SALT WATER CHLORINE GENERATOR
SMC
INSTRUCTION MANUAL
Model:
SMC20TA &
SMC30TA

DISCLAIMER
• While every eort has been made to ensure that the information contained in this guide
is accurate and complete, no liability can be accepted for any errors or omissions.
• Australian Innovative Systems Pty Ltd reserves the right to change the specications
of the hardware and software described herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language in any form, by any means, without the prior written permission
of Australian Innovative Systems Pty Ltd.
• Australian Innovative Systems Pty Ltd makes no warranties for damages resulting from lack of
supply of chlorine due to a mistaken operation or malfunction of the chlorine generator or use
of non-genuine replacement parts.
TRADEMARK ACKNOWLEDGEMENTS
AutoChlor™is a trademark of Australian Innovative Systems Pty Ltd
USE OF GENUINE AUSTRALIAN INNOVATIVE SYSTEMS REPLACEMENT PARTS IS RECOMMENDED.
This product is designed to perform optimally when used with genuine Australian Innovative Systems
replacement parts. Australian Innovative Systems Pty Ltd shall not be liable for any damages to this
product caused by the use of non-genuine replacement parts (e.g. electrode.). Please note that this
warranty does not apply to repairs arising out of the malfunction of non-genuine replacement parts,
although you may request such repairs on a chargeable basis.
PURCHASED FROM:
PURCHASED DATE:
NOTE: Proof of purchase / installation is required for warranty claims. Please keep your records in a safe place.

3
TM
1. Min/O
Press to reduce the chlorine output.
When no lights are lit, the chlorine
generator is o.
2. Max/On
Press to turn on and increase the
chlorine output.
3. Chlorine Production
Each light represents 10% of output
i.e. 5 lights = 50% output.
4. High Salt
If the light is on or ashing see
Troubleshooting Guide, pages 16–17.
5. Low Salt
If the light is on or ashing see
Troubleshooting Guide, pages 16–17.
6. Water Flow
If light ashes and chlorine generator
beeps then no water is owing through
the electrode housing.
See Troubleshooting Guide, pages 16–17.
7. Power Status
When light is on the chlorine
generator power supply is operating.
8. To Access Time Clock
Pull forward at these points and
the door will fold down.
9. Pump Outlet Socket
The three pin plug supplying power
to the pump is connected here.
1
4
5
3
6
7
9
8
2

4
CHLORINE GENERATOR INSTALLATION
ELECTRODE HOUSING
The electrode housing may be installed either horizontally or vertically in the pool return
line. The water can ow through the housing in either direction. Plumbing may be either
a 40mm or 50mm pipe.
Horizontal - the plumbing connection on the side of the electrode
housing must face downwards.
Vertical - the plumbing connection on the end of the electrode housing
must face downwards and the electrical connections must be protected
from the weather. The electrode housing should be installed in a
weatherproof, well ventilated pool shed.
Gas trap - the electrode housing must be installed to form a gas trap as shown
below. If water was to stop owing and the chlorine generator continue running,
chlorine gas pressure will build up in the housing and pipe work and cause damage.
This can happen if water continues to run back into the electrode housing (e.g.
from an outgoing pipe after the pump is turned o), allowing water to come in
contact with the electrodes producing a build-up of gas. A gas trap allows the gas
to displace water away from the sensor terminal, thus turning o the Chlorine
generator power supply and causing the “water ow” alarm to turn on.
GAS TRAP
NO GAS TRAP
OK
GAS TRAP
NO GAS TRAP
OK
GAS TRAP
NO GAS TRAP
OK

5
TM
4
5
3
1
2
The power supply should be installed in a weatherproof, well ventilated area and mounted
vertically within 1.5 metres of the electrode. Although the unit has an IP24 rating it can still
be susceptible to wind driven rain.
The SMC chlorine generator can be tted to pools with any type of heating system. Do
not install chlorine generator and water heater in reverse as the heavily chlorinated water
could damage the heating unit and may negate the heater warranty.
INSTALLATION WITH POOL HEATER
1. Pump
2. Filter
3. Water heater
4.Power supply
for chlorine
generator
5. Chlorine
generator
electrode

