Simplicity 555M User manual

Parts Manual
Rev. 02/2008
Intermediate
Walk-Behind Snowthrowers
TP 400-4148-01-IW-S
Mf
g
. No. Descri
p
tion
5HP Product
1694587 555M, 5HP
1694595 555M, 5HP
Mf
g
. No. Descri
p
tion
8HP Product
1694588 860E, 8HP
1694596 860M, 8HP
1731153
Part No.:

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
Handles & Controls Group ................................................................................................................................... 4
Engine, Pulleys, & Frame Group - 5HP Tecumseh ............................................................................................. 8
Engine, Pulleys, & Frame Group - 8HP Briggs & Stratton .................................................................................. 12
Auger & Impeller Group ....................................................................................................................................... 16
Auger Housing Group .......................................................................................................................................... 18
Traction Drive Group ............................................................................................................................................ 20
Wheels & Tires Group .......................................................................................................................................... 24
Decals Group ....................................................................................................................................................... 26
Chute Crank Control Group ................................................................................................................................. 28

Handles & Controls Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
070uhdc
The above parts group applies to the following Mfg. Nos.:
4
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694588 - 860E
1694595 - 555M
1694596 - 860M
TP 400-4148-01-IW-S

PART NO. DESCRIPTIONREF NO QTY.
Handles & Controls Group
Footnotes
NUT, 5/16-18 Hex Nyloc1 5025057SM 2 BRACKET, Snow Stick- Lower2 1726727ASM 1 SCREW, 5/16-18 x 3/4" Hex Head Cap3 1921332SM 4 CLUTCH CABLE, Auger Drive- RH4 7027426SM 1 HANDLE, Upper, Right Hand5 1726574SM 1 GRIP, Clutch, RH6 1722638SM 1 GRIP, Foam, Black7 1726317SM 2 HAIR PIN8 1722460SM 3 ROD, Shift, Lower9 1666255SM 1 NUT, 1/4-20 2B Hex10 1916622SM 2 LOCKWASHER, 1/4" Spring11 1916964SM 3 BOLT, 1/4-20 x 2" Short Square Neck Carriage, GR 512 1931317SM 2 ROD, Upper, Shift13 1720238SM 1 BLOCK, Pivot14 1668524SM 2 SHIFT ROD PIVOT ASSEMBLY15 1720240SM 1 SPRING, Compression16 1715123SM 1 COTTER PIN, .125 x 1.0017 1918452SM 1 BUSHING, .500 ID x .750 OD x .2518 1668185SM 2 WASHER, 1/2" Flat (.531 ID x 1.250 OD x .08 Thick)19 1924361SM 1 SHIFT ROD ASSEMBLY20 1668523SM 1 SCREW, 1/4-20 x 2-1/4" Hex Flange Lock21 1960705SM 1 WASHER, .250 (.27 ID x .62 OD)22 1921319SM 2 KNOB, Tapered - 3/8-16 Internal Thread- Red23 1726734SM 1 DASH ASSEMBLY24 1726983ASM 1 HANDLE, Lower25 1726572SM 1 WING KNOB, 5/16-1826 1716632SM 2 WASHER, 5/16" Internal Tooth Lock27 7090391SM 2 NUT, 5/16-18 Hex Flange Nyloc28 1960686SM 4 WASHER, .312 (.34 ID x .75 OD)29 1919326SM 2 ASSEMBLY, Rod w/Pin (Includes Ref. Nos. 31. 47, 54, 55 & 56)30 1722633SM 1 SPRING, Compression31 1722690SM 1 PUSH NUT32 1960519SM 1 ROD, Hold Down33 1722630SM 1 SCREW, 1/4-20 x 2" Hex Head Cap, GR 534 1960662SM 1 GRIP, Clutch, LH35 1722667SM 1 NUT, 1/4-20 Hex Centerlock36 1923358SM 2 SPACER, Handle37 1715655SM 2 HANDLE, Upper, Left Hand38 1726573SM 1 SCREW, 1/4-20 x 1-1/2" Hex Head Cap39 1922837SM 2 SPACER, .268 ID x .394 x .16540 1715654SM 2 SCREW, 1/4-20 x 3/4" Pan Head Torx Self-Tap41 1960671SM 2 SCREW, 5/16-18 x 1-1/2" Hex Head Cap, GR 542 1921221SM 5 LEVER, Pivot43 1722631ASM 1 NUT, 1/4-20 Hex Nyloc44 1920397SM 2
The above parts group applies to the following Mfg. Nos.:
5
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694588 - 860E
1694595 - 555M
1694596 - 860M
TP 400-4148-01-IW-S

Handles & Controls Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
070uhdc
The above parts group applies to the following Mfg. Nos.:
6
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694588 - 860E
1694595 - 555M
1694596 - 860M
TP 400-4148-01-IW-S

