Smacq Technologies USB-3100 Series User manual

USB-3100 Series Multifunctional
Data Acquisition Devices
User Manual
Rev. C
Smacq
Beijing Smacq Technology Co., Ltd.
Smacq.com
Smacq.cn

1 |
StatementL
Copyright
©2018 Beijing Smacq Technology Co., Ltd. All rights reserved
No content of this manual may be reproduced, modified or abridged without prior consent and
written permission.
Trademark information
Smacq is a registered trademark ofBeijing Smacq Technology Co., Ltd.
The names ofthe other products and companies mentioned inthis document are trademarks or
trade names oftheir respective companies.
Other Disclaimer
The information provided in this document may be modified and updated in subsequent
versions without prior notice.
Smacq does not provide any warranties, express or implied, for this document as well as the
information inside it, including but not limited to implied warranties of the marketable nature
of the product and its suitability for a particular purpose.
There may be a chance that inaccurate descriptions or errors exist in this document. Smacq
does not hold any liability for accidents because of the information and deductive functions
provided in this manual, as well as the resulting loss of any chance because of the use of this
document.
Smacq reserves the rights to change product specifications, prices, and decide whether to stop
the production.
Contact Us
If you have any questions or need assistance in using this product or this document, please contact
us via:
Phone: [phone]
E-Mail: servic[email protected]
Website: http://www.smacq.com
http://www.smacq.cn

2 |
Safety Requirements
Warning Only the voltage within the specified range can be connected. Voltage
exceeding the specified range may cause damage to the device, and even
present a negative impact on personal safety. Check the product
specification for detailed reference to the range of voltages that can be
connected by each port.
Warning Do not attempt to operate the device in other ways that are not
mentioned in this document. Incorrect use of the device may be
dangerous. In the event of device damage, the internal security
protection mechanism will also be affected.
Warning Do not attempt to replace device components or change devices in other
ways that are not mentioned in this document. Do not repair the device
yourself in the event of a product failure.
Warning Do not use the device in an environment where an explosion may occur
or where flammable flue or gas is present. If you must use the device in
this kind of environment, please fit it into a proper case.
Warning While the device is running, all chassis covers and fill panels need to be
closed.
Warning For equipment with exhaust vents, do not insert foreign objects into the
vents or block air circulation in the vents.

3 |
Measurement Categories
Warning For use in measurement category I (CAT I) only. Do not use in
measurement category II/III/IV. Use this device to connect signals or
make measurements.
Measurement categories Note
Measurement categories I (CAT I) means that measurements are made on a circuit that is not
directly connected to the main power supply. For example, a circuit that is not exported from the
main power supply, especially a circuit that is exported from a protected (internal) primary power
supply, is measured. In the latter case, the instantaneous stress will change. Therefore, the user
should be aware of the instantaneous affordability of the device.
Measurement categories II (CAT II) means that measurements are made on a circuit that is directly
connected to a low-voltage device. For example, a measurement on household appliances, portable
tools and similar equipment.
Measurement categories III (CAT III) means that measurements are made in construction
equipment. For example, a measurement on the distribution boards, circuit breakers, wiring
(including cables, Busbars, junction boxes, switches, sockets) in fixed equipment and equipment
for industrial use and certain other equipment (for example, fixed motors that are permanently
connected to fixtures).
Measurement categories IV (CAT IV) means that measurements are made on the source of
low-voltage equipment. For example, a measurement on a meter, a major overcurrent protection
device, and a pulse control unit.

4 |
Environment
Temperature
Operating 0℃ ~ 55℃
Storage -40℃ ~ 85℃
Humidity
Operating 5%RH ~ 95%RH, no condensation
Storage 5%RH ~ 95%RH, no condensation
Pollution degree 2
Highest elevation 2000 m
Pollution degree description
Pollution degree 1: No pollution, or only dry non-conductive pollution. This pollution degree has
no effect. For example: a clean room or an air-conditioned office environment.
Pollution degree 2: Generally only dry non-conductive pollution occurs. Temporary conduction
can sometimes occur due to condensation. For example: General indoor environment.
Pollution degree 3: Conductive pollution occurs, or dry non-conductive pollution becomes
conductive due to condensation. For example, an outdoor sheltered environment.
Pollution degree 4: Permanent conductive pollution caused by conductive dust, rain, or snow. For
example: Outdoor places.
Recycle precautions
Warning Some of the substances contained in this product may be harmful to the
environment or human health. In order to avoid releasing harmful
substances into the environment or endangering human health, it is
recommended that appropriate methods be used to recover this product
to ensure that most materials can be properly reused or recycled. For
information about processing or recycling, please contact your local
professional organizations.

