Simpli Home Bedford User manual

BEDFORD / FREEMONT / HAMPTON
LOW STORAGE MEDIA CABINET
MODEL # 3AXCBED-03
1/16
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

2/16
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following information ready:
Model # _______________________ Part Number or Letter_______________________
Purchased at ___________________Date of Purchase ___________________________
If you wish to return the product, please contact the retailer where the
product was purchased.
All manuals and user guides at all-guidesbox.com

3/16
All manuals and user guides at all-guidesbox.com

4/16
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
All manuals and user guides at all-guidesbox.com

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # 3AXCBED-03
PARTS DESCRIPTION
5/16
A
TOP
QTY 1
LEFT SIDE
QTY 1
BL
RIGHT SIDE
QTY 1
BR
CABINET SHELF
QTY 2
C D
BOTTOM SHELF
QTY 1
CENTRE SUPPORT
QTY 1
E
DOOR (L&R Same)
QTY 2
F
LEFT BACK PANEL
QTY 1
GL
RIGHT BACK PANEL
QTY 1
GR
F
r
o
n
t
/ Avant
Fro
nt /
A
v
a
n
t
Front
/ Avant
F
r
o
nt
/ Ava
n
t
Warning Label
All manuals and user guides at all-guidesbox.com

1
PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
23
4 5
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6
7
10
8
11
9
MODEL # 3AXCBED-03
ALLEN KEY SCREW
M6 X 30 mm
QTY 6
PHILLIPS SCREW
M3 X 12 mm
QTY 12
HANDLE
M4 X 25 mm
QTY 2 SETS
WOOD DOWEL
Ø8 X 30 mm
QTY 4
CAM LOCK PIN
CAM LOCK
QTY 6 SETS
PHILLIPS SCREW
M3 X 15 mm
QTY 8
MAGNET AND PLATE
QTY 2 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 15
SHELF SUPPORT
QTY 12
6/16
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25 - QTY 2
( )1 is extra
b. M4 X 15 - QTY 1
c. M4 X 25 - QTY 1
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

COMPONENTS – KEY DIAGRAM MODEL # 3AXCBED-03
7/16
A
F
F
D
BL
BR
C
C
E
GR
GL
Front
/ Avant
Front
/
Avant
Front / Avant
Front
/
Avant
All manuals and user guides at all-guidesbox.com

ASSEMBLY
STEP 1
MODEL # 3AXCBED-03
1. Insert 4 Dowels 10 into guide holes on Bottom Shelf D .
2. Use rubber mallet to tap Dowels 10 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach Cam Lock Pins 2 into pre-drilled holes on the Sides BL , BR .
4. Align and insert Cam Lock Pins 2 into guide holes on Bottom Shelf D .
5. Insert Cam Locks 2 into guide holes on Bottom Shelf D .
6. Once in place tighten Cam Locks 2 using a Phillips screwdriver.
NOTE: The screwdriver is not
included in the hardware pack.
8/16
Front
/ Avant
Front
/ Avant
Front /
Avant
D
BR
BL
10
2
All manuals and user guides at all-guidesbox.com

ASSEMBLY
STEP 2
MODEL # 3AXCBED-03
1. Attach Centre Support E to Bottom Shelf D using Allen Key Screws 1 through
guide holes.
2. Use Allen Key 3 to tighten. Do not over-tighten.
E
D
3
1
9/16
Front / Avant
Front
/
Avant
Front
/
Avant
Front /
Avant
All manuals and user guides at all-guidesbox.com

ASSEMBLY
STEP 3
MODEL # 3AXCBED-03
1. Attach Cam Lock Pins 2 into pre-drilled at the bottom of Top A .
2. Align pre-drilled holes on bottom of Top A with guide holes on Sides BL , BR
and align and insert Cam Lock Pins 2 into guide holes in Centre Support E .
3. Attach Top A with Sides BL , BR using Allen Key Screws 1 use Allen Key 3 to
tighten Screws. Do not over-tighten.
4. Attach Top A with Centre Support E using Cam Locks 2 .
10/16
2
3
1
D
Front
/
Avant
Front
/ Avant
Front
/ Avant
Front
/
Avant
A
E
BL
BR
All manuals and user guides at all-guidesbox.com

ASSEMBLY
MODEL # 3AXCBED-03
11/16
1. Attach Back Panels GL , GR to back of cabinet using Phillips Screws Round Head 6
through guide holes
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
STEP 4
NOTE:
The triangle ruler
is not included in
the hardware pack.
Adjust the cabinet frame before assembling the back panels.
STEP 5
Triangle ruler
90°
90°
90°
90°
Fro
nt
/
A
v
ant
A
GL
GR
Warning Label
6
Front / Avant
90°
90°
90°
90°
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

ASSEMBLY
STEP 5
MODEL # 3AXCBED-03
12/16
First Step
4
Last Step ( after adjust the door )
4
4
1. Attach hinges on Doors F to Sides BL , BR using Phillips Screws 4 into pre-drill holes:
- Using Phillips screwdriver to attach Screws 4 at middle hole of hinges for both top &
bottom hinges.
- Adjust the door to ensure they are aligned straight & square with bottom shelf & side.
- Using Phillips screwdriver to tighten the rest of screws 4 into pre-drill holes ( top & bottom
holes on hinges).
2. Attach Magnet Plates 8 to bottom corner of Doors F using Phillips Screws 5 into
pre-drilled holes on Doors F .
3. Attach Magnets 8 using Phillips Screws 5 into pre-drilled holes on Bottom Shelf D .
4. Use Phillips screwdriver to attach Handles 7 to Doors F through guide holes.
F
F
E
D
BR
BL
Front
/
Avant
Front /
Avant
Front
/
Avant
7
5
8
8
All manuals and user guides at all-guidesbox.com

ASSEMBLY
STEP 6
MODEL # 3AXCBED-03
13/16
1. Attach 4 Shelf Supports 9 for each Shelf C in desired location.
2. 2 Shelf Supports 9 may be used on back top of each Shelf C as a tipping restraint.
shelf level 1
shelf level 2
shelf level 3
shelf support
anti - tipping
9
C
C
9
C
C
All manuals and user guides at all-guidesbox.com

STEP 7
14/16
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
FURNITURE TIP OVER RESTRAINT ASSEMBLY
11
11
All manuals and user guides at all-guidesbox.com

15/16
1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
“locked” position.
7. Check to make sure the strap is securely laced and locked to the
brackets.
● DO NOT put a TV or other heavy objects on top of a Low Storage
Cabinet or any other furniture not intended for use with a TV
● DO NOT place heavy objects in top drawers
● DO NOT let children climb or hang on drawers, doors or shelves
Furniture Tip Over Restraint Instructions:
x
x
FURNITURE TIP OVER RESTRAINT ASSEMBLY
All manuals and user guides at all-guidesbox.com

16/16
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
customerser[email protected]om.
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
All manuals and user guides at all-guidesbox.com
all-guidesbox.com
