SLaudiolab SRS-200BS User manual

1
SRS-200BS
User’s Manual
(Bluetooth Stereo Headset)

2
Safety Notices
zPrior to use, please read “Bluetooth Stereo Headset user’s
manual”, carefully for its instructions and notices and use it
appropriately.
zPlease follow the instructions in order to prevent user’s risks
and property damages.
Warnings
zPlease do not damage the headset with a sharp object.
(such as nail, knife and scissors)
zPlease do not wet or soak headset in water.
zPlease do not let childrens or pets bite or suck the headset.
zPlease do not touch product with a wet hand.
zPlease do not use other battery chargers other than the battery
charger provided.
Cautions
zAvoid the direct ray of light or a hot and humid place.
(e.g., spa and sauna)
zDo not put in or near a thermic appliance such as heater and
microwave.
(Doing so may distort the product or result in explosion or fire.)
zDo not use the product near a microwave or wireless LAN.
(The electromagnetic interference between products using the
same frequence may result in malfunctuion or noise.)
zTurn off the product before storing, and keep it away from
places with high temperatures of more than 50°C, under direct
ray of light, or inside a hot vehicle. Keeping it in high
temperature may cause dagradation of the performance and
reduce the durability of the battery.
zPlease do not drop or shock the headset.

3
Cautio
!
zPlease do not rebuild, disassemble or repair the headset
arbitrarely. If rebuilt, disassembled or repaired arbitrarely it will
be not able to receive any free repair service.
zIf you are listening to music at a high volume for a long period
of time, it may damage your hearing.
zIf you hold the product with your hands too tight, the voice
quality may be degraded.
zPlease do not use this headset while you are driving. If its use is
inevitable, please follow the related laws and regulations and
make your conversation as short as possible.
Since the Bluetooth Stereo Headset has a possibility of bad
connection, it shall not be used for the services directly related
to safety.

4
Table of Contents
Safety Notices .............................................2
Warnings .......................................................... 2
Cautions ........................................................... 2
Introduction..................................................5
Package .......................................................5
Features....................................................... 6
Before Starting to Use................................. 7
Preparations..................................................... 7
Charging........................................................... 7
Usage...........................................................8
Turning On/Off the Headset............................. 8
Connecting the Headset to a Bluetooth Device8
Calling .............................................................. 9
Receiving a Call ............................................. 10
Hanging up the Call........................................ 10
Refusing a Call ............................................... 10
Volume Control .............................................. 10
Call Switching ................................................ 10
Listening to the Music.................................... 12
Speaking on the phone while playing music .. 12
Using SRS 3D Sound Effect.......................14
Specifications............................................. 14
Troubleshooting......................................... 16
LED Status Indication ................................ 17
Quality Warranty........................................18

5
Introduction
Wireless Stereo Headset, developed with the Bluetooth
technology, has the following primary features.
zWireless Stereo Headset
zWireless Remote Control function
zWireless Handsfree
zSRS sound effect
Package
zAfter purchasing, detach the BD_Address/serial number label
from the product, keep it attached to the blank of the warranty
(required for the after-sales service.).
DC chage
r
SRS-200BS Bod
y
Earphone
Sponges
Part of the components
shall be changed without
notice for quality
im
p
rovement.
User’s manual

6
Features
V
olume Up (+)
Button
V
olume Down (
–
)
Button
DC Charge
Terminal
Call
/
Termin
a
te
/
SRS
Button
Music Pla
y
/
Pause
/
Stop
Button
Move to the
Next Button
Move to the
Previous Button
Power Switch
Microphone
Input
Operation Status
LED

7
Cautio
!
Before Starting to Use
Preparations
zPlease read the instructions carefully before its useage.
Charging
zThe product includes a built-in battery. Please charge it with
the DC charger provided in the box.
zAfter purchasing this product, please charge the battery fully
before using it for the first time.
zPlease charge the headset until the indicator turns from Red
to Blue.
zDo not use the headset while charging.
Please do not charge this headset with the unspecified
chargers. It may cause damage and deterioration.