5 |
CONTENT
SAFETY REQUIREMENTS................................................................................................................. 2
MEASUREMENT CATEGORIES .......................................................................................................3
ENVIRONMENT ................................................................................................................................... 4
1. GETTING STARTED....................................................................................................................7
1.1. PRODUCT INTRODUCTION ......................................................................................................... 7
1.2. FUNCTION DIAGRAM ................................................................................................................8
1.3. PRODUCT SPECIFICATIONS ........................................................................................................ 8
1.4. PRODUCT UNPACKING.............................................................................................................12
Precautions .................................................................................................................................... 12
Check the packing list ....................................................................................................................13
2. INSTALLATION..........................................................................................................................14
2.1. CONNECTOR SIGNAL PINS DISTRIBUTION ................................................................................14
2.2. USB CABLE REINFORCEMENT DESIGN .................................................................................... 16
2.3. DRIVE INSTALLATION.............................................................................................................. 16
3. ANALOG INPUT（AI）............................................................................................................19
3.1. CIRCUIT DIAGRAM .................................................................................................................. 19
3.2. SIGNAL CONNECTION METHODS..............................................................................................19
3.3. FLOATING GROUNDED SIGNAL SOURCE ...................................................................................20
Using differential mode (DIFF) connection................................................................................... 20
Non-grounded reference single-ended mode (NRSE) connection ..................................................23
3.4. GROUNDED SIGNAL SOURCE ..................................................................................................24
Use a differential mode (DIFF) connection ...................................................................................24
Use a non-grounded reference single-ended mode (NRSE) connection .........................................25
3.5. SIGNAL ACQUISITION MODE .................................................................................................... 26
Hardware timing mode...................................................................................................................26
Continuous acquisition mode.........................................................................................................26
Limited number acquisition mode ..................................................................................................27
3.6. COMPREHENSIVE SAMPLING RATE AND SINGLE CHANNEL SAMPLING RATE .............................27
3.7. AI SAMPLING CLOCK ..............................................................................................................27
3.8. TRIGGER .................................................................................................................................28
Clear trigger ..................................................................................................................................29
Pre-trigger...................................................................................................................................... 29
4. ANALOG OUTPUT (AO) ...........................................................................................................31
4.1. CIRCUIT DIAGRAM ..................................................................................................................31
4.2. SIGNAL OUTPUT MODE............................................................................................................ 31
DC immediate output ..................................................................................................................... 31
Hardware timing ............................................................................................................................ 32

6 |
Finite number output mode ............................................................................................................32
Infinite loop output mode ...............................................................................................................32
Infinite non-loop output mode ........................................................................................................32
4.3. OUTPUT UPDATE RATE ............................................................................................................33
Synchronous update .......................................................................................................................33
4.4. AO SAMPLING CLOCK .............................................................................................................33
4.5. TRIGGER .................................................................................................................................34
Clear trigger ..................................................................................................................................35
5. DIGITAL INPUT（DI）............................................................................................................. 36
5.1. SIGNAL ACQUISITION MODE ....................................................................................................36
Hardware timing ............................................................................................................................ 36
Continuous acquisition mode.........................................................................................................36
Limited number acquisition mode ..................................................................................................37
5.2. SAMPLING RATE...................................................................................................................... 37
5.3. DI SAMPLING CLOCK ..............................................................................................................37
5.4. TRIGGER .................................................................................................................................38
Clear Trigger.................................................................................................................................. 39
Pre-Trigger ..................................................................................................................................... 39
6. DIGITAL OUTPUT（DO）.......................................................................................................40
6.1. SIGNAL OUTPUT MODE ............................................................................................................40
Immediate output............................................................................................................................ 40
Hardware timing ............................................................................................................................ 40
Finite number output mode ............................................................................................................40
Infinite loop output mode ...............................................................................................................41
Infinite non-loop output mode ........................................................................................................41
6.2. OUTPUT UPDATE RATE ............................................................................................................41
6.3. DO SAMPLING CLOCK .............................................................................................................42
6.4. TRIGGER .................................................................................................................................42
Clear trigger ..................................................................................................................................43
7. SYNCHRONIZATION SYSTEM............................................................................................... 44
7.1. SAMPLING CLOCK ...................................................................................................................44
7.2. EXTERNAL TRIGGER................................................................................................................ 45
8. SERVICE AND WARRANTY .................................................................................................... 47
9. ORDERING INFORMATION ...................................................................................................48

