Skytech H100 User manual

14+
H100
2.4G RC BOAT OPERATING
INSTRUCTIONS
1
1.This product adopts 370 strong magneto drive system，uses the
advanced 2.4 G technology of frequency connection,Further remote
distance.
2.Configuration of lithium ion battery.The speed about 20KM/H.
3.The characteristic flip：While sailing ship capsizing can control the
boat flip, ensure correct voyage.
4.Motor cooling system: extending the service life of the model.
5.Have left,right side navigation rudder:enhanced stability.
6.Low voltage alarm function:when the deficiency of the model,the
remote controller will send out alarm.（After the alarm sounds,please
get the boat back immediately.prevent the model without electricity in
coming back.）

QR code for
skytech website QR code for wechat

-1-
boat
hatch
switch of hatch
steering
engine bar
steering
rudder
guiding
rudder
propeller
outfall
Display racks
Turn left Trim Turn right Trim
forward trimbackward trim
throttle rocker direction rocker
RC boat main structure diagram
The default mode is left hand,press the button of turn left/right trim and open the
power switch at the sametime.Then loosening the Trim button .Switched to the
right hand mode when you listen a sound of “Di”.Restart it will be left hand mode.
2

-2-
Inserting batteries:remove the battery compartment on the back of the remote
controller and insert 4“AA” alkaline batteries,paying attention to the polarity
markings in the battery compartment(batteries must be purchased separately.
battery cover
4 x ”AA”
Charging the model battery
Inserting battery
1.Insert the plug
in the socket.
1.USB connected
to the computer.
NB:The red indicator turns on when charging and green indicator turns on when
charing is complete.
NB:The red indicator turns on when charging and go out when charing is complete.
This USB can be compatible with any phones,PC (7.4V USB)for rechargeable
batteries.
2.Connect the battery
and charger plug.
--
+
+
Style 1: charger with balance charge 110-240V power supply.(selective buying)
Style 2:USB(standard configuration)
2.Connect the battery
and charger plug.
1.Install batteries in correct polarity.
2.Do not mix old and new batteries.
3.Do not mix different type of batteries.
4.Non-rechargeable batteries cannot charging.
5.Rechargeable battery must be charged under adult supervision.
6.Power terminal shall not be short circuit.
7.Unable to connect to more than the recommended number of
power supply.
8.Only can be used the USB cable for charging with producers
provide,USB not a model.

-3-
forward/backward trim
Turn left/Right trim
Battery level:
boat battery level
Throttle/direction display
NB:CH1 is forward display ,CH2 is backward display.
CH3 is turn left display,CH4 is turn right display.
signal
Left/Right hand Mode
Intriduction of the Liquid crystal display
-3-

-4-
Inserting battery into the boat
Iubrication oil on the spindle tube wall
3.Connect the battery and power plug.
1.To the right or left turn on the switch of cabin, open up the cabin cover.
4.The cabin cover oblique inserted into the hull.
5.Tamp down the cabin cover.
6.Twisting the left/right of the switch until cocking the cabin cover.
2.Put the li-po into the battery holder of the hull.
fig.1 fig.2 fig.3
fig.6
fig.5fig.4
fig.1 fig.2 fig.3
fig.6
fig.5fig.4
fig.7 fig.8 fig.9

-5-
1.Put out the motor wire(see fig.1)
2.Put out the cooling rubbes hose(see fig.2)
3.Screw out the motor seat screw(see fig.3)
4.Remove the motor seat module (see fig.4)
5.Hold down the main shaft rubber pieces,using a wrench
lockout and propeller(see fig.5)
6.Put the spindle away a distance in the diection of the bow(see fig.6)
7.In amoderate amount of lubrication oil to the tail of the spindle tube.(see fig.7)
8.Spindle rotating forward and backward,pulls slowly,let the lubrication oil on the
spindle tube wall evenly.(see fig.8)
9.Hold down the main shaft rubber,using a wrench tightened the screw down and
propeller (see fig.9)
10.Load the motor seat module (see the fig.10)
11.Lock the motor seat screw(see fig.11)
12.To reconnect the cooling rubbes hose(see fig.12)
13.To reconnect the motor wire(see fig.13)
To pair the boat with the remote controller
WARNING
Put the model into the water (Boat need in the water to conduction the
power ).Turn on the remote controller. The controller LED indicator will
flashing and “Di”, the remote controller will “di-do-di” the controller LED
indicator will stay constant ,it means paired with the remote controller. Then
you can play it.
fig.10
fig.13
fig.11 fig.12
NB: 1.battery wire exhaust to boat side,to prevent the wire were cut off by the steering wheel.
2.All plug need tightly.
3.insure the cabin cover tightly,prevent leakage.
1.This product is suitable for people over the age of 14. Must only operate it
when supervised by an adult.
2.Finish the voyage,cannot recharge the battery immediately until the
battery cooling.
3.When the ship sailing,insure the area without people.Cannot have aquatic
or debris in the water,avoid the propeller were caught or damage to the
ship.
4.This product have some small parts,Don’t swallow in order to avoid
choking danger.
5.Please keep a sale distance with the voidhigh speed rotating propeller ,
avoid ground injury risk.Battery matters attention.
6.Motor is a hot parts,pls don’t touch it,in order to avoid scalding danger.
7.Regularly check the USB cable and other parts for damage,should stop
using until repair intact if have something broken..

5.Turn right
Throttle lever is pushed forwards and the direction rocker is pushed
right at the same time.The boat turns right.
Operation method /left hand mode
3.Backward
Throttle lever is pushed backwards. The boat moves backward.
2.Forward
Throttle lever is pushed forwards. The boat moves forward.
4.Turn left
Throttle lever is pushed forwards and the direction rocker is pushed left at the
same time.The boat turns left.
1.Correction
Throttle lever is pushed left，The direction of the rocker is pushed right, when
have a sound of “di”,means correction was successed.
-6-

-7-
6.Yaw left trim
Yaw left trim button
When the ship on the voyage turn right automatic，press the yaw left trim
button on the controller,boat will turn left slowly until it straight navigation.
10.180°Flip
7.Yaw right trim
Yaw right trim button
When the ship on the voyage turn left automatic，press the yaw right trim
button on the controller,boat will turn right slowly until it straight navigation.
8.Yaw backward trim
Yaw backward trim button
When the throttle level in the middle ，the boat still forward ,press the yaw
backward trim button on the controller until it stop forward.
9.Yaw forward trim
Yaw forward trim button
When the throttle level in the middle ，the boat still backward ,press the yaw
forward trim button on the controller until it stop backward.
When the boat turnover,Pls put the rocker forward(fig.1),put the throttle rocker
forward(fig.2),keep2-3s,then put the throttle roker back(fig.3),stay 2-3s,repeated
operation fig.2 and fig.3 until the boat flip.When we play the fig.2 and fig.3 ,keep
the rocker fixed.
fig.2 fig.3fig.1
