Simpli Home AXCBAN-07 User manual

Banting / Devlin / Argyle
Mid Century Low TV Stand
Model # AXCBAN-07
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH)
in our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to
protect against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly
·Dust with soft dry cloth
·Wipe up spills promptly
·Clean with a dry cloth
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish
·Use soft felt base coasters, placemats to help prevent scratches
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer
·If it can be avoided, do not put furniture near heating vents
·Keep the furniture 3 to 4 inches away from the wall, giving heat and air space to
circulate.
Care & Maintenance
6

WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves
or place heavy items on top shelves or drawers.
Improper use of furniture to support TVs may result in serious injury or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip
over onto a child and cause physical injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of
fire and electric shock that is associated with the use of electrical components
such as operation, user-maintenance, loading, storage and as applicable
electrical issues including grounding or double-insulation.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to
68.58 cm). For use with televisions weighing 220 lbs or less. Using larger or heavier
televisions may cause instability or tip over which can lead to serious injury or even
death.
The recommended maximum width of the television intended for use is 66 inch
(167.64 cm).
MAXIMUM LOAD 220 LBS MAXIMUM LOAD 25 LBS
7

.A
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
TOP DIVIDER
QTY 1
.C
TOP SHELF
QTY 1
.D.E
BOTTOM DIVIDER
QTY 3
TOP BACK PANEL
QTY 1
.F
BOTTOM SHELF
QTY 1
.G
BOTTOM BACK PANEL
QTY 1
.BL .BR
.H
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front / Avant
Front /
Avant
Warning Label
Front /
Avant
Part Description
8
Model # AXCBAN-07Pre-Assembly Information

DRAWER FRONT
QTY 4 RIGHT DRAWER SIDE
QTY 4
LEFT DRAWER SIDE
QTY 4
DRAWER BACK
QTY 4 DRAWER BOTTOM
QTY 4
.I
.K.L.M
.N.O
.JL .JR
LEG (L&R Same)
QTY 2
LEG UPPER CONNECTOR
QTY 2 LEG LOWER CONNECTOR
QTY 1
Up Side / Vertical
UpSide/Vertical
Up Side / Vertical
UpSide/Vertical
Part Description
9
Model # AXCBAN-07Pre-Assembly Information

FURNITURE TIP OVER
RESTRAINT
QTY 1 SET
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1 Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
.1
WOOD DOWEL
Ø8 X 30mm
QTY 28
ALLEN KEY
QTY 1
CAM LOCK PIN
CAM LOCK
QTY 28 SETS
ALLEN KEY SCREW
M6 X 30mm
QTY 34
.2.3.4
.5.6.7.8
.9.10
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 28
ALLEN KEY BOLT
M6 x 30 mm
QTY 12
ALLEN KEY BOLT
M6 x 15 mm
QTY 10
LOCK WASHER
Ø10 / Ø6.5 x 1.5 mm
QTY 10
WASHER
Ø16 / Ø6.5 x 1.5 mm
QTY 14
Hardware Description
10
Model # AXCBAN-07Pre-Assembly Information

A
BL EE
F
G
H
I
K
L
JR
JL
M
M
O
N
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
C
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Up Side / Vertical
D
E
BR
11
Model # AXCBAN-07Components - Key Diagram

Step 1
P
X
1. Attach four Cam Lock Pins 3 into pre-drilled holes at back of Drawer Front I .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
Step 2
1. Align Cam Lock Pins with guide holes and attach Drawer Sides JL , JR to Drawer Front I .
2. Insert two Cam Locks 3 into guide holes on each Drawer Side JL , JR .
3. Use Phillips screwdriver to secure Cam Locks. Do not over-tighten.
I
3
3
3
3
3
3
I
I
I
JR
JL
JR
JR
JL
JL
12
Model # AXCBAN-07Assembly

