OPERATOR’S MANUAL
Record all information and attach sales receipt
here for future reference.
Purchase Date:
Serial Number:
Visit us at www.power-washer.us to register
your warranty, nd replacement parts, and talk
with our service representatives about your
pressure washer.
Table of Contents
Safety Guidelines / Denitions 2
Important Safety Instructions 2-7
Specications 7
Carton Contents 8
Assembly Instructions 8-9
Operating Instructions 9-13
Maintenance 13-14
Storage 14-15
Repairs 15
Accessories 15
Trouble Shooting Guide 15-17
Warranty 18-19
IMPORTANT
Please make certain that the person who is to use this equipment carefully reads and understands
these instructions before operating. REV. 0 12/10
Pressure Washer Models
MSV2700
2700
2.4
PREMIUM RESIDENTIAL

2
This manual contains information that is important for you to know and understand. This informa-
tion relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you
recognize this information, we use the symbols below. Please read the manual and pay attention to
these symbols.
SAFETY GUIDELINES - DEFINITIONS
CONSUMER SAFETY INFORMATION
This product may not be equipped with a spark arresting mufer. If the product is not
equipped and will be used around ammable materials, or on land covered with materials such as
agricultural crops, forest, brush, grass, or other similar items, then an approved spark arrester must
be installed and is legally required in the State of California. It is a violation of California statues
section 130050 and/or sections 4442 and 4443 of the California Public Resources Code, unless
the engine is equipped with a spark arrester, as dened in section 4442, and maintained in effective
working order. Spark arresters are also required on some U.S. Forest Service land and may also be
legally required under other statutes and ordinances.
This product contains chemicals, known to the State of California, to cause cancer,
and birth defects or other reproductive harm. Wash hands after handling.
IMPORTANT SAFETY INSTRUCTIONS
Do not operate this unit until you have read and understand this Operators Manual and
the Engine Owners Manual for Safety, Operation, and Maintenance Instructions.
READ AND SAVE THESE INSTRUCTIONS
Spilled gasoline and its vapors can become
ignited from cigarette sparks, electrical arcing,
exhaust gases and hot engine components
such as the mufer.
RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN HOW TO PREVENT IT
Shut off engine and allow it to cool before add-
ing fuel to the tank.
Use care in lling tank to avoid spilling fuel.
Move pressure washer away from fueling area
before starting engine.
••
•
Indicates an imminently
hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates an potentially
hazardous situation which, if not avoided, may
result in minor or moderate injury.
Indicates an potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
Indicates a practice not related to
personal injury which, if not avoided, may result
in property damage.

3
Heat will expand fuel in the tank which could
result in spillage and possible re explosion.
WHAT CAN HAPPEN HOW TO PREVENT IT
Fill tank to 1/2" (12.7mm) below bottom of ller
neck to provide space for fuel expansion.
••
Operating the pressure washer in an explosive
environment could result in a re.
Operate and fuel equipment in well-ventilated
areas free from obstructions. Equip areas with
re extinguishers suitable for gasoline res.
••
Materials placed against or near the pressure
washer can interfere with its proper ventila-
tion features causing overheating and possible
ignition of the materials.
Never operate pressure washer in an area con-
taining dry brush or weeds.
••
Mufer exhaust heat can damage painted sur-
faces, melt any material sensitive to heat (such
as siding, plastic, rubber, vinyl, or the high
pressure hose) and damage live plants.
Always keep pressure washer a minimum of
4' (1.2m) away from surfaces (such as houses,
automobiles, or live plants) that could be dam-
aged from mufer exhaust heat.
••
Improperly stored fuel could lead to accidental
ignition. Fuel improperly secured could get
into the hands of children or other unqualied
persons.
Store fuel in an OSHA-approved container, in a
secure location away from your work area.
••
Use of acids, toxic or corrosive chemicals,
poisons, insecticides, or any kind of ammable
solvent with this product could result in seri-
ous injury or death.
Do not spray ammable liquids.
••
RISK TO BREATHING (Asphyxiation)
WHAT CAN HAPPEN HOW TO PREVENT IT
Breathing exhaust fumes will cause serious in-
jury or death! Engine exhaust contains carbon
monoxide, an odorless and deadly gas.
Operate pressure washer in a well ventilated
area. Avoid enclosed areas such as garages,
basements, etc.
Never operate unit in a location occupied by
humans or animals.
••
•
Some cleaning uids contain substances
which could cause injury to skin, eyes, or
lungs.
Use only cleaning uids specically recom-
mended for high-pressure washers. Follow
manufacturers recommendations. Do not use
chlorine bleach or any other corrosive com-
pound.
••

RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
Your pressure washer operates at uid pres-
sures and velocities high enough to penetrate
human and animal esh, which could result
in amputation or other serious injury. Leaks
caused by loose ttings or worn or damaged
hoses can result in injection injuries. DO NOT
TREAT FLUID INJECTION AS A SIMPLE CUT!
See a physician immediately.
Inspect the high-pressure hose regularly. Re-
place the hose immediately if it is damaged,
worn, has melted from contacting the engine,
or shows any signs of cracks, bubbles, pin-
holes, or other leakage. Never grasp a high-
pressure hose that is leaking or damaged.
Never touch, grasp, or attempt to cover a
pinhole or similar water leak on the high pres-
sure hose. The stream of water IS under high
pressure and WILL penetrate skin.
Never place hands in front of nozzle.
Direct spray away from self and others.
Make sure hose and ttings are tightened and
in good condition. Never hold onto the hose
or ttings during operation.
Do not allow the high pressure hose to contact
the mufer.
Never attach or remove wand or hose ttings
while system is pressurized - squeeze trigger
gun (when engine is off) to relieve pressure in
the system.
••
•
Injuries can result if system pressure is not
reduced before attempting maintenance or
disassembly.
To relieve system pressure, shut off engine,
turn off water supply and pull gun trigger until
water stops owing.
Use only hoses and accessories rated
for pressure higher than your pressure
washer’sPSI.
••
•
•
•
•
•
•
RISK OF INJURY FROM SPRAY
WHAT CAN HAPPEN HOW TO PREVENT IT
High velocity uid spray can cause objects to
break, propelling particles at high speed.
Light or unsecured objects can become haz-
ardous projectiles.
Always wear ANSI-approved Z87.1 safety
glasses. Wear protective clothing to protect
against accidental spraying.
Never point wand at, or spray people or ani-
mals.
Always secure trigger lock when wand is not in
service to prevent accidental operation.
Never permanently secure trigger in pull-back
(open) position.
••
•
•
•
•
4

RISK OF UNSAFE OPERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
Unsafe operation of your pressure washer
could lead to serious death to you or others.
Do not use chlorine bleach or any other
corrosive compound.
Become familiar with the operation and controls
of the pressure washer.
Keep operating area clear of all persons, pets,
and obstacles.
Do not operate the product when fatigued or
under the inuence of alcohol or drugs. Stay
alert at all times.
Never defeat the safety features of this product.
Do not operate machine with missing, broken,
or unauthorized parts.
Never leave wand unattended while unit is
running.
•
•
•
•
•
•
•
If proper starting procedure is not followed,
engine can kickback causing serious hand and
arm injury.
If engine does not start after two pulls,
squeeze trigger of gun to relieve pump pres-
sure. Pull starter cord slowly until resistance is
felt. Then pull cord rapidly to avoid kickback
and prevent hand or arm injury.
••
The spray gun/wand is a powerful tool that
could look like a toy to a child
Keep children away from the pressure washer
at all times.
••
Reactive force of spray will cause gun/wand
to kickback, and could cause the operator to
slip and fall or misdirect the spray. Improper
control of gun/wand can result in injuries to
self and others.
Do not overreach or stand on an unstable sup-
port.
Do not use pressure washer while standing on
a ladder.
Grip gun/wand rmly with both hands. Expect
the gun to kickback when triggered
••
•
•
5

