SIP B13-13 User manual
60
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
Ref: 050716
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
1
Pillar Drill Range
01700 - 01708
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
2
59
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
F32-20 Floor Pillar Drill 400v - SIP Part No. 01708
Conforms to the requirements of the following directive(s), as indicated.
2006/42/EC Machinery Directive
2014/30/EU EMC Directive
2011/65/EU RoHS Directive
And the following harmonised standard(s), including:
EN 60204-1:2006+A1:2009
EN 12717:2001+A1:2009
EN 55014-1:2006+A2:2011
EN 55014-1:1997+A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
Signed:
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 16/05/2016.
DECLARATION OF CONFORMITY
58
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
B13-13 Bench Pillar Drill - SIP Part. No. 01700
B16-12 Bench Pillar Drill - SIP Part. No. 01701
B16-16 Bench Pillar Drill - SIP Part No. 01702
B20-16 Bench Pillar Drill - SIP Part No. 01703
F16-16 Floor Pillar Drill - SIP Part No. 01704
F20-16 Floor Pillar Drill - SIP Part No. 01705
F28-20 Floor Pillar Drill - SIP Part No. 01706
F32-20 Floor Pillar Drill 230v - SIP Part No. 01707
F32-20 Floor Pillar Drill 400v - SIP Part No. 01708
Conforms to the requirements of the following directive(s), as indicated.
2006/95/EC Low Voltage Directive
2006/42/EC Machinery Directive
2004/108/EC EMC Directive
2011/65/EU RoHS Directive
And the following harmonised standard(s), including:
EN 61029-1:+A11:2010
EN ISO 12100:2010
EN 60204-1+A1:2009
EN 12717+A1:2009
EN 55014-1+A2:2011
EN 55014-2+A2:2008
EN 61000-3-2+A2:2009
EN 61000-3-3:2008
EN 61000-3-11:2000
Signed:
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 16/05/2016.
DECLARATION OF CONFORMITY
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
8. Technical Specifications
11. Electrical Connection
13. Guarantee
14. Getting To Know Your Drill
16. Assembly Instructions
21. Operating Instructions
27. Maintenance
28. Troubleshooting
29. Exploded Drawing - 01700
30. Parts List - 01700
32. Exploded Drawing - 01701
33. Parts List - 01701
35. Exploded Drawing - 01702
36. Parts List - 01702
38. Exploded Drawing - 01703
39. Parts List - 01703
41. Exploded Drawing - 01704
42. Parts List - 01704
44. Exploded Drawing - 01705
45. Parts List - 01705
47. Exploded Drawing - 01706
48. Parts List - 01706
50. Exploded Drawing - 01707
51. Parts List - 01707
53. Exploded Drawing - 01708
54. Parts List - 01708
58. Declaration of Conformity
4
When using the pillar drill, basic safety precautions should always be followed to re-
duce the risk of fire, electric shock and personal injury.
Read all these instructions before operating the drill and save this user manual for fu-
ture reference.
The pillar drill should not be modified or used for any application other than that for
which it was designed.
It was designed to be fitted with a cutting tool attachment or driving tool attachment,
usually a drill bit or driver bit, to be used for drilling holes in various materials.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
KNOW YOUR PILLAR DRILL: Read and understand the owner's manual and labels af-
fixed to the drill. Learn its applications and limitations, as well as the potential hazards
specific to it.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite
accidents. Floors must not be slippery due to oil, water or sawdust etc.
DO NOT USE THE DRILL IN DANGEROUS ENVIRONMENTS: Do not use the pillar drill in
damp or wet locations, or expose it to rain. Provide adequate space surrounding the
work area. Do not use in environments with a potentially explosive atmosphere.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the drill.
57
NOTES
56
NOTES
5
STORE THE PILLAR DRILL SAFELY WHEN NOT IN USE: The pillar drill should be stored in a
dry, locked cupboard wherever possible and out of the reach of children.
WEAR THE CORRECT CLOTHING: Do not wear loose clothing, neckties, rings, bracelets,
or other jewellery, which may get caught in moving parts. Non-slip footwear is recom-
mended. Wear protective hair covering to contain long hair. Roll long sleeves up
above the elbow.
USE SAFETY CLOTHING / EQUIPMENT: Wear CE approved safety goggles at all times,
normal spectacles only have impact resistant lenses, they are NOT safety glasses. A
face or dust mask should be worn if the operation is dusty and ear protectors (plugs or
muffs) should be worn, particularly during extended periods of operation.
PROTECT YOURSELF FROM ELECTRIC SHOCK: When working with the pillar drill, avoid
contact with any earthed items (e.g. pipes, radiators, hobs and refrigerators, etc.). It is
advisable wherever possible to use an RCD (residual current device) at the mains
socket.
STAY ALERT: Always watch what you are doing and use common sense. Do not oper-
ate the pillar drill when you are tired or under the influence of alcohol or drugs.
DISCONNECT THE PILLAR DRILL FROM THE MAINS SUPPLY: When not in use, before ser-
vicing and when changing accessories such as drill bits etc.
AVOID UNINTENTIONAL STARTING: Make sure the switch is in the OFF position before
connecting the drill to the mains supply.
NEVER LEAVE THE DRILL RUNNING / CONNECTED WHILST UNATTENDED: Turn the drill off
and disconnect it from the mains supply between jobs. Do not leave the drill until it
comes to a complete stop.
