Sitecom Cn-516 Installation instructions

USB Bluetooth Adapter

CN-512 Bluetooth 2.0+EDR klass 2

CN-516 Bluetooth 2.0+EDR klass 2

CN-520 Bluetooth 2.0+EDR klass 2

CN-521 Bluetooth 2.0+EDR klass 1

Full Manual

Cautions

This device‟s design and manufacturer has your safety in mind. In order to safely

and effectively use this device, please read the following before usage.

Usage Cautions

The user should not modify this device. The environmental temperature should be

within +5 ~ +35 degrees Celsius.

Repair

If the device has a problem, you should take it to an appointed repair center and

let the specialists do the repair. Never repair the device yourself, you might

damage the device or endanger yourself.

Disposing of the device

When you dispose of the device, be sure to dispose of it appropriately. Some

countries may regulate disposal of an electrical device, please consult with your

local authority.

Others

When using this device, please do not let it come into contact with water or other

liquids. If water is accidentally spilled on the device, please use a dry cloth to

absorb the spillage. Electronic products are vulnerable, when using please avoid

shaking or hitting the device, and do not press the buttons too hard.

Do not let the device come into contact with water or other liquid.

Do not disassemble, repair or change the design of the device; any

damage done will not be included in the repair policy.

Avoid hitting the device with a hard object, avoid shaking the device and

stay away from magnetic fields.

If during electrostatic discharge or a strong electromagnetic field the

product will malfunction, unplug the power cable. The device will return to

normal performance the next time it is powered on.

Contents

1. Installation of the Bluetooth Software ........................................................ 4

2. Configuring Bluetooth services .................................................................. 8

3. Device properties and Security settings ...................................................... 9

4. Remote Camera .................................................................................... 11

5. Wireless File Transfer ............................................................................. 17

6. Bluetooth Information Exchanger ............................................................ 21

6.1 Object Push Profile (OPP) ................................................................ 34

6.2 File Transfer Profile (FTP) ................................................................ 35

6.3 Basic Imaging Profile (BIP) .............................................................. 38

7. Bluetooth Settings ................................................................................. 40

7.1 Configure a connection to a BT Mouse and/or Keyboard ...................... 44

7.2 Configure a connection to a Bluetooth™ enabled printer...................... 50

7.3 Configure a Dial-up connection ........................................................ 61

7.4 Configure a Stereo Headset connection ............................................. 67

7.5 Configure a Headset connection ....................................................... 73

7.6 Configure a FAX connection ............................................................. 79

7.7 Configure a Network connection....................................................... 93

8. FAQ ..................................................................................................... 99

9. Glossary............................................................................................... 99

1. Installation of the Bluetooth Software

Place the installation CD-ROM into the PC. Setup should start

automatically. If setup does not start go to Windows File Explorer, locate

the CD-ROM and run „setup.exe‟

Choose „Install (v3.03.13(C))‟.

The InstallShield Wizard will start.

On the Welcome screen click Next to continue.

Read the License Agreement and select ‘I accept the terms in the

license agreement’. Click Next.

On the next screen click Install to continue.

Installation is in progress...wait a few seconds.

You will get a dialogue box indicating that the Installation process may

take up to 15 minutes. Click Yes to proceed.

You will get a prompt to insert the USB-BT device. Do so and click OK.

If your PC has an integrated BT module, this dialogue box will not appear.

To complete Installation click Finish.

In order to use the Bluetooth Software you have to reboot the PC.

Click Yes to proceed.

2. Configuring Bluetooth services

Right click the ICON in the tray bar and select Service Properties...

from the menu to open the „Service Properties‟ window

Now you are able to toggle the following Bluetooth™-services

Bluetooth Information Exchange Service:

... enables a (server) function that allows files, images and business cards

to be transferred from a remote device using Bluetooth Information

Exchanger.

I.e. Send a business card from a mobile phone to the PC

PAN Networking Service:

... enables a (server) function that allows networking to be performed

from a remote device using the PAN Networking Service.

I.e. Bluetooth™ Network connection from a PDA to the PC

Bluetooth COM Port Service:

... enables a (server) function that allows COM Service to be performed

from a remote location using the Serial Port Profile.

I.e. ActiveSync from a PC<->PDA via SPP

AV Remote Control Service:

... enables a (server) function that allows remote control to be performed

from a Bluetooth™ device supporting the AV Remote Control Service.

I.e. Control Microsoft Media Player from a stereo headset

3. Device Properties and Security settings

Open the „Device Properties and Security‟ window

Right click the ICON in the tray bar and select Device Properties and

Security... from the menu.

You will get a general overview of your Bluetooth™ Hardware properties

You can get useful information, such as Device Name, Device Address or

the Manufacturer Name of your Bluetooth chipset.

The LMP Version indicates which Bluetooth™ version your Hardware

supports.

Bluetooth™ v1.1 -> LMP Version 01

Bluetooth™ v1.2 -> LMP Version 02

Bluetooth™ v2.0 + EDR -> LMP Version 03

The Security Tab allows you to configure your Bluetooth™ device security

Discoverability mode:

Set whether your device is visible to other Bluetooth™ devices or not.