6
RISK OF INJURY OR PROPERTY DAMAGE WHEN
TRANSPORTING OR STORING
WHAT CAN HAPPEN HOW TO PREVENT IT
Fuel or oil can leak or spill and could result
in re or breathing hazard. Serious injury or
death can result. Fuel or oil leaks will damage
carpet, paint, or other surfaces in vehicles or
trailers.
If the pressure washer is equipped with a fuel
shut-off valve, turn the valve to the OFF posi-
tion before transporting to avoid fuel leaks. If
the pressure washer is not equipped with a
fuel shut-off valve, drain the fuel from the tank
before transporting. Only transport fuel in
an OSHA-approved container. Always place
pressure washer on a protective mat when
transporting to protect against damage to
vehicle from leaks. Remove pressure washer
from vehicle immediately upon arrival at your
destination.
••
RISK OF BURSTING
WHAT CAN HAPPEN HOW TO PREVENT IT
Over ination of tires could result in serious
injury and property damage.
Use a tire pressure gauge to check the tires
pressure before each use and while inating
tires
See the tire sidewall for the correct tire
pressure.
NOTE: Air tanks, compressors, and similar
equipment used to inate tires can ll small
tires similar to these very rapidly. Adjust pres-
sure regulator on air supply to no more than
the rating of the tire pressure. Add air in small
increments and frequently use the tire gauge
to prevent over ination.
••
RISK OF HOT SURFACES
WHAT CAN HAPPEN HOW TO PREVENT IT
Contact with hot surfaces, such as engine
exhaust components, could result in serious
injury.
During operation, touch only the control sur-
faces of the pressure washer. Keep children
away from the pressure washer at all times.
They may not be able to recognize the hazards
of this product.
••
High velocity uid spray directed at pneumatic
tire sidewalls (such as found on automobiles,
trailers, and the like) could damage the side-
wall resulting in serious injury.
On pressure washers rated above 1600 PSI
(110 Bar) use the widest fan spray (40º nozzle)
and keep spray a minimum of 8" (20cm) from
the pneumatic tire sidewall. Do not aim spray
directly at the joint between the tire and rim.
• •
•
•

7
RISK OF CHEMICAL BURN
WHAT CAN HAPPEN HOW TO PREVENT IT
Use of acids, toxic or corrosive chemicals,
poisons, insecticides, or any kind of ammable
solvent with the product could result in injury
or death.
Do not use acids, gasoline, kerosene, or any
other ammable material in this product. Use
only household detergents, cleaners, and
degreasers recommended for use in pressure
washers.
Wear protective clothing to protect eyes and
skin from contact with sprayed materials.
••
•
RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN HOW TO PREVENT IT
Spray directed at electrical outlets or switches,
or objects connected to an electrical circuit,
could result in a fatal electrical shock.
Unplug any electrically operated product be-
fore attempting to clean it. Direct spray away
from electric outlets and switches.
••
RISK OF INJURY FROM LIFTING
WHAT CAN HAPPEN HOW TO PREVENT IT
Serious injury can result from attempting to lift
too heavy an object.
The pressure washer is too heavy to be lifted
by one person. Obtain assistance from others
before lifting.
••
READ AND SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Model MSV2700
Max Pressure* 2700 PSI
Max Flow* 2.4 GPM
* Water ow and maximum pressure ratings determined in accordance with PWMA standard PW101.
NOTE: Photographs and line drawings used in this manual are for reference only and do not
represent a specic model.

8
CARTON CONTENTS
ASSEMBLY INSTRUCTIONS
1) Locate and remove all loose parts from the carton.
2) Cut the four corners of the carton from top to bottom and lay the panels at.
3) Place the handle onto the frame, depress the snap buttons, and slide the handle assembly down
on the frame until snap buttons snap into place.
Risk of Personal Injury. Avoid placing hands between the handle and frame when
assembling to prevent pinching.
4) Connect Gun to Wand. Tighten Securely.
5) Attach high pressure hose to gun. Tighten securely.
6) Remove the colored quick connect nozzled from plastic bag and insert them into grommets on the
nozzle holder.
Engine Frame
and Wheel
Assembly
High Pressure Hose Handle
Spray Gun
Spray Wand
Quick Connect
Nozzles
Nozzle
Cleaning
Tool
Engine
Manual
Operation
Manual
Bagged Parts

