Simple By Design 73SDRST03 User manual

PART LIST QUANTITY
A 1 PC
B 2 PCS
C 1 PC
D 1 PC
E 2 PCS
F
2 PCS
G
4 PCS + 1 PC
H
4 PCS + 1 PC
I
8 PCS + 1 PC
J
8 PCS + 1 PC
K 8 PCS + 1 PC
L
2 PCS
M
2 PCS
FRONT LOCKING WHEEL
BOLT
(1/4" x 1 3/4")
BARREL NUT
LONG SCREW
(3/16" x 1/2")
BACK WHEEL
CAM LOCK
DRAWER
DRAWER BOTTOM
BOTTOM SHELF
SIDE PANEL
CAM BOLT
SHELF
SAVE THESE INSTRUCTIONS
SIMPLE BY DESIGN 2 DRAWER STORAGE UNIT ASSEMBLY INSTRUCTIONS
STYLE #:
73SDRST03
TOP PANEL
ASSEMBLE ON A FLAT, PROTECTED SURFACE
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED
FIGURE
DESCRIPTION
Page 1/6

N
2 PCS + 1 PC
O
2 PCS
P 4 PCS + 1 PC
ASSEMBLE ON A FLAT, PROTECTED SURFACE
PHILLIPS HEAD SCREWDRIVER NEEDED FOR ASSEMBLY; NOT INCLUDED
CAP
SHORT SCREW
(1/8" x 1/2")
DRAWER STOP
SAVE THESE INSTRUCTIONS
SIMPLE BY DESIGN 2 DRAWER STORAGE UNIT ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST03
Page 2/6

ASSEMBLY INSTRUCTIONS (CONTINUED)
STYLE #:
73SDRST03
STEP 1
A. PLACE TOP PANEL (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. INSERT CAM BOLTS (G) INTO TOP PANEL (A)
USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. TIGHTEN COMPLETELY.
C. ATTACH DRAWER STOP (O) TO TOP PANEL (A)
WITH SHORT SCREW (N) USING PHILLIPS HEAD
SCREWDRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
STEP 2
A. PLACE BOTTOM SHELF (D) UPSIDE DOWN ON A
FLAT, PROTECTED SURFACE.
B. ATTACH BACK WHEELS (L) AND FRONT LOCKING
WHEELS (M) TO BOTTOM SHELF (D) WITH LONG
SCREWS (K) USING PHILLIPS HEAD SCREWDRIVER,
NOT INCLUDED. TIGHTEN COMPLETELY.
Page 3/6

STYLE #:
73SDRST03
STEP 4
A. SET SIDE PANELS (B) ONTO CAM BOLTS (G) IN
TOP PANEL (A).
B. INSERT CAM LOCKS (H) INTO SIDE PANELS (B).
C. TURN CAM LOCKS (H) USING PHILLIPS HEAD
SCREWDRIVER, NOT INCLUDED, TO SECURE SIDE
PANELS (B) TO TOP PANEL (A).
ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 3
A. PLACE SHELVES (C) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. ATTACH DRAWER STOPS (O) TO SHELVES (C) AT
FRONT WITH SHORT SCREWS (N) USING PHILLIPS
HEAD SCREWDRIVER, NOT INCLUDED. TIGHTEN
COMPLETELY.
Page 4/6

STEP 6
A. INSERT BARREL NUTS (J) INTO HOLES OF SIDE
PANELS (B) AT BOTTOM.
B. ATTACH BOTTOM SHELF (D) WITH LOCKING
WHEELS (M) AT FRONT TO SIDE PANELS (B) WITH
BOLTS (I) USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. TIGHTEN COMPLETELY.
C. TIGHTEN COMPLETELY ALL BOLTS (I) FROM
STEP 5.
STEP 5
A. INSERT BARREL NUTS (J) INTO HOLES ON
SHELVES (C) AT BOTTOM.
B. ATTACH SHELVES (C), KEEPING DRAWER STOPS
AT FRONT, TO SIDE PANELS (B) WITH BOLTS (I)
USING PHILLIPS HEAD SCREWDRIVER, NOT
INCLUDED. DO NOT TIGHTEN COMPLETELY.
STYLE #:
73SDRST03
ASSEMBLY INSTRUCTIONS (CONTINUED)
Page 5/6

STYLE #:
STEP 7
A. UNFOLD DRAWERS (E).
B. INSERT DRAWER BOTTOMS (F) INTO DRAWERS
(E).
STEP 8
A. ROTATE ASSEMBLED UNIT TO THE UPRIGHT
POSITION.
B. PLACE ASSEMBLED DRAWERS (E) INTO THE
ASSEMBLED UNIT AS SHOWN.
C. PRESS CAPS (P) INTO BOLT HOLES AT SIDE
PANELS (B).
D. ASSEMBLY IS COMPLETE.
73SDRST03
ASSEMBLY INSTRUCTIONS (CONTINUED)
DRAWERS: SPOT CLEAN WITH A DAMP, CLEAN CLOTH AS NEEDED. DO NOT RUB.
DO NOT SIT, STAND, OR CLIMB ON THE STORAGE UNIT.
WHEN USING STORAGE DRAWERS, DO NOT OVEREXTEND DRAWERS AS WEIGHT COULD CAUSE TIPPING.
INTENDED FOR INDOOR USE ONLY
** WE RECOMMEND THAT YOU PERIODICALLY TIGHTEN ALL BOLTS AND SCREWS WITH PHILLIPS HEAD SCREWDRIVER,
NOT INCLUDED.
WEIGHT LIMIT
TOP: 40 LBS; DRAWERS: 10 LBS EACH
CARE AND CLEANING
FRAME: WIPE CLEAN WITH A SOFT, DRY CLOTH AS NEEDED.
Page 6/6
