Skil PWRCORE 20 RO5028E-00 User manual
Cordless Bluetooth Speaker
WARNING: To reduce the risk of injury, the user must read and understand the
Owner’s Manual before using this product. Save these instructions for future reference.
For Customer Service 1300-017-545 OR www.skil.com.au
Model: RO5028E-00
TM
2
On/o button
Play/pause button
Bass button Indicator
Battery level indicator
Volume buttons
USB port
Dust cover
AUX port
Bluetooth pairing
button
1
3
2 SPECIFICATION
Rated Voltage 20V max
USB Output Voltage 5V d.c.
USB Output Current Max. 2.1A
Weight 1.2kg (with 2.5 Ah battery pack attached)
Weight 1.5kg (with 5.0 Ah battery pack attached)
3 4
5 5
5
5
Battery level indicator
a
b
c
4
• Permitted ambient temperature (tool/charger/battery):
-when charging 4...40°C
-during operation –20...+50°C
-during storage –20...+50°C
• Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
EXPLANATION OF SYMBOLS ON TOOL
3 Read the instruction manual before use
4 Do not dispose of electric tools and batteries together with
household waste material
USE
• Charging battery
! read the safety warnings and instructions provided
with the charger
• Removing/installing the battery 1
! read and follow the instruction delivered with the
charger or power supply
• Battery protection
The tool is suddenly being switched o or prevented from
being switched on, when
-the load is too high --> remove load and restart
-the battery temperature is not within the allowable
operating temperature range of -20 to +50°C --> 2
levels of the battery level indicator start ashing when
pressing button 5c; wait until battery has returned within
the allowable operating temperature range
-the battery is nearly empty (to protect against deep
discharge) --> a low battery level or ashing low battery
level 5b is shown by the battery level indicator when
pressing button; charge battery
! do not continue to press the on/o switch after the
tool is switched o automatically; battery may be
damaged
• On/o 1
-press and hold button for 1 second to turn on the speaker
-indicator will start ashing
-press and hold button for 3 seconds to turn o the
speaker
! after approx. 45 minutes of inactivity the speaker will
automatically turn o
• Volume
-use buttons to increase or decrease the volume
• Play/Pause
-use the Play/Pause button to play or pause a track
• Bass
-to add extra bass, press the Bass button
-to turn o the extra bass, press the Bass button again
• Connecting with Bluetooth
-turn on the speaker and it will automatically enter into
Bluetooth pairing mode
-indicator will start ashing
-the speaker will automatically try to connect to the last
device it was paired to
-if no connection can be made, the speaker will be
available for connection to other Bluetooth devices for
approx. 10 minutes
! after approx. 45 minutes of inactivity the speaker will
automatically turn o
-when a connection is made, the indicator will turn blue
continuously
-to pair to a dierent device press and hold the Bluetooth
pairing button for 3 seconds
-indicator will start ashing
! read the instructions provided with your device
• Connecting with AUX 1
INTRODUCTION
• This tool is intended for streaming audio from Bluetooth
devices or connecting an audio source to the auxiliary input
socket (AUX)
• This tool is intended for using a SKIL battery pack as power
source for USB devices
• This tool is not intended for professional use
• Read this instruction manual carefully before use and
save it for future reference
SAFETY
• This tool can be used by children aged 8 and above
and by persons who have physical, sensory or mental
limitations or a lack of experience or knowledge if a
person responsible for their safety supervises them
or has instructed them in the safe operation of the
tool and they understand the associated dangers
(otherwise, there is a danger of operating errors and
injuries)
• Supervise children (this will ensure that children do not
play with the tool)
• Cleaning and user maintenance of the tool shall not be
made by children without supervision
• Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
• Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
• Store the tool indoors in a dry and locked-up place, out of
reach of children
• Do not use tool/charger when damaged; take it to one of the
ocially registered SKIL Service Stations for a safety check
• Have your power tool serviced by a qualied repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
• Provide for good ventilation at the working place
BATTERIES
• Use power tools only with specically designated
battery packs. Use of any other battery packs may create
a risk of injury and re.