9
OPERATING INSTRUCTIONS
NOTE: The pump on this unit is maintenance free and requires no oil. If there is a problem with the
pump, contact our Customer Service Group on www.power-washer.us as soon as possible.
Risk of bursting. Use a tire pressure gauge to check the tire pressure before each use
and while inating tires; see the tire sidewall for the correct tire pressure.
NOTE: Air tanks, compressors, and similar equipment used to inate tires can ll small tires similar to
these very rapidly. Adjust pressure regulator on air supply to no more than the rating of the tire pres-
sure. Add air in small increments and frequently use the tire gauge to prevent over ination.
The engine is shipped without oil. Before starting engine, add the oil provided. Damage
to the engine will occur if the engine is ran without oil, this damage will not be covered under
warranty.
Compare the illustrations with your unit to familiarize yourself with the location of various controls
and adjustments. Save this manual for future reference.
BASIC ELEMENTS OF A PRESSURE WASHER
High Pressure Pump: Increases the pressure of the water supply.
Engine: Drives the high pressure pump. Refer to the engine manual for location and operation of
engine controls
High Pressure Hose: Carries the pressurized water from the pump to the gun and spray wand.
Spray Gun: Connects the spray wand to control water ow rate, direction, and pressure.
High Pressure Pump
Engine
Spray Gun
High Pressure Hose
Quick Connect Spray Wand

10
Quick Connect Spray Wand: Allows the user to quickly change the spray pattern. See next
sections for more details on your specic Spray Wand included with your machine.
Chemical Hose (not shown): Feeds cleaning agents into the pump to mix with the water. See How
to Apply Chemicals / Cleaning Solvents instructions.
BASIC ELEMENTS OF AN ENGINE
Refer to the engine manual for location and operation of engine controls.
Choke Control: Opens and closes carburetor choke valve.
Starter Grip: Pulling starter grip operates recoil starter to crank engine.
Engine Switch: Enables and disables ignition system.
PRESSURE WASHER TERMINOLOGY
PSI: Pounds per Square Inch. The unit of measure for water pressure. Also used for air pressure,
hydraulic pressure, etc. Sometimes noted as “Bar”, another unit of measure.
GPM: Gallons per Minute. The unit of measure for the ow rate of water. Sometimes noted as L/
min (Liters per Minute).
CU: Cleaning Units. GPM multiplied by PSI equals CU.
Bypass Mode: Allows water to re-circulate within the pump when the gun trigger is not pulled. This
feature allows the operator to release the trigger gun and reposition themselves without having to
turn the engine off in between cleaning actions.
Allowing the unit to run for more than two minutes without the gun trigger being pulled
could cause overheating and damage to the pump. Do not let the pressure washer run for more
than two minutes in Bypass Mode. Turn off the engine and relieve the pressure in the gun during
these extended situations.
Thermal Relief Valve (not shown): When the temperature inside the pump rises too high, this valve
will open and release a gush of water in an effort to lower the temperature inside the pump. The
valve will then close.
Chemical Injection System: Mixes cleaners or cleaning solvents with the water to improve cleaning
effectiveness. Depending on your machine, this could either be a Detergent Siphon Tube (which is
inserted into a container of detergent), or a Detergent Tank (which is lled with detergent and is an
integral part of the pressure washer frame).
Water Supply: All pressure washers must have a source of water. The minimum requirements for a
water supply are 20 PSI and 5 Gallons Per Minute.
PRESSURE WASHER OPERATING FEATURES - SPRAY WAND
The powerful spray from your pressure washer is capable of causing damage to
surfaces such as wood, glass, automobile paint, auto striping and trim, and delicate objects such
as owers and shrubs. Before spraying, check the items to be cleaned to assure yourself that it is
strong enough to resist damage from the force of the spray.

11
This model includes a variety of quick connect nozzles with different spray patterns. The chart
below explains the differences in the various nozzles. Note that not all machines are shipped
with every nozzle - check Carton Contents section of this manual to see which nozzles, if any, are
included with your pressure washer.
Nozzle Color Spray Pattern Uses Surfaces*
Red 0º Extreme cleaning of very
hard surfaces covered in
grease and oil.
Steel, Undamaged Concrete.
Yellow 15º Intense cleaning of
unpainted hard surfaces.
Grills, driveways, concrete or
brick walkways, unpainted
brick or stucco.
White 40º Standard cleaning nozzle for
most applications. Cleaning
of painted or delicate
surfaces.
Yard tools, sidewalks, lawn
furniture, unpainted siding,
stucco, gutters and eaves,
concrete, brick surfaces,
auto/RV, marine, wood,
painted brick and stucco,
vinyl, painted siding.
Black Low Pressure Applies cleaning solutions. Low pressure spray is safe
on all surfaces. Always
verify compatibility of
cleaning solution prior to
use.
* The powerful spray from your pressure washer is capable of causing damage to
surfaces such as wood, glass, automobile paint, auto striping and trim, and delicate objects such
as owers and shrubs. Before spraying, check the items to be cleaned to assure yourself that it is
strong enough to resist damage from the force of the spray.
Changing Nozzle on the Spray Wand
Risk of uid injection. Do not direct discharge stream toward persons, unpro-
tected skin, eyes, or any pets or animals. Serious injury will occur.
Flying objects could cause risk of serious injury. Do not attempt to change nozzles
while pressure washer is running. Turn engine off before changing nozzles.
Flying objects could cause risk of serious injury. Ensure nozzle is completely inserted
in quick connect socket snap ring is fully engaged (forward) before squeezing gun trigger.
Changing Nozzles on Spray Wand (continued)
1) Pull quick connect coupler back and insert nozzle.
2) Release quick connect coupler and twist nozzle to make sure it is secure
in the coupler.
How to Apply Chemicals / Cleaning Solvents
Applying chemicals or cleaning solvents is a low pressure operation. Your
pressure washer is equipped with a detergent siphon hose.

