Singer VITA COOK AF-4640 User manual

VITA COOK AF-4640
Aerofryer Oven
Φριτέζα Αέρος & Φουρνάκι
GB INSTRUCTION MANUAL
GR ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
ºC
Mi
Min

2
ENGLISH
SAFETY INSTRUCTIONS
Before use make sure to read all of the below instructions in order
to avoid injury or damage, and to get the best results from the
appliance. Make sure to keep this manual in a safe place. If you
give or transfer this appliance to someone else make sure to also
include this manual.
In case of damage caused by user failing to follow the instructions
in this manual the warranty will be void. The manufacturer/
importer accepts no liability for damages caused by failure to
follow the manual, a negligent use or use not in accordance with
the requirements of this manual.
1. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.
4. Keep the appliance and its cord out of reach of children less
than 8 years.
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
6. Regarding the instructions for cleaning the surfaces
which come in contact with food or oil, please refer to the
paragraph “CLEANING AND MAINTENANCE” of the manu
al.
7. This appliance is intended to be used in household and similar
applications such as: staff kitchen areas in shops, offices and
other working environments; farm houses; by clients in hotels,

3
ENGLISH
motels and other residential type environments; bed and
breakfast type environments.
8. This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
9. Before inserting the plug into the mains socket, please check
that the voltage and frequency comply with the specifications
on the rating label.
10. Always plug the appliance into an earthed plug socket.
11. Disconnect the mains plug from the socket when the appliance
is not in use and before cleaning.
12. If an extension cord is used it must be suited to the power
consumption of the appliance, otherwise overheating of the
extension cord and/or plug may occur. There is a potential risk
of injuries from tripping over the extension cord. Be careful to
avoid dangerous situations.
13. Ensure that the mains cable is not hung over sharp edges and
keep it away from hot objects and open flames.
14. Do not immerse the appliance or the mains plug in water or
other liquids. There is danger to life due to electric shock!
15. To remove the plug from the plug socket, pull the plug. Do not
pull the power cord.
16. Do not touch the appliance if it falls into water. Remove the
plug from its socket and send it to an authorized service center
for repair.
17. Do not plug or unplug the appliance from the electrical outlet
with a wet hand.
18. Never attempt to open the housing of the appliance, or to
repair the appliance yourself. This could cause electric shock.
19. Never leave the appliance unattended during use.
20. This appliance is not designed for commercial use.
21. Do not use the appliance for other than intended use.

4
ENGLISH
22. Do not wind the cord around the appliance and do not bend it.
23. Place the appliance on a stable, level surface from which it
cannot fall off.
24. Please prevent the product to be exposed to excessive dirt
and humidity.
25. Clean the product itself with a slightly damp cloth.
26. Do not operate the machine without supervision, if you should
leave the workplace, always switch the machine off or remove
the plug from socket (pull the plug itself, not the lead).
27. Do not place the appliance against a wall or against other
appliance. Leave at least 10cm free space on the back and
sides and above the appliance.
28. During hot air frying, hot steam is released through the air
outlet openings. Keep your hands and face at a safe distance
from the steam and from the air outlet openings. Also be
careful of hot steam and air when you remove the basket from
the appliance.
29. Immediately unplug the appliance if you see dark smoke
coming out of the appliance. Wait for the smoke emission to
stop before you remove the basket from the appliance.
30. Make sure before each use of the appliance that the heating
element and surroundings are clean and clear from any food
remainders in order to ensure a flawless function.
31. WARNING!! Caution, hot surface.
Please do not touch surface while in use. The temperature
of accessible surfaces may be high when the appliance is
operating.
32. Hot air comes out of the air vent at the back side of the
appliance. Be sure to keep sufficient distance to materials, like
glass, that are sensitive to heat.

5
ENGLISH
SERVICE & REPAIR
1. For service or repair under warranty, please contact the authorized service
company that is mentioned on the guarantee card that accompanies the
product.
2. Do not operate any product with a damaged cord or plug. If the supply
cord is damaged, return the appliance to a SINGER service center for
examination repair or adjustment. Do not attempt to dismantle any part of
the appliance. This should only be done at an authorized SINGER service
centre.
3. The partial or total non-respect of the safety instructions in the present
instruction manual will automatically release Singer of any type of
responsibility in case of malfunction of the machine or injuries to persons
or animals.
4. In case of manipulation, repairing or any modification of the machine
made by unqualified persons or in case of improper use, the guarantee
will be automatically cancelled.