DO NOT ABUSE THE MAINS LEAD: Never attempt to move the drill by the mains lead or
pull it to remove the plug from the mains socket. Keep the mains lead away from
heat, oil and sharp edges. If the mains lead is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order to avoid un-
wanted hazards.
CHECK FOR DAMAGED PARTS: Before every use of the drill, a guard or other part that is
damaged should be carefully checked to determine that it will operate correctly and
perform its intended function. Check for alignment of moving parts, free running of
moving parts, breakage of parts, and any other conditions that may affect its opera-
tion. A guard or other part that is damaged should be correctly repaired or replaced
by an authorised service centre unless otherwise indicated in this instruction manual.
Have defective switches replaced by an authorised service agent. Do not use the drill
if the switch does not turn it on and off.
KEEP ALL GUARDS IN PLACE: And in full working order.
MAINTAIN THE PILLAR DRILL WITH CARE: Keep bits sharp and clean for the best and
safest performance. Follow instructions for lubricating and changing accessories. All
extension cables must be checked at regular intervals and replaced if damaged.
Always keep the hand grip/s on the drill clean, dry and free of oil and grease.
USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or
SIP directly for recommended accessories. Follow the instructions that accompany the
SAFETY INSTRUCTIONS….cont
6
SAFETY INSTRUCTIONS….cont
accessories. The use of improper accessories may cause hazards and will invalidate
any warranty you may have.
REMOVE ADJUSTING KEYS AND WRENCHES: Form a habit of checking to see that keys
and adjusting wrenches are removed from the drill before every use.
SECURE THE WORKPIECE: Use clamps or a vice to hold the workpiece. This frees up
both hands to operate the pillar drill.
DO NOT OVERREACH: Keep proper footing and balance at all times.
USE THE RIGHT TOOL: Do not use the drill or attachment to do a job for which it was not
designed.
DO NOT FORCE THE PILLAR DRILL: It will do the job better and more safely at the rate
which it was designed.
DO NOT OPERATE THE PILLAR DRILL IN EXPLOSIVE ATMOSPHERES: Do not use the drill in
the presence of flammable liquids, gases, dust or other combustible sources. Drilling
operations may create sparks which can ignite the dust or fumes.
DO NOT EXPOSE THE PILLAR DRILL TO RAIN OR USE IT IN WET CONDITIONS: Water enter-
ing pillar drill will greatly increase the risk of electric shock.
HAVE YOUR PILLAR DRILL REPAIRED BY A QUALIFIED PERSON: The tool is in accordance
with the relevant safety requirements. Repairs should only be carried out by qualified
persons using original spare parts, otherwise this may result in considerable danger to
the user.
DO NOT dismantle, tamper with or use the drill without all guards fitted as this may be
dangerous and will invalidate the warranty.
Keep hands away from the path of the drill bit, never reach around the drill bit.
Make sure the drill bit is clear of the workpiece before the switch is turned on.
Allow the drill bit to run up to full speed before drilling.
Stop operation immediately if you notice anything abnormal.
Wait for the drill bit to stop completely and remove the plug from mains supply be-
fore servicing or adjusting the drill or changing bits.
Be alert at all times, especially during repetitive, monotonous operations. Don't be
lulled into a false sense of security. Drill bits can be extremely unforgiving.
Use of improper accessories may cause damage to the drill and surrounding area
as well as increasing the risk of injury.
Turn off the drill and wait for it to completely stop before moving workpiece or
changing settings or bits etc.
Do not modify the pillar drill to do tasks other than those intended.
When drilling, particularly hard items such as metal, use clamps to hold the work-
piece; To avoid injury, the work should never be held with the bare hands.
Secure the base of the drill to a work bench or the floor before using the pillar drill. If
the work is heavy or large and likely to cause the drill to tip over, use additional sup-
ports as appropriate under and around the workpiece.
55
PARTS LIST - 01708….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
67. Nut M5 WD01-00697 92. Nut WD02-00380
68. Microswitch holder WD01-00709 93. Washer M6 WD01-00702
69. Washer M6 WD01-00702 94. Screw (M6 x 12) WD02-00381
70. Spring washer M6 WD01-00707 95. Screw (10 x25) WD02-00382
71. Nut M6 WD01-00710 96. Casting WD02-00383
72. Cam assembly WD02-00368 97. Spindle pulley WD02-00384
73. Screw (M5 x 16) WD01-00838 98. Key WD02-00385
74. Washer WD01-00881 99. Spindle shaft WD02-00386
75. Protecting ring WD01-00839 100. Bearing 6007 WD02-00387
