FibroPool 8567I Operating instructions

INSTALLATION GUIDE AND OPERATING INSTRUCTIONS
AUTOMATIC CHLORINE FEEDERS
8567I / 8567O / 8568I / 8568O
I) INSTALLATION
8567I / 8568I
1. Your 85671 / 85681 automatic chlorine feeder is
designed for permanent installation in the pool water
return line.
2. Always install the chlorine feeder after the heater.
If there is no heater, install after the filter. Damage to
the heater or filter may result if concentrated
chlorine is allowed to flow through them.
3 . 8567I / 8568I is furnished with 1 ½ female
threads. 8568I is also e uipped with male threads. If
male end and union connections are desired , order
91382 PVC male union connector package. Thread or
socket adapters may also be approved for used. Only
use pipe sealants formulated and approved for use
with ABS plastic connection. Do not over tighten pipe
fitting. Proper fitting makeup is hand tight plus 1 to 1
½ turns maximum.
NOTICE: After starting up system,re-check all
connections for leaks. Re-tighten as re uired.
4 .Refer to s ction II DIRECTIONS FOR USE
NOTE: Never install chlorine feeder directly into copper plumbing
as pipe damage may occur. If you have brass or bronze
backwash valves, or other sensitive metallic compone nts,
consult your dealer for precautions or recommendations for
your particular system.
8567O / 8568O
A. PLANNING INSTALLATION
1. The inlet connection should be made in the piping
after the pump and before the filter, mark location
on pipe.
2. The outlet connection should be made in the
piping after the heater. If no heater is being used,
connection should be made after the filter. Mark
location on pipe.
3 . Based on the locations from steps. No 1 and No 2,
cut tubing to re uired lengths be sure ends are cut
evenly and cleanly.
NOTE : Never install chlorine feeder directly into copper
plumbing as pipe damage may occur. If you have brass or
bro nze backwash valves, or other sensitive metallic
components, consult your dea ler for precautions or
recommendations for your particular system.
B.CONNECTION TO CHLORINATOR
1. Wrap Teflon tape on large male thread of check valve and
thread it securely into outlet port of chlorinator.
NOTICE: the check valve is marked with a “dot” it also has
a ball that clicks when you shake it.
2. Wrap teflon tape on large male thread of the inlet fitting
adapter and thread it securely into the inlet port of
chlorinator.
3. To connect inlet tubing to chlorinator, place compression
nut over inlet tubing and nut up about 2”. Insert the tubing all
the way into the inlet fitting adapter socket and, holding
tubing in place tighten nut firmly by hand. Do not over
tighten
4. Connect outlet tubing to the check valve in the same
manner as in step 3 above.
C. CONNECTION TO PLUMBING LINES
NOTICE: The saddle fittings and clamps are designed to fit
the O.D of 1 ½” or 2” pipe.
5. Drill a 3/8” hole at location identified in step 1 of planning
installation section. Clean all burrs, shavings etc. Fit saddle

