Skimz SM110 User manual

ModelRecommendedFeedinletØ ReturnoutletpipeØ FoamOutletØ DrainoutletØ
 feedpump(max)hose(mm)(mm)hose(mm)hose(mm)
SM110500l/hrEheim12/1632‐‐
SM150800l/hrEheim16/2240‐‐
SM1801200l/hrEheim16/2250‐‐
SM2001500l/hrEheim19/2750‐‐
SM2502000l/hrEheim19/2750Eheim16/22Eheim16/22
SM3003000l/hrEheim19/2763Eheim16/22Eheim16/22
Specifications and equipment are subjected to change without prior notice or obligation on the part of the manufacturer.
Design Reg. no. D2008/977/D
Warranty Policy
Skimz Aquatics (Company) warrants this product to the original purchaser against defective material and
workmanship that occurs during normal use of the body for two (2) years and one (1) year warranty on the pump.
Company will, at Company’s option, either repair or replace without charge.
Products Covered by Warranty
All Skimz equipment is covered by warranty from the date of purchase
To be effective, register your product at: www.skimz.sg.
Exclusions:
• Damage resulting from accident, misuse, lack of reasonable care, subjecting the product to abnormal
working conditions or any other failure not resulting from defects in materials or workmanship.
• Damage caused by tampering, modification or attempted repair by anyone other than the Company.
• Transfer of product to someone other than the original purchaser.
Deliver, mail or ship the product, together with a copy of the purchase receipt or other evidence of purchase to:
Skimz Aquatics
5 Ang Mo Kio Industrial Park 2A
#04-30 AMK Tech II
Singapore 567760
You must pay any postage, shipping charges, insurance costs and other expenses to return the product to Skimz
Aquatics. However, if the necessary repairs are covered by the warranty, Company will pay the return shipping
charges.
Warranty Information
Maintenance
It is recommended to clean the pumps every 3 months. Check and clean the impeller, and if
necessary soak the pump and impeller in white vinegar to dissolve any calcium deposits.
Technical Data
Protein Skimmer Quick Guide
SM110 / SM150 / SM180 / SM200 / SM250 / SM300
SKIMZ AQUATICS
skimz.sg [email protected]
Professional
Professional
Protein Skimmers
Protein Skimmers

Page 2
Step 1
1. Make sure all o-rings are in correct
position.
2. Attach the Aquabee skimmer pump
according to the diagram.
3. When screwing the pump, do not tighten
the coupling too much.
Step 2
1. Connect the air tube to the pump air inlet.
2. Then connect the air tube to the air intake
valve.
3. Larger Monzter skimmers using AquaBee
5000 pumps are fitted with silencer SS-5.
A. Lid for collection cup
B. Collection cup
C. Neck
D. Twist-lock fitting
E. Air intake valve
F. Skimmer body
G. Feed pump inlet
H. Air tube
I. AquaBee skimmer pump
J. Pump air inlet
K. Valve for feed pump
L. Feed pump
M. Outlet pipe
N. GF water outlet valve
Page 3
Step 3
1. Measure the require length of the outlet
pipe.
2. Cut to the length of the pipe slightly above
the sump water level (ideal position is at
the water surface).
3. Connect the outlet pipe as shown in the
diagram.
4. It is recommended to run the outlet over a
sponge to remove any stray bubbles.
Step 4
1. The recirculating skimmer should be
provided with water from the aquariums
either by a separate feed pump or by
gravity feed.
2. Choose a suitable pump and connect it to
the inlet with a flexible hose.
3. It is recommended to fit a ball valve on the
outlet of the feed pump to achieve better
adjustment of the skimmer water level.
Step 5
1. Open the water outlet valve and plug the
pumps to the power supply.
2. Allow the skimmer to be filled with water
until it overflow from the outlet pipe.
3. Adjust the skimmer water lever by using
the water outlet valve.
4. Set the air intake valve to 2 o’clock position
and leave it to settle down for a day or so
(initial break-in period). When foam
formation begins after break-in period, fine
adjustment to the skimmer can be done via
adjustment of air intake valve and water
outlet valve for optimum performance.
