Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH)
in our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to
protect against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly
·Dust with soft dry cloth
·Wipe up spills promptly
·Clean with a dry cloth
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish
·Use soft felt base coasters, placemats to help prevent scratches
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer
·If it can be avoided, do not put furniture near heating vents
·Keep the furniture 3 to 4 inches away from the wall, giving heat and air space to
circulate.
Care & Maintenance
6

.A
TOP
QTY 1
.BL .BR .C
.D.E.F
RIGHT LEG
QTY 1
LEFT LEG
QTY 1
LEG BACK CONNECTOR
QTY 1
LEG FRONT CONNECTOR
QTY 1 LEG LOWER CONNECTOR
QTY 1 LEG SUPPORTER QTY 2
Front /
Avant
Up Side / Vertical
Up Side / Vertical
Up Side / Vertical
Front /
Avant
Front /
Avant
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Part Description
7
Model # AXCBAN-09Pre-Assembly Information

.1.2
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
ALLEN KEY BOLT
M6 x 15 mm
QTY 20
LOCK WASHER
Ø10 / Ø6.5 x 1.5 mm
QTY 20
WASHER
Ø16 / Ø6.5 x 1.5 mm
QTY 24
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 4
ALLEN KEY
QTY 1
.3.4
.5
Hardware Description
8
Model # AXCBAN-09Pre-Assembly Information

Front /
Avant
Up Side / Vertical
A
C
DBR
BL
F
F
E
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
9
Model # AXCBAN-09Components - Key Diagram

Step 1
1. Align Parts C , D and E to Right Leg BR .
2. Use one Bolt 1 , one Lock Washer 2
and one Washer 3 to secure each part
C , D , E with BR .
3. Use Allen Key 5 to tighten Bolts.
Do not over-tighten.
E
D
C
BR
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
Front / Avant
Up Side / Vertical
5
1
2
3
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
5123
10
Model # AXCBAN-09Assembly

Step 2
1. Repeat Step 1 for Left Leg BL .
BL
BR
D
C
E
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
Front / Avant
Up Side / Vertical
3215
BR
D
C
E
BL
3215
11
Model # AXCBAN-09Assembly

Step 3
Step 4
1. Align Leg Supporters F to Legs BL , BR .
1. Use Allen Key 5 to tighten Bolts.
2. Use four Bolts 1 , four Lock Washers 2 and four Washers 3 to secure each part
F with BL , BR .
3. Use Allen Key 5 to tighten Bolts.
BL
BL
BL
BR
BR
BR
D
D
D
C
C
C
E
E
E
F
F
3
2
1
5
F
F
5
12
Model # AXCBAN-09Assembly

Step 5
5
1
2
3
1. Attach the assembled metal frame to Top A .
2. Use six Bolts 1 , six Lock Washers 2
and six Washers 3 to secure metal frame
and Top A .
3. Use Allen Key 5 to tighten Bolts.
4. Use four Phillips Screws Round Head 4 and four
Washers 3 to secure Top A and metal frame.
5. Use Phillips screwdriver to snugly tighten Screws.
4
3
F
A
A
A
13
Model # AXCBAN-09Assembly

Step 6
Note: Levelers on bottom of legs can be adjusted if floor is uneven.
14
Model # AXCBAN-09Assembly

Step 7
1. YOU MUST press the lock on the right of the flip down keyboard tray before opening.
15