76. Pulley cover WD02-00369 101. Ring WD02-00388
77. Washer M8 WD01-00672 102. Circlip WD02-00389
78. Bolt (M8 x 10) WD02-00370 103. Screw (M4 x 60) WD02-00434
79. Clamp WD02-00371 104. Spring washer (M4) WD02-00435
80. Overload 5A WD02-00432 105. Washer (M4) WD02-00436
81. Lock washer WD02-00433 106. Washer WD02-00437
82. Eccentric shaft WD02-00374 107. Quill WD02-00393
83. Centre pulley WD02-00375 108. Bearing 51107 WD02-00394
84. Bearing 6202 WD01-00771 109. Spindle WD02-00395
85. Circlip WD01-00831 110. Arbor MT4 17823
86. Belt A686 WD02-00376 111. Chuck WD02-00396
87. Protecting ring WD01-00770 112. Chuck guard 75mm 68328
88. Clamp WD02-00377 113. Drift key WD01-00862
89. Mains lead WD01-00720 114. Switch WD02-00430
90. Tension spring WD02-00378 115. Label WD02-00438
91. Tension spring cover WD02-00379 116. Switch box WD02-00439
54
PARTS LIST - 01708
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00329 34. Lock handle WD02-00352
2. Column flange WD02-00330 35. Label WD02-00353
3. Spring washer M10 WD01-00795 36. Connection WD02-00354
4. Bolt (M10 x 35) WD02-00331 37. Pinion shaft WD02-00355
5. Crank handle WD02-00332 38. Indicator WD01-00897
6. Bolt (M6 x 12) WD01-00905 39. Screw WD02-00356
7. Circlip WD01-00742 40. Roll pin (5 x 25) WD01-00869
8. Worm shaft WD02-00333 41. Screw (M10 x 10) WD02-00345
9. Table support WD02-00334 42. Bearing 6005 WD01-00889
10. Worm pin WD02-00335 43. Warning label WD01-00685
11. Table WD02-00431 44. Roll pin (6 x 18) WD01-00760
12. Spring washer M20 WD02-00337 45. Belt tension handle WD02-00358
13. Bolt (M20 x 55) WD02-00338 46. Lock handle WD02-00359
14. Indicator WD01-00897 47. Circlip WD01-00816
15. Lock handle WD02-00339 48. Circlip WD01-00871
16. Angle label WD02-00340 49. Adjusting shaft WD01-00872
17. Worm gear WD02-00341 50. Shaft WD02-00360
18. Column WD02-00342 51. Washer M12 WD01-00819
19. Rack WD02-00343 52. Washer M10 WD02-00361
20. Hex. wrench 3mm WD01-00790 53. Nut M8 WD01-00687
21. Hex. wrench 4mm WD01-00737 54. Motor plate WD02-00362
22. Screw (M10 x 10) WD02-00345 55. Bolt (M8 x 30) WD02-00363
23. Hex. wrench M5 WD02-00397 56. Spring washer M12 WD01-00676
24. Hex. wrench M6 WD01-00861 57. Nut M12 WD01-00821
25. Rack collar WD02-00346 58. Motor WD02-00428
26. Screw (M6 x 12) WD01-00740 59. Grub screw (M8 x 10) WD01-00689
27. Handle knob WD02-00347 60. Motor pulley WD02-00365
28. Screw (M6 x 12) WD01-00740 61. Motor pulley key WD02-00366
29. Handle cap WD02-00349 62. Nut M10 WD01-00717
30. Screw (M8 x 20) WD01-00801 63. Belt A787 WD02-00367
31. Spring washer M8 WD01-00673 64. Microswitch WD01-00706
32. Handle WD02-00350 65. Washer M5 WD01-00881
33. Scale WD02-00351 66. Spring washer M5 WD01-00882
7
Remove the key from the chuck after adjustment.
Use only the chuck key provided by the manufacturer or a duplicate of it.
Appropriate personal protective equipment MUST be worn and MUST be designed
to protect against all hazards created. Severe permanent injury can result from
using inappropriate or insufficient protective equipment - Eyes in particular are at
risk.
Do not overload the tool. Allow the tool to operate at its optimum speed for maxi-
mum efficiency.
Always ensure that the accessories such as drill bits, as well as the drill are rated /
designed for use with required application, and are the bits are correctly and se-
curely fastened before connecting the tool to the mains supply.
The work must be clamped firmly while drilling. Any tilting, twisting or shifting results
not only in a rough hole but also increases the hazard, which could result in injury or
drill breakage. For flat work lay the piece on a wooden base and clamp it firmly
down against the table to prevent it from turning If the piece is of irregular shape
and cannot be laid flat on the table, it should be securely blocked and clamped.
Understand the operating environment; Before each use the operator should as-
sess, understand and where possible reduce the specific risks and dangers associ-
ated with the operating environment. Bystanders should also be made aware of
any risks associated with the operating environment.
SAFETY INSTRUCTIONS….cont
When using the pillar drill for certain operations, particularly during ex-
tended periods; ensure the operator as well as those in the area wear
ear protection.
When using the pillar drill always ensure the operator as well as those in
the area wear eye protection.
Some materials have the potential to be highly toxic; always wear a
face mask when operating the pillar drill.
CAUTION: The warnings and cautions mentioned in this user manual can not cover all possible
conditions and situations that may occur. It must be understood by the operator that common
sense and caution are factors which cannot be built into this product, but must be applied.
