.0 x 1.7
CANON ZR60/65MC/70MC/80/85, Elura 40MC/60MC,Optura30 8.4V 3.5 x 1.35
CASIO QV-10A/11/70/100/120/200/300/700/770/780/2000UX/2300UX
QV-2400UX/2800UX/2900UX/3000EX/3000Plus/3500EX/4000E,
QV-5000SX/5500SX/7000SX/8000SX 6.5V 4.0 x 1.7
EPSON PC 550/600/650/700/750Z/800Z/850Z/2100Z/3000Z/3100Z 6.5V 4.7 x 1.7
FUJIFILM Finepix 50i/1300/1400Z/2300/2400Z/2700Z/2800Z/2900/3800/4800Z,
4900Z/6800Z/6900Z/DX-10, F401/402/601, M603, MX-500/600Z/700/1200
MX-1300/1400Z/1500/1700/2700/2900Z,S1 Pro, S2 Pro,S-304/602/3100 5.0V 4.0 x 1.7
HP PhotoSmart 120,315,318,320,612,620,720,850 6.5V 4.0 x 1.7
JVC GRDV800U,GRDVL520U 8.4 V 3.5 x 1.35
KODAK DC40/50/120/200/200plus/210/210plus/215/220/240/240i/260/265/280
DC290/3200z/3400z/DC5000z 6.5V 4.75 x 1.7
KODAK DC4800, LS443, DX7430/7440/7590/7630 5.0V 4.0 x 1.7
KYOCERA Finecam S3/S3L/S4/S5 5.0V 4.0 x 1.7
MINOLTA Dimage 5/7/7Hi/7i/3D/1500/EX1500/2300/2330z, E201. RD3000, S304/S404 6.5V 4.7 x 1.7
NIKON Coolpix 100/300/600/700/750/800/900/950/990/2000 6.5V 4.7 x 1.7
NIKON CoolPix 775/880/885/995/4300/4500/5000/5700/8700 8.4V 4.75 x 1.7
OLYMPUS C-100/120/200Z/211/300Z/320L/700UZ/720UZ/730UZ/960Z/990Z/2000Z
C-2020Z/2030/2040Z/2100Z/2500L/3000Z/3020Z/3040Z/4000Z/4040Z/5050Z
D-200L/220L/320L/340L/340R/360L/370L/400Z/450L/450Z/460Z/500L/550Z
D-600L/620L, E-10/20/20P/100 RS 6.5V 4.7 x 1.7
OLYMPUS C-1/1Z/2/40Z/220Z, D-40Z/100/150Z/230/395/540/580 3.3V 4.0 x 1.7
OLYMPUS C-50Z, Stylus 300/410 4.2V 4.0 x 1.7
PANASONIC DMC-F7 5.0V 4.0 x 1.7
PANASONIC DMC-FZ1 8.4V 4.7 x 1.7
PANASONIC DMC-LC5/LC40 8.4V 4.7 x 1.7
PANASONIC PVDV - 102/203/402/53 8.4V 4.7 x 1.7
PANASONIC PVL-352/452/453/672 6.5V 4.0 x 1.7
PANASONIC SVAV-25/50A/50S/100,PVDV-103/953 8.4V 4.0 x 1.7
PANASONIC PVGS-9/12/15 8.4V 4.7 x 1.7
PENTAX Optio 330RS/430RS 4.2V 4.0 x 1.7
PREMIER DC620/820/1310,/1311/1500/2000 6.5V 4.7 x 1.7
RICOH Caplio PR1/PR10/PR120,RDC-2/2E/7/300/300Z/1500/1700/4200
RDC-4300/5000/5300/6000, 5.0V 4.0 x 1.7
SAMSUNG Digimax 800 6.5V 3.0 x 1.0
SANYO VPC-MZ1/AZ1 3.3V 4.0 x 1.7
SONY CD200/250/300/400/450/1000, F707/717, FD85/87/90/92/95/97/100
FD200,S50/70/75/85,.CCDTRV-118/128/318/460/608, DCRDVD-101/102
DCRHC-85,DCRTRV-260/460 8.4V Sony L/M
SONY P1/2/3/5/9/20/30/31/50/51/71 4.2V Sony S/C
SONY Cybershot DSC P8,P10,P32, P52,P72,P92,V-1, 4.2V Sony F/C
SONY DSC-V1/W1/P4/P8/P10/P32/P52/P72/P92/P93 4.2V 3.0 x 1.0
TOSHIBA PDR-M1/M3/M4/M5/M11/M21/M25/M60/M61/M65/M70/M71/M81 5.0V 4.0 x 1.7
Digital Camera/Camcorder SUP-60 Connector Plug Chart
Sima Products Corporation 140 Pennsylvania Ave. Bldg #5
Oakmont, PA 15139 USA
www.simacorp.com
Made in China © 2005 Sima Products Corporation PN21715
