Introduction
This publication describes the installation procedure for the Expansion Signal (XSIG) Card (4100-5116).
This product is compatible with 4100U and 4100ES Fire Alarm Control Panels (FACP).
Important: Verify FACP System Programmer, Executive, and Slave Software compatibility when installing, or replacing system components. Refer to
the Technical Support Information and Downloads website for compatibility information.
579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions
*0579516J*

Introduction to the Expansion Signal Card
Overview
The Expansion Signal (XSIG) Card provides three additional notification appliance circuits (NACs) for use with either an amplifier audio NAC or a power
supply card NAC (SPS, RPS, XPS). It is not compatible with the ES-PS simple NAC or NAC Cards. When you add an XSIG Card for audio NAC expansion,
program the card for operation with the specific amplifier that it is expanding.
Each XSIG card must be dedicated to provide either all Audio or all DC notification; these operations cannot be mixed.
Functions of the XSIG Card:
1. Provides three 1.5 A Class B NACs for Audio or DC notification.
2. Switches between two power audio input sources, for example, Flex-35/Flex-50-style dual-channel power stage switching.
3. Accepts Class A Adapter and Class B Expander for a total of six Class B NACs or three Class A NACs on each card that can be used with audio
or DC signaling.
4. Accepts constant supervision audio NAC module for a total of three Constant Supervision NACs on each card for use with audio signaling
only.
5. When configured for use with non-alarm audio, quickly and automatically switches to an audio source when a signal is detected at either
input.
6. Supports earth fault isolation in conjunction with the source NAC supplying the card input.
The XSIG Card also supports the WALKTEST system test as long as the following programming guidelines are followed:
• Custom Control must be written to turn on the NACs when the "WALKTEST Group Active" pseudo turns ON.
• Lists can be created for the NACs to allow you to have them turn ON when different groups are activated. However, a Custom Control equation
would be required for each WALKTEST group.
Optional equipment
Optional equipment to accompany the XSIG card consists of the following:
• 4100-1266 Expansion Signal (XSIG) Card XNAC: increases the quantity of Class B NACs from three to six
• 4100-1267 Expansion Signal (XSIG) Card Class A Adapter: upgrades the three on-card NACs to Class A
• 4100-1268 Expansion Signal (XSIG) Constant Supervision NAC: replaces the on-card NACs with three Class A/B Constant Supervision
NACs
page 2 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Expansion Signal (XSIG) Card illustration
Figure 1 is an illustration of the Expansion Signal (XSIG) card.
Figure 1: XSIG Card
XSIG Card receives power and communications from PDI
The XSIG card is a 4100 Comm slave according to the 4100 slave architecture. The card plugs onto the Power Distribution Interface (PDI) that supplies
card power and 4100 Comm communications.
XSIG Card LEDs
LEDs on the XSIG card are used to indicate card status. See Table 1.
Table 1: Status LEDs
*LED No. Use Interpretation Color
2 On when the amplifier is not communicating with
the system CPU
ON Steadily during comm loss; flashing during firmware failure. Yellow
3Status of audio NAC 1 ON Steadily when NAC is ON;
ON Steadily when NAC detects trouble. Yellow
4 NAC1 routing relay status = routed to Input 2 (audio
use only) ON Steadily when NAC1 is routed to Input 2. Green
5Status of audio NAC 3 ON Steadily when NAC is ON;
ON Steadily when NAC detects trouble. Yellow
6 NAC2 routing relay status = routed to Input 2 (audio
use only) ON Steadily when NAC2 is routed to Input 2. Green
7Status of audio NAC 2 ON Steadily when NAC is ON;
ON Steadily when NAC detects trouble. Yellow
8 NAC3 routing relay status = routed to Input 2 (audio
use only) ON Steadily when NAC3 is routed to Input 2. Green
*LED1 is not provided on the XSIG card.
page 3 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Requirements and Limitations
Refer to Table 2 for electrical and environmental requirements.
Table 2: Electrical and environmental specifications
Electrical Specifications
Voltage 24 VDC from FACP (19 VDC to 32 VDC)
Power requirements
Supervision current 20 mA
Alarm current 52 mA – Power Supply or 100 W Amplifier
80 mA – Flex-35 or Flex-50 Amplifier
NAC specifications
DC use 1.5 A maximum
Audio use 1.5 A maximum, 50 W, OR 100 speakers (whichever comes first)
Environmental specifications
Operating temperature 32°F to 120°F (0°C to 49°C)
Humidity Up to 93% relative humidity at 90°F (32°C)
Installing the Expansion Signal Card onto the PDI
Overview
The Expansion Signal (XSIG) card mounts on the PDI. The module can be mounted on any of the PDI connectors.