7 |
1. Getting Started
This chapter describes the basic functions ofUSB-3100 Series Data Acquisition Devices,as
well as product specifications and precautions in the process ofproduct unpacking.
1.1. Product introduction
USB-3100 Series data acquisition device is the multifunctional data acquisition devices based on
high-speed USB2.0 interface. When connected to thecomputer, it can be used for continuous
high-speed signal acquisition and high-speed control signal output.
USB-3100 series of data acquisition devices can measure analog anddigital signals continuously
and save the data tothe computer hard drive without interruption. Itcanalso provide digital signal
output, periodic repetitive signal output, and high-speed uninterrupted non-repetitive signal output
controlled bya computer.
USB-3100 series data acquisition device supports operating inWindows OS, providing standard
DLLs andsupport for mainstream development languages including VC++, VB, C#, LabVIEW,
and MATLAB.
USB-3100 series data acquisition device provides multiple models, in terms offunction and
performance. For detailed reference, please turn toChapter 1.3 for specification description of
each model.
Key Features
High speed USB interface, Plug and Play,USB powered
16-bit analog input resolution, support continuous uninterrupted acquisition
Up to 1MS/s sampling rate for analog input
Multi-range and separate range support on all analog input channels
Support single-ended or differential signals onall analog input channels
16-bitanalog output resolution, with output range of ±10V
Support 4 channel synchronous analog output, up to 100kS/s sampling rate
Support continuous analog output of nonrepetitive arbitrary waveforms ofinfinite
length
Analog output waveform supports calculation of scale and offset.
Up to 10MS/s/Ch sampling rate for digital I/O

8 |
1.2. Function Diagram
Figure 1.1 shows the schematic diagram ofUSB-3100 series data acquisition device.
USB bus
Trigger source:
Software trigger
External trigger
Din trigger
Sampling clock source:
Internal module sampling
clock source
External sampling clock
source
AI
Digital I/O
FIFO cache
Figure 1.1 USB-3100 series data acquisition device functions
1.3. Product specifications
The following product specification parameters, unless otherwise stated, are acquired at the
temperature of 25°C and the humidity of 40%, while the device is turned on for 20 minutes.
Analog input
Number of channels
USB-3130/3131/3132/3133：24 Single-Ended /12 Difference
USB-3120/3121/3122/3123：16 Single-Ended / 8 Difference
USB-3110/3111/3112/3113：8 Single-Ended / 4 Difference
ADC type SAR
Resolution 16-bit
Highest sampling rate USB-3113/3123/3133: 1MS/s, continuous, all channels
USB-3112/3122/3132: 500Ks/s, continuous, all channels

9 |
USB-3111/3121/3131: 250Ks/s, continuous, all channels
USB-3110/3120/3130: 125KS/s, continuous, all channels
Timing resolution 10ns
Channel synchronization No
Range ±10.24 V/±5.12 V/±2.56 V/±1.28 V/±0.64 V
Input coupling mode DC
Input impedance 500 MΩ
Small signal bandwidth
(-3db）
450KHz
Input bias current 0.7nA
Analog input max voltage The ground voltage of each input side does not exceed ±12 V
Software FIFO 2 MPts/Ch
Pre-trigger FIFO 4096 Pts
AI capture mode Continuous acquisition mode and limited number acquisition mode
Analog input accuracy (with temperature coefficient of 5 ppm/℃)
Range Gain error
(ppm of reading)
Offset error
(ppm of range)
Random noise
(μVrms)
Full range
absolute
accuracy
(μV)
±10.24 V 20 10 195 820
±5.12 V 50 15 110 550
±2.56 V 55 30 70 315
±1.28 V 100 60 60 220
±0.64 V 200 120 50 100
Analog output
Number of channels 4
Resolution 16-bit
DNL ±1 LSB
Highest update rate 100 kHz/Ch
Timing resolution 10 ns
Channel
synchronization Yes
Input range ±10 V
Output coupling DC
Highest sampling rate
Highest sampling rate

