Singer FEATHERWEIGHT II 118 User manual

BUYER'S MODEL NO. 118 FACTORY MODEL ORIGINAL ISSUE FEBRUARY, 2004 SECTION ----
REFER TO IMPORTANT NOTICE BELO
W
P.NO.77339
PARTS LIST
FOR
IMPORTANT:
WHEN ORDERING THE PARTS
A
LWAYS CHECK THE SERIAL
NUMBER OF THE MACHINE.
FIRST DIGIT OF THE SERIAL
NUMBER MUST MATCH WITH
THE LAST DIGIT OF THE FACTOR
MODEL ABOVE.
FIRST DIGIT
CA11860,CE118S0
SERIAL
NO.
FACTORY
MODEL
0
×××××××
Model 118

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 35818 WASHE
R
FACTORY MODEL CA11860,CE118S0 60786 M4 SCRE
W
ORIGINAL ISSUE March, 2004 67447 M5 SCRE
W
77042 M4 PHILLIPS SCRE
W
81018 SHUTTLE SHAFT PLATE
81019 SHUTTLE SHAFT BASE
81314 EXTENSION TABLE
2
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 10963 E6 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 43389 WASHE
R
43390 WASHE
R
43930 SPRING PIN
64637 WASHE
R
66474 M5 SCRE
W
66725 M3 SCRE
W
67447 M5 SCRE
W
73472 COLLAR
79447 REAR COVER FIXING PLATE
81008 TAKE-UP LEVER CRAN
K
81009 BELT PULLEY
81057 NEEDLE BAR CRAN
K
81062 TAKE-UP LEVE
R
81063 CRANK SHAF
T
81064 SHAFT
81065 BLANCE
R
81082 BELT GUIDE PLATE
81097 BALL BUSHING
81098 SECURING PLATE
81099 SPRING GEA
R
81100 COLLAR
81101 TORSION SPRING
81102 CLUTCH
81103 HAND WHEEL SCRE
W
81135 MAIN SHAFT
81232 SCRE
W
81258 SCRE
W
81267 E9 CLIP-ON-WASHE
R
81315 HAND WHEEL
81332 BELT PULLEY
3
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 39817 SCRE
W
61222 M4 PHILLIPS SCRE
W
64653 M3 SCRE
W
66725 M3 SCRE
W
67232 NEEDLE
77042 M4 PHILLIPS SCRE
W
80046 EXTENSION SPRING
81004 SUPPORT BUSH
81005 SUPPORT FIXING PLATE
81006 COLLAR
81007 STOPPER
81010 PIN
81011 SUPPORT CONNECTION PLATE
81012 SUPPORT CONNECTION SHAFT
81055 NEEDLE BA
R
81056 NEEDLE CLAMP
81058 NEEDLE BAR CLAMP
81061 NEEDLE BAR SUPPOR
T
81074 COMPRESSION SPRING
81075 THREADER SHAFT SET
81087 LEVER
81142 LIMITING PLATE
81144 BOBBIN WINDER COMPLETE
81145 RATCHET
81162 SUPPORT SHAFT
81191 EXTENSION SPRING
81192 THREADER ASSEMBL
Y
81215 TORSION SPRING
81216 NEEDLE CLAMP SCRE
W
81234 M3.5 HEX SCREW
81253 COLLAR
85061 PIN
85075 PIN
4
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 67447 M5 SCRE
W
ORIGINAL ISSUE March, 2004 68891 WASHE
R
76250 PRESSER FOOT HOLDE
R
77035 M4 PHILLIPS SCRE
W
79456 NEEDLE PLATE
79491 SCRE
W
79495 ZIGZAG PRESSER FOOT
81013 IDLER UNIT
81021 RELEASE LEVE
R
81024 SHUTTLE RACE COVE
R
81053 PRESSER BA
R
81066 IDLER BRACKE
T
81092 COMPRESSION SPRING
81133 PRESSER BAR HOLDER
81134 PRESSER BAR BLOC
K
81202 TIMING BELT
81256 SCREW FOR SHAN
K
81257 SET SCRE
W
81333 THREAD GUIDE
81334 SHUTTLE COVER SPRING PLATE
81373 M2 SCRE
W
81374 SCRE
W
5
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1520 E3 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 43389 WASHE