Use connector P4, labeled on the backside of the given card, to connect to any of the eight PDI connectors as shown in Figure 2 .
Note: Figure 2 is a general-purpose illustration that applies to most 4 inch (102 mm) X 5 inch (127 mm) cards.
Figure 2: Mounting onto the Power Distribution Interface (PDI)
page 4 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Card configuration
Overview
This section contains instructions on configuring the XSIG card through jumpers and DIP switches.
Setting the EOLR Jumpers (P3 & P4)
These jumpers are used to connect an end-of-line resistor to the inputs when the card is installed as the last in the line of XSIG cards. The default
position is OUT (Positions 1-2).
P3
Input 1: Position 2-3 (IN) when last in line of XSIG cards; otherwise, Position 1-2 (OUT).
P4
Input 2: Position 2-3 (IN) when last in line of XSIG cards; otherwise, Position 1-2 (OUT).
Setting the Device Address and Baud Rate (SW1)
Switch SW1 on the XSIG card is an eight-position DIP switch. From left to right, see Figure 3 below, these switches are designated as SW1-1 through
SW1-8. The function of these switches is as follows:
• SW1-1. This switch sets the baud rate for the internal 4100 communications line running between the card and the 4100 CPU. Set this switch
to ON.
• SW1-2 through SW1-8. These switches set the card's address within the 4100 FACP. Refer to Figure 4 for a complete list of the switch settings
for all of the possible card addresses.
Note: You must set these switches to the value assigned to the card by the Programmer.
Figure 3: DIP Switch SW1
page 5 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

XSIG Card Addresses
Figure 4: XSIG Card Addresses
page 6 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Wiring
Overview
This section describes wiring for the XSIG card. Audio NAC, DC NAC, Amplifier (Constant and Non-Constant Supervision), and Power Supply Wiring are
included.
Wiring guidelines
Make sure these prerequisites are accounted for before installing the cards:
• Conductors must test free of all grounds.
• All wires must be between 18 AWG (0.8231 mm2) and 12 AWG (3.309 mm2), or as the local code dictates.
• T tapping is not permitted for any field wiring.
Note: For guidance regarding proper wiring practice for TrueAlert ES speaker appliances, refer to the Speaker Wiring Application Guidelines in the ES-
PS IDNAC card Installation Instructions, 579-1289.
Audio NAC wiring without constant supervision
Provide Audio NAC wiring without constant supervision as shown in Figure 5.
See note 1
See note 1
See note 2
See note 3 See note 3
See note 4
Figure 5: Audio NAC Wiring without constant supervision
Note:
1. 4081-9008
2. 4100-1266
3. 4100-5116
4. 4100-1267
Note:
• Leave the 10 K, 1/2 W resistors (378-030 – brown/black/orange) on the B+ and B- terminals of unused circuits.
• All wiring is between 18 AWG (0.8231 mm2) (minimum) and 12 AWG (3.309 mm2) (maximum).
• Field wiring is power-limited.
• Maximum speaker load per NAC is 50 W. Maximum current per NAC is 1.5 A. Maximum number of speakers per NAC is 100.
• Shields, when required, are normally connected to 0 V as shown. Alternate shield termination using earth ground is provided on amplifier
chassis.
• Signal wiring must test free of all grounds.
page 7 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Audio NAC wiring with constant supervision
Provide Audio NAC wiring with constant supervision as shown in Figure 6.
Figure 6: Audio NAC wiring with constant supervision
Note:
1. Leave the 10 K, 1/2 W resistors (378-030 – brown/black/orange) on the B+ and B- terminals of unused circuits.
2. For 25 V Systems, use 4081-9008 EOL Harness 10K 1/2W. For 70 V System, use 4081-9018 EOL Harness 10K 1W.
3. 4100-1268 XSIG Constant Supervision NAC Adapter Card.
4. 4100-5116 XSIG Card.
Note:
• Leave the 10 K, 1/2 W resistors (378-030 – brown/black/orange) on the B+ and B- terminals of unused circuits.
• Remove the 10 K resistors from the B+ and B- terminals on the XSIG card.
• All wiring is between 18 AWG (0.8231 mm2) (minimum) and 12 AWG (3.309 mm2) (maximum).