6
ENGLISH
PARTS DESCRIPTION
1. Main unit
2. Display
3. Handle rotating basket
4. Rotating basket
5. Removal tool handle
6. Baking rack (3 x)
7. Fat collecting tray
control panel
1. Led display
2. Temperature indicator
3. Working indicator
4. Time indicator
5. Temperature +
6. Temperature -
7. Mode indicators
8. Light button
9. Power button
10.Rotating button
11.Preheat button
12.Time -
13.Time +
1 3 2
4
7
5
6
ºC
Min
1
89 10
11 12
13
7
2
4
5
6
3

7
ENGLISH
BEFORE THE FIRST USE
• When the device is turned on for the first time, a slight odour will occur. This
is normal, ensure adequate ventilation. This fragrance is only temporary
and will disappear soon.
• Remove all packaging material.
• Remove any stickers or labels from the appliance.
• Wipe the inside and outside of the appliance with a moist cloth.
Fat collecting/baking tray
• Always place the fat collecting tray in the lower rails of the cooking space
to collect dripping fat, food residues or crumbs. It can also be used as a
baking tray by placing food on it, place the baking tray in the middle rails.
Removal tool
• Use the removal handle to take
out the rotating basket from
the cooking space by pressing
the handle and secure it in the
handle holder.
• Lift the rotating basket gently
out of the cooking space and
put it on a heat-resistance
surface.
Rotating basket
• The rotating basket can be used
to prepare chips or other potato
products, pieces of vegetables,
meat and frozen products like
chicken nuggets or squid rings.
• Don’t overfill the basket with
ingredients, if it’s to full, the food
will not cook evenly.
• Close the basket and ensure that
it is shut correctly so that it can’t
open during use.
3
1
2
1
2
3

8
ENGLISH
• Toggle the red switch to the right. Insert the left side of the rotating basket
into the cooking space. To do this, plug the left end of the shaft as far as it
will go into the round holder on the left side of the cooking space into the
lock position.
• Then hang the right end of the shaft into the support on the right side of
the cooking space.
• Release the switch to lock the basket into place.
• Check if it is placed correctly.
Baking racks
• The baking racks are slid onto the rails in the cooking space.
• The heating element is located at the top of the cooking space.
• The higher a rack is placed, the more intense the heat is from above.
• In the upper part, the food is cooked faster and crispy.
• The middle position can be selected to achieve uniform heating from all
sides.
• The bottom rails are suitable for gentle cooking.
USE
• Put the mains plug in an earthed wall socket.
• Open the door.
• If the fat collecting tray is not to be used as a baking tray, slide it into the
lowest rails of the cooking space
• Select a suitable accessory for the food to be prepared.
• Process the food and place it on or in the accessory and attach this
accessory in the device.
• To attach and remove the rotating basket press the release button.
• Close the door.
• Press the on/off switch. The display will become active.
• Set the temperature and cooking time manually or choose between one
of the 10 programs.
• Manual setting:
• Touch the up or down symbol at the temperature setting to set the desired
temperature (lowest 80°C, highest 200°C).
• Touch the up and down symbol at the time setting to set the desired time(1
minute to 90 minutes).

9
ENGLISH
• Program setting:
• Activate the desired program by touching the program symbol, it’s
activated when the symbol starts flashing.
• Touching the same symbol again will cancel the selection.
• See for presetting information the table below:
Program Program Default temperature/
time Quantity
Aerofryer Fries *1 200°C/25 min 500g
Homemade Fries *2
Proposed time
120°C/10min
200°C/25min
500g
Roast 180°C/20min 200g
Fish 180°C/20min 200g
Shellfish/Crustaceans 180°C/15min 250g
Pizza 180°C/10min 1 pcs
Frozen pizza Proposed time
180°C/15min 1 pcs
Chicken 180°C/25min 500g
Bake 160°C/40min 1 pcs
Rotisserie 190°C/30min 200g
Dehydrating 30°C/4hours 250g
Reheat 115°C/12min

10
ENGLISH
Extra information:
• *1: When using the rotating frying basket, suitable up to 500g fries. When
using the 3 grill racks, suitable up to 750g. (Shake every 5 minutes)
• *2: Add 1/2 a tablespoon of oil. When using the rotating frying basket,
suitable up to 400g fries. When using the 3 grill racks, suitable up to 600g.
(Shake every 5 minutes)
• The cooking time depends on the thickness of the food. Times can also
vary due to the quantity and consistency of the food. The time settings
are only guidelines and can be adapted to your taste. Double the time for
tough meat and extend the time by at least 20% for deep-frozen food.
• Make sure that meat and poultry are thoroughly cooked before serving.
• To change the temperature or cooking time of a selected program, touch
the temperature and time setting buttons, the same as for manual setting
and set a new value.
• Successively illuminating operating lamps indicate that the device is
operating. If operation is interrupted, they flash.
• If the rotating basket is in use, touch the button to start the rotating
function. Touching the button again will stop the rotating function.
• Switch on the light pushing the button to check the condition of the
food during use or open the door, the light will switch on and the operation
is interrupted automatically. Operation is resumed once the door is closed
again.
• After the cooking time has elapsed, the device switches off automatically
and it will give a beep sound. If the device must be stopped prematurely,
press the on / off switch. To switch the device off completely, press and
hold the on / off switch until the display goes out.
• Open the door and take the cooked items out of the device.
Always use oven gloves and use the removal handle/tool to take out the
accessories.
• After use, remove the mains plug from the wall socket.
• Allow the used accessories and device to cool down and then clean them.
CLEANING AND MAINTENANCE
• Before cleaning, unplug the appliance and wait for the appliance to cool
down.
• Never immerse the device in water or any other liquid. The device is not