R
ORIGINAL ISSUE March, 2004 62215 M4 NUT
66725 M3 SCRE
W
77042 M4 PHILLIPS SCRE
W
81003 STUD SCRE
W
81042 CHECK SPRING GUID
E
81091 PRESSER FOOT LIFTER
81093 TENSION SHAFT FIXING PLATE
81094 THREAD TENSION SHAF
T
81095 COMPRESSION SPRING
81096 COMPRESSION SPRING
81136 THREAD TENSION BASE
81137 TENSION RELEASE LEVE
R
81138 TENSION RELEASE LEVE
R
81139 TENSION SPRING BASE
81161 SHAFT
81179 THREAD GUIDE PLATE
81188 GUIDE PLATE
81189 SLIDE SCRE
W
81209 CHECK SPRING
81228 TENSION PLATE
81239 M3.5 SCRE
W
81240 M3 SCRE
W
81241 M3 SCRE
W
81250 TENSION PLATE
81316 DIAL
81317 DIAL RING
81324 THREAD GUIDE PLATE
81358 WASHE
R
85075 PIN
6
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 10963 E6 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 43393 WASHE
R
ORIGINAL ISSUE March, 2004 56858 M2 PHILLIPS SCRE
W
61221 M4 PHILLIPS SCRE
W
64637 WASHE
R
66725 M4 SCRE
W
67251 M3.5 SCRE
W
67444 COLLAR
67447 M5 SCRE
W
76281 BOBBIN
81014 SHUTTLE RACE
81015 WASHE
R
81016 SHUTTLE RACE SHAFT
81017 BOBBIN CASE
81025 BOBBIN CASE STOPPE
R
81026 SPRING PLATE
81027 BOBBIN CASE LIMITING PLATE
81028 BALL BUSHING
81029 BEVEL GEA
R
81030 FEED-DOG LIFTING CAM
81031 LOWER SHAFT BELT GEAR
81068 LOWER SHAFT
81105 SECURING PLATE
81125 WASHE
R
81185 FEED-DOG FEEDING CAM
81232 SCRE
W
85075 KNOCK PIN
7
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 59221 WASHE
R
ORIGINAL ISSUE March, 2004 66474 M5 SCRE
W
66725 M4 SCRE
W
76111 HEADED PIN
76197 HEADED PIN
81034 FEED DOGS
81035 FEED DOG BASE
81036
A
DJUSTING SCRE
W
81037 SHAFT
81038 FEED REGULATING BRACKE
T
81039 FEED REGULATING SHAFT
81040 FEED REGULATING ARM
81041 FIXING PLATE
81043 SPRING
81044 FEED REGULATING LINK L.
81045 PIN
81046 FEED REGULATING LINK R.
81047 BALL BUSHING
81049 TORSION SPRING
81054 COLLAR
81069 HORIZONTAL FEED SHAFT
81105 SECURING PLATE
81232 SCRE
W
81244 SCRE
W
81254 SCRE
W
85075 KNOCK PIN
8
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 1615 WASHE
R
2206 WASHE
R
8400 E5 CLIP-ON-WASHE
R
9122 WASHE
R
28735 CRINKLE WASHE
R
31246 WASHE
R
32316 WASHE
R
43392 WASHE
R
46411 SPRING WASHE
R
61222 M4 PHILLIPS SCRE
W
61381 CRINKLE WASHE
R
62215 M4 NUT
66318 M4 SCRE
W
66727 HEX SCRE
W
67447 M5 SCRE
W
72858 WASHE
R
76482 WASHE
R
77042 M4 PHILLIPS SCRE
W
77403 SCRE
W
79411 SELECTOR CAM BASE
79412 PATTERN INDICATOR SUPPOR
T
79413 FEED LEVER
79414 OPERATING ARM
A
79416 OPERATING ARM B
79417 SPRING
79418 SHAFT
79425 OPERATING PLATE
79433 BELT ADJUSTMENT PLATE
79434 SHAFT
79435 GEAR SHAFT
79436 SHAFT
79440 HORIZONTAL SHAFT LINK PLATE
79442 SUPER CHANGE LEVER
79445 M4 SHOULDER SCRE
W
79448 OPERATING ARM A ASS
Y
79450 NOTCHED SPRING
79458 OPERATING ARM
