Simoco SDM600 Series User manual

Field House,
Uttoxeter Old Road,
Derby.
DE1 1NH.
Tel: [phone]
Fax: [phone]
www.simocowirelesssolutions.com ©2017 Simoco Wireless Solutions
1270 Ferntree Gully Road,
Scoresby Victoria,
3179
Australia.
Tel: [phone]
Fax: [phone]
www.simocowirelesssolutions.com
SDM622
User Manual
Issue: 1.0
Document Number: TNM-U-E-0145
Date: October 2017

This page has been intentionally left blank.

Table of Contents
Preface vii
Personal Safety ix
Waste Electrical and Electronic Equipment (WEEE) Notice xviii
1 Introduction 1
Overview 1
Configuration 1
Installation 1
SDM622 Features 1
2 Controls 3
Main Screen 4
Layout 4
Soft Labels 5
Text Panel 5
Icons 5
3 Basic Operation 9
Turning the Radio On and Off 9
Password Screen 9
Welcome Screen 10
Key Lock 10
Volume Adjustment 11
Selecting a Zone 11
Select a Channel 12
Make a Call 12
Receive a Call 13
Receive Individual Calls 14
Send a Message 14
Emergency Alarm 15
Scan Functions 15
Start a Scan 15
4 Menu System 17
General 17
Menu Navigation 18
Menu Screens 19
Home Screen (Channel & Zone) 20
Alert Offset 20
Backlight 21
Brightness 22
Call Divert 22
Call Log 24
Contrast 25
Contacts 25
Keybeeps 26
Mute Adjust 26
Radio Information 27
Document Number: TNM-U-E-0145 Issue: 1.0 Page iii

RSSI 27
Selcall Functions 28
Speaker Volume Menu 29
Text Message Menu 29
Scan Menu 34
DTMF Operation 35
5 Special Function Buttons 36
6 Troubleshooting 39
Document History 40
Simoco Support 41
Abbreviations 43
Document Number: TNM-U-E-0145 Issue: 1.0 Page iv

List of Figures
Figure 1: Controller Microphone Buttons 3
Figure 2: Display layout 4
Figure 3: Icon Row Locations 5
Figure 4: Idle Screen 9
Figure 5: Password Screen 9
Figure 6: Welcome Screen 10
Figure 7: Key Lock 10
Figure 8: Volume Adjustment 11
Figure 9: Zone Screen 11
Figure 10: Channel Screen 12
Figure 11: Receive a Call 14
Figure 12: Main Menu 17
Figure 13: Settings Menu 18
Figure 14: Menu Options 19
Figure 15: Home Screen 20
Figure 16: Alert Volume Menu Screen 21
Figure 17: Backlight Menu Screen 21
Figure 18: Brightness Menu Screen 22
Figure 19: Call Divert Menu screen 22
Figure 20: Call Divert – Target Type screen 23
Figure 21: Call Divert – Enter Target screen 23
Figure 22: Call Divert – Contact List screen 23
Figure 23: Call Divert screen - Diversion in Place 24
Figure 24: Call Divert screen 24
Figure 25: Call Log Menu Screen 24
Figure 26: Contrast Menu Screen 25
Figure 27: Contact Menu Screen 25
Figure 28: Contact Details Screen 26
Figure 29: Key Beeps Menu Screen 26
Figure 30: Mute Adjust Screen 26
Figure 31: Radio Information Menu 27
Figure 32: Radio Info Screens 27
Figure 33: RSSI Menu 28
Figure 34: Selcall Received 28
Figure 35: Speaker Volume Menu 29
Figure 36: Text Message Menu 30
Figure 37: Messages Inbox 30
Figure 38: Send Status Menu 31
Figure 39: Send Template Screen 31
Figure 40: New Message Screen 32
Figure 41: Send Message screen 33
Figure 42: Message View Screen 33
Figure 43: Message Options Screen 33
Document Number: TNM-U-E-0145 Issue: 1.0 Page v

