Simplicity 1700 Series User manual

Parts Manual
Rev. B
Conquest / 1700 / 2700
Series Yard Tractors & Mower Decks RMO
Mf
g
. No. Descri
p
tion
20HP Product
1694746 Conquest, 20HP Hydro RMO
1694747 1720H, 20HP Hydro RMO
1694752 2720H, 20HP Hydro RMO
Mf
g
. No. Descri
p
tion
22HP Product
1694624 Conquest, 22HP Hydro RMO
1694625 Conquest, 22HP Hydro RMO (CE/Export)
1694626 1722H, 22HP Hydro RMO
1694628 2722H, 22HP Hydro RMO
2690264 Conquest, 22HP Hydro RMO and 54" Mower Deck
2690272 2722H, 22HP Hydro RMO and 54" Mower Deck
Mf
g
. No. Descri
p
tion
23HP Product
1694816 Conquest, 23HP Hydro RMO (CE/Export)
1694818 1723H, 23HP Hydro RMO
1694819 Conquest, 23HP Hydro RMO
1694820 2723H, 23HP Hydro RMO
2690414 Conquest, 23HP Hydro RMO and 54" Mower Deck
2690415 Conquest, 23HP Hydro RMO and 50" Mower Deck
2690417 2723H, 23HP Hydro RMO and 54" Mower Deck
2690702 Conquest, 23HP Hydro RMO and 50" Mower Deck
(CE/Export)
Mf
g
. No. Descri
p
tion
Mower Decks
1694038 44" Mower Deck
1694044 44" Mower Deck
1694173 44" Mower Deck (CE/Export)
1694039 50" Mower Deck
1694045 50" Mower Deck
1694174 50" Mower Deck (CE/Export)
1694366 54" Mower Deck
1694367 54" Mower Deck
TP 400-4204-B-CQ-SMA
17
3
1172
Not for
Reproduction

Not for
Reproduction

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
Frame Group - Manual Steering .......................................................................................................................... 4
Steering Group - Manual Steering ....................................................................................................................... 8
Engine & Electric Clutch Group - 20HP Briggs & Stratton .................................................................................. 10
Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin ........................................................... 12
Transmission Group ............................................................................................................................................. 14
Transmission SERVICE PARTS - Tuff Torq K-66L ............................................................................................. 18
Controls Group ..................................................................................................................................................... 24
Cruise Control Group ........................................................................................................................................... 28
Electrical Group .................................................................................................................................................... 30
Hood, Grille & Dash Group .................................................................................................................................. 34
Seat & Seat Deck Group ...................................................................................................................................... 36
Lift Group - Manual Lift ......................................................................................................................................... 38
Wheels & Tires Group .......................................................................................................................................... 40
Decals Group - Brand & Model ............................................................................................................................ 42
Decals Group - Safety & Common ...................................................................................................................... 44