8
Part number 01700 01701 01702
Model B13-13 B16-12 B16-16
Input Voltage 230v ~ 50hz 230v ~ 50hz 230v ~ 50hz
Power 350 w 375 w 375 w
Speed Range 620-2620 rpm 300-2550 rpm 180-2770 rpm
Number of Speeds 5 12 16
Drill Bit Size 1.5-13 mm 3-16 mm 3-16 mm
Max. Drilling Capacity (mild Steel) 13 mm 16 mm 16 mm
Spindle Taper B16 B16 MT2
Table Size 160 x 160 mm 202 x 195 mm Ø 290 mm
Base Size 290 x 190 mm 340 x 210 mm 415 x 245 mm
Column Ø 46 mm 58 mm 72 mm
Swing 210 mm 260 mm 325 mm
Height 580 mm 840 mm 980 mm
Spindle Travel 50 mm 60 mm 80 mm
Collar Ø 40 mm 40 mm 55 mm
Max. Distance Chuck to Table 220 mm 405 mm 450 mm
Max. Distance Chuck to Base 300 mm 515 mm 630 mm
Net Weight 14.7 Kg 27 Kg 38 Kg
Gross Weight 16.7 Kg 29 Kg 40 Kg
TECHNICAL SPECIFICATIONS
53
EXPLODED DRAWING - 01708
52
PARTS LIST - 01707….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
69. Washer M6 WD01-00702 94. Screw (M6 x 12) WD02-00381
70. Spring washer M6 WD01-00707 95. Screw (10 x25) WD02-00382
71. Nut M6 WD01-00710 96. Casting WD02-00383
72. Cam assembly WD02-00368 97. Spindle pulley WD02-00384
73. Screw (M5 x 16) WD01-00838 98. Key WD02-00385
74. Washer WD01-00881 99. Spindle shaft WD02-00386
75. Protecting ring WD01-00839 100. Bearing 6007 WD02-00387
76. Pulley cover WD02-00369 101. Ring WD02-00388
77. Washer M8 WD01-00672 102. Circlip WD02-00389
78. Bolt (M8 x 10) WD02-00370 103. Switch box WD02-00390
79. Clamp WD02-00371 104. Switch WD01-00895
80. Circlip WD02-00372 105. Screw (ST3.2 x 12) WD02-00391
81. Knurled screw WD02-00373 106. Washer WD02-00392
82. Eccentric shaft WD02-00374 107. Quill WD02-00393
83. Centre pulley WD02-00375 108. Bearing 51107 WD02-00394
84. Bearing 6202 WD01-00771 109. Spindle WD02-00395
85. Circlip WD01-00831 110. Arbor MT4 17823
86. Belt A686 WD02-00376 111. Chuck WD02-00396
87. Protecting ring WD01-00770 112. Chuck guard 75mm 68328
88. Clamp WD02-00377 113. Drift key WD01-00862
89. Mains lead WD01-00720 114. Hex. wrench 3mm WD01-00790
90. Tension spring WD02-00378 115. Hex. wrench 4mm WD01-00737
91. Tension spring cover WD02-00379 116. Hex. wrench 5mm WD02-00397
92. Nut WD02-00380 117. Hex. wrench 6mm WD01-00861
93. Washer M6 WD01-00702
9
TECHNICAL SPECIFICATIONS….cont
Part number 01703 01704 01705
Model B20-16 F16-16 F20-16
Input Voltage 230v ~ 50hz 230v ~ 50hz 230v ~ 50hz
Power 550 w 375 w 550 w
Speed Range 180-2770 rpm 180-2770 rpm 180-2770 rpm
Number of Speeds 16 16 16
Drill Bit Size 3-16 mm 3-16 mm 3-16 mm
Max. Drilling Capacity (mild Steel) 16 mm 16 mm 16 mm
Spindle Taper MT2 MT2 MT2
Table Size 290 x 290 mm 250 x 250 mm 290 x 290 mm
Base Size 462 x 274 mm 450 x 265 mm 450 x 265 mm
Column Ø 72 mm 72 mm 72 mm
Swing 360 mm 325 mm 360 mm
Height 990 mm 1550 mm 1565 mm
Spindle Travel 83 mm 80 mm 83 mm
Collar Ø 55 mm 55 mm 55 mm
Max. Distance Chuck to Table 405 mm 725 mm 682 mm
Max. Distance Chuck to Base 600 mm 1205 mm 1174 mm
Net Weight 50 Kg 47 Kg 53 Kg
Gross Weight 52 Kg 50 Kg 57 Kg
10
TECHNICAL SPECIFICATIONS….cont
Part number 01706 01707 01708
Model F28-20 F32-20 F32-20
Input Voltage 230v ~ 50hz 230v ~ 50hz 400v ~ 50hz
Power 750 w 1100 w 1100 w
Speed Range 280-2380 rpm 150-2450 rpm 180-2500 rpm
Number of Speeds 12 12 12
Drill Bit Size 5-20 mm 5-20 mm 5-20 mm
Max. Drilling Capacity (mild Steel) 25 mm 32 mm 32 mm
Spindle Taper MT3 MT4 MT4
Table Size 290 x 290 mm 420 x 470 mm 415 x 470 mm
Base Size 460 x 272 mm 573 x 427 mm 565 x 425 mm
Column Ø 80 mm 92 mm 92 mm
Swing 360 mm 510 mm 510 mm
Height 1600 mm 1722 mm 1730 mm
Spindle Travel 82.5 mm 120 mm 120 mm
Collar Ø 65 mm 75 mm 75 mm
Max. Distance Chuck to Table 687 mm 726 mm 735 mm
Max. Distance Chuck to Base 1177 mm 1204 mm 1205 mm
Net Weight 60 Kg 117 kg 115 kg
Gross Weight 64 Kg 122 kg 122 kg
51
PARTS LIST - 01707
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00329 36. Connection WD02-00354
2. Column flange WD02-00330 37. Pinion shaft WD02-00355
3. Spring washer M10 WD01-00795 38. Indicator WD01-00897
4. Bolt (M10 x 35) WD02-00331 39. Screw WD02-00356
5. Crank handle WD02-00332 40. Roll pin (5 x 25) WD01-00869
6. Bolt (M6 x 12) WD01-00905 41. Screw WD02-00357
7. Circlip WD01-00742 42. Bearing 6005 WD01-00889
8. Worm shaft WD02-00333 43. Warning label WD01-00685
9. Table support WD02-00334 44. Roll pin (6 x 18) WD01-00760
10. Worm pin WD02-00335 45. Belt tension handle WD02-00358
11. Table WD02-00336 46. Lock handle WD02-00359
12. Spring washer M20 WD02-00337 47. Circlip WD01-00816
13. Bolt (M20 x 55) WD02-00338 48. Circlip WD01-00871
14. Indicator WD01-00897 49. Adjusting shaft WD01-00872
15. Lock handle WD02-00339 50. Shaft WD02-00360