10 |
Output impedance 0.1 Ω
Output drive current 10 mA
Power-on status Within ±50 mV
Hardware FIFO 2048 Pts/Ch
AO output mode
DC direct output, Onboard FIFO waveform periodic output, onboard
FIFO waveform trigger N loop, non-repetitive loop signals to computer
caches
Output voltage
establishment time 4 us
Edge slope 9.2 V/us
Analog output accuracy
Range (V) -10 ~ 10
Gain error (reading’s ppm) 30
Gain temperature coefficient (reading’s
ppm/℃) 5
Offset error (range’s ppm) 50
Offset temperature coefficient (range’s
ppm/℃) 5
Full range absolute precision (mV) 5
Reference temperature coefficient
(ppm/℃) 5
INL error (range’s ppm) 120
Digital I/O
Number of channels 4 input, 4 output
Ground reference DGND
Digital input pull-up
resistance 10KΩ
Digital input voltage High level: 1.95 V ~ 5 V
Low level: 0 V ~ 1.2 V
Digital output voltage High level: 3.3 V
Low level: 0 v ~ 0.003 V
Digital output
power-on status Low level

11 |
DIN highest sampling
rate 10 MS/s/Ch
DOUT highest update
rate 10 MS/s/Ch
Timing resolution 10ns
Channel
synchronization Yes
DIN software FIFO 2MPts/Ch
DIN pre-trigger FIFO 2048Pts/Ch
DOUT hardware FIFO 2048Pts/Ch
DIN capture mode
Continuous acquisition mode and OneShot mode
When the sampling rate is set at 4MS/s/Ch, the USB-3100 series only
support OneShot mode with sampling point limit of 15000.
DOUT output mode
Direct output; onboard FIFO waveform periodic generation; onboard
FIFO waveform trigger N loop; Uninterrupted non-repetitive signals for
computer caches
DOUT edge time Ascending edge: 6ns
Descending edge: 8ns
External trigger
Number of channels 1 input, 1 output
Input voltage High level: 1.95 V ~ 5 V
Low level: 0 V ~ 1.2 V
Output voltage High level: 3.3 V
Low level: 0 v ~ 0.003 V
Output power-on status Low level
Output edge time Ascending edge: 6ns
Descending edge: 8ns
External sampling clock I/O
Number of channels 1 input, 1 output
Input voltage High level: 1.95 V ~ 5 V
Low level: 0 V ~ 1.2 V
Output voltage High level: 3.3 V
Low level: 0 v ~ 0.003 V
Output power-on status Low level

12 |
Output frequency range DC ~ 1 MHz
Output edge time Ascending edge: 6ns
Descending edge: 8ns
Calibration
Recommended
warm-up time No less than 20Minutes
Recommended
calibration interval 1year
Bus interface
USB USB2.0 High Speed interface
Power supply requirements
USB interface power
supply 4.5 V ~ 5.5 V
Typical current without
load 400mA
Maximum Load 600mA
Physical properties
Size (mm) Without connectors: 150*96*28
Connectors included: 150*112*28
Weight (g) Without connectors: about 185g
Connectors included: about 230g
I/O connectors Bolt terminals
Bolt terminal
connection
16 AWG ~ 28 AWG
USB connectors USB Type B
1.4. Product unpacking
Precautions
To prevent electrostatic discharge (ESD) from damaging the device, please note the following:
Please wear a grounding wristband or touch a grounded object first to ensure being

13 |
grounded.
Before removing the equipment from the packaging, please first connect the anti-static
packaging to the grounded object.
Do not touch the exposed pins of the connector.
Place your device in anti-static packaging when you are not using the device.
Check the packing list
After unpacking the product, follow the packing list in the box, check the host and each
attachment individually to ensure that the items in the box are consistent with the packing list.
If you find that any item is missing, please get in touch with us for help as soon as possible.
If you find that the product comes in damaged after unpacking, please get in touch with us as soon
as possible. Do not install damaged equipment on your devices.

14 |
2. Installation
This chapter describes signal connection and drive installation ofUSB-3100 series
data acquisition device.
2.1. Connector signal pins distribution
Figure 2.1 USB-3100 signal pins distribution
Attention When USB 3100 DAQ device is connected with a single-ended connector
via analog input, AI SENSE should only be connected to the terminal of
the group in which the channel is located, that is, the positive and
negative ends of the measured analog signal should be connected to the