44" Mower Deck - Belt, Idler Arm & Hitch ............................................................................................................ 46
44" Mower Deck - Height Adjustment & Roller Bar ............................................................................................. 48
44" Mower Deck - Housing, Arbors & Blades ...................................................................................................... 52
50" Mower Deck - Clutch & Support .................................................................................................................... 56
50" Mower Deck - Height Adjustment & Roller Bar ............................................................................................. 58
50" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 62
54" Mower Deck - Drive Group ............................................................................................................................ 66
54" Mower Deck - Height Adjustment & Roller Bar Group .................................................................................. 68
54" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 72
Not for
Reproduction

Frame Group - Manual Steering
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986747
The above parts group applies to the following Mfg. Nos.:
4
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Frame Group - Manual Steering
Footnotes
TOWER & SUPPORT ASSEMBLY1 1733139ASM 1
CAPSCREW, Hex Washer Head Taptite, 3/8-16 x 3/42 1923683SM 4
CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/43 1960541SM 4
SUPPORT, Seat Deck4 1723528ASM 1
NUT, Hex Flange 3/8-16 Whiz Lock, Large5 1928352SM 2
NUT, Hex Flange Two-Way Lock, 1/2-136 1930644SM 2
BACKPLATE7 1722602ASM 1
CAPSCREW, Hex Head 1/2-13 x 1, Black8 1923114SM 2
CAPSCREW, Hex Head 3/8-16 x 1, Black9 1921210SM 2
FRAME ASSEMBLY, Front & Rear10 1726989ASM 1
NUT, Hex Flange Two-Way Lock, 3/8-1611 1930645SM 7
WASHER, 3/8, Black12 1922755SM 1
WASHER, 3/8, Black13 1960103SM 2
LINK, Drag14 1722541SM 1
NUT, Hex Jam 1/2-2015 1919262SM 1
JOINT, Ball16 1702779SM 1
SPACER, 3/8 x 1/2 x 5/817 1708236SM 1
CARRIAGE BOLT, 3/8-16 x 118 1931350SM 2
ROD, Tie19 1722626ASM 1
AXLE ASSEMBLY w/LH Spindle (Includes Ref. Nos. 22, 24, 41, 42 & 43)20 1722200ASM 1
SPACER, 25/64 x 5/8 x 5/16, Powder Metal21 1611705SM 2
BUSHING, 31/32 x 1-1/4 x 3/4, Powder Metal22 1721682SM 6
NUT, Hex Flange Two-Way Lock, 7/16-1423 1930650SM 2
FITTING, Lube24 2821133SM 3
SPINDLE REPLACEMENT KIT, LH (Includes Ref. Nos. 22, 26, 27, 28, 29 & 30)25 1686985SM 1
CAPSCREW, 3/8-16 x 7/8, GR826 2823485SM 1
WASHER, Spring, 3/827 1663151SM 1
HUB & ARM ASSEMBLY28 1725112SM 1
KEY, Woodruff29 2830671SM 1
SPINDLE, LH30 1724264SM 1
CARRIAGE BOLT, 3/8-16 x 1-1/231 1931352SM 1
SPACER, 11/16 x 21/32 x 2 3/3232 1721752SM 1
CAPSCREW, Hex Head, 7/16-14 x 2 G833 1927531SM 2
HOOK, "J"34 1721918ASM 1
BUMPER, Black35 1721805ASM 1
BUMPER, Chrome35 1723502SM 1
SCREW, Truss Head Torque Drive, 5/16-18 x 7/836 1960086SM 4
CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/437 1930591SM 2
PLATE, Axle Wear38 1724801ASM 1
NUT, Hex Flange Whix Lick, 5/16-1839 1931277SM 2
The above parts group applies to the following Mfg. Nos.:
5
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Frame Group - Manual Steering
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986747
The above parts group applies to the following Mfg. Nos.:
6
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Frame Group - Manual Steering
Footnotes
SPINDLE, RH40 1722199SM 1
WASHER41 1919394SM 1
RETAINING RING42 2832577SM 1
CAPSCREW, Hex Flange Whiz Lock, 3/8-16 x 3/443 1933260SM 4
