Parts Manual
Rev. 03/2009
Regent RD
Series Lawn Tractor
TP 400-4848-D-RG-S
Mf
g
. No. Descri
p
tion
19.5HP Product
2690782 Regent RD, 19.5HP B&S Hydro and 40" Mower Deck
(CE/Export)
Mf
g
. No. Descri
p
tion
22HP Product
2690783 Regent RD, 22HP B&S Hydro and 40" Mower Deck
(CE/Export)
1736068
Part No.:

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
Frame & Front Axle Group ................................................................................................................................... 4
Steering Group ..................................................................................................................................................... 6
Engine Group ....................................................................................................................................................... 8
Controls Group ..................................................................................................................................................... 10
Electrical Group .................................................................................................................................................... 14
Hood, Grille & Dash Group .................................................................................................................................. 18
Seat Deck & Fuel Group ...................................................................................................................................... 20
Mulching Flap Group ............................................................................................................................................ 22
Lift Group - Manual .............................................................................................................................................. 24
Wheels & Tires Group .......................................................................................................................................... 26
Decals Group ....................................................................................................................................................... 28
Back Plate Group ................................................................................................................................................. 30
Collector Group .................................................................................................................................................... 34
40" Mower Deck - Belt & Idler Arm Group ........................................................................................................... 36
40" Mower Deck - Housing, Hitch, Arbors & Blades Group ................................................................................ 40

Not for
Reproduction
Frame & Front Axle Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988017
The above parts group applies to the following Mfg. Nos.:
4
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Frame & Front Axle Group
Footnotes
Cap, Hub 1.51D1 1726504SM 2
Ring, Klipring2 1611710SM 2
Washer .828 x 1.62 x .05833 2860183SM 4
Axle, Front (Includes Ref. Nos. 1, 2, 3, 17 & 19) (Includes Ref. Nos. 1, 2, 3, 17 & 19)5 1728018SM 1
Bushing, Axel Pivot6 1730186SM 2
Hook, Hitch .312THK7 1721918ASM 1
Capscrew HD 7/16-14 x 1.58 1960652SM 2
Nut, Hex-Flange 5/8-11LK11 2860646SM 1
Nut, Hex-Flange 5/16-18LK12 1931277SM 2
Capscrew, Hex 3/8-16 x 1.2513 1960032SM 2
Spacer15 1731912SM 2
Rod, Tie16 1728080ASM 1