8
Cautio
!
Usage
Turning On/Off the Headset
zMove the switch as shown, to turn on the power.
zMove the switch as shown, to turn off the power.
Connecting the Headset to a Bluetooth Device
zConnection between headset and Bluetooth mobile phone or
other Bluetooth devices is made wirelessly through an
encoded authentication.
The following registration process should be performed
for the initial connection.
1. Set the headset into stand by mode. With call button pressed, you
may turn on the power. (As the operation status LED flicks in Blue
and Red color, stand-by mode lasts for around three minutes.)
2. Search the headset from the Bluetooth device, referring to the
Bluetooth device user’s manual.
3. Select “SRS-200BS” from the searched list.
4. Enter “0000” when Bluetooth asks for password or pin-number.
5. Select “SRS-200BS” from the list of registered devices.
Please refer to the User’s Manual of your mobile phone for the
details about Bluetooth headset connection, registration and
deletion.
* Once registered, there is no need for re-registering for future
connection.
* If there is no registered devices in three minutes of register-stand-by
mode, it automatically switches to connect-stand-by mode. In this
case, turn off the device and try to register from the beginning.

9
Cautio
!
Cautio
!
Calling
Calling to the Latest Number
zPress the call button to check the last call history saved
in the phone.
zPress the call button again to call the last number.
(Depends on the type of the mobile phone, you may call
without saving the call history.)
Calling with a Voice
zPlease press the call button for more than 2 seconds.
zYou can use it according to the sequence of voice calling
function of your mobile phone.
When the mobile phone supports voice calling function and is
connected through a handsfree profile, calls can be placed
with a voice.
Calling with a Mobile Phone
zPlease call with your mobile phone.
zCheck the calling tone from the mobile phone and push the
call button on your headset. You can either hear the calling
tone or communicate through headset. (In case of the mobile
phone that supports an automatic call switching function, the
call automatically switchs to the headset.)
Making a call in a noisy place or outside may cause a difficulty
for communication.

10
Receiving a Call
zPlease press the call button when the phone rings.
Hanging up the Call
zPlease press the call button to hang up the phone.
Refusing a Call
zPlease press the call button for more than 2 seconds.
Volume Control
zAdjust the headset speaker volume by pressing the volume
button while talking.
Call Switching
While having a conversation, use it when switching from headset
to Mobile phone or vice versa.
From headset
To Bluetooth mobile phone
Press the call button for more
than 2 seconds
From Bluetooth mobile phone
To headset
Press the call button for more
than 2 seconds

11
Cautio
!
This product is constructed with a multi-party call ability.
(To have a multi-party call, user’s device should support the
Bluetooth function.)
zCalling Waiting
You can put the current call in a wait state by pushing the
button shortly while talking on the phone, and can
terminate the call in a wait state by pushing the button
for a longer period of time (more than 2 seconds).
zReceiving Another Call While Talking on the Phone
1. You can take another incoming call by pushing the button
shortly while talking on the phone and can
send a busy signal to the incoming call by pushing the
button for a longer period of time (more than
2 seconds).
2. You can take the incoming call after hanging up the current
call by pushing the music play button shortly.
This function is available on GSM phones.
Multi-Party Call Function (3-Way Call)

12
Listening to the Music
Press the button to listen to the music saved in the phone
through the headset.
Speaking on the phone while playing music
This ability is available in the phone that provides all audio
transmitting profile(A2DP), headset profile(HSP), and hands-free
profile(HFP).
Dialing while playing music
zPress for 2 seconds to finish music player mode.
zPress the call button and hold this key briefly to view
the call history.
zPress the call button again to call the last number.
(Depends on the type of the mobile phone, you may call
without saving the call history.)
zPlease press the call button to hang up the phone.
Headset Button
Play Press for 2 seconds
Stop Playing Music Press for 2 seconds
Pause Press shortly while playing music
Adjusting volume Press
Play the
Previous / Next Song Press
Rewind / Fast Rewind Press for 2 seconds