FITTING, Grease for Wear Plate44 2821133SM 2
WASHER, 5/845 1960035SM 2
CAPSCREW, Hex Head, 5/8-11 x 3-1/246 2860645SM 1
NUT, Hex Flange Two-Way Lock, 5/8-1147 2860646SM 1
PLATE, Axle48 1722212ASM 1
The above parts group applies to the following Mfg. Nos.:
7
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Steering Group - Manual Steering
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
985890
The above parts group applies to the following Mfg. Nos.:
8
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Steering Group - Manual Steering
Footnotes
STEERING WHEEL, Straight, Shaft1 1722318SM 1
CAP, Steering Wheel, SMI Logo2 1722319SM 1
CAP, Steering Wheel, Plain2 1725024SM 1
PIN, Spring, 5/16 x 2-1/23 1960540SM 1
COVER, Rubber, Upper Steering Shaft4 1722749SM 1
WASHER, 3/45 1960114SM 5
BUSHING, 15/32 x 7/8 x 7/8, Nylon6 2176440SM 2
NUT, Hex KEPS 5/6-187 1960636SM 2
PLATE, Mounting Steering8 1721736ASM 1
NUT, Push9 1933988SM 2
CARRIAGE BOLT, 5/16-18 x 1-1/410 1960655SM 2
GEAR & SHAFT ASSEMBLY, Steering11 1724470ASM 1
CAPSCREW, Hex Head, 3/8-16 x 1-1/4, Black12 1960032SM 1
NUT, Hex Flange Two-Way Lock, 3/8-1613 1930645SM 1
CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/414 1664847SM 2
SHAFT & PINION ASSEMBLY, Steering Manual15 1721626SM 1
RING, Clipring Extension16 1611710SM 1
BEARING, 3/4 x 1-11/16 x 13/16, 3" Long Housing17 1722459SM 1
SPACER, 3/4 x 1-1/16 x 3/8, Powder Metal18 1722461SM 1
NUT, Hex Flange Whiz Lock, 3/8-16, Small19 1931211SM 2
CAPSCREW, Hex Whiz Lock Flange, 3/8-16 x 3/4, Black20 1933260SM 2
CLIP, Hairpin21 1960033SM 1
The above parts group applies to the following Mfg. Nos.:
9
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Engine & Electric Clutch Group - 20HP Briggs & Stratton
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
985904
The above parts group applies to the following Mfg. Nos.:
10
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694625 - Conquest
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Engine & Electric Clutch Group - 20HP Briggs & Stratton
Footnotes
HOSE, Oil Drain, 10-1/2 Long, 3/8-18 Fittings1 1723165SM 1
ENGINE, 20HP Briggs & Stratton Vanguard Twin, Model # 358777, Type # 0110-E12* 1
SEAL, Circle3 1722949SM 1
BULKHEAD4 1722388ASM 1
CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1/2, Black5 1925003SM 2
CONTROL, Throttle Double, 39" Long, w/Knobs6 1727223SM 1
TIE, Wire7 1701011SM 2
CLAMP, Hose Type E8 2860112SM 2
HOSE, Fuel, 58" Long9 1718678SM 1
SHIELD, Side10 1722392ASM 2
CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 3/811 1929000SM 8
PULLEY & HUB ASSEMBLY12 1722288SM 1
TIE, Self Locking, 3-5/8 Long13 2832747SM 1
WASHER, Hex, 7/16, 1/4, Black14 1708264SM 1
LOCKWASHER, 7/1615 1918199SM 1
CAPSCREW, Hex Head, 7/16-20 x 3-1/216 1960649SM 1
CLUTCH, Electric, Ogura17 1686883SM 1
KEY, HI PRO, 1/4 x 2-1/218 1720463SM 1
CAPSCREW, Hex Washer Head Taptite 3/8-16 x 1-1/219 2830598SM 4
LOCKWASHER, External Tooth, 3/820 2820427SM 1
SHIELD, Muffler Bottom21 1722414ASM 1
NUT, Speed, 1/4-20, Lug22 1960368SM 8
CAPSCREW, Hex Flange Whiz Lock, 1/4-20 x 5/823 1960295SM 4
NUT, Speed, 1/4-20, Lug24 1935255SM 2
DUCT, Muffler Top25 1722389ASM 1
CLIP, Wire26 2834683SM 2
DUCT, Muffler Extension27 1722390ASM 1
CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 1/2, Black28 1924856SM 2
MUFFLER, Briggs & Stratton, Vanguard Twin29 1722625SM 1
GASKET, Briggs & Stratton, Vanguard Twin30 * 1
LOCKWASHER, 1/431 1916964SM 4
CAPSCREW, Hex Flange Whiz Lock, 1/4-20 x 5/832 * 4
Note* See your local Briggs & Stratton distributor for parts and service.
The above parts group applies to the following Mfg. Nos.:
11