15 |
same terminal, otherwise it will cause a measurement error.
Table 2.1, Signal pin allocation
Signal name Single-ended input Differential input
AI 0 Analog input 0 Analog input 0 Cathode
AI 1 Analog input 1 Analog input 0 Negative
AI 2 Analog input 2 Analog input 2 Cathode
AI 3 Analog input 3 Analog input 2 Negative
AI 4 Analog input 4 Analog input 4 Cathode
AI 5 Analog input 5 Analog input 4Negative
AI 6 Analog input 6 Analog input 6 Cathode
AI 7 Analog input 7 Analog input 6 Negative
AI 8 Analog input 8 Analog input 8 Cathode
AI 9 Analog input 9 Analog input 8 Negative
AI 10 Analog input 10 Analog input 10 Cathode
AI 11 Analog input 11 Analog input 10 Negative
AI 12 Analog input 12 Analog input 12 Cathode
AI 13 Analog input 13 Analog input 12 Negative
AI 14 Analog input 14 Analog input 14 Cathode
AI 15 Analog input 15 Analog input 14 Negative
AI 16 Analog input 16 Analog input 16 Cathode
AI 17 Analog input 17 Analog input 16 Negative
AI 18 Analog input 18 Analog input 18 Cathode
AI 19 Analog input 19 Analog input 18 Negative
AI 20 Analog input 20 Analog input 20 Cathode
AI 21 Analog input 21 Analog input 20 Negative
AI 22 Analog input 22 Analog input 22 Cathode
AI 23 Analog input 23 Analog input 22 Negative
AI SENSE Analog input reference Not defined
AGND Simulated ground Simulated ground
AO 0 Analog output 0 No differential mode
AO 1 Analog output 1 No differential mode
AO 2 Analog output 2 No differential mode
AO 3 Analog output 3 No differential mode
AGND Simulated ground No differential mode
DO 0 Digital output 0 Not available
DO 1 Digital output 1 Not available

16 |
Signal name Single-ended input Differential input
DO 2 Digital output 2 Not available
DO 3 Digital output 3 Not available
DGND Digital ground Not available
EXT TRIG out Trigger signal output Not available
EXT TRIG in External trigger signal input Not available
CONV out Sampling clock output Not available
CONV in External sampling clock input Not available
NC Not connected Not connected
2.2. USB cable reinforcement design
USB cable connectors are prone to be pulled off during operation. USB-3100 series data
acquisition devices provide a cable reinforcement design, with which a strap can beused tofix
the USB cable to the device to prevent the accidents. Check Figure 2.2 for details.
Figure 2.2 USB cable reinforcement design
2.3. Drive installation
Smacq USB-3100 series data acquisition device support Microsoft Windows XP,Windows 7,
Windows 8/8.1, and Windows 10, including all the 32-bit and 64-bit versions. Toinstall the
driver for USB-3100 devices, you need to turn off driver signature enforcement first.

17 |
Here is an example step-by-step tutorial on how to install the driver in Windows 7.
1) Connect your USB-3100 card to the computer and launch the Device Manager in
Windows.
2) There should be a device with an exclamation point.”
Right-click it, select “Update driver”.
3) In the pop-up dialog box, select “Browse my computer for driver software”
4) And then select “Let me pick from a list of device drivers on my computer”
5) Click on “Next” and then select “Have disk”
6) Click Browse in the pop-up dialog box, then enter the \USB-3000SeriesDAQ\driver
folder in the CD-ROM, then enter the "win7" folder, then the 32-bit operating system
enters the "x86" folder, the 64-bit operating system enters the "x64" folder, select the
"susb.inf" file, and then click "Open". (The drivers of Windows8/8.1 and Windows10
are the same as those of Windows7, using the same file. )
7) Then in the dialogue of “Install from disk”, click on “Yes”.
8) Click “Next”, if the Windows security warning pops up, you need to select “Install this
driver software anyway” to finish the installation.
After these steps, the operating system will start installing the driver, which usually takes about 30
seconds. After the driver is installed, the exclamation point in Device Manager will disappear, as
shown in the following Figure 2.3.

18 |
Figure 2.3 the Device Manager after the driver is correctly installed

19 |
3. Analog Input（AI）
This chapter describes measuring the relevant content ofanalog input signals on USB-3100
series data acquisition devices.AI here is short for Analog Input.
3.1. Circuit diagram
Figure 3.1 analog input circuit
3.2. Signal connection methods
USB-3100 series data acquisition devices support analog input acquisition connection methods
ofnon-grounding reference single-ended input (NRSE) and differential input (DIFF).
Table 3.1 lists the recommended connection methods for floating-ground signal sources and
grounding signal sources
Analog input
mode
Floating grounded signal source (not
connected to GND of the building)
Grounded signal source
Example
Ungrounded thermocouples
Signals that are isolated
Battery-powered devices
Signals that are not isolated