7
TM
ADDING SALT TO A NEW POOL
Calculate the pool’s water volume as follows: average length x average width x average
depth in metres. Multiply this answer by 5. The answer is the amount of salt
in kilograms you need to add to increase the salinity of your pool from fresh water to
5000 ppm (the recommended salt level for this chlorine generator).
Turn on the power to the chlorine generator and press the “Min/O” button. Continue
pressing the “Min/O” button until all of the green production lights turn o. This will
lower chlorine generator production but leave the pump running.
Add the calculated quantity of salt (rened NaCl recommended) to the shallow end of the
pool. Brush the salt to help it dissolve. Undissolved salt may stain your pool’s nish.
It is recommended to leave the pump running for 12 – 24 hours, then turn on the
chlorine generator production by pushing the “Max/On” button and increase the
output to maximum.
Your chlorine generator is designed to maintain a sanitizing chlorine level in your pool.
It will take a number of days of continuous running to reach this level. Have the water
chlorine level tested daily until it reaches 1.5 – 2.0 ppm. At this point you can adjust the
running time and production level to suit your requirements.
The most eective method of chlorinating your pool is to run the pump long enough
to pass all the pool water through the lter/chlorine generator’s cell at least once a day.
If your chlorine generator does not produce enough chlorine, increase the running time.
Chlorine demand and running time will vary and depends on a number of factors such as:
bather load, chemical balance, water temperature, sunlight exposure, type of ltration
media, etc.
Check the water chemical balance (page 15). A correct chemical balance
and chlorine level will ensure optimum pool water quality.
For example, Pool size = 60,000 ltrs; Pump ow = 200 ltrs/min.
Pool size (ltrs) / [pump ow (ltrs/min) x 60 mins] = 5 hours to lter the water once.

8
INTRODUCTION TO THE TIME CLOCK
The time clock is accessed by pulling down the bottom ap of the front cover. There are
four buttons: “Clock”, “Timer”, “Man” and “Auto”.
“Clock” and “Timer”: Used to enter and exit the timer settings. Once
the timing program is set they are not used again unless you wish to alter the
program times.
“Man”: Used to change settings during programming. Used also to manually
turn the chlorinator and pump on and o.
“Auto”: Used to advance to the next setting during programming. Used also
to enter the automatic time clock operation.
The time clock has a 24-hour clock face which is divided into 48 segments, each of
30 minutes duration (Fig. 1). Each of these segments can be turned ON (darkened) or
OFF (not showing) as required, allowing for very exible operation of your chlorinator
and water ltering.
Fig. 1

9
TM
For your convenience the time clock has two factory programs ON periods.
This program is recommended for the average pool. These are 8.00am
to 12.00 midday and 4.00pm to 8.00pm. (Fig. 2)
To have the time clock operate correctly, you will rst need to input the correct time of
day into the clock (see Entering Correct Time on page 10).
The time clock will then, after about an hour with the power applied, maintain the correct
time and settings for about 2 weeks with no power connected. This back up function
allows the clock to operate during any power outage (e.g. cheaper tari) and not lose the
programmed settings.
Now you have to decide:
1. To use the preset times and do nothing further with the time clock.
2. How long per day you want to run the chlorinator.
3. What times you want the chlorinator to run, bearing in mind the pump noise
and the eect this could have on your neighbours.
(See Programming The Timer on page 11)
Fig. 2
NB: Consult your electricity
supplier to ensure your
tari rate provides
electricity during
these times.

