Pheanoo D6 User manual
Model: D6
READ
ME FIRST
Quick Start Guide
Everything you need to know about setting up included
CHECKING THE COMPONENTS
1
POWER YOUR SYSTEM
4
Subwoofer x 1
Soundbar x 1
User manual x 1Remote control x 1 Quick Start Guide x 1Screws bagx 1
HDMI(ARC) cable x 1 3.5mm to RCA audio cable x 1
Quick
Start Guide
User manual
Mounting template x 1
Turning On
“Batteries not included for shipping safety. Two AAA batteries needed”
5CHOOSE INPUT MODE
Select the soundbar input mode by pressing the TV ARC, AUX, OPT, and
BT mode button on the remote control
BT mode
AUX mode
TV ARC mode
OPT mode
Option 1 (Preferred) : HDMI ARC
Option 3 : AUX
Option 2 : OPTICAL
BLUETOOTH CONNECTION
TV CONNECTION
INPUT MODE INDICATORS
LED Indicators are located here
3CONNECTING A TV
HDMI ARC PORT ONLY
OPTION 1 (Preferred) : HDMI ARC
If the TV has an ARC (Audio Return Channel)label
on one of its HDMIports, connect the HDMI cable to
your TV’s HDMI ARC jack and the soundbar’s
TV(ARC) jack.
HDMI connection is unavailable if your TV does not have a HDMI port labeled “ARC”
Connecting via HDMI(ARC) enable the following functions using the TV’s remote
control:
– Turn the power on and off
Both the TV and the sound bar turn on/off at the same time.
– Volume adjustment
The sound bar’s volume can be adjusted when the TV’s audio output is set to the
sound bar.
NOTE
Input mode on soundbar needs to match the connected external device (TV, Projector, Cable box, etc.) output mode.
Make sure LED light on soundbar matches TV connection method.
NOTE
6CHANGE AUDIO SETTINGS ON YOUR TV
TV
1. Only Option 1: HDMI ARC connections needs to enable CEC
2. These are names different brands might use for HDMI-CEC: Samsung(Anynet+++), Vizio(CEC),
Sony(Bravia Sync), LG(SimpLink), Sharp(Aquos Link), Philips (EasyLink), Roku(1-Touch Play)
NOTE
2.Enable Consumer Electronics Control
(CEC) on your TV(Exclusive for Option 1: HDMI ARC connection)
Continued on back page
7CONTROL YOUR SOUNDBAR
7a. Top panel
7b. Remote control
Long Press 3 Seconds---Power On/Off
Short Press 1 Second---Switch Input Source
Volume Down Volume Up
2
OPTION 3 : AUX
If the TV has no ARC label on its HDMI ports, connect
the 3.5mm to RCA audio cable to your TV’s AUDIO
OUT jack and the soundbar’s AUX jack.
Make sure that the cable ends match the color of the ports.
Some TV models have AUDIO IN jack only. it can’t deliver audio
signal to soundbar.
NOTE
OPTION 2 : OPTICAL
If the TV has no ARC label on its HDMI ports,
connect the optical cable to your TV’s OPTICAL
OUT jack and the soundbar’s OPTICAL jack.
If you hear audio coming from TV’s internal speaker, make sure TV
speaker off or min volume
NOTE
SOUNDBAR ASSEMBLE DETAILS
Wall brackets x 2
Adapter x 1
1. POWER
Turns on the Sound Bar or sets it to standby mode.
2. MUTE
Turns off the sound temporarily
3.TREB+
Increase treble level
4.TREB-
Decrease treble level
5. VOL+
Increase volume
6. VOL-
Decrease volume
8. BASS+
Increase bass level
9. BASS-
Decrease bass level
7. RESET(PLAY/PAUSE)
Start, pause or resume play in BT Mode Press and
hold for about 2 seconds to reset the volume
level and switch to the Music EQ effect.
10. MUSIC
Selects MUSIC for the sound effect
11. MOVIE
Selects MOVIE for the sound effect
12. DIALOGUE
Selects DIALOGUE for the sound effect
13. INDICATOR
Press to turns on/off the indicators on the Bar Speaker.