Spindle & Cup Assembly RH17 1727872ASM 1
Nut, Hex-Flange 3/8-16 LK18 1930645SM 2
Spindle & Cup Asmy LH19 1727873ASM 1
Tower20 1727260SM 1
Frame21 1736499YP 1
Bolt M8 x 7522 1735874YP 2
Nut M823 1735934YP 2
Washer 8.424 1735989YP 6
Washer 825 1736000YP 6
Screw, Tap 5/16-18 x 0.6226 1930601SM 4
Bolt M8 x 2027 1735868YP 4
Pivot, Hood29 1728086SM 2
Support, Muffler30 1735973YP 1
Bolt, RD HD 5/16-18 x 1.031 1931335SM 2
Washer 0.62532 1960035SM 1
Capscrew, Hex 5/8-11 x 3.25033 2860744SM 1
Link, Drag34 1735919YP 1
Ball-Joint, CS16 M10-M1235 1735851YP 2
Nut M1236 1735928YP 2
Distance, Front Axle 0-9521-29137 1735892YP 2
Nut M10 DIN6923 838 1735926YP 2
The above parts group applies to the following Mfg. Nos.:
5
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Steering Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988023
The above parts group applies to the following Mfg. Nos.:
6
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Steering Group
Footnotes
Shaft, Steering Gear & Spline1 1727813SM 1
Washer 0.7502 1960114SM 2
Bushing3 1729665SM 2
Steering Wheel4 1728069SM 1
Nut, Hex-Lock 5/8-186 1960576SM 1
Cap, Steering Wheel Simplicity7 1722319SM 1
Nut M88 1735934YP 4
Bracket, Sector Support9 1727940SM 1
Bolt M8 x 2510 1735870YP 4
Gear, Steering .250 THK 26 Teeth11 1728027SM 1
Spacer, Sector Gear12 1728122SM 2
Screw, Hex LK Flange 3/8-16 x 1.0013 1934654SM 2
Nut, Hex-Flange 3/8-16 LK14 1931211SM 2
Ring, Klipring15 1611710SM 1
Washer 8.416 1735989YP 4
Washer 817 1736000YP 4
The above parts group applies to the following Mfg. Nos.:
7
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Engine Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988015
The above parts group applies to the following Mfg. Nos.:
8
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Engine Group
Footnotes
ENGINE, 19.5HP B&S Intek Single (Model # 441777 Type # 0128 Trim # B1)1* 1
ENGINE, 22HP B&S Intek Twin (Model # 31P677 Type # 0116 Trim # B1)1* 1
Valve Shut-Off2 1717473SM 1
Shield, Heat4 1735962YP 1
Screw, TAPTT 5/16-18 x 0.625 1930601SM 4
Shield, Heat (19.5HP)6 1727996SM 1
Shield, Heat (22HP Twin)6 1727997SM 1
Muffler B&S Twin (22HP Twin)7 1727994SM 1
Bracket, Muffler Mount8 1727976SM 1
Pipe, Exhaust RH Side (22HP Twin)9 1727979SM 1
Pipe Exhaust LH Side (22HP Twin)10 1727980SM 1
Muffler B&S Single (19.5HP)12 1727993SM 1
Pipe, Exhaust (19.5HP)13 1728959SM 1
Screw, TAPTT 1/4-20 x 0.514 1925003SM 4
Clip, Wire15 2834683SM 1
Control, Throttle Single (19.5HP)16 1734504SM 1
Control – Throttle Twin (22HP Twin)16 1734505SM 1
Clamp, Hose UM500817 1735883YP 2
Hose, Fuel 1-9920-24718 1735913YP 1
Clip, Hose19 1730268SM 2
Screw, TAPTT 3/8-16 x 1.00 (19.5HP)20 2827187SM 3
Washer, LK EXT-TOOTH .37521 2820427SM 1
Washer, Flat .3822 1924940SM 1
Pulley & Hub Assembly24 1732576SM 1
Tie25 1735980YP 1
Rod, Clutch Retainer, Long (BLK)26 1732875SM 1
Clutch, Electric (LONG OGURA)28 1732833SM 1
Washer, Hex .45329 1708264SM 1
Lockwasher 7/1630 1918199SM 1
Capscrew, Hex-Head 7/16-20 x 3.5031 1960649SM 1
Gasket, Exhaust32 1731214SM 1
Screw, Hex-Head T/R .38-16 x 1.2533 2828635SM 1
Screw34 1936228SM 2
Lockwasher35 1917356SM 2
The above parts group applies to the following Mfg. Nos.:
9
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Controls Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988009
The above parts group applies to the following Mfg. Nos.:
10
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Controls Group
Footnotes
Pedal, Forward1 1735940YP 1
Ratchet2 1735952YP 1
