Simplex Aval PKW1100 User manual

Aval PKW1100 PROM Burner
User’s Guide


2001 Simplex Time Recorder Co., Westminster, MA 01441 USA
All specifications and other information shown were current as of publication, and are subject to change without notice.
579-317
Rev. A
The 4100 Programmer software does not support the Aval PKW1100 PROM Burner. This
publication will show you how to manually download software to the PROM burner and then
show you how to burn the PROMs.
• 4100 Programming Unit with appropriate software.
• Available communications port configured as COM1.
• RS-232 Null Modem Cable.
• Aval PWK1100 PROM Burner.
This publication discusses the following topics:
Topic See Page #
Introduction 1
Setup 1
Download 4
At the C:\> prompt, type mode com1: 9600,n,8,1 to set up the correct communications
parameters for COM1.
Connect one end of the download cable to COM1 on the 4100 Programming Unit and connect the
other end to the RS-232 port of the PROM burner.
Follows Steps 1 through 9 to verify the setup on the PROM burner. Figures 1 through 9 represent
screens displayed on the PROM burner’s LCD.
NOTE: Actual screen information may differ from illustrations.
1. Turn the PROM burner ON.
• Unit beeps and Figure 1 appears.
Figure 1
Introduction
Overview
Requirements
In this Publication
Setup
COM Port
PROM Burner
A11
AUTO AUTO
Command >
Menu: [9] - [F]