16. Angle label WD02-00340 51. Washer M12 WD01-00819
17. Worm gear WD02-00341 52. Washer M10 WD02-00361
18. Column WD02-00342 53. Nut M8 WD01-00687
19. Rack WD02-00343 54. Motor plate WD02-00362
20. Screw (M4 x 10) WD01-00783 55. Bolt (M8 x 30) WD02-00363
21. Overload WD02-00344 56. Spring washer M12 WD01-00676
22. Screw (M10 x 10) WD02-00345 57. Nut M12 WD01-00821
25. Rack collar WD02-00346 58. Motor WD02-00364
26. Screw (M6 x 12) WD01-00740 59. Grub screw (M8 x 10) WD01-00689
27. Handle knob WD02-00347 60. Motor pulley WD02-00365
28. Screw (M6 x 12) WD02-00348 61. Motor pulley key WD02-00366
29. Handle cap WD02-00349 62. Nut M10 WD01-00717
30. Screw (M8 x 20) WD01-00801 63. Belt A787 WD02-00367
31. Spring washer M8 WD01-00673 64. Microswitch WD01-00706
32. Handle WD02-00350 65. Washer M5 WD01-00881
33. Scale WD02-00351 66. Spring washer M5 WD01-00882
34. Lock handle WD02-00352 67. Nut M5 WD01-00697
35. Label WD02-00353 68. Microswitch holder WD01-00709
50
EXPLODED DRAWING - 01707
11
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the power supply:
These SIP drills (01700-01707) are fitted with a standard 230v ~ 13 amp type plug. Be-
fore using the drill, inspect the mains lead and plug to ensure that neither are dam-
aged. If any damage is visible have the drill inspected / repaired by a suitably quali-
fied person. If it is necessary to replace the plug a heavy duty impact resistant plug
would be preferable.
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be connect-
ed to the terminal, which is marked L or coloured red. The wire which is coloured yel-
low / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly.
Secure the cable in the cord grip carefully.
The wires for the plug are coloured in the following way:
ELECTRICAL CONNECTION
12
ELECTRICAL CONNECTION….cont
3PH Wiring: 01708 only.
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the power supply:
The SIP 01708 F32-20 pillar drill requires 400v 50hz supply. Before each use, inspect the
mains lead and plug (where applicable) to ensure that neither are damaged. If any
damage is visible have the pillar drill inspected / repaired by a suitably qualified per-
son. If it is necessary to replace the plug a heavy duty impact resistant plug would be
preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue/Grey Phase
Brown Phase
Black Phase
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Warning: Never connect live, neutral or any phase wires to the earth ter-
minal of the plug. Only fit an approved plug with the correct rated fuse. If
in doubt consult a qualified electrician.
Warning: Always use a qualified electrician to wire in the 3ph pillar drill, never
wire the pillar drill without any knowledge of electrics, this is extremely danger-
ous and will cause personal injury or even death.
49
PARTS LIST - 01706….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
68. Circlip WD01-00713 98. Spring washer M16 WD01-00853
69. Spindle shaft WD02-00309 99. Lock handle WD02-00322
70. Bearing 6005 WD01-00889 100. Worm pin WD02-00323
71. Bearing ring WD02-00191 101. Table support WD02-00324
72. Screw (M8 x 25) WD01-00891 102. Bolt (M6 x 12) WD01-00905
73. Casting WD02-00311 103. Crank handle WD02-00325
74. Label WD02-00312 104. Circlip WD01-00742
75. Lock washer WD01-00725 105. Worm shaft WD02-00207
76. Clip WD01-00724 106. Worm gear WD02-00208
77. Screw (M5 x 6) WD01-00894 107. Locking handle WD01-00852
78. Tension spring WD02-00313 108. Angle label WD02-00328
79. Tension spring cover WD02-00314 109. Lamp socket WD01-00837
80. Nut M12 WD01-00821 110. Chuck guard 65mm 07664
81. Switch box WD02-00315 111. Drift key WD01-00862
82. Switch WD01-00895 112. Hex. wrench 4mm WD01-00737
83. Screw (M3 x 10) WD01-00896 113. Hex. wrench 6mm WD01-00861
84. Mains lead clamp WD01-00700 100. Worm pin WD02-00323
85. Mains lead WD01-00720 101. Table support WD02-00324
86. Indicator WD01-00897 102. Bolt (M6 x 12) WD01-00905
87. Circlip WD01-00787 103. Crank handle WD02-00325
88. Bearing 6203 WD01-00714 104. Circlip WD01-00742
89. Quill WD02-00316 105. Worm shaft WD02-00207
90. Spindle WD02-00317 106. Worm gear WD02-00208
91. Bearing 6006 WD01-00900 107. Locking handle WD01-00852
92. Washer WD01-00901 108. Angle label WD02-00328
93. Arbor WD02-00318 110. Chuck guard 65mm 07664
94. Chuck WD02-00319 111. Drift key WD01-00862
95. Table WD02-00320 112. Hex. wrench 4mm WD01-00737
96. Table arm WD02-00321 113. Hex. wrench 6mm WD01-00861
97. Bolt (M16 x 30) WD01-00854
48
PARTS LIST - 01706
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00284 34. Washer M8 WD01-00672
