Sitecom USB to Fast IrDA User manual

1
User Manual
Sitecom USB to Fast IrDA

2
Introduction
Thank you for choosing the USB-IrDA adapter. The
USB-IrDA is an Infrared adapter that connects to a PC or
server via the Universal Serial Bus (USB) port.
System Requirements
• Pentium-class CPU with USB port PC.
• 1 available USB type A (downstream) port.
• Windows 98, Windows Me, Windows 2000 or
Windows XP operating system.

3
Installation of USB-IrDA on Win98/ME
Note :
1. Please install USB-IrDA as the procedure below.
2. If the installation has not been completed, don’t plug
the USB-IrDA to your computer.
To install the USB-IrDA drivers
A1.
Please insert the driver disk into floppy disk and execute
“ IRXpress.exe ”, then click “Next” to continue.

4
A2.
Click “Next” to continue.
A3.
Click "Next" to continue.

5
A4. Click "Next" to continue.
A5. For Win 98, please select “KC Technology, Inc.”,
and select “ IRXpress USB IrDA Adapter – Windows
98 ”. Click “OK” to continue.

6
A6. For Win ME, please select “KC Technology, Inc.”,
and select “ IRXpress USB IrDA Adapter - Windows
Me ”. Click “OK” to continue.
A7. Click “Finish”, Windows has finished installing the
device.

7
A8.
Select “ Yes, I want to restart my computer now ”.
Then click “Finish” to restart the system and complete
the device.
◆After restarting the computer, please plug
the flat end of the USB cable into the
downstream A connector located in the
back of your computer or USB HUB port,
and the upstream B connector into the
USB-IrDA adapter.

8
◆
◆◆
◆USB device installed list as following
B1.To make sure you have installed successfully, please
move the cursor to “My computer” Æ
ÆÆ
Æ“Control
Panel” Æ
ÆÆ
Æ“System Properties” Æ
ÆÆ
Æ“Device
Manager” Æ
ÆÆ
Æ”Infrared devices”. It will show a new
direction “IRXpress USB IrDA Adapter“.

9
B2.And under the same window, you can
select ”Network adapters”. It will show “IRXpress
USB IrDA Adapter – Windows 98”.

10
B3. It will show “IRXpress USB IrDA Adapter –
Windows Me” on Win ME.

11
B4.And under the same window, you can select ”Ports
[COM & LPT]”. It will show “Virtual Infrared COM
Port”.

12
B5.And under the same window, you can select ”Ports
[COM & LPT]”. It will show “Virtual Infrared LPT
Port”.

13
◆
Uninstallation
If you want to remove the driver of USB-IrDA, you can
move the cursor to “My computer” Æ
ÆÆ
Æ“Control Panel” Æ
ÆÆ
Æ
“Add/Remove Programs”. It will show a dialog then select
“Install/Uninstall”
C1.
(1) Select
“IRXpress USB-IrDA” from the list.
(2) Click “Add/Remove” to uninstall the driver of
USB-IrDA.

14
C2. Click “Yes” to continue.
C3. Click “OK” to complete the device’s removal.

15
Installation of USB-IrDA under Win2000
Note :
1. Please install USB-IrDA as the procedure below.
2. If the installation has not been completed, don’t plug
the USB-IrDA to your computer.
To install the USB-IrDA drivers
D1. Please insert the driver disk into floppy disk and
execute “ IRXpress.exe ”, then click “Next” to continue.

16
D2. Click “Next” to continue.
D3. Click "Next" to continue.

17
D4. Select “Yes, I want to restart my computer now ”,
then click “Finish” to restart the system and complete the
driver installation.
◆
◆◆
◆After restarting the computer, please plug
the flat end of the USB cable into the
downstream A connector located in the back
of your computer or USB HUB port and the
upstream B connector into the USB-IrDA
adapter.

18
◆
◆◆
◆USB device installed list as following
E1.To make sure you have installed successfully, please
move the cursor to “My computer” Æ
ÆÆ
Æ“Control
Panel” Æ
ÆÆ
Æ“System Properties” Æ
ÆÆ
Æ“Hardware” Æ
ÆÆ
Æ
“Device Manager” Æ
ÆÆ
Æ”Infrared devices”. It will
show a new direction “IRXpress USB Infrared
Adapter“.

19
E2. And under the same window, you can
select ”Universal Serial Bus controllers”.
It will show “ IRXpress USB IrDA Adapter ”.

20
◆
Uninstallation
If you want to remove the USB-IrDA, you can move the
cursor to “My computer” Æ
ÆÆ
Æ“Control Panel” Æ
ÆÆ
Æ
“Add/Remove Programs”. It will show a dialog then
select “Install/Uninstall”.
F1.
- Select “IRXpress USB-IrDA” from the list.
- Click “Change/Remove” to uninstall the driver of
USB-IrDA.
