Simple By Design 73SDRST02 User manual

PART LIST QUANTITY
A 1 PC
B 2 PCS
C 3 PCS
D 1 PC
E 4 PCS
F 4 PCS
G 4 PCS + 1 PC
H 4 PCS + 1 PC
I 16 PCS + 1 PC
J 16 PCS + 1 PC
K 16 PCS + 1 PC
L 2 PCS
M 2 PCS
SAVE THESE INSTRUCTIONS
SIMPLE BY DESIGN 4 DRAWER STORAGE UNIT ASSEMBLY INSTRUCTIONS
STYLE #:
73SDRST02
ASSEMBLE ON A FLAT, PROTECTED SURFACE
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED
FIGURE
DESCRIPTION
TOP PANEL
SIDE PANEL
SHELF
BOTTOM SHELF
DRAWER
DRAWER BOTTOM
CAM BOLT
CAM LOCK
BOLT
(1/4" x 1 3/4")
BARREL NUT
LONG SCREW
(3/16" x 1/2")
BACK WHEEL
FRONT LOCKING WHEEL
Page 1/8

N 4 PCS + 1 PC
O 4 PCS
P 12 PCS + 1 PC
SAVE THESE INSTRUCTIONS
SIMPLE BY DESIGN 4 DRAWER STORAGE UNIT ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST02
ASSEMBLE ON A FLAT, PROTECTED SURFACE
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED
SHORT SCREW
(1/8" x 1/2")
DRAWER STOP
CAP
Page 2/8

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST02
STEP 1
A. PLACE TOP PANEL (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. INSERT CAM BOLTS (G) INTO TOP PANEL (A)
USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. TIGHTEN COMPLETELY.
C. ATTACH DRAWER STOP (O) TO TOP PANEL (A)
WITH SHORT SCREW (N) USING PHILLIPS HEAD
SCREWDRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
STEP 2
A. PLACE BOTTOM SHELF (D) UPSIDE DOWN ON A
FLAT, PROTECTED SURFACE.
B. ATTACH BACK WHEELS (L) AND FRONT LOCKING
WHEELS (M) TO BOTTOM SHELF (D) WITH LONG
SCREWS (K) USING PHILLIPS HEAD SCREWDRIVER,
NOT INCLUDED. TIGHTEN COMPLETELY.
Page 3/8

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST02
STEP 3
A. PLACE SHELVES (C) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. ATTACH DRAWER STOPS (O) TO SHELVES (C) AT
FRONT WITH SHORT SCREWS (N) USING PHILLIPS
HEAD SCREWDRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
STEP 4
A. SET SIDE PANELS (B) ONTO CAM BOLTS (G) IN
TOP PANEL (A).
B. INSERT CAM LOCKS (H) INTO SIDE PANELS (B).
C. TURN CAM LOCKS (H) USING PHILLIPS HEAD
SCREWDRIVER, NOT INCLUDED, TO SECURE SIDE
PANELS (B) TO TOP PANEL (A).
Page 4/8

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST02
STEP 6
A. INSERT BARREL NUTS (J) INTO HOLES OF SIDE
PANELS (B) AT BOTTOM.
B. ATTACH BOTTOM SHELF (D) WITH LOCKING
WHEELS (M) AT FRONT TO SIDE PANELS (B) WITH
BOLTS (I) USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. TIGHTEN COMPLETELY.
C. TIGHTEN COMPLETELY ALL BOLTS (I) FROM
STEP 5.
STEP 5
A. INSERT BARREL NUTS (J) INTO HOLES ON
SHELVES (C) AT BOTTOM.
B. ATTACH SHELVES (C), KEEPING DRAWER STOPS
AT FRONT, TO SIDE PANELS (B) WITH BOLTS (I)
USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. DO NOT TIGHTEN COMPLETELY.
Page 5/8

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST02
STEP 7
A. UNFOLD DRAWERS (E).
B. INSERT DRAWER BOTTOMS (F) INTO DRAWERS
(E).
STEP 8
A. ROTATE ASSEMBLED UNIT TO THE UPRIGHT
POSITION.
B. PLACE ASSEMBLED DRAWERS (E) INTO THE
ASSEMBLED UNIT AS SHOWN.
C. PRESS CAPS (P) INTO BOLT HOLES AT SIDE
PANELS (B).
D. ASSEMBLY IS COMPLETE.
Page 6/8

PART LIST QUANTITY
1 1 PC
2 1 PC
3 1 PC
4 1 PC
ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL
STYLE #:
73SDRST02
PHILLIPS HEAD SCREWDRIVER, DRILL, & 7/32" DRILL BIT NEEDED FOR ASSEMBLY; NOT INCLUDED.
FOR SAFETY REASONS, INSTALL THIS PRODUCT USING THE INCLUDED ANTI-TIP HARDWARE TO HELP PREVENT THE
PRODUCT FROM UNEXPECTEDLY TIPPING OR SHIFTING.
THE INCLUDED MATERIALS ARE DESIGNED TO MOUNT THE ANTI-TIP HARDWARE TO DRYWALL.
PLEASE CONSULT A REPRESENTATIVE AT A HARDWARE/HOME IMPROVEMENT STORE TO DISCUSS
ADDITIONAL MOUNTING OPTIONS FOR OTHER TYPES OF WALLS.
FIGURE
DESCRIPTION
LONG SCREW
(5/16" X 1 3/8")
SHORT SCREW
(1/8" x 1/2")
WALL ANCHOR
STRAP
STEP 9
A. REMOVE TOP DRAWER FROM ASSEMBLED UNIT.
B. ATTACH STRAP (4) WITH SHORT SCREW (2) TO
THE UNDERSIDE OF TOP PANEL (A) USING PHILLIPS
HEAD SCREW DRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
Page 7/8

ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL (CONTINUED)
STYLE #:
73SDRST02
WEIGHT LIMIT
TOP: 40 LBS; DRAWERS: 10 LBS EACH
CARE AND CLEANING
FRAME: WIPE CLEAN WITH A SOFT, DRY CLOTH AS NEEDED.
DRAWERS: SPOT CLEAN WITH A DAMP, CLEAN CLOTH AS NEEDED. DO NOT RUB.
DO NOT SIT, STAND, OR CLIMB ON THE STORAGE UNIT.
WHEN USING STORAGE DRAWERS, DO NOT OVEREXTEND DRAWERS AS WEIGHT COULD CAUSE TIPPING.
INTENDED FOR INDOOR USE ONLY
** WE RECOMMEND THAT YOU PERIODICALLY TIGHTEN ALL BOLTS AND SCREWS WITH PHILLIPS HEAD SCREWDRIVER,
NOT INCLUDED.
STEP 10
A. DETERMINE WHERE THE STORAGE UNIT IS TO BE
PLACED, THEN MARK THE POSITION ON THE WALL
SO THE WALL ANCHOR (3) WILL ALIGN WITH THE
STRAP (4) ON THE BACK OF THE STORAGE UNIT.
B. DRILL HOLE IN THE WALL. PRESS WALL ANCHOR
(3) INTO THE HOLE.
STEP 11
A. CONNECT STRAP (4) WITH LONG SCREW (1) TO
WALL ANCHOR (3) USING PHILLIPS HEAD
SCREWDRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
C. REPLACE TOP DRAWER INTO ASSEMBLED UNIT.
Page 8/8