12
DETERGENT SIPHON HOSE
1) Press chemical hose onto the barbed tting located near the high pressure hose connection on
the pump.
2) Place other end of chemical hose with lter on it into container holding chemical/cleaning solution.
NOTE: For every 7 gallons of water pumped, one gallon on chemical/cleaning solution will be used.
3) Set your Wand to Low Pressure Setting by inserting the Black Nozzle into your Wand. See How
To use Spray Wand section in this owners manual.
4) After use of chemicals, place chemical hose into container of clean water and draw clean water
through chemical injection system to rinse thoroughly. If chemicals remain in the pump it could be
damaged. Pumps damaged due to chemicals will not be covered under warranty.
NOTE: Only use soaps and chemicals designed for pressure washer use. Do not use bleach!
NOTE: Chemicals and soaps will not siphon when Variable Spray Wand is in the High Pressure
Setting, or if the Quick Connect Spray Wand is equipped with the Red, Yellow, Green, or White
Nozzles.
Risk of property damage. NEVER pull water supply hose to move pressure washer.
This could damage the hose and/or the pump inlet.
• DO NOT use Hot water, only use cold water.
• NEVER turn water supply off while pressure washer engine is running, or damage to the pump will
occur!
• DO NOT stop spraying water for more than two minutes at a time. Pump operates in bypass mode
when spray gun trigger is not pressed. If pump is left in bypass mode for more than two minutes
internal components of the pump can be damaged.
If you do not understand these precautions, please go to www.power-washer.us
to speak to a service representative for further instructions.
STARTING YOUR PRESSURE WASHER
Prior to starting, refer to your Engine Owners Manual for the proper starting procedure.
1) In a well ventilated outdoor area add fresh, high quality, unleaded gasoline with a pump octane
rating of 86 or higher. Do not overll. Wipe up spilled fuel before starting engine. Refer to Engine
Owners Manual for correct procedure and fuel information.
2) Check engine oil level. See Engine Owners Manual for correct procedure.
3) Connect the water hose to the water source. Turn the water source on to
Filter Screen
remove all air from the hose. When a steady stream of water is present, turn
the water source off.
4) Verify the lter screen is in the water inlet of the pump.
5) Connect water source to pump inlet. NOTE: Water Source must provide a
minimum of 5 gallons (18.9 liters) per minute at 20 PSI (137.9kPa).
To reduce the possibility of contamination always protect against backow when
connected to a potable water system.
6) Connect high pressure hose to pump outlet.
7) If applying a chemical or cleaning solution, see How To Apply Chemicals/Cleaning Solvents
instructions in this manual.
8) Turn water source on.
9) Remove all air from the pump and high pressure hose by depressing trigger until a steady stream
of water is present.
10) Start engine. See Engine Owners Manual for correct procedure.