Figure 44: Scan Menu 34
Document Number: TNM-U-E-0145 Issue: 1.0 Page vi

Preface
Declaration
This User Manual covers the SDM622 Controller Mircophone.
Any performance figures quoted are subject to normal manufacturing and service
tolerances. The right is reserved to alter the equipment described in this manual in the
light of future technical development.
Copyright
All information contained in this document is the property of Simoco. All rights are
reserved. This document may not, in whole or in part, be copied, photocopied,
reproduced, translated, stored, or reduced to any electronic medium or machine-
readable form, without prior written permission from Simoco.
Disclaimer
There are no warranties extended or granted by this document. Simoco accepts no
responsibility for damage arising from use of the information contained in the
document or of the equipment and software it describes. It is the responsibility of the
user to ensure that use of such information, equipment and software complies with
the laws, rules and regulations of the applicable jurisdictions.
Equipment and Manual Updates
In the interests of improving the performance, reliability or servicing of the equipment,
Simoco reserves the right to update the equipment or this document or both without
prior notice.
Document Number: TNM-U-E-0145 Issue: 1.0 Page vii

Errors and Omissions
The usefulness of this publication depends upon the accuracy and completeness of the
information contained within it. Whilst every endeavour has been made to eliminate
any errors, some may still exist. It is requested that any errors or omissions noted
should be reported to either of the following who are part of the Simoco Wireless
Solutions:
Field House 1270 Ferntree Gully Road,
Uttoxeter Old Road Scoresby Victoria,
Derby 3179
DE1 1NH Australia.
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
http://www.simocowirelesssolutions.com/ http://www.simocowirelesssolutions.com/
Document Number: TNM-U-E-0145 Issue: 1.0 Page viii

Personal Safety
These Safety Precautions advise personnel of specific hazards which may be
encountered during the installation and operation of the Simoco radio equipment and
that control measures are required to prevent injury to personnel, and damage to
equipment and/or the environment.
Before commencing the installation of any of the Simoco radio equipment, personnel
are to acquaint themselves with all risk assessments relevant to the work site and the
task. They must then comply with the control measures detailed in those risk
assessments.
References covering safety regulations, health hazards and hazardous substances are
detailed under the relevant WARNINGS sections below.
Adequate precautions must be taken to ensure that other personnel do not activate
any equipment that has been switched off for maintenance. Refer to the relevant
Electrical Safety Regulations appropriate to the country of operation.
Where dangerous voltages are exposed during a task, safety personnel are to be
provided as detailed in the relevant Electrical Safety Regulations. Where safety
personnel are required for any other reason, management are to ensure that the
personnel detailed are aware of the hazard and are fully briefed on the action to be
taken in an emergency.
RF Radiation
WARNING: RF RADIATION
An RF radiation hazard exists in the Mobile Radio equipment.
To avoid RF injury, do not touch the antenna when the transmitter is in use.
Do not operate the transmitter with antenna disconnected.
Compliance with RF energy exposure standards: to minimise exposure to RF fields
during equipment service and repair, the antenna terminal of the mobile radio
should be connected to a suitable non-radiating RF load when the transmitter is in
use.
Dangerous Voltages
WARNING: RF RADIATION
The mobile radio equipment is only to be connected to 12 V negative earth systems.
In vehicles with a 24 V supply, an approved 24 V/12 V converter must be used.
The supply must not be taken from a 12 V tap on a 24V battery.
Fused 12 V supply leads, antenna cables and speaker wiring is to be routed as far
away as possible from gas or fuel lines or any electronic control device. The radio
transceiver and antenna are to be mounted as far away as possible from these
devices and their cabling.
The equipment is to be installed, by a competent person, in accordance with the
requirements of local radio communications authorities and/or health and safety
Document Number: TNM-U-E-0145 Issue: 1.0 Page ix

regulations and vehicle manufacturer’s guidelines.
Post installation checks should be performed to ensure that there is no effect on the
operation of the vehicle’s electronics.
Beryllium and Beryllia
WARNING: Beryllium and Beryllia
The power amplifier module uses semiconductor devices containing beryllium oxide.
Refer to the Control Of Substances Hazardous to Health Regulations (COSHH) 2002
and/or the appropriate Safety Data Sheet.
Heat Sink Compound
WARNING: Heat Sink Compound
Dow corning DC340 heat sink compound is used in the heat sink of some Base
Stations. Refer to the COSHH Regulations 2002 and the appropriate product Safety
Data Sheet.
General Precautions
Do NOT operate your mobile radio, without a hands-free kit, whilst driving a vehicle.
Do NOT operate your radio in an explosive atmosphere – unless the radio’s level of
IECEx approval is approved for use in that atmosphere.
Obey the ‘Turn Off Two-way Radios’ signs where these are posted, e.g. on a petrol
station forecourt.
Do NOT touch the antenna while the radio is transmitting.
Do NOT operate the radio if the antenna has become disconnected or damaged.
Hazardous Substances
Before using any hazardous substance or material, the user must be conversant with
the safety precautions and first aid instructions:
nOn the label of the container in which it was supplied.
nOn the material Safety Data Sheet.
nIn any local Safety Orders and Regulations.
Hints For Using The Radio
When transmitting, hold the radio a few centimetres from your mouth and speak
across it, rather than into it.
Keep the length of your conversation to a minimum to conserve battery life and
replace the microphone on its cradle after use.
When it is possible to move location, avoid making calls from known poor signal-
strength areas such as the radio systems fringe areas (limit of range) or from screened
or shadowed areas, e.g. an underground car park or underpass.
Document Number: TNM-U-E-0145 Issue: 1.0 Page x

