Simblee RFD77807 User manual

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Contents of Kit
1.
• RFD77310ENS210SensorShield
• RFD77201Simblee7pinDIPShield
• RFD22121USBProgrammingShield
• RFD221262xAAABatteryShield
2.
• ENS210Temperatureand
HumiditySensor
• MaximumAccuracy:
+/-0.2degreesCelsius
and+/-3.5%RH
• I2Csensor(SCLGPIO5
andSDAGPIO6)
• PushbuttononGPIO2
• LEDonGPIO3
RFD77807 Kit – ams ENS210
Sensor Starter Kit
Figure 1-RFD77807Simbleeams
ENS210StarterKit
Features of the RFD77310 – ams ENS210 Sensor Shield
Figure 2-RFD77310amsENS210
SensorShield

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
3.
PlacetheRFD77201ontopoftheRFD22126
BatteryShield.PlacetheamsENS210Sensor
ShieldontopoftheRFD77201.Pleasenote
thattheshieldsareseatedasshowninthe
belowpictures:
Assembling the Kit for Use
Figure 3-Kitremovedfrompackaging Figure 4-PlaceRFD77201Simblee
7pinDIPontopofRFD221262xAAA
BatteryShield
Figure 5-PlaceRFD77310amsENS210
SensorShieldontopofRFD77201Simblee
7pinDIP
Figure 6-CompletedDemoAssembly

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Insertthe2AAAbatteriesintothebat-
teryshield.Then,slidetheswitchonthe
sideofthebatteryshieldtoturnonthe
powershieldandpowerontheSimblee
device.TheyellowLEDonthebattery
shieldwillindicatethatpowerisbeing
supplied.
Figure 7-Insert2AAAbatteries
intoholder
Figure 8-BatteryOn/OSwitch
Figure 9-LEDPowerIndicator

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
4.
OpentheSimbleeForMobileappon
yourmobiledevice.Ifyouhavenot
downloadedtheSimbleeForMobile
app,pleaseseeAppendixAonhowto
downloadtheSimbleeForMobileapp.
OntheFoundSimbleesscreen,thesensor
willshowuponthescreen,provided
thattheSimbleedeviceison.Clickon
theitem.Waitforamomentwhilethe
SimbleeInterfaceloads.
Connecting to the Simblee using Simblee For Mobile
Figure 11-AndroidSimbleeForMobile
FoundSimbleesPage
Figure 10-iOSSimbleeForMobile
FoundSimbleespage

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
TheSimbleewillnowdisplaythe
temperatureandhumidityreadings
oftheENS210sensor.
Figure 12-iOSSimbleeForMobile
AppInterface
Figure 13-AndroidSimbleeFor
MobileAppInterface

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
TodisconnectfromtheSimbleedevice
oniOSdevices,clickonthebackarrow
onthetopleftofthescreenpointing
left.ThiswillreturnyoutotheSimblee
“FoundSimblees”screen.Toexitthe
apponAndroiddevices,clickontheleft
backarrowatthebottomofthescreen.
Figure 14-iOSSimbleeForMobile
BackButtonLocation
Figure 15-AndroidSimbleeForMobile
BackButtonLocation

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Downloading the Simblee For Mobile App on iOS Devices
OpentheAppStoreonyouriPhone/iOS
DevicerunningoniOSv8.0orlater
Searchfor“Simblee”.
Clickonthe“+Get”andInstalltostart
downloadingtheapp,thenclickonthe
“+Open”toopentheapp
Appendix A – Downloading the Simblee For
Mobile App on iOS and Android Devices

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
UponopeningtheSimbleeapp,aprompt
willasktoAllowInternetAccess.Click
onYes.Theapplicationwillalsorequire
thatBluetoothbeenabledonyourdevice.
Whenenteringtheapp,theappwill
displayanemptybrowserifnoSimblees
areinrange.
Figure 18-iOSSimbleeForMobile
InternetAccess
Figure 19 -SimbleeForMobile
DefaultScreen

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Downloading the Simblee For Mobile App (Android)
OpentheGooglePlayStoreonyour
AndroiddevicerunningonAndroid
Version6.0oraboveandsearchfor
“Simblee”.ClickontheSimbleeFor
Mobileitem,andtheInstallpagewill
appear.Clickthe“Install”button,and
then“Open”oncedoneinstalling.
Figure 20-AndroidGooglePlay
StoreSearch
Figure 21 -SimbleeForMobileon
AndroidGooglePlayStore

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Notethatthisappneedslocation
access,clickonAllowwhenprompted.
Figure 22-AndroidSimbleeForMobile
LocationAccess
Figure 23 -AndroidSimbleeFor
MobileLocationAccessRequest

1601 Pacic Coast Hwy • Suite 290 • Hermosa Beach • CA • 90254
www.simblee.com • Tel: [phone] • [e-mail]
CONFIDENTIAL – INTERNAL USE ONLY
Document – Copyright 2017 RF Digital Corporation – Jan 31, 2017
Theapplicationwillalsorequirethat
Bluetoothbeenabledonyourdevice.
Whenenteringtheapp,theappwill
displayanemptybrowserifnoSimblees
areinrange.
Figure 24 -AndroidSimbleeForMobile
DefaultScreen
Simblee Resources
FormoreinformationonusingSimblee,
pleaseseethefollowinglinks:
SimbleeQuickStartGuide
SimbleeUserGuide
GettingStartedwithSimbleeforMobile
GettingStartedwithSimbleeCOM
SimbleeDatasheet