13
Receiving a call while playing music
zThe bell rings automatically stopping the music.
(Operation status LED flickers Red in 5 second interval.)
zWhen the music stops and the bell rings, press the call button
briefly.
zPlease press the call button to hang up the phone.
zWhen the call ends, the music automatically comes back on.
(Depends on the manufacturer of the Bluetooth device, you
may have to press to start the music.
* This device saves the information of the connected device, and
reconnection of the latest device is possible when asked by
the user.
* Disconnected headset and Bluetooth devices are available for
reconnection in 3 minutes, they are automatically reconnected.
* Then, it should maintain the connection status.
R
e-connect
i
on
F
unct
i
on

14
Cautio
!
Using SRS 3D Sound Effect
zHeadset facilitates the SRS 3D sound effect function. Use the
SRS 3D sound effect to enjoy a high quality 3D sound.
zPress the call button for 4 seconds while listening to music
for high quality SRS sound effect. The Blue operation status
LED flickers twice in 5 second interval.
Press SRS button for 4 seconds while listening to music for high
quality SRS sound effect. (1 ring tone after 2 ring tones)
zSRS effect offers two types of mode.
(SRS Normal or SRS Max)
zTo disable the SRS function, press the call button again.
(Red SRS operation status LED turn off)
z Is a trademark of SRS Labs, Inc.
zSRS WOW HD, SRS and technology is incorporated
under license from SRS Labs, Inc.
Normal →SRS Normal Press the call button for 4 seconds
(1 ring tone after 2 ring tones)
SRS Normal →SRS Max Press the call button for 4 seconds
(1 ring tone after 2 ring tones)
SRS Max →Normal Press the call button for 4 seconds
(1 ring tone after 2 ring tones)
Hold down this
Key for 4 seconds

15
Specifications
Specification Description
Product Name Radio Device for Radio data
communication System
(SRS-200BS)
Authentication Number FCC ID : U6KSRS200BSA
MIC : SLA-SRS-200BS
CE0678
Bluetooth ID : B012701
Bluetooth Specification Version 2.0
Supported Bluetooth
Profile
Audio transmission profile(A2DP),
Headset profile(HSP), Handsfree profile(HFP)
and Remote control profile(AVRCP)
Frequency Range 2.402 ~ 2.480 GHz
Transmission Output 0.1mW ~ 2.5mW
DSP effect SRS WOW HD
Range Maximum 10 meters
Operating Temperature -10 ~℃50℃
Standby Time Maximum 50 hours
Tal k Time Maximum 3.5 hours
Music Play Time Maximum 3.5 hours
Battery Charging Time 2 hours
Adaptor Spec Rated Input: AC 100~240V, 50/60Hz
Rated Output: DC 5V, 700mA
Dimension SRS-200BS Body (61.0 x 29.5 x 7.6 mm)
Weight 27g ( including earphone)

16
Troubleshooting
Problem Action
The operation status
LED is not turned on.
If the operation status LED is not responding even▶
after turning on the power switch, it is because the
battery is discharged. Use after charging it
sufficiently.
Device registration
can not be done.
▶Registration should be made from the user’s
Bluetooth device after setting the headset to the
registration status and turning on the Bluetooth
operation of the Bluetooth device. (Please refer to
the Bluetooth device usage from the user’s manual
of the Bluetooth device.)
Authentication code is
Not working.
When connecting between Bluetooth devices, the▶
accurate authentication number should be entered.
(In case of this product, the number is “0000”).
It has bad
connections.
It is frequently
disconnected while
listening to music.
The radio wave is not sta▶ble. Please try to use it in
another location.
It is either under a bad status of receiving radio▶
waves due to an obstacle between Bluetooth
devices or by a long distance between them. Please
make shorter the distance between two devices.
The battery standby is
too short.
Since battery is a consumable article, its▶standby
time will get shorter from the initial use.
The use time can be shorter if the charged product is▶
left in a low or high temperature for a long period of
time.
Heat is generated
from headset .
It requires a consider▶able amount of current while
talking. Heat is generated in this process and when
talking or playing music for a long period of time.
You may continue to use since it doesn’t influence on▶
the lifetime and performance of the product.