To avoid unnecessary drain on the vehicle battery, keep the engine running when
using the radio for extensive periods of time.
RF Energy Exposure Awareness and Control Information
and Operational Instructions for Occupational Use
Notice.
This Radio equipment is intended for use in Occupational/Controlled conditions
where users have full knowledge of their exposure and can exercise control over their
exposure to meet the occupational limits in FCC, ICNIRP or other International
Standards. This radio device is NOT authorised for general population, consumer use.
This two-way radio uses electromagnetic energy in the Radio Frequency (RF) spectrum
to provide communications between two or more users over a distance. It uses RF
energy or radio waves to send and receive calls. RF energy is one form of
electromagnetic energy. Other forms include, but are not limited to, electric power,
sunlight and x-rays. RF energy, however, should not be confused with these other
forms of electromagnetic energy, which, when used improperly, can cause biological
damage. Very high levels of x-rays, for example, can damage tissues and genetic
material.
Experts in science, engineering, medicine, health, and industry work with organizations
to develop standards for safe exposure to RF energy. These standards provide
recommended levels of RF exposure for both workers and the general public. These
recommended RF exposure levels include substantial margins of protection.
All Simoco two-way radios are designed, manufactured, and tested to ensure they
meet government established RF exposure levels. In addition, manufacturers also
recommend specific operating instructions to users of two-way radios. These
instructions are important because they inform users about RF energy exposure and
provide simple procedures on how to control it.
Please refer to the following websites for more information on what RF energy
exposure is and how to control your exposure to assure compliance with established
RF exposure limits:
http://transition.fcc.gov/oet/rfsafety/rf-faqs.html
http://www.osha.gov/SLTC/radiofrequencyradiation/index.html
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct/index-
eng.php
Document Number: TNM-U-E-0145 Issue: 1.0 Page xi

Federal Commuunication Commission (FCC)and Industry
Canada Regulations
The FCC and Industry Canada rules require manufacturers to comply with the RF
energy exposure limits for mobile two-way radios before they can be marketed in the
United States (US) and Canada. When two-way radios are used as a consequence of
employment, there is a requirement that users are fully aware of and able to control
their exposure to meet occupational requirements. Your Simoco two-way radio has an
RF exposure awareness label attached to the equipment directing users to specific user
awareness information. Do not remove this exposure awareness label from the device.
Additionally, your Simoco user manual, or separate safety booklet includes information
and operating instructions required to control your RF exposure and to satisfy
compliance requirements.
Compliance with RFExposure Standards
Simoco two-way radios are designed and tested to comply with a number of national
and international standards and guidelines (listed below) for human exposure to RF
electromagnetic energy.
This radio complies with the IEEE (FCC), Industry Canada and ICNIRP exposure limits
for occupational/controlled RF exposure environments at operating duty factors of up
to 50% talk 50% listen, and is authorised for occupational use only.
This radio also complies with the essential requirements and other provisions of the
Radio Equipment Directive 2014/53/EU.
In terms of measuring RF energy for compliance with these exposure guidelines, your
radio generates measureable RF energy only while it is transmitting (during talking),
not when it is receiving (listening) or in standby mode.
This Simoco two-way radio is designed to comply with the following national and
international RF energy exposure standards and guidelines:
nUnited States Federal Communications Commission (FCC), Code of Federal Regu-
lations; 47 CFR part 2 sub-part J.
nAmerican National Standards Institute (ANSI)/Institute of Electrical and Electronic
Engineering (IEEE) C95.1-1992.
nAustralian Communications Authority Radio Communications Standard et seq.
nIEEE C95.1-1999 Edition.
nIndustry Canada RSS-102.
nRadio Equipment Directive 2014/53/EU.
Document Number: TNM-U-E-0145 Issue: 1.0 Page xii