10
1. Turn on the power to the chlorine generator. If the unit starts running, press
the “Man” button to turn it o.
2. Press the “Clock” button and the word CLOCK will appear on the screen.
(Remember this is a 24 hour clock).
3. Press and hold down the “Auto >>” button until the correct time of day is
showing on the screen. Release the button. A short press of the button will
advance the time 5 minutes. If you go too far you will have to go forward until
you come back to the correct time again.
4. Press the “Clock” button to save and exit this program.
ENTERING CORRECT TIME
Fig. 3

11
TM
PROGRAMMING THE TIMER
All segments between the start and stop times need to be turned ON (darkened)
as shown in the below picture.
1. Press the “Timer” button, the word TIMER will appear on the screen.
There will be one dark segment ashing.
2. Change this segment to ON or OFF with the “Man” button as required.
3. Advance to the next segment by pressing the “Auto >>” button.
4. Continue setting each segment ON or OFF until you have completed
the full 24 hours.
5. Press the “Timer” button to save and exit this program.
You have now completed the timer set up.
Fig. 4

12
TIMER OPERATION
AUTOMATIC OPERATION:
Press the “Auto” button to put the chlorine generator into automatic timed operation.
The word AUTO, the time of day and your set times will appear on the screen. The
chlorine generator and the lter pump will turn on and o at the times you entered
during programming.
Fig. 5

13
TM
MANUAL OPERATION:
Press the “Man” button to either turn the generator o (e.g. for maintenance) if it is
running, or turn it on if the generator is not running. To return to the auto timer
function the “Auto” button must be selected.
Fig. 6
Fig. 7

14
MAINTENANCE
ELECTRODE INSPECTION:
SMC series generators have a reverse polarity feature which reduces electrode cleaning
to the minimum. Regular inspection of the electrode is recommended.
ELECTRODE REMOVAL:
Ensure the power to the chlorine generator is switched o.
Unplug the electrode lead from
the electrode.
Step 1
Unscrew (anticlockwise) the large
threaded locking nut.
Remove the electrode from the housing.
Look inside the electrode for signs of
calcium build up (a white chalk-like
substance). If there is calcium build up the
electrode will require cleaning. If cleaning
is not required reassemble the electrode.
Cleaning and reassembly are on page 15.
Step 2
Step 3

15
TM
ELECTRODE CLEANING:
Mix up a solution of 1 part hydrochloric acid to 8 parts water. Submerse the electrode
in this solution, as shown in the picture below.
There will be a reaction as the calcium is dissolved. When the reaction ceases
(about 10 minutes) rinse the electrode in clean water, wipe the brass terminals dry and
check that all calcium has been dissolved. If not, repeat the process with a new solution.
ELECTRODE REASSEMBLY:
Ensure the silicon seal is still in place on the inside circumference of the electrode cap.
Insert the electrode back into the housing and screw on (clockwise) the locking nut.
Plug the electrode lead back on to the electrode terminals and turn on the power to
the chlorine generator.
WATER CHEMISTRY:
Have your water tested regularly. Transport
the test water in an opaque container and
have the test done as soon as possible for the
most accurate results. The following is a list of
recommended water chemistry levels.
CAUTION:
• When working with acid the
use of eye protection and
rubber gloves is strongly
recommended.
• When mixing, add acid to
water, but NEVER water
to acid.
Salt: 5000 ppm
Total alkalinity: 90 – 150 ppm
Chlorine: 1.5 – 2.0 ppm
Cyanuric acid: 40 – 65 ppm
pH: 7.2 – 7.4