fitting, with gasket, into oval shaped hole in clamp and insert
fitting, gasket and pipe and tighten securely to achieve a
good seal. Do not over tighten clamp.
6. Drill a 3/8” hole at location identified in step 2 of planning
installation section. Install saddle fitting as in step 5 above.
7. connect inlet and outlet tubing to the saddle fittings with
compression Nuts as in step 3 above. Do not over tighten.
NOTICE: After starting up system, re-check all connections for
leaks. Re- tighten as re uired.
II) DIRECTIONS FOR USE
GENERAL
Before using your chlorinator , your pool /spa water should be
properly balance and conditioned and should have a chlorine
residual of approximately 1.0 to 1.5 ppm. Follow dealer and
chemical manufacturer's directions and instruction. Check
chlorine residual daily and adjust the dial valve for more or less
chlorine. The chlorine demand for pools and spas varies based
on usage, temperature, sunlight, etc. Initially , you'll have to
experiment to determinate the proper amount of chlorine and the
correct valve setting re uired for your pool and filter time cycle.
Follow chemical manufacturer's instructions for proper chlorine
level.
REFILLING CHLORINATOR
-Use only 3” diameter slow dissolving Trichloro-S Triazinetrione
chlorine tablets.
-Never use Trichloro-S – Triazinetrione chlorinate tablets.
-Never mix chemicals as it may cause fire and/ or an explosion.
- Never mix Trichloro-S Triazinetrione Chlorine tablets with
Calcium Hypochlorite, or with any other form of of concentrated
chlorine or other chemicals.
- Never add any other types of chlorine, PH adjusters, shock
treatments or algaecides through the skimmer. If these products
must be used they should be added directly into the pool water.
-Never isolate chlorine feeder with valve or other devices.
-Read and follow all safety instructions prior to operating or
servicing feeder.
-To reduce the risk of injury, do not permit children to use this
product.
-Wear eye and skin protection while maintaining or servicing
this unit
- Do not inhale fumes from the chlorinator or chemical
container .
- Chlorine feeder may under pressure, use caution, removing
cover.
1. Shut off all pumps and pump timers.
2. Turn chlorine feeder flow control valve to “OFF”
3. Verify chlorine feeder return line to pool is unrestricted
4. Wait one minute to relieve system pressure before
attempting to remove cover.
5. Remove cover.
6. Refill chlorine feeder only with 3” diameter slow
dissolving Trichloro-S Triazinetrione Chlorine tablets.
7. Secure Cover to Chlorine feeder.
8. Turn flow control valve to desired setting and Restart
Pump.
III) MAINTENENCE
A) TO CHANGE O-RING
8567I / 8567O
1. Read and follow instructions in Step 1 to 5 in Refilling
chlorinator section.
2. Remove the O-ring and replace with a replacement O-ring
(65431033080).
3. Replace cover, if chlorinator needs to be refilled read and
follow instructions in steps 6 to 8 in refilling chlorinator
section.
8568 I / 8568O
1. Read and follow instructions in Step 1 to 5 in Refilling
chlorinator section
2. Replace O-ring with a replacement O-ring (65431036080).
Reassemble being sure slip washers are in place on step of
cover (inside).
3. Replace cover. If chlorinator needs to be refilled; Read and
follow instructions in steps 6 to 8 in Refilling chlorinator
section.
B) TO REMOVE FLOW CONTROL VALVE HANDLED
Set pointer to Full insert screwdriver in slot opposite pointer,
lift up and rotate handle counterclockwise. This allows the
handled index lock tab to clear the body ridge.
C)WINTERIZING
Where freezing temperatures can be expected, drain all water
from chlorinator, ( For in- line permanently installed unit
remove drain plug) carefully remove undissolved tablets, and
rinse out chlorinator thoroughly with water. Replace cover
and drain plug.
D) VACUUMING
When vacuuming , close flow control valve to prevent bypass
of sediment and possible clogging of control valve
E)LUBRICATION
Never use petroleum type lubricants on cover O-ring. To
lubricate use jack's No. 327 lube only.

8567 I SERIES
REF
NO.
PART
NUMBER
DESCRIPTION NO.
REQ'D
1 647016703080 Cover 1
2 65431033080 O-Ring 1
3 88601004 Drain Plug W/Gasket 2
4 647016875000 Control Valve Assembly 1
8567O SERIES
REF
NO.
PART
NUMBER
DESCRIPTION NO.
REQ'D
1 647016703080 Cover 1
2 65431033080 O-Ring 1
3 88601004 Drain Plug W/Gasket 2
4 647016875000 Control Valve Assembly 1
5 647016807080 Inlet Fitting Adapter 2
6 647016806001 Compression Nuts 4
7 65749011080 Plastic Tubing- 8 ft. 1
8 647016805080 Saddle Fitting 2
9 6502101300 Saddle Clamp 2
10 647016873000 Check Valve Assembly 1
8568I SERIES
REF
NO.
PART
NUMBER
DESCRIPTION NO.
REQ'D
1 647016703080 Cover Cap 1
2 647016802000 Cover 1
3 65431036080 O-Ring 1
4 88601004 Drain Plug W/Gasket 2
5 647016875000 Control Valve Assembly 1
8568O SERIES
REF
NO.
PART
NUMBER
DESCRIPTION NO.
REQ'D
1 647016803080 Cover Cap 1
2 647016802000 Cover 1
3 65431036080 O- Ring 1
4 88601004 Drain Plug w/ Gasket 2
5 647016875000 Control Valve Assembly 1
6 647016807080 Inlet Fitting Adapter 2
7 647016806001 Compression Nuts 4
8 65749011080 Plastic Tubing- 8ft 1
9 647016805080 Saddle Fitting 2
10 65021013000 Saddle Clamp 2
11 647016873000 Check Valve Assembly 1