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694625 - Conquest
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986651
The above parts group applies to the following Mfg. Nos.:
12
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694626 - 1722H
1694628 - 2722H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin
Footnotes
MUFFLER1 1736543SM 1
MUFFLER (Only used on 20HP Models)1 1722625SM 1
GASKET2* 2
LOCKWASHER, 5/163 1917356SM 4
CAPSCREW, Socket Head, 5/16-18 x 7/8, G84 2860660SM 4
HOSE, Oil Drain5 1723165SM 1
ENGINE, 22HP Briggs & Stratton VANGUARD Twin, Model 386777, Type 0111E16* 1
ENGINE, 23HP Briggs & Stratton VANGUARD Twin, Model 386777, Type 0111E16* 1
ENGINE, 21HP Briggs & Stratton VANGUARD Twin, Model 385777, Type 0119-E16* 1
ENGINE, 20HP Briggs & Stratton VANGUARD Twin, Model 358777, Type 0110-E16* 1
SEAL, Circle7 1722949SM 1
BULKHEAD8 1722388ASM 1
CAPSCREW, Hex Head Taptite, 1/4-20 x 1/29 1925003SM 2
CONTROL, Throttle Double 39" Long w/Knobs (Only used on 20HP Models)10 1727223SM 1
CONTROL, Throttle Double10 1734506SM 1
TIE11 1701011SM 1
CLAMP, Hose Type E12 2860112SM 2
HOSE, 59" Long13 1718678SM 1
CLIP, Wire14 2834683SM 2
SHIELD15 1722392ASM 2
SCREW, Hex Head Taptite, 1/4-20 x 3/816 1927428SM 8
KEY17 1720463SM 1
PULLEY & HUB ASSEMBLY, 4-1/2 OD18 1722288SM 1
WASHER, Hex19 1708264SM 1
LOCKWASHER, 7/1620 1918199SM 1
CAPSCREW, Hex Head, 7/16-20 x 2-3/421 1960648SM 1
CLUTCH, Electric, OGURA22 1686883SM 1
CLUTCH, Electric, Big Brake OGURA22 1720532SM 1
TIE23 2832747SM 1
CAPSCREW, Hex Head Taptite, 3/8-16 x 1-1/224 2830598SM 4
LOCKWASHER, External Tooth, 3/825 2820427SM 1
SHIELD, Muffler Bottom26 1722414ASM 1
CAPSCREW, Hex Head Flange Lock, 1/4-20 x 5/827 1960295SM 8
CAPSCREW, Hex Head Taptite, 5/16-18 x 1/228 1924856SM 2
NUT, Speed, 1/4-2029 1960368SM 8
NUT, Speed, 5/16-1830 1935255SM 2
DUCT, Muffler Top31 1722389ASM 1
DUCT, Muffler Extension32 1722390ASM 1
Note* See your local Briggs & Stratton distributor for parts and service.
The above parts group applies to the following Mfg. Nos.:
13
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694626 - 1722H
1694628 - 2722H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Transmission Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986602
The above parts group applies to the following Mfg. Nos.:
14
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Transmission Group
Footnotes
SCREW, Pan Head Torx Taptite, 1/4-20 x 1-1/41 1960676SM 2
PAD, Footrest, LH, Differential Lock2 1722174SM 1
PAD, Footrest, RH3 1722173SM 1
FASTENER, 11/16" Long, Stem Plastic5 1704351SM 15
NUT, Hex Flange Whiz Lock, 3/8-16, Large6 1928352SM 2
NUT, Hex KEPS, 3/8-167 1960637SM 6
CARRIAGE BOLT, 3/8-16 x 18 1931350SM 6
NUT, Hex Flagne ESNA, 5/16-189 1960686SM 8
SUPPORT10 1721728ASM 2
BUSHING, 5/8 x 3/4 x 13/32, Powder Metal11 1676148SM 2
WASHER, 3/812 1924940SM 3
CAPSCREW, Hex Head, 3/8-16 x 2-1/413 1922130SM 1
PIN, Quick14 1722460SM 7
ROD, Differential Lock, 15-3/16 Long15 1722151SM 1
WASHER, 7/1616 1918267SM 3
ROD & TUBE ASSEMBLY, Differential Lock Pedal17 1721360SM 1
KNOB18 1716289SM 1
SPACER, 25/64 x 5/8 x 1-1/2, Hardened19 1669105SM 1
KNOB, 3 Sided Soft20 1723126SM 1
ROD, Free Wheel, 18-3/16 Long21 1721622SM 1
CAPSCREW, Hex Head, 3/8-16 x 1, Black22 1921210SM 1
PIVOT ASSEMBLY, Differential Lock23 1722903SM 1
WASHER, 5/16, Black24 1919326SM 2
CAPSCREW, Hex Head, 5/16-18 x 326 1960590SM 4
ROD, Differential Latch, 2 Bends, 6-3/16 Long27 1722152SM 1
CAPSCREW, Hex Head, 5/16-18 x 128 1921333SM 1
ARM, Differential Lock29 1722383SM 1
TRANSMISSION ASSEMBLY, K66L Transmission (Used on models with tranmission
expansion tank, attached or mounted to transmission.)