RFExposure Compliance and Control Guidelines and
Operating Instructions
To control exposure to yourself and others and ensure compliance with the
Occupational/Controlled environment exposure limits always adhere to the following
procedures.
Guidelines:
nUser awareness instructions should accompany the device when transferred to
other users.
nDo not use this device if the operational requirements described herein are not
met.
Operating Instructions:
Transmit no more than the rated duty factor of 50% of the time. To Transmit (Talk),
push the Push To Talk (PTT) button. To receive calls (listen), release the PTT button.
Transmitting 50% of the time, or less, is important because the radio generates
measurable RF energy exposure only when transmitting (in terms of measuring for
standards compliance.
Mobile Operation:
Transmit only when people outside the vehicle are at least the recommended minimum
lateral distance away from a properly installed according to installation instructions,
externally mounted antenna.
Notes:
1. Table A lists the recommended minimum lateral distance for bystanders in an
uncontrolled environment from the transmitting antenna for the SDM600AC
(150 MHz – 174 MHz) mobile rated power (25 Watts) installed in a vehicle.
2. Table B lists the recommended minimum lateral distance for
occupational/controlled use.
3. Table C lists the recommended minimum lateral distance for bystanders in an
uncontrolled environment from the transmitting antenna for the SDM600TU
and SDM600UW (406.1 MHz – 512 MHz) mobile rated power (25 Watts)
installed in a vehicle.
4. Table D lists the recommended minimum lateral distance for
occupational/controlled use.
Rated Power of Vehicle- installed Mobile
Two-way Radio
Recommended Minimum Lateral Distance
from Transmitting Antenna
25 Watts with 1/4 dipole (2.14 dBi gain) 90 cm (35.5 inches)
Table A: Rated Power and Recommended Lateral Distance for General Population Uncontrolled
Exposure for SDM600AC (150 MHz to 174 MHz).
Document Number: TNM-U-E-0145 Issue: 1.0 Page xiii

Rated Power of Vehicle-installed Mobile
Two-way Radio
Recommended Minimum Lateral Distance
from Transmitting Antenna
25 Watts with 1/4 dipole (2.14 dBi gain) 40 cm (15.75 inches)
Table B: Rated Power and Recommended Lateral Distance for Occupational/Controlled Exposure for
SDM600AC (150 MHz to 174 MHz).
Rated Power of Vehicle- installed Mobile
Two-way Radio
Recommended Minimum Lateral Distance
from Transmitting Antenna
25 Watts with 1/4 dipole (2.14 dBi gain) 75 cm (29.5 inches)
Table C: Rated Power and Recommended Lateral Distance for General Population Uncontrolled
Exposure for SDM600TU and SDM600UW (406.1 MHz to 512 MHz).
Rated Power of Vehicle- installed Mobile
Two-way Radio
Recommended Minimum Lateral Distance
from Transmitting Antenna
25 Watts with 1/4 dipole (2.14 dBi gain) 34 cm (13.5 inches)
Table D: Rated Power and Recommended Lateral Distance for Occupational/Controlled Exposure for
SDM600TU and SDM600UW (406.1 MHz to 512 MHz).
Vehicle Installation Instructions
The antenna(s) used for the SDM600 series of mobile two-way radios must be installed
to provide a separation distance of at least 90 cm (35.5 inches) from all persons for
SDM600AC (150 MHz -174 MHz), 75 cm (29.5 inches) for SDM600TU and SDM600UW
(406.1 MHz – 512 MHz). The gain of the antenna(s) may not be greater than 0 dBd
(2.14 dBi).
If the required separation distance extends beyond the physical boundary of the
vehicle, the antenna must be installed on the centre of the roof ONLY and must be
installed in a vehicle having the following characteristics in order to prevent
bystanders from being exposed to levels exceeding the limits set for General
Population/Uncontrolled exposure environment:
nAll passengers must be sitting under a solid metal roof.
nThe rooftop width must be at least 180 cm (71 inches) for SDM9000AC (150 MHz –
174 MHz), 150 cm (59 inches) for SDM600TU and SDM600UW (406.1 MHz – 512
MHz).
Document Number: TNM-U-E-0145 Issue: 1.0 Page xiv