13
MAINTENANCE
Risk of burn hazard. When performing maintenance, you may be exposed to hot sur-
faces, water pressure, or moving parts that can cause serious injury or death.
Risk of re hazard. Always disconnect spark plug wire, let engine cool, and release all
water pressure before performing any maintenance or repair. The engine contains ammable fuel.
Do not smoke or work near open ames while performing maintenance.
To ensure efcient operation and longer life of your pressure washer, a routine maintenance sched-
ule should be prepared and followed. If the pressure washer is used in unusual conditions, such as
high-temperatures or dusty conditions, more frequent maintenance checks will be required.
ENGINE
Consult the Engine Owners Manual for the manufacturer’s recommendations for any and all mainte-
nance. NOTE: The engine drain plug is located at the rear of the unit.
PUMP
The pump was lled with oil at the factory. The pump on this unit is maintenance free and requires
no oil. If there is a problem with the pump contact us at www.power-washer.us
Risk of unsafe operation. If engine does not start after two pulls, squeeze trigger of
gun to relieve pump pressure. Pull starter cord slowly until resistance is felt, then pull cord rapidly to
avoid kickback and prevent hand or arm injury.
11) Depress trigger on gun to start water ow.
Risk of unsafe operation. Stand on a stable surface and grip gun/spray wand rmly
with both hands. Expect the gun to kick when triggered.
12) Release trigger to stop water ow.
Risk of injury from spray. Always engage the trigger lock
Trigger Lock Engaged
when gun is not in use. Failure to do so can cause accidental spraying.
13) Adjust Variable Spray Wand for task, or change Quick Connect Nozzle
based on the task at hand.
SHUTTING DOWN YOUR PRESSURE WASHER
1) After each use, if you have applied chemicals, clean your chemical sys-
tem as described in How to Apply Chemicals / Cleaning Solvents section
on previous page.
Risk of Property Damage. Failure to clean chemical system could result in damage to
the pump.
2) Turn off the Engine. See Engine Owners Manual for complete details.
Risk of property damage. Never turn the water off with the engine running.
3) Turn off the water source.
4) Pull trigger on spray gun to relieve any water pressure in the hose or spray gun.
5) See Storage section in this manual for proper procedures.

14
NOZZLE CLEANING
If the nozzle becomes clogged with foreign materials, such as dirt, excessive pressure may develop.
If the nozzle becomes partially clogged or restricted, the pump pressure will pulsate. Clean the
nozzle immediately using the nozzle kit supplied and the following instructions:
1) Shut off the pressure washer and turn off the water supply.
2) Pull trigger on gun handle to relieve any water pressure.
3) Disconnect the spray wand from the gun.
4) Remove the high-pressure nozzle from the
spray wand. Remove any obstructions with the nozzle
cleaning tool provided, or a straightened paper clip,
and work back and forth until the obstruction is
removed.
5) Direct water supply into nozzle end to backush loosened particles for 30 seconds.
6) Reassemble the nozzle to the wand.
CLEAN THE WATER INLET FILTER
This screen lter should be checked periodically and cleaned if necessary.
Filter Screen
1) Remove lter by grasping end and removing it from water inlet of pump.
2) Clean lter by ushing it with water on both sides.
3) Re-insert lter into water inlet of pump.
NOTE: Do not operate the pressure washer without lter properly installed.
STORAGE
ENGINE
Consult the Engine Owners Manual for manufacturer’s recommendations for storage.
PUMP
The manufacturer recommends using a pump protector/winterizer when storing the unit for more
than 30 days and/or when freezing temperatures are expected. Pump protector/winterizer is usually
available at the store where the pressure washer was purchased. If a pump protector/winterizer is
not available, RV antifreeze needs to be run through the pump as outlined in the steps below.
NOTE: Using a pump protector/winterizer or RV antifreeze is to provide proper lubrication to the
internal seals of the pump regardless of temperature or environment.
1) Obtain a funnel, 6 ounces (170 mL) of RV Antifreeze, and a 16" to 36"
(40-91 cm) section of garden hose with a male hose connector
attached to one end.
Risk of Property Damage. Use only RV Antifreeze. Any
other antifreeze is corrosive
and can damage the pump.
2) Disconnect the spark plug wire.
3) Connect the length of garden hose to the water inlet of the
pump.
4) Add RV Antifreeze to hose as shown.
5) Pull starter rope slowly several times until antifreeze comes
out of the high pressure hose connection of the pump.
6) Remove garden hose from water inlet of pump.
7) Reconnect spark plug wire.