Step 3
1. Slide Drawer Bottom L firmly into slots on Drawer Sides JL , JR and Drawer Front I .
Step 4
1. Align Drawer Back K with Drawer Bottom L and press firmly into slot .
2. Attach Drawer Back using two Allen Key Screws 4 through drilled holes on
each Drawer Side JL , JR .
3. Use Allen Key 2 to tighten Screws. Do not over-tighten.
K
L
I
JR I
II
JR
JR JR
JL JL
JL JL
L
K
4
2
L
L
13
Model # AXCBAN-07Assembly

Step 5
Step 6
C
1
1. Insert four Wood Dowels 1 into guide holes on Top Divider C .
2. Use rubber mallet to tap Dowels 1 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
P
X
Front / Avant
D
3
1
1. Insert four Dowels 1 into guide holes on Top Shelf D .
2. Use rubber mallet to tap Dowels 1 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach nine Cam Lock Pins 3 into pre-drilled holes at back of Top Shelf D .
4. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten. 14
Model # AXCBAN-07Assembly

Step 7
CD
Front / Avant
4
2
4
Step 8
1. Align Wood Dowels with guide holes on Top Shelf D and Divider C to Top Shelf D .
2. Use three Allen Key Screws 4 to attach Top Shelf D through guide holes from
Top Shelf D to pre-drilled holes of Top Divider C .
3. Use Allen Key 2 to tighten Screws. Do not over-tighten.
E
Front /
Avant
1
1. Insert four Wood Dowels 1 into guide holes on Bottom Dividers E .
2. Use rubber mallet to tap Dowels 1 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
15
Model # AXCBAN-07Assembly

Step 9
D
C
E
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
D
E
Front / Avant
1. Align Wood Dowels with guide holes on Top Shelf D ; align Cam Lock Pins
with guide holes on each Bottom Divider E and attach Dividers E Top Shelf D .
3
2. Insert three Cam Locks 3 into drilled holes on each Bottom Divider E .
Use Phillips screwdriver to secure Cam Locks.
16
Model # AXCBAN-07Assembly

Step 10
Front / Avant
BR
Front /
Avant
BL
1
11
1
1. Insert four Wood Dowels 1 into guide holes on each Side BL , BR .
2. Use rubber mallet to tap Dowels 1 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
Step 11
Front / Avant
Front / Avant
D
BR
BL
4
4
4
1. Align Wood Dowels with guide holes on Sides BL , BR.
2. Use three Allen Key Screws 3 to attach Top Shelf D through guide holes from
Top Shelf D to pre-drilled holes of each Side BL , BR .
3. Use Allen Key 2 to tighten Screws. Do not over-tighten.
2
17
Model # AXCBAN-07Assembly

Step 12
F
BR
E
BL
E
E
1. Align Wood Dowels with guide holes on Bottom Shelf F
attach Dividers E , Sides BL , BR to Bottom Shelf F .
Front / Avant
Front / Avant
Front / Avant
F
BL
BR
E
Front / Avant
5
2
2. Use six Allen Key Bolts 5 to attach Sides BL , BR through guide holes
from Bottom Shelf F to Sides BL , BR .
3. Use three Allen Key Screws 4 to attach each Divider G through guide holes
from Cabinet Shelf F to pre-drilled holes of each Divider G .
4. Use Allen Key 2 to tighten Screws and Bolts. Do not over-tighten.
4
2
18
Model # AXCBAN-07Assembly

Step 13
P
X
3
3
A
Front /
Avant
1. Attach three Cam Lock Pins 3 into pre-drilled holes at back of Top A .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
19
Model # AXCBAN-07Assembly

Step 14
A
BR
BL C
Front / Avant
Front /
Avant
1. Align Wood Dowels with guide holes on Top A ; align Cam Lock Pins with guide
holes on Top Divider C and attach Top A .
2. Insert three Cam Locks 3 into drilled holes on Top Divider C .
Use Phillips screwdriver secure Cam Locks.
3. Use three Allen Bolts 5 to attach Sides BL , BR through guide holes to Top A .
4. Use Allen Key 2 to tighten Bolts. Do not over-tighten.
A
C
BL
BR
Front /
Avant
5
2
3
20
Model # AXCBAN-07Assembly
