SingularXYZ T8 Pro User manual

T8 Pro
High Precision
Tablet Manual
V1.0, modified on 2021.12.04

Corporate Office
SingularXYZ Intelligent Technology Ltd.
Room 211, Floor 2, Building A, No. 599 Gaojing Road, 201702 Shanghai, China
Tel: [phone]
Fax: [phone]
Website: http://www.singularxyz.com
E-mail: [e-mail]
Trademark notice
© 2021 SingularXYZ Intelligent Technology
Ltd. All rights reserved.
SingularXYZ is the official trademark of SingularXYZ Intelligent Technology Ltd., registered in
People’s Republic of China, EU, USA and Canada.
FCC Notice
SingularXYZ
○
RT8Procomply with the limits for a Class B digital device, pursuant to the Part 15
of the FCC rules when it is used in the Portable Mode.
Operation is subject to the following twoconditions:
4 This device may not cause harmful interference;
5 It must accept any interference received, including interference that may
causeundesired operation.
Copyright Notice
This is the V1.0 (Dec, 2021) revision of the T8Pro User Guide. It cannot be copiedor
translated into any language without the written permission of SingularXYZ.
Technical Assistant
If you have any question and can't find the answer in this manual, please contact your local
dealer from which you purchased the T8Pro. Alternatively, request technical support from
SingularXYZ .Website: www.singularxyz.com or technical support email:
[e-mail] feedback about this Guide will help us to improve it with
future revisions.
Safety Information
Before using the Tablet, please make sure that you have read and understood this User Guide,
as well as the safety requirements.
4 Connect your devices strictly based on this UserGuide
5 Avoid falling to ground, or colliding with other items

T8 Pro High Precision Tablet Manual V1.0
3
6 Do not rotate GNSS antenna
7 Do not cover the radio, keep a sound ventilationenvironment
8 Change the cable if damaged
Related Regulations
The tablet contains integral Bluetooth wireless technology. Regulations regarding the use of the datalink
vary greatly from country to country. In some countries, the unit can be used without obtaining an end-
user license. But in some countries the administrative permissions are required. For license information,
please consult your localdealer.
Use and Care
The tablet can withstand the rough treatment that typically occurs in the field. However,the tablet is high-
precision electronic equipment and should be treated with reasonable care.
Warning and Caution
An absence of specific alerts does not mean that there are no safety risks involved. A Warningor Caution
information is intended to minimize the risk of personal injury and/or damage tothe equipment.
WARNING- A Warning alerts you to a potential risk of serious injury to your person and/or damage to the
equipment, because of improper operations or wrong settings of the equipment.
CAUTION- A Caution alerts you to a possible risk of damage to the equipment and/or data loss.
Warranty Notice
SingularXYZ does not warranty devices damage because of force majeure (lighting, high voltage or
collision). SingularXYZ does not warranty the disassembleddevices.

T8 Pro High Precision Tablet Manual V1.0
4
Content
1.1 About the T8Pro ................................................................................................................................................................ 5
1.2 T8Pro Features.................................................................................................................................................................. 5
1.3 Specifications......................................................................................................................................................................6
2.1 Basic supply kit ..................................................................................................................................................................7
2.2 Optional Choices............................................................................................................................................................... 7
3.1 Helix antenna........................................................................................................................................................................8
3.2 Geodetic antenna..............................................................................................................................................................8
4.1 SingularPad software..................................................................................................................................................... 9
4.1.1 Connection.............................................................................................................................................................. 9
4.1.2 Set work mode .................................................................................................................................................... 10
4.1.3 Survey and Stakeout........................................................................................................................................ 10
4.2 SingularSure + High Precision software ..................................................................................................11
4.2.1 Setup CORS connection or connect to your single Basestation...........................................11
4.2.2 Check satellites information and NMEA message..................................................................... 12
4.2.3 Send command to communicate with the integrated board................................................12
4.2.4 SingularSurv Software....................................................................................................................................13
4.3 Other 3rd Party GIS software......................................................................................................................... 13

T8 Pro High Precision Tablet Manual V1.0
5
Chapter 1
Introduction
1.1 About the T8Pro
Embedded with high precision GNSS module, the T8 Pro can simultaneously track all running and
planned constellations including GPS, GLONASS, BeiDou, Galilei, QZSS and Navic, providing centimeter
level positioning accuracy to satisfy the demands of most GIS applications.
1.2 T8Pro Features
Below is the T8Pro key features:

T8 Pro High Precision Tablet Manual V1.0
6
1.3 Specifications

T8 Pro High Precision Tablet Manual V1.0
7
Chapter 2
Packing Overview
This section provides overall T8Pro tablet parts list, including basic supplies and customized kits
based on yourrequirements.
2.1 Basic supply kit
Item Picture
T8Pro Tablet
Type-C Cable
Battery Charger
2.2 Optional Choices
Item
Helix Antenna
Geodetic Antenna (optional)

T8 Pro High Precision Tablet Manual V1.0
8
Bracket
Range Pole
Chapter 3
Installation and Setup
This section shows T8Pro installation in difference work mode, including use the helix antenna
and geodetic antenna.
3.1 Helix antenna
Below picture is about how T8Pro connect with Helix antenna. Then can conduct the position
collection work after fixed the helix antenna well. Suggest make the antenna head to sky.
3.2 Geodetic antenna
Below shows how T8Pro connect with the geodetic antenna. Use the provided cable make the
connections.

T8 Pro High Precision Tablet Manual V1.0
9
Chapter 4
Operation
4.1 SingularPad software
SingularPad can connect to internal OEM board and set work mode directly.
4.1.1 Connection

T8 Pro High Precision Tablet Manual V1.0
10
4.1.2 Set work mode
After connection, it will show a icon in the software as Rover, click and set CORS parameters: IP, Port, User,
Password and MountPoint. Finally remember apply it.
4.1.3 Survey and Stakeout
Then the status will get fixed, and you can start your work

T8 Pro High Precision Tablet Manual V1.0
11
4.2 SingularSurv + High Precision software
High-Precision software is designed to configure the correction for integrated GNSS board, and also for checking
information of the GNSS board, including satellites status, NMEA message, firmware version and more. Before you
start your work with SinglarSurv, you need to get single via High-Precision not SinglarSurv.
4.2.1 Setup CORS connection or connect to your single Basestation
--make sure you have put SIM card to the tablet, or connected with WiFi beforesetup.
Click Setup IP, input the IP address and Port for your server Select MountPoint from the list→ input the account
name and password →click CONNECT
After CORS configuration you will find the positioning status changed to FIX. And High-Precision software will
share the location to the tablet, which means when there has another software requests the location, it will get the
high accuracy location.

T8 Pro High Precision Tablet Manual V1.0
10
4.2.2 Check satellites information and NMEA message
Click Satellites and NMEA to check the corresponding information.
4.2.3 Send command to communicate with the integrated board.
Input the command for the board, click send command. Here take “log version” as example, you can getthe
firmware version information.

T8 Pro High Precision Tablet Manual V1.0
13
4.2.4 SingularSurv Software
Go SingularSurv, in Connection, select Controller GNSS, and click Connect. Then you can go toTopo
Survey to collect points.
4.3 Other 3rd Party GISsoftware
For GIS software which supports read the tablet location, all can work by T8 PRO high precision tablet.
Blow shows some samples of GIS software.