Arm3 1735847YP 1
Pedal, Brake4 1735941YP 1
Lever, Parking Brake5 1735918YP 1
Lever, Brake6 1735917YP 1
Rod, Traveling7 1735959YP 1
Rod, Brake8 1735957YP 1
Pulley, Tensioning9 1735951YP 1
Pulley, Idler (Includes References: 52, 71, 72, 73, 74, 75, 76, 77, & 78)10 1735950YP 1
Holder, Left11 1735910YP 1
Holder, Right12 1735911YP 1
Support, Switch13 1735974YP 1
Latch, Brake Lock14 1735595ASM 1
Pedal, Reverse15 1727246SM 1
Pad, Foot Pedal16 1727259SM 1
Latch, Cruise17 1727897SM 1
Rod, Cruise .312DIA 2.83 LG18 1727899SM 1
Bolt, Shoulder 5/16-18 x 1.62 LG19 1728976SM 1
Spacer, Foot Pedal20 1728024SM 1
Rod, Cruise, Latch, Upper21 1727898SM 1
Rod, .250dia 15.95 LG22 1727267SM 1
Bushing 0-9421-41823 1735880YP 2
Washer, Lock24 1736001YP 1
Spring, Flat 0-9740-22125 1735972YP 1
V-Belt, 13 x 2580 Li BBT26 1735987YP 1
Pulley Compensa C-00237/127 1735949YP 2
Pedal, Forward Rubber28 1735942YP 1
Bolt 0-9016-44729 1735853YP 1
Pedal, Brake Pad30 1727261SM 1
Spring TLZ 250.150.0530 Yellow31 1735968YP 1
Spacer, Pivot32 1727935SM 1
Distance, Pedal 0-9521-28833 1735896YP 4
Bushing 0-9462-20234 1735881YP 4
Ball-Joint, CS 13 DIN 71802 M8 Silver35 1735850YP 1
Clip Linkage .250 dia36 1728111SM 2
Spring, TZ 2x14 x 62 Yellow37 1735969YP 1
Pedal, Forward Top38 1735943YP 1
Bolt, Eye M6 x 80 BN100639 1735875YP 1
Bolt M6 x 1640 1735866YP 1
Washer 6.441 1735998YP 2
Nut M843 1735936YP 1
Spindle 2 x 2044 1735963YP 2
The above parts group applies to the following Mfg. Nos.:
11
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Controls Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988009
The above parts group applies to the following Mfg. Nos.:
12
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Controls Group
Footnotes
Pin, Flex 5 x 2545 1735946YP 4
Lock Ring 1246 1735920YP 4
Bolt, RD HD SH SQ NK 5/16-18 x 1.2547 1960223SM 2
Nut, Hex-Flange 5/16-18 x 1.6248 1931277SM 4
Bolt M10 x 4049 1735855YP 2
Washer 10.550 1735990YP 2
Washer 10.051 1735991YP 2
Nut M1052 1735925YP 4
Lock Ring 1653 1735921YP 1
Screw, Tap 5/16-18 x 0.6254 1930601SM 1
Nut M1055 1735924YP 1
Nut M8 DIN 6923 8 Yellow, Tooth56 1735938YP 1
Bolt M8 x 4557 1735873YP 1
Washer 8.458 1735989YP 7
Nut M859 1735934YP 7
Washer 860 1736000YP 5
Bolt M8 x 7561 1735874YP 4
Bolt, Shoulder 5/16-18 x 1.1563 1729576SM 1
Transmission, K-46HD64 1729589SM 1
Nut M666 1735933YP 3
Spring67 2159181SM 1
Washer 14 x 26/0.268 1735994YP 3
Nut M869 1735935YP 1
Bolt M8 x 1670 1735854YP 1
Screw, M10 x 4571 1736455YP 2
Lock Ring, 4072 1736456YP 2
Bushing, Pulley, Tension73 1736457YP 2
Pulley74 1736458YP 1
Ball-Bearing, Pulley, 62032RS75 1736459YP 1
Washer, 11, Zinc76 1736460YP 2
Arm, Pulley, Tension77 1736461YP 1
Bearing, Slide78 1736462YP 1
The above parts group applies to the following Mfg. Nos.:
13
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Electrical Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988014
The above parts group applies to the following Mfg. Nos.:
14
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Electrical Group
Footnotes
Harness, Main1 1735475YP 1
Support, Battery2 1727282SM 1
Screw, Hex Washer Head, TAPTITE .31-18 x .623 1930601SM 4
Battery, 12V 230 AMP CCA DRY4 1685215SM 1
Hold Down, Battery5 1730007SM 1
Bolt, Round Head Carriage .25-20 x .886 1931318SM 1
Washer, Flat .257 1960353SM 1
Nut, Push .258 1960518SM 1
Nut .25 ESNA9 1920397SM 1
Solenoid, 12V10 1728963SM 1
Screw, Hex-Washer Head TAPTITE .25-20 x .5011 1925003SM 2
Switch Assembly, Ignition (Includes References 13, 14, 15, & 16)12 1716061YP 1