PART NO. DESCRIPTIONREF NO QTY.
Handles & Controls Group
Footnotes
TOOL, Clean-Out45 7075909SM 1 NUT, #10-24 Hex Center Lock46 7091267SM 1 ROD, Hand Control, not shown; part of item 3047 1722632 1 HOLDER, Clean-Out Tool, Upper48 1726728SM 1 CLUTCH CABLE, Ground Drive- LH49 7027425SM 1 BOLT, 5/16-18 x 2" Curved Head Square Neck GR 250 7091740SM 4 WASHER, #10 Internal Tooth Lock51 7090011SM 1 SCREW, #10-24 x 2" Hex Washer Head Machine, GR552 7091266SM 1 LOCKWASHER, Spring 5/16, not shown; part of item 3053 1917356SM 4 BUSHING, .250 ID x .375 OD x .750, not shown; part of item 3054 1722635 1 PIN, Clevis, not shown; part of item 3055 1722634 1 SPRING, Compression, not shown, part of item 3056 1722613 1
The above parts group applies to the following Mfg. Nos.:
7
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694588 - 860E
1694595 - 555M
1694596 - 860M
TP 400-4148-01-IW-S

Engine, Pulleys, & Frame Group - 5HP Tecumseh
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
070epi5t
The above parts group applies to the following Mfg. Nos.:
8
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694595 - 555M
TP 400-4148-01-IW-S

PART NO. DESCRIPTIONREF NO QTY.
Engine, Pulleys, & Frame Group - 5HP Tecumseh
Footnotes
SCREW, 5/16-24 x 3/4" Hex Head Cap, GR 51 1921515SM 4 WASHER, 5/16" Flat2 1924874SM 1 WIRE, Belt Stop3 1725424SM 1 LOCKWASHER, 5/16" Exterior Tooth4 1920427SM 3 ENGINE, 5HP Tecumseh, Model LH195SA-67427V5* 1
HOSE, Oil Drain6 1726942SM 1 NUT, 5/16-18 Hex Flange Lock- small7 1931277SM 3 NUT, 5/16-18 Hex Flange Lock8 1931277SM 1 ROD, Idler9 1715092SM 1 ROLL PIN, 3/16 x 3/4"10 2816169SM 2 FRAME ASSEMBLY, Intermediate (Orange)11 7072566SM 1 SPEED NUT, 1/4-20 U-Type12 1926018SM 6 BUSHING, 1.00 long13 1666001SM 2 SUPPORT, Tie Bar14 1715559A 1 SCREW, #10-24 x 1/2" Hex Washer Self-Tap15 1929477SM 2 JAM NUT, 3/8-16 Hex Center Lock16 1960251SM 4 WASHER, 3/8" Flat17 1924940SM 3 ROD, Belt Guide18 1674315SM 2 NUT, 3/8-16 Hex Nyloc Heavy Thin19 1922694SM 4 SUPPORT, Frame20 1715756A 1 SCREW, 5/16-18 x 1/2" Hex Washer Self-Tap21 1924856SM 4 SUPPORT, Pivot22 1715111SM 1 WASHER, 5/16" Flat23 1919381SM 2 SCREW, 5/16-18 x 1-3/4 Hex Head Cap, GR 524 1922127SM 3 SCREW, 5/16-18 x 1-3/4 Hex Head Cap, GR 525 1922127SM 1 COVER, Bottom, Orange26 7072555SM 1 SCREW, 1/4-20 x 5/8" Hex Washer Self-Tap27 7091819SM 9 WASHER, 7/16" Flat28 1925125SM 1 COTTER PIN, 1/8 x 3/4"29 1918451SM 1 IDLER ARM ASSEMBLY30 1715112SM 1 BOLT, 3/8-16 x 1-1/4" Short Square Neck Carriage31 1960268SM 1 SPACER, .377 ID x .75 OD x .312 Long32 2174870SM 1 PULLEY, Idler33 2118414SM 1 BELT, Auger Drive, V Groove34 1717393SM 1 BELT, Traction Drive, V Groove35 1715127SM 1 SPRING, Extension36 1715118SM 1 PAD, Brake37 1669313SM 1 RIVET, Blind38 2825160SM 2 ASSEMBLY, Idler Arm w/Brake Pad39 1717320SM 1 BOLT, 3/8-16 x 1-3/4 Short Square Neck Carriage, GR 540 7091810SM 1 WASHER, 3/8" Flat (.41 ID x 1.00 OD x .13 Thick)41 1922755SM 1 PULLEY, Idler42 1668477SM 1 COVER, Belt43 1725379SM 1 SPRING, Idler- Extension44 1720237SM 1
Note*See your local Tecumseh distributor for engine service parts.
The above parts group applies to the following Mfg. Nos.:
9
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694595 - 555M
TP 400-4148-01-IW-S

Engine, Pulleys, & Frame Group - 5HP Tecumseh
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
070epi5t
The above parts group applies to the following Mfg. Nos.:
10
2008Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694587 - 555M
1694595 - 555M
TP 400-4148-01-IW-S