30 1733941SM 1
TRANSMISSION ASSEMBLY, K66AC Transmission (Used on models with remote
expansion tank Ref. No. 51)
30 1733208SM 1
PIN, Cotter, 3/4, Black31 1918447SM 1
ROD, Brake, 17-27/64 Long32 1721424SM 1
SPRING, Compression33 1722684SM 1
SPRING, Compression34 8191045SM 1
NUT, Hex Flange ESNA, 3/8-1635 1960687SM 2
SCREW, Whiz 5/8-18 x 136 1960667SM 1
SPACER37 1732088SM 1
ARM & WELD PINS ASSEMBLY, Control K6638 1732191SM 1
V-BELT39 1721392SM 1
PULLEY & HUB ASSEMBLY, Transmission40 1722194SM 1
The above parts group applies to the following Mfg. Nos.:
15
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Transmission Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986602
The above parts group applies to the following Mfg. Nos.:
16
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Transmission Group
Footnotes
NUT, Hex Flange, M10-1.5, Nylon Insert41 1719968SM 1
FAN, 5 Blades, 3 Holes42 1719233SM 1
CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1-1/843 1933958SM 3
CARRIAGE BOLT, 5/16-18 x 144 1931335SM 1
WASHER, 5/1645 1960141SM 1
STRAP, 4-1/4 Long46 1721593ASM 1
CAPSCREW, Hex Head, 5/16-18 x 2-1/247 1921719SM 1
ACTUATOR, Switch48 1727215ASM 1
CAPSCREW, Hex Head Taptite, 5/16-18 x 1/249 1924856SM 2
CAP, Expansion Tank Plastic (Used on models with tranmission expansion tank.)50 1722711SM 1
TANK, Oil Natural (Used on models with tranmission expansion tank.)51 1722430SM 1
CLAMP, Hose Worm Drive #20 1-3/4" (Used on models with tranmission expansion tank.)52 1723214SM 2
HOSE, Expansion Tank Formed (Used on models with tranmission expansion tank.)53 1722468SM 1
BOLT, Shoulder, 3/8-1654 1732129SM 1
The above parts group applies to the following Mfg. Nos.:
17
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
1694818 - 1723H
1694819 - Conquest
1694820 - 2723H
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
2690702 - Conquest
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Transmission SERVICE PARTS - Tuff Torq K-66L
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1721952
The above parts group applies to the following Mfg. Nos.:
18
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
TP 400-4204-B-CQ-SMA
Not for
Reproduction

PART NO. DESCRIPTIONREF NO QTY.
Transmission SERVICE PARTS - Tuff Torq K-66L
Footnotes
STAY2 1724704SM 1
HOUSING, UPPER4 1724692SM 1
HOUSING, LOWER5 1724694SM 1
CAP, M20B6 1724696SM 1
BOLT, 8 x 757 1718226SM 5
FILTER (25)8 1720761SM 1
MAGNET9 1718065SM 1
WASHER, SEAL11 1720796SM 2
BUSHING, 25.412 1724693SM 2
RING 3512 1708650SM 1
O-RING, P1813 1707786SM 2
SEAL14 1708651SM 1
BOLT 10 x 1216 1720788SM 1
SCREW, TAPPING17 1707789SM 5
CASE, CENTER18 1724697SM 1
PACKING20 1708691SM 2
PIN 3 x 9.821 1718070SM 1
FILTER (25)22 1725633SM 1
BOLT, 10 x 6523 1724698SM 3
CYLINDER BLOCK24 1718079SM 2
SHAFT, PUMP25 1724699SM 1
RING 1526 1708672SM 4
BEARING 6202UC327 1718083SM 1
HOUSING28 1724700SM 1
BEARING, THRUST29 1708675SM 1
WASHER 12 x 24 x 131 1718084SM 1
SHAFT, MOTOR32 1724701SM 1
BEARING, 6302UC336 1724702SM 1
THRUST METAL38 1718089SM 2
PLATE, SWASH39 1724703SM 1
BEARING K8110640 1718237SM 1
THRUST PLATE A41 1721267SM 1
THRUST PLATE B42 1718239SM 1
SPRING43 1725730SM 1
SHAFT (BYPASS)44 1720838SM 1
LEVER, BYPASS45 1720418SM 1
RING46 1718061SM 1
PIN 3.0A x 2047 1707839SM 1
SHOCK ABSORBER48 1718039SM 1
PIN50 1724705SM 1
The above parts group applies to the following Mfg. Nos.:
19
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
TP 400-4204-B-CQ-SMA
Not for
Reproduction

Transmission SERVICE PARTS - Tuff Torq K-66L
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
1721952
The above parts group applies to the following Mfg. Nos.:
20
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1694624 - Conquest
1694625 - Conquest
1694626 - 1722H
1694628 - 2722H
1694746 - Conquest
1694747 - 1720H
1694752 - 2720H
1694816 - Conquest
2690264 - Conquest
2690272 - 2722H
2690414 - Conquest
2690415 - Conquest
2690417 - 2723H
TP 400-4204-B-CQ-SMA
Not for
Reproduction