2. Column flange WD02-00285 35. Motor plate WD02-00296
3. Spring washer M10 WD01-00795 36. Spring washer M12 WD01-00676
4. Bolt (M10 x 25) WD01-00796 37. Nut M12 WD01-00821
5. Rack WD02-00286 38. Grub screw (M8 x10) WD01-00689
6. Column WD02-00287 39. Motor pulley WD02-00297
7. Grub screw (M6 x 12) WD01-00740 40. Motor WD02-00298
8. Rack collar WD02-00288 41. Nut M8 WD01-00687
9. Screw (M6 x 16) WD01-00708 42. Cam assembly WD02-00299
10. Handle cap WD02-00289 43. Washer WD02-00300
11. Screw (M8 x 20) WD01-00801 44. Protecting ring WD01-00839
12. Spring washer M8 WD01-00673 45. Speed label WD02-00301
13. Handle knob WD02-00290 46. Pulley cover WD02-00302
14. Handle WD02-00291 47. Microswitch WD01-00706
15. Label WD02-00292 48. Washer M5 WD01-00881
16. Knob WD01-00867 49. Spring washer M5 WD01-00882
17. Scale WD02-00293 50. Nut M5 WD01-00697
18. Connection WD02-00294 51. Nut M6 WD01-00710
19. Pinion shaft WD02-00295 52. Spring washer M6 WD01-00707
20. Roll pin (5 x 16) WD01-00868 53. Washer M6 WD01-00702
21. Warning label WD01-00685 54. Microswitch holder WD01-00709
22. Screw (M5 x 10) WD01-00726 55. Eccentric shaft WD02-00303
23. Spindle pulley nut (M24 x 1.5) WD01-00907 56. Centre pulley WD02-00304
24. Roll pin (5 x 25) WD01-00869 57. Bearing 6202 WD01-00771
25. Roll pin (6 x 18) WD01-00760 58. Circlip WD01-00831
26. Locking handle WD01-00870 59. Belt A550 WD02-00305
27. Belt tension handle WD01-00812 60. Knurled screw WD02-00306
28. Circlip WD01-00813 61. Circlip WD01-00704
29. Circlip WD01-00871 63. Screw (M5 x 16) WD01-00838
30. Shaft WD01-00872 64. Mains lead clamp WD01-00700
31. Adjusting shaft WD01-00873 65. Protecting ring WD01-00770
32. Washer M12 WD01-00819 66. Belt A620 WD02-00307
33. Bolt (M8 x 25) WD01-00695 67. Spindle pulley WD02-00308
13
Guarantee:
These SIP pillar drills are covered by a 12 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the pillar drill outside the scope of this manual - any claims deemed to be out-
side the scope of the warranty may be subject to charges Including, but not limited to
parts, labour and carriage costs.
This guarantee does not cover consumables such as the chuck, belts etc.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always
replace the fuse with the same value as the original.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating.
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.
ELECTRICAL CONNECTION….cont
GUARANTEE
Note: Proof of purchase will be required before any warranty can be hon-
oured.
14
GETTING TO KNOW YOUR DRILL
01700
Ref. No. Description Ref. No. Description
1. Pulley Cover 9. Belt Tension Lock
2. Motor 10. Column Support
3. NVR On/Off Switch 11. Base
4. Chuck Guard 12. Main Drill Head
5. Chuck 13. Column
6. Feed Handle 14. Column Support Bolts
7. Table 15. Depth Stop
8. Table Support Collar
47
EXPLODED DRAWING - 01706
46
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
68. Circlip WD01-00713 91. Bearing 6006 WD01-00900
69. Spindle shaft WD01-00888 92. Washer WD01-00901
70. Bearing 6005 WD01-00889 93. Arbor MT2 66633
71. Bearing ring WD01-00890 94. Chuck WD01-00789
72. Screw (M8 x 25) WD01-00891 95. Table WD01-00902
73. Casting WD01-00892 96. Table arm WD01-00903
74. Label WD01-00893 97. Bolt (M16 x 30) WD01-00854
75. Lock washer WD01-00725 98. Spring washer M16 WD01-00853
76. Clip WD01-00724 99. Lock handle WD01-00904
77. Screw (M5 x 6) WD01-00894 100. Worm pin WD01-00850
78. Tension spring WD01-00842 101. Table support WD01-00849
79. Tension spring cover WD01-00841 102. Bolt (M6 x 12) WD01-00905
80. Nut M12 WD01-00821 103. Crank handle WD01-00906
81. Switch box WD01-00910 104. Circlip WD01-00742
82. Switch WD01-00895 105. Worm shaft WD01-00911
83. Screw (M3 x 10) WD01-00896 106. Worm gear WD01-00848
84. Mains lead clamp WD01-00700 107. Locking handle WD01-00852
85. Mains lead WD01-00720 108. Angle label WD01-00851
86. Indicator WD01-00897 110. Chuck guard 55mm 07662
87. Circlip WD01-00787 111. Drift key WD01-00862
88. Bearing 6203 WD01-00714 112. Hex. wrench 4mm WD01-00737
89. Quill WD01-00898 113. Hex. wrench 6mm WD01-00861
90. Spindle WD01-00899
PARTS LIST - 01705….cont
15
GETTING TO KNOW YOUR DRILL….cont
01701 - 01708
Ref. No. Description Ref. No. Description
1. Pulley Cover 11. Base
2. Motor 12. Main Drill Head
3. NVR On/Off Switch 13. Column
4. Chuck Guard 14. Column Support Bolts
5. Chuck 15. Depth Stop
6. Feed Handle 16. Table Lock
7. Table 17. Table Height Adjust
8. Table Support Collar 18. Rack Collar
9. Belt Tension Lock 19. Rack
10. Column Support
16
ASSEMBLY INSTRUCTIONS
Line up the 4 holes on the bottom of the column with those
on the base.