79459 PATTERN SELECTING DIAL
79464 DIAL INDICATO
R
79469 BEVEL GEA
R
79473 BELT
79478 PATTERN DIS
K
79479 SEAL
81337 BEVEL GEA
R
9
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1504 E7 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 1513 E4 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 1520 E3 CLIP-ON-WASHE
R
8400 E5 CLIP-ON-WASHE
R
8466 WASHE
R
9122 WASHE
R
10963 E6 CLIP-ON-WASHE
R
58220 WASHE
R
61221 SCRE
W
61222 M4 PHILLIPS SCRE
W
61228 SCRE
W
61341 M4 SCRE
W
66318 M4 SCRE
W
66725 M3 SCRE
W
66727 M4 SCRE
W
68439 M4 NUT
73299 M4 TORQUE NUT
77042 M4 PHILLIPS SCRE
W
79401 FOLLOWER
79402 PATTERN CAM BASE
A
79403 PATTERN CAM BASE B
79404 FOLLOWER SUPPORT
79405 NOTCHED SPRING
79410 SHAFT
79419 SUPER CHANGE LIN
K
79421 SUPER CHANGE ARM
79423 LENGTH OPERATION PLATE
79424 LENGTH OPERATION LEVER
79432 SUPER CHANGE ASS
Y
79437 SUPER STITCH FOLLOWER
79438 FOLLOWER BASE
79443 SUPER LINK PLATE
79446 COLLAR
79449 COIL SPRING
79457 SUPER STITCH CAM
79466 PATTERN CAM
79467 PATTERN SELETION CAM
79468 CAM GEAR
81054 COLLAR
81256 SCRE
W
81338 SCRE
W
81340 PIN
81353 OPERATING PLATE
81354
A
DJUSTING PLATE
81355 SHAFT
81371 CAM BUSH
81375 WASHE
R
81376 M4 SCRE
W
81377 SPRING
81378 SCRE
W
10
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1513 E4 CLIP-ON-WASHE
R
FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 9122 WASHE
R
28735 CRINKLE WASHE
R
32949 WASHE
R
61222 M4 PHILLIPS SCRE
W
63805 WASHE
R
73299 M4 TORQUE NUT
77042 M4 PHILLIPS SCRE
W
77044 SCRE
W
77507 CLIP-ON-WASHE
R
79406 ZIGZAG GUIDE PLATE
79407 GUIDE LIN
K
79408 ZIGZAG CONTROL BLOCK
79427 ZIGZAG DIAL BASE
79429 GUIDE PLATE LINK
79439 ZIGZAG ADJUST PLATE
79451 EXTENSION SPRING
79452 M4 SCRE
W
79474 ZIGZAG DIAL
81050 ECCENTRIC SCREW
81127 M4 SCRE
W
81181 FIXING PLATE
81210 SHAFT
81231 SCRE
W
81343 PLATE
81345 REVERSE STITCH LEVE
R
81379 SPRING
11
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1520 E3 CLIP-ON-WASHE
R
FACTORY MODEL CA11860 10963 E6 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 43647 M3 SCRE
W
45849 WASHE
R
46411 WASHE
R
53735 WASHE
R
58741 CORD GUARD
61222 M4 PHILLIPS SCRE
W
63501 WASHE
R
67251 SCRE
W
76714 PULLEY
77041 UNITY FASTENE
R
77042 M4 PHILLIPS SCRE
W
77053 M3 SCRE
W
77524 GEAR CLUTCH
79430 TERMINAL BLOCK BRACKE
T
79431 INTERMEDIATE GEAR PLATE
79453 M4 CP BOLT
79454 M4 CP BOLT
79471 BELT
79472 BELT
79480 LAMP CORD UNI
T
79481 LIGHT BULB
79482 SWICTH ASSEMBL
Y
79483 MOTOR
(
120V
)
79485 TERMINAL BLOC
K
79486 M3 NUT
79487 M3 BINDING SCREW
79488 INSULATION PLATE
79489 CONNECTOR
79490 PLATE
79499 MOTOR PULLEY
81081 BELT GUIDE PLATE
81107 LAMP PLATE
81207 BULB COVER
81232 SCRE
W
81271 CP BOLT
81380 MOTOR SUPPORT
81383 TERMINAL COVE
R
12
SERIAL NO.