15
REPAIRS
To assure product SAFETY and RELIABILITY, repairs, maintenance, and adjustment should be per-
formed by an Authorized Warranty Service Center. Always use identical replacement parts. For the
location of the nearest Authorized Service Center go to www.power-washer.us
Recommended accessories for use with our pressure washer are available for purchase from your
local retailer or authorized service center. if you need assistance in locating any accessory for your
pressure washer, please go to www.power-washer.us
Risk of uid injection. When using replacement lances or guns with this pressure wash-
er, DO NOT use a lance and/or lance/gun combination that is shorter in
length than what was provided with this pressure washer as measured from the
nozzle end of the lance to the gun trigger.
The use of any other accessory not recommended for use with this tool could be haz-
ardous. use only accessories rated equal to or greater than the rating of the pressure washer.
ACCESSORIES
TROUBLESHOOTING GUIDE
PROBLEM CAUSE CORRECTION
Engine will not
start (see Engine
manual for further
troubleshooting).
No Fuel Add fuel.
Pressure builds up after two
pulls on the recoil starter or
after initial use.
Squeeze gun trigger to relieve pressure.
Choke level in the “No Choke”
position.
Move choke to the “CHOKE” position.
Spark plug wire not attached. Attach spark plug wire.
Engine Switch in the “OFF”
Position.
Place engine switch in “ON” Position.
Choke lever in the “CHOKE”
position on a “hot” engine
or an engine that has been
exposed to thermal heat for a
long period of time.
Move choke to the “NO CHOKE” position.
PRESSURE WASHER
1) Drain all water from high pressure hose, coil it, and store it in cradle of the pressure washer
handle.
2) Drain all water from the spray gun and wand by holding spray gun in a vertical position with nozzle
end pointing down and squeezing trigger. Store in gun holder.
3) Store chemical hose, if so equipped, so it is protected from damage.

16
TROUBLE SHOOTING GUIDE (continued)
PROBLEM CAUSE CORRECTION
No or low pressure
(initial use).
Continued on next
page.
Spray Wand not in High
Pressure Position.
See How to Use Spray Wand instructions.
Low Water Supply. Water Supply must be at least 5 GPM and
20 PSI.
Leak at high pressure hose
tting.
Repair Leak. Apply sealant tape if
necessary.
Nozzle Obstructed. See Nozzle Cleaning instructions.
Water Filter Screen Clogged. Remove and clean lter.
No or low pressure
(initial use).
Air in hose. Turn off the engine, then the water source.
Disconnect the water source from the
pump inlet and turn the water source on to
remove all the air from the hose. When a
steady stream of water is present, turn the
water source off. Re-connect water source
to pump inlet and turn on water source.
Squeeze trigger to remove remaining air.
Choke in the “CHOKE”
Position.
Move choke to the “NO CHOKE” position.
High pressure hose is too long. Use high pressure hose under 100 feet
(30m).
Will not draw
chemicals.
Spray wand not in low
pressure.
See How to Use Spray Wand section.
Chemical lter is clogged. Clean lter.
Chemical screen not in
cleaning solution.
Make sure end of chemical hose is fully
submerged into cleaning solution.
Chemical is too thick. Dilute chemical. Chemical should be the
same consistency as water.
Pressure hose is too long. Lengthen water supply hose instead of high
pressure hose.
Chemical build up in chemical
injector.
Have parts cleaned or replaced by
Authorized Service Center.
No or low pressure
(after period of
normal use).
Worn seal or packing. Have parts cleaned or replaced by
Authorized Service Center.
Worn or obstructed valves. Have parts cleaned or replaced by
Authorized Service Center.
Worn unloader piston. Have parts cleaned or replaced by
Authorized Service Center.
Water leaking at
gun/spray wand
connection.
Work or broken o-ring. Check and Replace

17
PROBLEM CAUSE CORRECTION
Water leaking at
pump.
Loose Hose Connection. Tighten.
Loose Connections. Tighten.
Piston packings worn. Have parts cleaned or replaced by
Authorized Service Center.
Work or broken o-rings. Have parts cleaned or replaced by
Authorized Service Center.
Pump head or tubes damaged
from freezing.
Have parts cleaned or replaced by
Authorized Service Center.
Pump pulsates. Nozzle Obstructed. See Nozzle Cleaning paragraph in
MAINTENANCE section for the correct
procedure.
TROUBLE SHOOTING GUIDE (continued)