Mobile Antenna
nInstall the antenna at the centre of the roof or the centre of the trunk deck, taking
into account the bystander exposure conditions of backseat passengers and
recommended minimum lateral distances in Tables 1(a) and 2(a). These mobile
antenna installation guidelines are limited to metal body motor vehicles or vehicles
with appropriate ground planes.
nThe antenna installation must additionally be in accordance with:
lThe requirements of the antenna manufacturer/supplier.
lInstructions in the Radio Installation Manual, including minimum antenna cable
lengths.
lThe installation information of how to install the antenna to facilitate
recommended operating distances to all potentially exposed persons.
nUse only Simoco approved supplied antenna or Simoco approved replacement
antenna. Unauthorized antennas, modifications, or attachments could damage the
radio and may violate FCC regulations.
Approved Accessories
nThis radio meets the FCC RF exposure guidelines when used with the Simoco
accessories supplied or designated for the product. Use of other accessories may
not ensure compliance with the FCCs RF exposure guidelines and may violate FCC
regulations.
nFor a list of Simoco approved antennas and accessories please see your local
Simoco dealer or contact Simoco Customer Services.
Electromagnetic Interference/Compatibility
Note: Nearly all electronic devices are susceptible to Electromagnetic Interference
(EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic
compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility issues, turn off your radio
in any facility where posted notices instruct you to do so. Hospitals or health care
facilities may be using equipment that is sensitive to external RF energy.
Medical Devices
Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In the event of such
interference, it would be advisable to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
Document Number: TNM-U-E-0145 Issue: 1.0 Page xv

If you use any other personal medical device, consult the manufacturer of the device to
determine if it is adequately shielded from RF energy. Your Doctor may also be able to
help you in obtaining this information.
Use of Communication Devices While Driving
nAlways check the laws and regulations on the use of radios in the countries and
areas where you drive.
nGive your full attention to driving and to the road.
nIf available, use the hands-free facility.
nIf driving conditions or regulations require it, pull off the road and park before
making or answering a call.
Acoustic Safety
Exposure to loud noises from any source for extended periods of time may temporarily
or permanently affect your hearing. The louder the radio’s volume, the less time is
required before your hearing could be affected. Hearing damage from loud noise is
sometimes undetectable at first and can have a cumulative effect.
To protect your hearing:
nUse the lowest volume setting necessary in order to do your job.
nOnly turn up the volume if you are in noisy surroundings.
nBefore adding a headset or earpiece to the radio, turn down the volume.
nLimit the amount of time you use headsets or earpieces at high volume.
nWhen using the radio without a headset or earpiece, do not place the radio’s
speaker directly against your ear.
Operational Warnings
Vehicles with Air Bags
WARNING: FOR VEHICLES FITTED WITH AIR BAGS
ALWAYS REFER TO THE MANUFACTURER’S MANUAL PRIOR TO INSTALLATION
OF ELECTRONIC EQUIPMENT TO AVOID INTERFERENCE WITH THE AIR BAG
WIRING.
Do not place a portable radio in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a portable radio is placed in the
air bag deployment area and the air bag inflates, the radio may be propelled with
great force and cause serious injury to vehicle occupants.
Explosive Atmospheres
Explosive atmospheres refer to hazard classified locations that may contain hazardous
gas, vapours or dusts.
WARNINGS
Always turn off your radio prior to entering any area with a potentially explosive
atmosphere, unless the radio type is especially qualified for use in such areas as
“Intrinsically Safe” (e.g. Factory Mutual, CSA, UL, ATEX, IEC Approved).
Document Number: TNM-U-E-0145 Issue: 1.0 Page xvi