Screw the 4 bolts supplied through the column and into the
base.
Fully tighten to secure (001).
FIT THE COLUMN TO THE BASE - BENCH DRILL
FIT THE COLUMN TO THE BASE - FLOOR DRILL
Line up the 4 holes on the bottom of the
column support with those on the base
(002).
Screw the 4 x bolts supplied through the col-
umn support and into the base.
Fully tighten to secure.
Slide the column into the column support (003).
Secure in place by tightening the 2 grub screws (004).
001
002
003 004
45
PARTS LIST - 01705
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD01-00863 34. Washer M8 WD01-00672
2. Column flange WD01-00864 35. Motor plate WD01-00874
3. Spring washer M10 WD01-00795 36. Spring washer M12 WD01-00676
4. Bolt (M10 x 25) WD01-00796 37. Nut M12 WD01-00821
5. Rack WD02-00282 38. Grub screw (M8 x10) WD01-00689
6. Column WD02-00283 39. Motor pulley WD01-00876
7. Grub screw (M6 x 12) WD01-00740 40. Motor WD01-00877
8. Rack collar WD01-00799 41. Nut M8 WD01-00687
9. Screw (M6 x 16) WD01-00708 42. Cam assembly WD01-00909
10. Handle cap WD01-00800 43. Washer WD01-00878
11. Screw (M8 x 20) WD01-00801 44. Protecting ring WD01-00839
12. Spring washer M8 WD01-00673 45. Speed label WD01-00879
13. Handle knob WD01-00802 46. Pulley cover WD01-00880
14. Handle WD01-00803 47. Microswitch WD01-00706
15. Label WD01-00866 48. Washer M5 WD01-00881
16. Knob WD01-00867 49. Spring washer M5 WD01-00882
17. Scale WD01-00805 50. Nut M5 WD01-00697
18. Connection WD01-00806 51. Nut M6 WD01-00710
19. Pinion shaft WD01-00809 52. Spring washer M6 WD01-00707
20. Roll pin (5 x 16) WD01-00868 53. Washer M6 WD01-00702
21. Warning label WD01-00685 54. Microswitch holder WD01-00709
22. Screw (M5 x 10) WD01-00726 55. Eccentric shaft WD01-00883
23. Spindle pulley nut (M24 x 1.5) WD01-00907 56. Centre pulley WD01-00884
24. Roll pin (5 x 25) WD01-00869 57. Bearing 6202 WD01-00771
25. Roll pin (6 x 18) WD01-00760 58. Circlip WD01-00831
26. Locking handle WD01-00870 59. Belt O-565 WD01-00833
27. Belt tension handle WD01-00812 60. Knurled screw WD01-00885
28. Circlip WD01-00813 61. Circlip WD01-00704
29. Circlip WD01-00871 63. Screw (M5 x 16) WD01-00838
30. Shaft WD01-00872 64. Mains lead clamp WD01-00700
31. Adjusting shaft WD01-00873 65. Protecting ring WD01-00770
32. Washer M12 WD01-00819 66. Belt O-678 WD01-00886
33. Bolt (M8 x 25) WD01-00695 67. Spindle pulley WD01-00887
44
EXPLODED DRAWING - 01705
17
FIT THE RACK & TABLE - ALL OTHER MODELS
ASSEMBLY INSTRUCTIONS….cont
FIT THE TABLE - 01700
Ensure that the table support lock is loose.
Slide the table support over the column until it is in position.
Secure in place by tightening the table lock towards the rear of the table support.
Fit the rack inside the table support as shown
(005).
Fit the table support / rack assembly over the col-
umn (006) and slide down until the rack fits inside the
column support (007).
Slide the rack collar, tapered side facing
down, over the column until it locates over
the rack.
Tighten the grub screw to hold in position
(008).
005
006 007
Rack
Collar
008
18
ASSEMBLY INSTRUCTIONS….cont
FIT THE HEAD ONTO THE COLUMN
Danger / Caution: Due to the weight of the head; at least 2 persons are
required to safely fit it to the column.
Note: Ensure that any dust or debris left over from the manufacturing pro-
cess is removed from inside the head and from around the column prior to
fitting them together.
Screw the table lock loosely into the table
support.
Fit the table into the table support.
Tighten the table lock to secure in position
(010).
Secure the table support arm in place by fitting
the table height lock.
Also fit the table height adjust lever as shown left.
Secure in place by tightening the grub screw.