Washer .6213 2101025SM 1
Lock Washer, Int. Tooth .6214 1960547SM 1
Nut, Hex-Flange, Ignition Switch .62 - .3215 1717549SM 1
Cover, Ignition Switch16 1717550SM 1
Hour Meter (22HP Twin)17 1728068SM 1
Plug, Hour Meter (19.5HP)18 1729993SM 1
Switch, PTO19 1722887SM 1
Switch, RMO Module20 1726556SM 1
Switch, Head lights22 1716951SM 1
Plug23 1722611SM 1
Switch, Push (Foot Pedal)27 1732006SM 1
Switch, Push NC (Seat)28 1732005SM 1
Cable, #6 10.0 Lg Red29 1716549SM 1
Cable, #6 25.0 Lg Red30 1721830SM 1
Cable, #6 20.0 Lg Black31 1713163SM 1
Lockwasher, Spring .2532 2816964SM 2
Nut, Hex KEPS LK .31-2434 2860750SM 2
Capscrew, Hex .25-20 x .7535 2823341SM 2
Washer, Flat .2536 2821319SM 2
Nut, Hex .25-2037 2816622SM 2
Boot, Insulator, Battery38 1677296SM 1
Boot, Insulator, Red39 1713535SM 1
Tie, RT 360 /L=150/40 1735980YP 5
AUX. Plug, 12V, (With Cover)42 7073090SM 1
Switch, NO (RMO)43 1732004SM 1
Nut, Flange, Whiz .25-2045 1960294SM 1
Key, RMO Module46 1726557SM 1
Microswitch, MKH 12 D13 S147 1735922YP 2
Beeper, PF 27 A 29 EP48 1735852YP 1
Wire 9-8316-61649 1736003YP 1
Wire 9-8316-61550 1736002YP 1
The above parts group applies to the following Mfg. Nos.:
15
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Electrical Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988014
The above parts group applies to the following Mfg. Nos.:
16
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Electrical Group
Footnotes
Cable Clip, WSBH 1-0-152 1735882YP 7
Clip, Speed Wire53 2834683SM 1
Plug, Shut-Off54 1734025SM 1
Clip, Cable WCK 460 01/A55 1735884YP 1
Socket Assembly56 1723451SM 2
Bulb, 1141-12V 21CP57 1677371SM 2
Reflector, Headlight58 1728973SM 1
Lens, Headlight59 1728974SM 1
Headlight Assembly (Includes References 56, 57, 58 & 59)60 1727296SM 1
Key, Ignition (Set of 2)61 1717163SM 1
Fuse62 1731957SM 1
The above parts group applies to the following Mfg. Nos.:
17
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Hood, Grille & Dash Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988018
The above parts group applies to the following Mfg. Nos.:
18
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
PART NO. DESCRIPTIONREF NO QTY.
Hood, Grille & Dash Group
Footnotes
Hood, With Louvers1 1722110CSM 1
Duct, Air Inlet2 1733457SM 1
Panel, Hood RH Side3 1728029CSM 1
Panel,Hood LH Side4 1728030CSM 1
Grille5 1727297CSM 1
Hinge, Hood LH6 1727279SM 1
CS, Hex LK ¼-20 x 0.6257 1960295SM 12
Nut, Hex-Flange LK .25-208 1930641SM 12
Dashboard9 1727293SM 1
Knob, Brake Lock10 1728089SM 1
Knob, Cruise Lock11 1728090SM 1
Nut, Push Pal .25012 1960518SM 2
CS, Hex Tapit 5/16-18 x 0.7513 1664847SM 2
Washer 0.31214 1919381SM 2
Cover, Steering Shaft15 1727999SM 1
Headlight Assembly16 1727296SM 1
Screw, Phillips HD18 1960392SM 3
Rod, Dash Support19 1723123SM 1
Nut, Flange20 1933896SM 3
Screw, Self-Tap21 1925003SM 1
Guide, Hood LH24 1732030SM 1
Guide, Hood RH25 1732031SM 1
Braid, Steel Insert 0-9634-21926 1735878YP 2
Hinge, Hood RH27 1727280SM 1
Bumper, Front28 1735879YP 1
Bolt M8 x 2030 1735868YP 4
Washer 8.431 1735989YP 4
Washer 832 1736000YP 4
Nut M833 1735934YP 4
Ending Rubber34 1731971SM 1
The above parts group applies to the following Mfg. Nos.:
19
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S

Not for
Reproduction
Seat Deck & Fuel Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
2988021
The above parts group applies to the following Mfg. Nos.:
20
2009
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
2690782 - Re
g
ent RD
2690783 - Regent RD
TP 400-4848-D-RG-S
