Simplicity 1695299 Setup guide

Attachment
Illustrated
Parts List
Rev. 04/2007
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2007 TP 400-4530-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1695299 54" Turbo Blower
1734809
Part No.:

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
Mower Driven Vac Group ..................................................................................................................................... 4

Mower Driven Vac Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
987705
The above parts group applies to the following Mfg. Nos.:
4
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695299 - 54" Turbo Blower
TP 400-4530-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Mower Driven Vac Group
Footnotes
TURBO HOUSING, Fan1 1720742SM 1
RETAINER, Bearing2 1665982SM 4
BEARING3 2108202SM 2
"S" HOOK4 1672689SM 1
BOLT, Carriage, 5/16 - 18 x 3/4 (Qty of 2 included in Ref. No. 69)5 1931333SM 5
CAPSCREW, 5/16 - 18 x 3/46 1921332SM 3
PUSH NUT, 5/167 1933988SM 4
NUT, Flange Lock, 5/16 - 18 (Qty of 2 included in Ref. No. 69)8 1927557SM 8
FAN ASSEMBLY9 1706631ASM 1
PULLEY ASSEMBLY10 1706634SM 1
KEY, Woodruff, #6111 2860403SM 1
SCREW, Set Torx, 5/16 - 18 x 5/1612 1960619SM 2
V-BELT, 3L 36.913 1720932SM 1
DECAL, Patent (Not shown, not serviceable)14 ----- 1
IDLER ARM ASSEMBLY15 1720934ASM 1
BELT STOP16 1704419SM 1
BUSHING17 1666114SM 1
CAPSCREW, 3/8 - 16 x 218 1923701SM 1
WASHER, 3/819 1924940SM 4
WASHER, 3/820 1922755SM 1
LOCKWASHER, Spring, 3/821 1916965SM 1
NUT, Hex, 3/8 - 1622 1916950SM 1
PULLEY, Idler23 2174561SM 1
CAPSCREW, Hex Head, 3/8 - 16 x 1-1/2, G524 1921969SM 1
SPRING, Extension25 2174896SM 1
SCREW, Truss Head Phillips, 1/4 - 20 x 3/426 1935945SM 6
CAPSCREW, Hex Head, 1/4 - 20 x 1-1/4, G527 1921961SM 1
WASHER, 1/428 1921319SM 1
NUT, Hex Lock ESNA, 1/4 - 2029 1920397SM 8
PLATE ASSEMBLY30 1720721ASM 1
PIN, Pivot (Included in Ref. No. 69)31 1720718SM 2
LOCKWASHER, Spring, 1/4 (Qty of 4 included in Ref. No. 69)32 1916964SM 6
NUT, Hex, 1/4 - 20 (Qty of 4 included in Ref. No. 69)33 1916622SM 6
CLIP, Hairpin34 1704628SM 2
PULLEY ASSEMBLY (Included in Ref. No. 69)35 1720737SM 1
CAPSCREW, Hex Head, 7/16 - 14 x 2-1/4, G8 (Included in Ref. No. 69)36 1927120SM 1
STRAP37 1706630ASM 1
SCREW, Hex Washer Head Taptite, 1/4 - 20 x 5/838 1927429SM 3
COVER, Arbor R.H. Turbo39 1734303ASM 1
ROD & ANCHOR40 1720951SM 1
SCREW, Truss Head Phillips, #10 - 24 x 3/4 (Included in Ref. No. 69)41 1960404SM 4
NUT, Nylon Hex Lock, 10-24 (Included in Ref. No. 69)42 1933896SM 4
PLATE, Support43 1720749ASM 1
SPRING, Extension (Included in Ref. No. 69)44 1719590SM 1
The above parts group applies to the following Mfg. Nos.:
5
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695299 - 54" Turbo Blower
TP 400-4530-00-AT-SMA

Mower Driven Vac Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
987705
The above parts group applies to the following Mfg. Nos.:
6
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695299 - 54" Turbo Blower
TP 400-4530-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
Mower Driven Vac Group
Footnotes
TAB, Locking (Included in Ref. No. 69)48 1720921SM 3
CAPSCREW, Hex Head, 1/4 - 20 x 5/8 (Qty of 2 included in Ref. No. 69)49 1921959SM 4
COVER50 1720918ASM 1
SPACER51 1713588SM 1
CAPSCREW, Hex Head, 5/16 - 18 x 2-1/2, G552 1921719SM 1
NUT, Hex Lock ESNA, 5/16 - 1853 1919438SM 1
LOCKWASHER, Spring, 5/16 (Qty of 6 included in Ref. No. 69)54 1917356SM 7
NUT, Hex, 5/16 - 18 (Qty of 6 included in Ref. No. 69)55 1917372SM 7
BRACKET, "C"56 1700654ASM 1
NUT, Speed, 5/16 - 1857 1935255SM 1
KNOB, Plastic58 1700669SM 1
BOLT, Carriage, 1/4 - 20 x 1-1/4 (Included in Ref. No. 69)59 1931320SM 1
NUT, Hex Two-Way Lock Flange, 3/8 - 1660 1930645SM 1
SCREW, Hex Washer Head Taptite, 1/4 - 20 x 3/8 (Included in Ref. No. 69)61 1929000SM 2
BRACKET, "L"62 1668500SM 1
SPRING, Extension63 1727149SM 1
BAFFLE, Front L.H.64 1720613ASM 1
BAFFLE, Front R.H.65 1721023ASM 1
DECAL, Danger Thrown Objects66 1700259SM 1
BOLT, Carriage, 5/16 - 18 x 3/4 (Included in Ref. No. 69)68 1931332SM 6
HARDWARE BAG69 1660617SM 1
INSTRUCTION MANUAL (Not shown)70 1720927 1
The above parts group applies to the following Mfg. Nos.:
7
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1695299 - 54" Turbo Blower
TP 400-4530-00-AT-SMA