Grub Screw
Table Height Lock
Table Height Adjust
Table Lock
010
009
43
PARTS LIST - 01704….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
69. Screw (M5 x 16) WD01-00838 92. Worm gear WD01-00848
70. Mains lead clamp WD01-00700 93. Table support WD01-00849
71. Protecting ring WD01-00839 94. Worm pin WD01-00850
72. Protecting ring WD01-00770 95. Angle label WD01-00851
73. Mains lead WD01-00720 96. Locking handle WD01-00852
74. Mains lead clamp WD01-00700 97. Locking handle WD01-00814
75. Nut M12 x 1.75 WD01-00840 98. Spring washer M16 WD01-00853
76. Tension spring cover WD01-00841 99. Bolt (M16 x 30) WD01-00854
77. Tension spring WD01-00842 100. Table arm WD01-00855
78. Screw WD01-00843 101. Table WD01-00856
79. Casting WD01-00844 102. Circlip WD01-00787
80. Label WD01-00807 103. Bearing 6204 WD01-00857
81. Lock washer WD01-00725 104. Quill WD01-00858
82. Clip WD01-00724 105. Spindle WD01-00859
83. Screw (M4 x 6) WD01-00723 106. Bearing 6201 WD01-00732
84. Switch box WD01-00784 107. Washer WD01-00860
85. Screw (M5 x 12) WD01-00701 108. Arbor MT2 66633
86. Switch WD01-00782 109. Chuck WD01-00789
87. Screw (ST3 x 10) WD01-00845 110. Chuck guard 55mm 07662
88. Crank WD01-00846 111. Hex. Wrench 4mm WD01-00737
89. Bolt (M6 x 10) WD01-00847 112. Hex. Wrench 6mm WD01-00861
90. Circlip WD01-00742 113. Drift key WD01-00862
91. Worm shaft WD01-00810
42
PARTS LIST - 01704
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD01-00793 35. Washer M8 WD01-00672
2. Column flange WD01-00794 36. Motor plate WD01-00820
3. Spring washer M10 WD01-00795 37. Nut M12 WD01-00821
4. Bolt (M10 x 25) WD01-00796 38. Grub screw (M8 x 10) WD01-00689
5. Rack WD02-00280 39. Motor pulley WD01-00822
6. Column WD02-00281 40. Motor WD01-00823
7. Screw (M6 x 12) WD01-00740 41. Spring washer M12 WD01-00676
8. Rack collar WD01-00799 42. Nut M8 WD01-00687
9. Screw (M6 x 16) WD01-00708 43. Cam pin WD01-00824
10. Handle cap WD01-00800 44. Cam WD01-00825
11. Screw (M8 x 20) WD01-00801 45. Washer WD01-00826
12. Spring washer M8 WD01-00673 46. Speed label WD01-00827
13. Handle knob WD01-00802 47. Nut M5 WD01-00697
14. Handle WD01-00803 48. Pulley cover WD01-00828
15. Knob WD01-00804 49. Washer M6 WD01-00702
16. Scale WD01-00805 50. Microswitch WD01-00706
17. Connection WD01-00806 51. Washer M6 WD01-00702
18. Label WD01-00807 52. Spring washer M6 WD01-00707
19. Roll pin (5 x 18) WD01-00808 53. Screw (M6 x 16) WD01-00708
20. Pinion shaft WD01-00809 54. Microswitch holder WD01-00709
21. Warning label WD01-00685 55. Nut M6 WD01-00710
22. Roll pin (6 x 18) WD01-00760 56. Eccentric shaft WD01-00829
23. Indicator WD01-00811 57. Centre pulley WD01-00830
24. Belt tension handle WD01-00812 58. Bearing 6202 WD01-00771
25. Circlip WD01-00813 59. Circlip WD01-00831
26. Locking handle WD01-00814 60. Belt O-500 WD01-00832
27. Roll pin (6 x 18) WD01-00760 61. Belt O-565 WD01-00833
29. Screw (M5 x 10) WD01-00726 62. Spindle pulley WD01-00834
30. Circlip WD01-00816 63. Circlip WD01-00713
31. Shaft WD01-00817 64. Spindle shaft WD01-00835
32. Adjusting shaft WD01-00818 65. Bearing 6203 WD01-00714
33. Washer M12 WD01-00819 66. Knurled screw WD01-00836
34. Bolt (M8 x 25) WD01-00695 67. Circlip WD01-00704
19
ASSEMBLY INSTRUCTIONS….cont
Carefully raise the head above the column.
Ensure that the hole in the bottom of the drill
head lines up with the column.
Lower the drill head down the column taking
care that the head and the column stay
square with each other.
Line up the spindle with the table and base
(011).
Secure in place by tightening the 2 x grub
screws on each side (012).
FIT THE FEED HANDLE - 01700 & 01701
To fit the feed handles; simply screw them
into the hub, as shown (013).
FIT THE FEED HANDLE - 01702 - 01708
Fit the cast feed handle over the hub.
Secure in place by tightening the 3 x screws, as
shown (014).
011
012
013
014
20
FIT THE ARBOR & CHUCK
Slide the arbor and chuck into the spindle.
Rotate the arbor with small upward pressure until it
‘seats’ correctly.
Tap the arbor with a piece of scrap wood or a mallet
to ensure it stays in place (019).
ASSEMBLY INSTRUCTIONS….cont
Prior to fitting the chuck / arbor; Fit the chuck guard:
Slide the chuck guard over the spindle collar ensuring
that the ‘open’ part of the guard faces towards the
back.
Tighten the screw to secure in place.
Ensure that the outside of the arbor and the inside of
the chuck are clean and free of dust/debris.
Slide the arbor into the chuck with reasonable force,
as shown (017).
Ensure that the chuck jaws are wound all the way in
(inside the chuck) to prevent them from getting dam-
aged (018).
015
016
017
018
019
Fit the cover and secure with the screw (015).
41
EXPLODED DRAWING - 01704
This manual suits for next models