16
TROUBLESHOOTING GUIDE
PROBLEM REASON SOLUTION
There are no lights on the
chlorine generator and the
pump is not running
1. There is no mains power
2. The time clock is on Auto
and in an OFF period
1. Unplug the chlorine
generator from the
power and test power
outlet with another
known working appliance
2. Press the time clock
manual button to start
the chlorine generator
The power status light is on
and the pump is running,
but no other lights are on
The chlorine generator
production is turned o
Press the “Max/on” button
The chlorine generator
is not generating enough
chlorine
1. Chlorine production is
reduced on the chlorine
generator.
2. Chlorine generator is not
operating long enough
3. Calcied electrode
4. Water chemistry is
incorrect
1. Press the “Max/on” to
increase the chlorine
production
2. Increase the time
clock running time
3. Clean the electrode
(see maintenance)
4. Correct water chemistry
The Water Flow light is
ashing and the generator
is beeping
1. The pump is not
running, chlorine
blocked, or air locked
2. Electrode lead not
properly plugged in
1. A large air bubble in
the electrode housing
will cause this alarm.
Clean out the skimmer
box. Check & clear any
blockage. Re-prime
the pump.
2. Check the electrode lead
plug is properly plugged
onto the electrode

17
TM
PROBLEM REASON SOLUTION
The high salt light is on
or ashing
Water salinity is to high or
chlorine generator is faulty
Have salinity level tested by
pool professional
The low salt light is on
or ashing
1. Water salinity is too low
2. Electrode is calcied
3. Faulty electrode
1. Have the salinity level
tested by pool professional
and increase it to
5000 ppm if necessary
2. Clean electrode
(see maintenance)
3. Have the electrode
tested and replace
if necessary
There is a white powdery
material on the pool
bottom?
Excessive water hardness Test the water chemistry
and adjust
TROUBLESHOOTING GUIDE

18
TECHNICAL SPECIFICATIONS
Chlorine output SMC 20TA: 22 gms/hr (grams of chlorine gas equivalent/hour)
SMC 30TA: 33 gms/hr (grams of chlorine gas equivalent/hour)
Input voltage 190 – 250 volts. 50 – 60 Hz
Input current 1.0 amps (excluding pump)
Output voltage 15 – 26 volts DC
Output current SMC 20TA: 4 amps
SMC 30TA: 7 amps
Unit cooling Fan forced air ow
Reverse time 6 – 12 hours programmable
No ow protection Automatic water ow sensing
Water ow 150 – 450 lt/minute. 480 kpa max. pressure
IP rating 24
Certication Q031143
Salt level 5000 ppm – 25000 ppm
Note: 1 gram of chlorine gas equivalent is equal to 10 grams of 10% liquid sodium hypochlorite
(liquid pool chlorine).
If the supply cord is damaged, it shall only be replaced by the manufacturer or its service
agent or similarly qualied person in order to avoid a hazard.

19
TM
WARRANTY
Your AutoChlorTM chlorine generator is covered by a thirty six (36) month in-factory repair
warranty, on all parts and labour, from the date of purchase. This warranty applies
to the original purchaser and is not transferable.
All chlorine generators are fully tested prior to being packed. If within 36 months of
purchase a problem occurs due to faulty workmanship or components, AIS will (at their
discretion) repair or replace the chlorine generator.
The manufacturer will not be liable for any consequential loss or damage caused by
operation outside the prescribed limits as outlined in the instruction manual, incorrect
installation, connection to an incorrect mains power supply, changes to internal wiring,
misuse, abuse, negligence, accidental damage, normal wear and tear, infestation or
damage caused by water entry.
Note: This warranty is strictly for in-factory repair. In the case of failure the complete
unit must be returned to the manufacturer or their designated agent.
CONTACT DETAILS:
In the unlikely event of a problem with your chlorine generator, please contact:
Australian warranty claims: 1800 676 076
Online warranty www.aiswater.com.au and go to: Support – Online warranty.
For assistance outside of the warranty period: call [phone] (extension 3)
For international warranty claims: Contact your local dealer.
Your local dealer:

www.aiswater.com.au
Australian Innovative SystemsTM
51 Millennium Place, Tingalpa,
Queensland 4173 Australia
AIS Contacts
Head Oce [phone] or 1300 965 222 (Australia wide)
Email: [e-mail]
Facsimile [phone]
WARRANTY HOTLINE [phone] (Australia wide)
TM