• Field wiring is power-limited.
• Maximum speaker load for each NAC is 50 W. Maximum current per NAC is 1.4 A. The maximum number of speakers per NAC is 100.
• Shields, when required, are normally connected to 0 V as shown. Alternate shield termination using earth ground is provided on amplifier
chassis.
• Signal wiring must test free of all grounds.
page 8 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

DC NAC wiring
Provide CD NAC wiring as shown in Figure 7.
Figure 7: DC NAC wiring
Note:
1. Leave the 10 K, 1/2 W resistors (378-030 – brown/black/orange) on the B+ and B- terminals of unused circuits.
2. 4081-9008
3. 4100-1266
4. 4100-5116
5. 4100-1267
Note:
• Leave the 10 K, 1/2 W resistors (378-030 – brown/black/orange) on the B+ and B- terminals of unused circuits.
• All wiring is between 18 AWG (0.8231 mm²) (minimum) and 12 AWG (3.309 mm²) (maximum).
• Field wiring is power-limited.
• Maximum current is 1.5 A for each NAC. Total NAC capacity is 3 A as limited by the source NAC rating.
• Signal wiring must test free of all grounds.
page 9 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Wiring to amplifiers without constant supervision
Provide wiring to an amplifier without constant supervision as shown in Figure 8.
Figure 8: Wiring to an amplifier without constant supervision
* 4100-5116
Note:
1. Up to five XSIG cards are allowed on each power supply. These can be distributed among NACs or all five can be connected to one NAC.
2. XSIG cards must be in the same unit as the source NACs.
3. The last XSIG card in the chain requires EOLR Jumpers P3 & P4 to be installed in the IN position (2-3); otherwise, jumpers are installed in the
OUT position.
4. The source NAC is wired in a Class B configuration even when the source NAC is configured as Class A.
5. The minimum wire gauge is 18 AWG (0.8231 mm²).
page 10 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Wiring to amplifiers with constant supervision NACs
Provide wiring to an amplifier with constant supervision NACs as shown in Figure 9.
Figure 9: Wiring to an amplifier with constant supervision NACs
* 4100-5116
Note:
1. Up to five XSIG cards are allowed on each power supply. These can be distributed among NACs or all five can be connected to one NAC.
2. XSIG cards must be in the same location as the source NACs.
3. The last XSIG card in the chain requires EOLR Jumpers P3 & P4 to be installed in the IN position (2-3); otherwise, jumpers are installed in the
OUT position.
4. The source NAC is dedicated to providing a signal to the XSIG card and is wired in a Class B configuration.
5. The minimum wire gauge is 18 AWG (0.8231 mm²).
6. Remove the 10k, 1/2 W EOL resistors from the amplifiers and XSIG Cards that accept the Constant Supervision NAC modules.
page 11 579-516 Rev. J
Expansion Signal (XSIG) Card Installation Instructions

Wiring to Power Supply NACs
Provide wiring to power supply-mounted DC NACs as shown in Figure 10.
Figure 10: Wiring to Power Supply NACs
* 4100-5116
Note:
1. Up to five XSIG cards are allowed on each power supply. These can be distributed among NACs or all five can be connected to one NAC.
2. XSIG cards must be in the same location as the source NAC.
3. The source NAC does not supervise for shorts during standby; short circuit supervision is provided by the XSIG NACs.
4. The EOLR Jumper P3 is installed in the IN position (2-3) for the last card in the chain.
5. The power supply source NAC is always wired in a Class B configuration even when the NAC is configured as Class A.
6. All wiring is between 18 AWG (0.8231 mm2) (minimum) and 12 AWG (3.309 mm2) (maximum).
Troubleshooting
Overview
This section describes possible causes of trouble messages that can appear on the FACP display. Trouble messages appear on the left as titles, and
possible causes are listed to the right in the text.
Card Missing/Failed Trouble
Trouble message appears when the XSIG card loses communications with the panel master.
Wrong Card Trouble
Trouble message appears when the XSIG card does not match the card type configured by the Programmer.
Short/Open Circuit Trouble
Open Circuit Troubles apply to opens on all wiring.
Short Circuit Troubles apply to shorts on all wiring.
579-516 Rev. J
© 2020 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice. Additional listings may be applicable, contact your local Simplex®
product supplier for the latest status. Listings and approvals under Simplex Time Recorder Co. Simplex, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. NFPA 72 and
National Fire Alarm Code are registered trademarks of the National Fire Protection Association (NFPA).