Other devices will be still able to establish a connection to your device as

long as your Connectability mode is set to „Connectable mode‟

Connectability mode:

Set whether you allow remote Bluetooth™ devices to connect to the local

device or not. Even if the local device is not discoverable, incoming

connections are still accepted.

Pairing mode:

Set whether you allow pairing or not.

If „Pairable mode‟ is set and encryption is required by one of the

Bluetooth™ devices a passkey will be requested on both devices once

upon first connection.

Security mode:

You can set whether the connection to the remote device will be encrypted

or not. This security feature enforces an encrypted connection. The

connection can also be encrypted even if Security mode is set to „Non-

secure‟ if the remote device requests encryption i.e. mobile phones

4. Remote Camera

Launch the „Remote Camera‟ application

Right click the ICON in the tray bar and select Remote Camera.

Activate Bluetooth on the Remote Camera and click the „Camera

Search...‟ button.

Device Discovery will be performed...this may take a few seconds.

All available Bluetooth™ cameras will be listed.

Right click the camera and select „Connect‟ or just double click the

camera ICON

A green/yellow connected chain will be displayed if the Bluetooth™

connection is established.

A second window appears which shows an almost live preview of the

camera picture. It is possible to change the size of the preview window.

The resolution of the preview window is much smaller than the real

resolution of the picture that will be taken by the camera.

Basically you will take one picture by clicking on the right trigger button.

[Camera ICON]

It is also possible to take consecutive pictures by clicking the left trigger

button. [Camera ICON]

The pictures will be automatically transferred to the PC.

A progress bar indicates the status of the image transfer

You will see a small preview of the transferred pictures in Remote Camera”

application. Just double click a picture to open it in your default picture

viewer.

You can easily disconnect the Camera by right clicking on the camera

ICON and selecting Disconnect from the context menu.

A dialogue box appears and asks whether the Bluetooth™ connection to

the remote camera should be registered or not. The connection to the

remote camera will be stored if Yes is selected. Every time you open the

Remote Camera application the BT connection will be established. If you

click No, you have to search for a Buetooth™ camera again, every time

you launch the the Remote Camera application.

It is possible to change some default settings in the Remote Camera

application. Choose [Bluetooth]->[Properties]->[...] from the menu.

Device detection filter

The Remote Camera application may discover devices other than digital

cameras, depending on which profiles are supported.

Adjusting the setting to “Loose filtering” will increase the chance that

devices other than cameras will be detected. The further you slide the

setting towards “Tight filtering,” the stricter the criteria determining device

detection, and the lower the chance that unwanted devices will be

included.

Change number of consecutive images

Allows you to set the number of consecutive images captured by your

digital camera.

Settings for size of captured image

Images will be sent to your PC after having been automatically converted

to the size specified in the dialog box above, regardless of the size of the

original image data.

Inbox settings

Opens Browse folders...” dialog box and allows you to select the folder

where you would like your captured images to be saved.

5. Wireless File Transfer

Launch the „Wireless File Transfer‟ application

Right click the ICON in the tray bar and select Wireless File Transfer.

There is a second way to launch the Wireless File Transfer application. A

right click a file allows you to select „to Bluetooth‟ -> „Search other

devices‟

A third way would be to launch the Wireless File Transfer application from

the Start menu:

[START]->[All Programs]->[Bluetooth]->[Wireless File Transfer]

The Wireless File Transfer application starts and Device Discovery is

performed.

Note:

If the desired device does not appear in the list, please check that the

device is switched on.

After device discovery, select the Bluetooth™ devices to which you want to

send the file. You can also add more than one File or Folder to the list.

Finally click „Send‟ and the Files/Folders will be transferred to the selected

Bluetooth™ devices.

Note:

When sending files, a message requesting permission to receive the files

may appear on the destination (receiving) device. The content of the

message will vary with the Bluetooth™ software installed. Please be sure

to follow the instructions provided.

A progress bar indicates transfer status

After the File/Folder is transferred a dialogue box appears and confirms

successful transfer.

This manual suits for next models

Table of contents

Other Sitecom Adapter manuals

Popular Adapter manuals by other brands

Nokia

Nokia A040 Safety and regulatory information

Chung Nam Electronics

Chung Nam Electronics WLANTUBGM user manual

VOLTCRAFT

VOLTCRAFT VMA-3L 16 operating instructions

Renkforce

Renkforce 55 71 93 operating instructions

Algo

Algo 8301 Installation/configuration

VersaLogic

VersaLogic VL-ADR-01 Reference manual

Icy Box

Icy Box IB-AA508 Quick installation guide

Siemens

Siemens SIMOGEAR BA 203-KS Mounting and operating instructions

ADT

ADT Pulse Nano quick start guide

Powerlink

Powerlink 30017744 user manual

TP-Link

TP-Link Archer T4UH Quick installation guide

Beijer Electronics

Beijer Electronics G Series user manual

iSystem

iSystem Infineon TC377TE user manual

EKVIP

EKVIP 022415 operating instructions

SIIG

SIIG M1 Quick installation guide

VDO

VDO ADAPTOR KIT X39.106 manual

Mercury

Mercury LPSA70 user manual

Asus

Asus USB-AC50 quick start guide

Sitecom CN-516 Installation instructions

Popular Adapter manuals by other brands