17
LED Status Indication
Headset Status LED Indication Status Sound
Power On Blue LED blinks 4 times Getting higher
2 syllables
On Charging Red LED turns on
Charging completion Blue LED turns on
Connection Standby
Mode (Pairing Mode)
Red and Blue LEDs blink
(max. 3 minutes)
Getting higher
4 syllables
Connection
Completion,
Connection Alive
Blue LED blinks at the interval of 5
seconds
Connection Failure,
No Connection
Blue LED blinks at the interval of 3
seconds
When Receiving
a Call
Red LED blinks at the interval of 1
second Ring Tone
On Busy Same as Connection Alive mode
When Listening
Stereo Music Same as Connection Alive mode
Battery Level
30% dsodf
Red LED blinks at the interval of 5
seconds
Battery Level
10% dsodf
Red LED blinks at the interval of 5
seconds
4-syllables Warning
(interval of
30 seconds)
Insufficient Battery Red LED blinks 4 times 4-syllables warning
In SRS operating
Blue LED blinks twice at the interval
of 5 seconds
(Red LED blinks in insufficient
battery level)
1 ring tone after
2 ring tones

제품 보증서
Thank you for purchasing SLaudiolab products. Since
the quality assurance period of this product starts from
the date of purchase, please have the purchase date
written on this sheet to have appropriate services.
SLaudiolab assures this product as shown below
according to the following compensation rules and
regulations.
Quality Warranty
Free Repair/Maintenance Services
zFree repair/maintenance services shall be provided when
problem occurs under normal use of this product within one
year from the date of purchase (within the warranty period).
zThe warranty period for batteries is 6 months from the date
of purchase.
Charged Services
zServices applicable to the following cases shall be charged
even within the warranty period.
- When the problem occurs from user’s fault, intent and Alteration.
- When the problem occurs due to the defect of connecting device.
- When the problem occurs from a natural disaster such as fire,
earthquake, flood or thunderbolt.
- When the problem occurs from an abnormality of power source.
- When the repair/maintenance has been made by a person or
technician other than those from SL Audio Laboratory service
centers and/or authorized agents.
Parts Retention Period
zThe holding time of each part for maintenance is 3 years
after sterilization.

Compensation Criteria
Type of Consumer Claims Within the
Warranty
Period
After the
Warranty
Period
When a major repair is required due to a
functional or performance defect caused
under normal use within 10 days from the
date of purchase.
Replace or
refund N/A
When a major repair is required due to a
functional or performance defect caused
under normal use within 30 days from the
date of purchase.
Replace N/A
When a problem occur more than three
times cause of the same reason (on the
4th time).
Replace or
refund Charged repair
When the replacement requires a major repair
within 30 days from the date of replacement. Refund N/A
When a problem has recurred again after it
repaired for the 4th time. (on the 5th time).
Replace or
refund N/A
When the repair is not possible.
(within the parts retention period)
Replace or
refund
Refund the amount
depreciated from the
purchase price plus
10% to the amount.
If the replacement is not possible. Refund N/A
Product Bluetooth Stereo Headset
Model SRS-200BS
Serial No
Date of Purchase
Name Tel
Customer Add
Name Tel
Agent Add
SLaudiolab Co., Ltd.
6F Won-il Bldg, #57-30 Nonhyun-Dong, Gangnam-Gu, Seoul

For CE Marking
Declaration of conformity
We, SLaudiolab Of 6F Won-il Bldg, #57-30 Nonhyun-Dong
Gangnam-Gu, Seoul, Korea
Declare under our sole responsibility that our product
SLaudiolab type SRS-200BS
To which this declaration relates is in conformity with the
Appropriate standards EN 300 328, EN 301 489-1,
EN301 489-17,EN50360 and EN 60950-1 following the
provisions of
Radio Equipment and Telecommunication Equipment
Directive 1999/5/EC with requirements covering
EMC directive 89/336/EEC and Low Voltage directive
73/23/EEC.
Signature
Seoul March 2007
Park Persson, Head of Product Business Unit Accessories