120V

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1520 E3 CLIP-ON-WASHE
R
FACTORY MODEL CE118S0 10963 E6 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 43647 M3 SCRE
W
45849 WASHE
R
46411 WASHE
R
53735 WASHE
R
54350 SEAL
58741 CORD GUARD
61222 M4 PHILLIPS SCRE
W
63501 WASHE
R
67251 SCRE
W
72924 LAMP HOLDER BRACKE
T
72925 CAP BOLT
72935 LIGHT BULB
72988 M4 BOLT WITH WASHE
R
73900 SCRE
W
74358 WASHE
R
76714 PULLEY
77041 UNITY FASTENE
R
77042 M4 PHILLIPS SCRE
W
77053 M3 SCRE
W
77524 GEAR CLUTCH
79430 TERMINAL BLOCK BRACKE
T
79431 INTERMEDIATE GEAR PLATE
79453 M4 CP BOLT
79454 M4 CP BOLT
79471 BELT
79472 BELT
79482 SWICTH ASSEMBL
Y
79485 TERMINAL BLOC
K
79486 M3 NUT
79487 M3 BINDING SCREW
79488 INSULATION PLATE
79489 CONNECTOR
79490 PLATE
79492 MOTOR
(
230V
)
79494 REFLECTING PLATE
79499 MOTOR PULLEY
79502 BRACKE
T
79503 LAMP PLATE
79504 LAMP CPRD
81081 BELT GUIDE PLATE
81232 SCRE
W
81271 CP BOLT
81380 MOTOR SUPPORT
81383 TERMINAL COVE
R
13
SERIAL NO.
230V

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1424 WASHE
R
FACTORY MODEL CA11860,CE118S0 1520 E3 CLIP-ON-WASHE
R
ORIGINAL ISSUE March, 2004 63271 NUT
68891 WASHE
R
73299 M4 TORQUE NUT
77042 M4 PHILLIPS SCRE
W
79444 COVER FIXING PLATE
79462 INDICATOR WINDO
W
79470 COVER FIXING PLATE
79476 CONTROL PANEL
81073 WASHE
R
81128 SPRING
81129 M4 SCREW
81131 SHAFT
81159 TENSION DISC BASE B
81160 SCREW
81174 BOBBIN WINDER LATCH
81178 REFLECTING SHEET
81180 DISC
81203 SPRING
81211 CUSHION
81238 M3.5 PHILLIPS SCRE
W
81241 M3 PHILLIPS SCRE
W
81242 M3.5 PHILLIPS SCRE
W
81243 M3.5 SCREW
81272 TENSION DISC BASE
A
81352 FACE COVE
R
14
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARK
S
PART #
DESCRIPTION
BUYER'S MODEL NAME 1424 WASHE
R
FACTORY MODEL CA11860,CE118S0 56858 M2 PHILLIPS SCRE
W
ORIGINAL ISSUE March, 2004 61224 M4 PHILLIPS SCRE
W
68891 WASHE
R
77042 M4 PHILLIPS SCRE
W
81073 TRUBBER FOOT
81104 PIN FIXING PLATE
81157 THREAD GUIDE
81158 GUIDE PLATE
81163 SPRING PLATE
81182 PIN FIXING PLATE
81211 CUSHION
81233 TAPPING SCRE
W
81241 M3 SCRE
W
81242 M3.5 SCREW
81243 TAPPING SCRE
W
81276 TAPPING SCRE
W
81322 SPOOL PIN
81323 HANDLE
15
SERIAL NO.

BUYER'S MODEL NO. 118 SECTION PAGE REVISION REMARKS
PART #
DESCRIPTION
BUYER'S MODEL NAME 51007
A
CCESSORY SET
FACTORY MODEL CA11860,CE118S0 63398 SEWING MACHINE OI
L
ORIGINAL ISSUE March, 2004 67233 NEEDLE SET
(
3 PCS
)
72959 FOOT CONTROL
(
120V
)
74793 SMALL SCREW DRIVE
R
76252 ZIPPER FOOT
76281 BOBBIN
76322 BUTTONHOLE FOOT
76757 DUST COVE
R
77151 INSTRUCTION BOOK
(
En
g
/Es
p
/Fra
)
79070 SPOOL PIN CAP
79455 LARGE SCREW DRIVER
79497 OVERCASTING FOOR
79498 STRAIGHT STITCH FOOT
85124 SPOOL PIN CAP
85365 BUTTONHOLE OPENER / BRUSH
77152 INSTRUCTION BOOK
(
En
g
/Ita/Ger
)
72962 FOOT CONTROL
(
230V
)
16
SERIAL NO.