14. TV ARC
Set the input source for the Soundbar to HDMI ARC mode
15. BT
Set the input source for the Soundbar to Bluetooth mode
16. AUX
Set the input source for the Soundbar to AUX mode
17. OPT
Set the input source for the Soundbar to Optical mode
STEP 1: Plug the audio connector
into the audio input port on
another main unit
STEP 2: Align the arrows on the
two stickers
STEP 3: Twist clockwise about 20
degrees until locks securely
STEP1 STEP2 STEP3
Very Important!!!
!
RL
AUDIO OUT
DIGITAL AUDIO
OUT
OPTICAL
AUX
HDMI IN
ARC
TV(ARC) OPTICAL
OR OR
9
1. Press the (Bluetooth) button on the Soundbar (or remote
control unit) until the Bluetooth LED blinks in blue.
2. Go to the Bluetooth settings on your device and make sure
Bluetooth is turned ON.
3. Select “D6”.
•The Bluetooth LED turns solid blue to indicate that the Sound-
bar is being paired with your Bluetooth device
BLUETOOTH CONNECTION (OPTIONAL)
1
Bluetooth ON
2
D5
3
TROUBLESHOOTING
10
Bluetooth A device cannot
connect with the
SoundBar The SoundBar is already connected with another Bluetooth device. Disconnect the
connected device, then try again.
You have not enabled the Bluetooth function of the device. See the user manual of the
device on how to enable the function.
Distorted sound orlf you play audio from the TV through the SoundBar, make sure that the
TV is muted.
ISSUES PROBLEMS SOLUTIONS
Sound
No sound from
SoundBar speakers
Distorted sound
or echo
1. Make sure that the soundbar is plugged into a power source
2. Make sure the soundbar’s HDMI cable is inserted into an HDMI ARC or Audio Return
Channel connector on your TV, not a standard HDMI connector.
3. If the soundbar is connected to your TV’s HDMI ARC connector, make sure that
Consumer Electronics Control (CEC) is enabled in your TV system menu. Your TV may
refer to CEC by a different name. Refer to your TV owner’s guide.
4. On the remote control, select the correct audio input.
5. Ensure the audio output format is set to PCM
8
FIRMWARE UPDATE
1 1
Occasionally, PHEANOO provides important firmware updates for your soundbar. Updating the
firmware on your soundbar gives you all the benefits of the latest improvements. If an update is
available from PHEANOO, you can download it onto a USB device, and then upload it to your
soundbar.
IMPORTANT
Mounting your PHEANOO D6 Sound Bar
2.Paste the EVA foam A (with
holes) on the wall bracket
1.Remove the 2 screws from
the main unit
3.Install the wall bracket into
the main unit
7.Hang the soundbar on the wall
4.Mark the wall
wall
wall
wall
1
2
5. Drill screw holes at markings
Insert the wall anchors
Insert the screws into the wall anchors
1
2
3
3
6.Paste the EVA foam B (without
holes) on the wall brackt
EVA foam A
EVA foam B
bracket
Recommended USB 2.0 Drives
PC/MAC
Step 1. Preparing the USB Drive
1. Important Specs for USB Drive:USB2.0; Max Drive Size:32GB
2. Plug anUSB driveinto your PC / Mac
3. Reformat the USB drive to"FAT16"or"FAT32"format.
Step 2.
Download the Firmware Version from www.pheanoo.com/firmware.html
A. Download the “D5 FIRMWARE” B. Unzip the download file
C. Open the folder to locate “fw5000.upd”
firmware files
D. Copy and Paste the “fw5000.upd” files into your USB drive.
Do not change the name of the files
(Do not copy the folder or the update will not work)
Step 3. Press the Power on button on your remote control
Power on the soundbar
Step 4. Plug USB Drive into USB Port
Back of PHEANOO soundbar
Step 5. Upgrading the Soundbar
Soundbar will automatically start upgrading after
the USB drive is inserted .
The front indicator on the soundbar will be Purple
while upgrading.
After the upgrading completed, The front indicator
will change to RED .
Then unplug the soundbar from wall outlet and
remove the USB Drive.
USB
(FOR UPGRADE ONLY)
USB
(FOR UPGRADE ONLY)
1 2
43
1. Only drives with these specs will work:USB2.0;Max Drive Size: 32GB.
2. Do notremove USB drive or turn off your Soundbar while upgrading.
* If soundbar system does not work after the firmware upgrade, please contact our support
immediately at[email protected]