Do not remove, install or change batteries in such areas. Sparks in a potentially
explosive atmosphere can cause an explosion or fire resulting in serious bodily injury
or even death.
The areas with potentially explosive atmospheres referred to include fuelling areas
such as below decks on boats, fuel or chemical transfer or storage facilities, areas
where the air contains chemicals or particles, such as grain dust or metal powders.
Areas with potentially explosive atmospheres are normally (but not always) posted.
Blasting Caps and Blasting Areas
WARNING
Always turn off your radio prior to entering any area with a potentially explosive To
avoid possible interference with blasting operations, always turn off your radio when
you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off
Two-way radios”. Obey all signs and instructions.
Units Mounted in Vehicles
In addition to the safety instructions and operational safety guidelines listed above,
for units mounted in vehicles, the following should be strictly adhered to:
WARNING
To reduce the risk of injury during sudden braking or impact, ensure that the units are
correctly secured.
Ensure that the installation and operation of the unit(s) is such that the driver will not
be distracted from driving safely and can comply with any local regulatory
requirements.
Vehicles Equipped with Air Bags
Do not place or install equipment in the area over an air bag or in the air bag
deployment area. Any equipment placed or installed in the air bag deployment area
may be propelled with great force in the event of the air bag being activated, which
could result in serious injury to any vehicle occupants.
The equipment is to be installed, by a competent person, in accordance with the
requirements of local radio communications authorities and/or health and safety
regulations and vehicle manufacturer’s guidelines. Units mounted in vehicles should
be secure to ensure that they do not break free during operation or in the event of an
accident.
Document Number: TNM-U-E-0145 Issue: 1.0 Page xvii

Mounting fixings/screws can damage cables and wires that run under some mounting
surfaces in the vehicle. Contact the vehicle manufacturer for the detailed locations of
cables and wires in your vehicle, and avoid mounting any units in these locations.
Waste Electrical and Electronic Equipment (WEEE) Notice
The Waste Electrical and Electronic Equipment (WEEE) Directive
became law in most EU countries during 2005. The directive applies
to the disposal of waste electrical and electronic equipment within
the member states of the European Union.
As part of the legislation, electrical and electronic equipment will
feature the crossed out wheeled bin symbol (see image at left) on
the product or in the documentation to show that these products
must be disposed of in accordance with the WEEE Directive.
In the European Union, this label indicates that this product should not be disposed of
with domestic or “ordinary” waste. It should be deposited at an appropriate facility to
enable recovery and recycling.
Document Number: TNM-U-E-0145 Issue: 1.0 Page xviii

1 Introduction
Overview
The SDM600 series radios are versatile digital (DMR standard) or analogue (FM) two-
way mobile radios. The SDM600 series is available in a number of frequency bands and
versions for specific applications. This manual describes the operation of the SDM622
Controller Microphone variant (P/No MAR-622CM).
The SDM622 DMR radio consists of a Transceiver unit that may be mounted in the
vehicle boot or under a seat, and a Controller Microphone, which is designed to mount
on the vehicle console or within view and reach of the operator.
The radio is programmable with a Field Personality Programmer (FPP), and can operate
in Conventional mode (DMR Tier II), Trunked mode (DMR Tier III), or Analogue PMR
mode. Your Simoco representative can help in programming your SDM622 radio
facilities to meet your present and future requirements.
This guide describes the facilities that are currently available and can be programmed
into the SDM622. Where such features are exclusive to Tier II, Tier III or Analogue
modes, this will be indicated in the text (as DMR-Tier II, DMR-Tier III, or Analogue).
Configuration
The SDM622 radio must be configured using the Field Personality Programmer (FPP)
prior to operation. The configuration process defines the radio channels, signalling
and other settings so that the radio will operate with your system.
Installation
As the installation of your SDM622 radio is a technical and possibly hazardous
operation, we recommend that it is installed and set up for use by your dealer or an
authorised installer. However, if you need information regarding the correct
procedures for installation, please refer to the SDM600 series Installation Instructions
supplied with the radio, or available on the Simoco Wireless Solutions Website, at
https://www.simocogroup.com/portal/resource-library/installation-instructions-
guides/dmr.
SDM622 Features
The SDM622 radio has the following features:
n6 programmable direct Function Buttons.
n10 additional indirect Function Buttons (keys 0 - 9).
n2000 Channels.
Document Number: TNM-U-E-0145 Issue: 1.0 Page 1

n40 Zones (up to 250 Channels per zone).
n102 x 64 LCD graphic display, with up to 8 lines of 14 characters
nContext based soft menu labels.
nLight Emitting Diode (LED) PTT/Rx indicator.
A radio Channel can be defined as either Analogue or DMR mode, and a Zone may
contain a mix of Analogue or DMR Channels.
Zones are typically programmed with channels belonging to common function groups.
Document Number: TNM-U-E-0145 Issue: 1.0 Page 2
