Sine Audio SaiYin DS5101 User manual

EN
DS5101 / DS5102 / DS5103
V1.2 (2019) E-mail:[e-mail]
User Man ual
Mini Sound Bar
2.0 Channel Stereo
For PC monitors and small size TVs
by Sine Audio

> Important Notes
Before you use this sound bar, please follow the secure reminder below
in order to keep the product is safe to use.
1. Please use the charge equipment has output voltage less than 5.15V
and output current is more the 0.9A.
2. Please do not put this product in rain, moist , over high temperature
environment or under strong sunshine.
3. Please do not drop / throw / squeeze in case of product damage.
4. Do not let it touch benzol or thinner that chemicals have corrosivity.
5. Please do not use this product when you are riding a bike / motocycle
or driving a car.
6. Please charge this product over 4 hours before you begin your first
use because its battery is not full charged when this product is packaged
7. The battery’s working life is relevant to your charge time and its
operation environment, you can lengthen its working life by following the
advise below:
Please use this product at least on time every two weeks.
Please do not let the battery be in the state of power off, when you
are planning not to use the product you should charge this product at
lease one time every month.
Please keep the product far away from heat source ,strong magnetic
equipment and wireless transmitter, such as router.
Please charge this product when it is power off and not to charge it
frequently.
8. Please do not throw or burn this product when it is damaged, it
contains battery, throw it away without selecting location is harmful to
people’s health and environment, you should ask for the help of
authoritative local department. You can contact the local relevant
department to dispose this product according to the specific laws.

9. Please do not take apart this product by yourself, you can contact
seller or customer service if the product is under warranty.
10. Please charge this product with the supplied USB cable.
> Package Contents
1 X Sound bar
1 X User manual
1 X USB cable (Charging Cable)
1 X Audio cable
Note: Accessories are subject to change without notice.
> Features
2.0 channel stereo mini sound bar
2 full range drivers with 2 bass reflectors
Analog audio interface ( AUX input )
Play music from USB Thumb Drive and TF card
Stream music from smart phone or tablet
Fit for PC monitors and small size TVs
Built-in lithium ion battery
Support for hands-free
> Specifications
Power supply:
Output power :
Frequency response :
Signal to noise ratio :
Total harmonic distortion :
Audio format:
USB ( DC 5.0V 0.9A Max. )
Lithium ion battery ( 3.7V )
5W X 2 ( 10W ) DS5101 / DS5103
8W X 2 ( 16W ) DS5102
70Hz –20KHz
80dB ( A-weighting )
0.5% ( 20KHz LPF )
MP3 ( USB Thumb Drive / TF card )
Note: Specifications are subject to change without notice.

> FCC information
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:(1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changers or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of more of the following measure:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This
equipment should be installed and operated with minimum distance of
20cm from your body.
V1.2 Print In China (2019)

> Warranty information
The warranty period for this product is 12 months from the date of its
original purchase. If manufacturing defects occur, please contact your
dealer at the first time, we will instruct you on how to return the defective
unit back to us for repair or replacement.
The following are excluded from the Sine Audio warranty coverage:
Product over warranty.
Damage resulted from misuse and abusive action.
Damage resulted from chemical, fire, radioactive substance, and
poison, liquid.
Damage resulted from natural disaster.
> System Overview
>> Top View
1 2 3 4
5 6 7
1. Power / Play & Pause / Mute / Hook on & Hook off / Next track
2. Volume down / Fast volume down 3. Volume up / Fast volume up
4. Mode (source) / Previous track / Pairing / Repeat / Reject a call
5. Blue light
6. Microphone
7. Red light
>> Connector panel
Micro USB port
(For Charging)
TF Card slot
(MP3 Playing)
AUX in port
(Audio in)
USB port
(MP3 Playing)

> Using the System
>> Indicator light status
Red light
Charging
Stay solid
Full charged
OFF
Blue
light
AUX Mode
Stay solid
BT / USB / TF Mode
Flash
Pairing ( BT Mode )
Flash fast
Playing (BT/USB/TF Mode)
Flash slowly
Playing repeat 1 track
Intermittent flash
Pause / Mute
Intermittent double flash
>> Selecting a source
BT
Bluetooth, Connection to a Bluetooth Device.
USB/TF
Play music from USB thumb drive or TF card.
AUX
Auxiliary, Connection with a 3.5mm audio cable.
>> Button functions
M
Click
Mode ( source ) selection
Double click
Previous track (BT / USB / TF Mode)
Long press
Disconnect to pairing (BT Mode)
Long press
Repeat 1 track / all tracks (USB / TF Mode)
Long press
Reject a call ( incoming call )
－ / ＋
Click
Volume down / Volume up
Long press
Fast volume down / Fast volume up
Long press
Power on / Power off
Click
Play / Pause or Mute
Click
Hook off / Hook on ( incoming call )
Double click
Next track (BT / USB / TF Mode)

> Bluetooth function
>> External Bluetooth devices can be connected to the mini sound bar
via Bluetooth connection.
1. Press the M (Mode) button on the sound bar to enter the Bluetooth
mode. The blue light keeps flashing fast after the tone is heard.
2. Activate the Bluetooth function of the external device and search for
Bluetooth devices.
3. Select Sine Audio from the Bluetooth device list.
4. Follow the instructions shown on your device’s screen.
5. Play music form Bluetooth device.
>> Disconnecting the Bluetooth device:
Press M (Mode) button on the sound bar to enter other mode.
Disconnect using your Bluetooth device. The sound bar starts
searching for another Bluetooth device.
Long press the M (Mode) button on the sound bar about 2 seconds
to disconnect the current Bluetooth device. Long press about 2
seconds again to reconnect the current Bluetooth device.
Notes:
If you cannot pair your Bluetooth device, you may need to remove
the sound bar form the pairing list, and try pairing again.
Bluetooth works best within a range of up to 33 feet (10 meters).
The music streaming may be interrupted by obstacles between the
Bluetooth device and sound bar, such as walls, metallic casing that
covers the device, or other devices nearby that operate in the same
frequency.
If the connected device goes out of Bluetooth range, the system will
reconnect automatically when the device comes back within range.

> Troubleshooting
1. No power or no sound
Long press the power button to turn on the sound bar.
Battery is low power, please charge in time, and check the USB cable
(charging cable) is properly connected to the USB Port.
Short press the power button to Play music or restore sound.
Ensure that the source device has correct volume settings and is
playing a track.
2. Poor audio quality
Try with different source devices.
Bring the Bluetooth device closer to the sound bar and make sure
that no obstacles are disturbing the connection.
Ensure that the cables connected to the source devices are correctly
plugged in and the plugs are fully inserted.
Reduce the volume of your source device.
3. Bluetooth device cannot be connect to the sound bar
Bring the Bluetooth device closer to the sound bar.
Switch off your device and / or sound bar, then back on, repeat the
pairing process.
Make sure the sound bar is not connected another Bluetooth device.
Make sure that you have selected Sine Audio from the Bluetooth
device list on your device.
Ensure you are using the correct device.
4. If the device is still not connected, try the following:
Remove the sound bar (Sine Audio) from the list of "paired devices"
on your phone / tablet.
Turn the sound bar off and then on again.
Pair it again with your phone/tablet. It should now successfully
establish the pairing.