18
WARRANTY STATEMENT
At SIMPSON CLEANING SYSTEMS, we only distribute top quality industrial / commercial / person-
al pressure washers that are designed for light- and heavy-duty use, maximum reliability, durability,
and long life. Our pressure washers are built for their respective duty applications and steady use
due to higher quality levels.
The manufacturer of this product agrees to repair or replace designated parts that prove defective
within the warranty period listed in the chart below. Specic limitations/extensions and exclusions
apply, and are listed in the chart below. This warranty covers defects in material and workmanship
and not parts failure due to normal wear, depreciation, abuse, accidental damage, negligence, im-
proper use, maintenance, or storage. To make a claim under the terms of the warranty, all parts said
to be defective must be available or returned (if requested) to a SIMPSON CLEANING SYSTEMS
designated Warranty Service Center for warranty inspection. The judgments and decisions of the
Warranty Service Center concerning the validity of warranty claims are nal.
These warranties pass through to the end user. As a factory authorized and trained Warranty Ser-
vice Center the factory will honor the terms of all component warranties and satisfy claims of the
appropriate warranty provisions.
Normal wear items include, but are not limited to, Valves and Seals, which are not covered by this
warranty.
This Warranty replaces all other warranties, express or implied, including without limitation any
warranties of merchantability or tness for a particular purpose and all such warranties are hereby
disclaimed and excluded by the manufacturer. The Manufacturer’s warranty obligation is limited
to repair and replacement of defective products as provided herein and the Manufacturer shall not
be liable for any further loss, damages, or expenses – including damages from shipping, accident,
abuse, acts of God, misuse, or neglect. Neither is damage from repairs using parts nor purchased
from the manufacturer or alterations performed by non-factory authorized personnel. Failure to in-
stall and operate equipment according to the guidelines put forth in the instruction manual shall void
warranty.
This warranty does not cover the following: machines used for rental purposes, damage resulting
from shipping (claims must be led with shipping company), accident, abuse, act of God, misuse, or
neglect. Neither is damage from repairs or alterations performed by non-factory authorized person-
nel or failure to install and operate equipment according to the guidelines put forth in the instruction
manual.
The manufacturer will not be liable to any persons for consequential damage, for personal injury, or
for commercial loss.
SIMPSON WARRANTY CONTINUED ON NEXT PAGE

19
Warranty Period and Details for Specific Parts & Components
High Pressure Electric Axial Pumps:
One (1) year on pump & motor workmanship, defects, or material.
Warranty does not apply to failures on other pump parts due to:
• Freight damage
• Freeze damage
• Damage caused by parts or accessories not obtained from / or approved by SIMPSON
CLEANING SYSTEMS
• Normal wear of moving parts or components affected by moving parts
• Unltered Hard Water
High Pressure Gas Axial Pump:
One (1) year on pump workmanship, defects, or material.
Warranty does not apply to failures on other pump parts due to:
• Freight damage
• Freeze damage
• Damage caused by parts or accessories not obtained from / or approved by SIMPSON
CLEANING SYSTEMS
• Normal wear of moving parts or components affected by moving parts
• Unltered Hard Water
High Pressure Triplex Pump:
Five (5) years on pump workmanship, defects, or material.
Lifetime Warranty on the forged brass manifold.
This warranty is covered by the Triplex Pump Manufacturer’s Warranty (included with Pressure
Washer when shipped).
Warranty does not apply to failures on other pump parts due to:
• Freight damage
• Freeze damage
• Damage caused by parts or accessories not obtained from / or approved by SIMPSON
CLEANING SYSTEMS
• Normal wear of moving parts or components affected by moving parts.
Engine:
The engine warranty is covered under the terms and conditions as outlined by the engine manufac-
turer’s warranty (included with the owner’s manual) and is the sole responsibility of the engine manu-
facturer.
Machine Steel Frame:
One (1) year from date of rst start up.
Accessories:
Ninety (90) days. Includes tips, guns, wands, injectors, unloaders, hose reel, brushes, foamers,
GFCI units, thermal relief, lters, tanks, wheels, tires, etc.

20
SIMPSON© 2010, a division of The FNA Group. All Rights Reserved. In our effort towards Continu-
ous Improvement, specications are subject to change without notice.
Part Number 7104216
1825 Greenleaf Avenue Elk Grove Village, IL 60007 www.power-washer.us
2700
2.4
PREMIUM RESIDENTIAL
