Sinclair SDV5 Series Operating instructions

FULL DC INVERTER SYSTEMS
EXTENSION KIT SDV5-EK
COMMERCIAL AIR CONDITIONERS SDV5

1
2
3
4
5
12V DC
-10~60oC
24W
0~40oC
10~90%
6
7
890g
1
2
3
4
GND 12V
XYE（ODU）
XYE（CTR1）
XYE（CTR2）
Installation Method
Parameters
Installation and Operation
Manual of XYE Extension Kit
I. Structural Dimensions Unit: mm
Direction A
No. Name
XYE port for connecting to SDV5 refrigerant system
supports 8 refrigerant systems and 64 indoor units
XYE port for connecting to centralized controller
Extended 1-way XYE protocol interface
XYE port for connecting to centralized controller
Extended 1-way XYE protocol interface
Function Overview
Plastic expansion pipe
Wall
6 mm bit drilling,
bit depth not
less than 30 mm
12V DC power port
Specifications
No. Model
Power Supply
Specifications
Operation
Conditions
Voltage
Power
Ambient temperature
Ambient humidity
Storage temperature
MA-EK
Weight
Color
This Kit is used to extend the XYE port of outdoor unit as the 2-way one which can
connect to 2 centralized controllers or gateways.
225
128
95
28
209
Cross round head wood screw
GB950-86 M4X20
II. Installation Diagram
Gray
Port parameters

Operating Methods
For outdoor units, XYE Extension Kit is applicable to SDV5 VRF unit; for the centralized
controller and gateway solutions, XYE Extension Kit is applicable to CCM15,
GW-MOD, IMMP-BAC, GW-LON, CCM-180A, CCM-270A.
Debugging Help：
1. If the centralized controller or gateway cannot find the equipment, open the box lid and
check the LEDs for troubleshooting. Each communication terminal has a corresponding
LED. If the LED is flashing, it indicates that there is no problem with the connection.
Otherwise, check the connection.
2. If the device found is different from the actual machine, open the box lid and check the
digital display data. The digital display cyclically displays the number of IDUs and ODUs.
7
X Y E
X Y E
XY E
CTR1
X Y E
CTR2
X Y E
ODU
X Y E
Connection Diagram
Main ODU
IDU IDU IDU
CCM or GW CCM or GW