• Only use the following batteries and chargers with this
tool
-SKIL battery: BY5197E-03 BY5196E-03
-SKIL charger: SC5358E-01 QC5360E-01 QC5359E-00
• When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
• Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, ush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
• Do not use a battery pack or tool that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
• Do not expose a battery pack or tool to re or
excessive temperature. Exposure to re or temperature
above 130°C may cause explosion.
• Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specied in the instructions. Charging improperly or at
temperatures outside the specied range may damage the
battery and increase the risk of re.
5
-open dust cover
-plug in audio cable in the AUX port and connect to a MP3
player, CD player or other audio device
-indicator will turn blue
! without a connection the speaker will automatically
enter into Bluetooth pairing mode
• Charging an external USB device 1
-open dust cover
-connect a USB device with USB charging cable to port
! any device that uses more than the maximum output
current (see technical data) will trip a self-resetting
overload protection and disable the speaker,
reactivate by removing the USB device and turn on
the speaker
! when not in use, remove the charger cable(s) and
battery
MAINTENANCE / SERVICE
• This tool is not intended for professional use
• Always keep tool clean (especially ventilation slots)
! remove battery from tool before cleaning
ENVIRONMENT
• Do not dispose of electric tools, batteries, accessories
and packaging together with household waste
material. The electric tools, accessories and packaging
should be sorted for environmental friendly recycling
! prior to disposal protect battery terminals with heavy
tape to prevent short-circuit
6
WARRANTY
SKIL WARRANTY POLICY
For all SKIL warranty & enquiries, please contact 1300 01
SKIL (1300 01 7545) Monday to Friday 9:00am to 5:00pm
EST
Chervon Australia Pty Ltd ABN 36 165 077 501 (“Chervon”)
warrants to the original domestic purchaser that this product
will be free from defects in materials and workmanship for 5
years from date of purchase, and any battery or charger will
be free from defects in materials and workmanship for 3 years
from date of purchase. Consumables will be covered by a
3-month warranty and a complete list can be found inside the
manual.
Notwithstanding the foregoing, if a SKIL consumer Power Tool
is used for industrial, professional or commercial purposes,
the foregoing warranty will apply for a duration of ninety
days from the date of purchase. This ninety-day commercial
warranty pertains to the SKIL Power Tool range only.
This SKIL product warranty is only applicable to purchases
from authorised SKIL retailers. This warranty will not apply to
SKIL products that are purchased from Amazon, eBay and
any other non-authorised online retailer. This SKIL product
warranty does not apply to any parallel imported product and
does not apply to any SKIL products that are not purchased
from an authorised SKIL retailer. To make a claim, return
the faulty item together with proof of purchase directly to
your closest service agent or to the place of purchase. Any
handling and transportation costs (and other expenses
incurred in claiming this warranty) are not covered by this
warranty and will not be borne by Chervon. The replacement
product or part or repaired product will be made available
for your collection at an address nominated by Chervon.
Where a valid warranty claim is made, Chervon will replace
the defective product or repair the fault. Where the product is
repaired, Chervon may use refurbished parts. This warranty
does not cover normal wear and tear, misuse or abuse.This
warranty may also be further limited or voided as specically
detailed in the product manual. Chervon has no other liability
under this warranty. The benets to you given by this warranty
are in addition to other rights and remedies imposed by State
and Federal legislation that cannot be excluded. Our goods
come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a
major failure. Chervon Australia Pty Ltd, Unit 14, 5 Kelletts
Road, Rowville, VIC. 3178.
Ph; 1300 01 SKIL (1300 01 7545).
Email: [email protected]
The following accessories and consumables have a 3-month
warranty period:
Chucks Allen keys
Brushes Angle grinder anges
Collets Dust canisters
Industry leading battery
technology wraps each
cell with cooling material
to keep the battery
powering on for 25%
longer run time compare
to general battery
technology.
SKIL’s patented technology
extends the battery life 2X
longer compare to general
battery technology.
LONGER
RUN TIME
PWRCORE 20™
LITHIUM
*
2X
BATTERY LIFE
PWRCORE 20™
LITHIUM
*
*
