DF56 – Power Supply for Backplane 20 – 30 Vdc
3
AVOIDING ELECTRICAL DISCHARGES
ATTENTION
Electrostatic discharges may damage semiconductor electronic components in printed circuit
boards. They usually occur when touching components or connector pins from modules and racks,
without wearing the appropriate equipment to prevent discharges. It is recommended to take the
following precautions:
•Before handling modules and racks, remove the electrostatic charge from your body by
wearing a proper wristband or touching grounded devices;
•Avoid touching electronic components or connector pins from racks and modules.

DF56 – User’s Manual
4
DF56 – POWER SUPPLY FOR
BACKPLANE 20 – 30 VDC
Description
This redundant power supply works independently or with another redundant power supply module
to assure a constant power supply to the application.
When two redundant power supplies are used, if one of them fails, the backup will automatically
assume the operation. A relay is provided to indicate failure on each power supply giving the user a
chance to replace the faulty one.
This module has two voltage outputs:
a) 5 Vdc @ 3A distributed by Power Lines in the Inter-Module-Bus (IMB) through racks to supply
module circuits.
b) 24 Vdc @ 300mA for external use through terminals 1B and 2B.
The DC applied voltage and the 5Vdc and 24 Vdc are isolated.
Installation and Configuration
For systems based on DF92 and DF93 racks, with DF90 and DF91
Redundant mode
Splitting Power concept: In this situation, two modules will supply power to a bus segment. If one
of them was turned off or fails, the other power supply must be able to supply energy, alone, to the
segment.
Expansion of load capacity by adding power supplies or pairs of redundant power supplies
If the system consumption is greater than 3A, it can be subdivided in up to 8 groups sized for
consumption of up to 3A each, and each group is individually powered by a power supply, or
redundant pair of power supplies. More details on the Power supplies positioning topic.
Power supplies positions in the racks
On DF92, the pair of redundant power supplies must be installed in the first and second slots.
On DF93 is recommended the placement of the redundant pair in the first and second slots, but it
can be installed in any slots if necessary.
Configuration of CH1 jumper
The DF56 CH1 jumper always must be connected to the Rposition.
For systems based on DF1A and DF78 racks
Single Module: Less than 3 A are required.
There is an address restriction related to the location of the power supply. This restriction is the first
rack (address 0) must have a power supply module in the first slot. The CH1 jumper (power supply)
must be set in the Eposition.
More Than One Module: More than 3 A are required.
For systems based on DF1A rack they must be placed in the first slot of the rack. Jumper W1 on
the rack that has the new power supply must be cut. Every new power supply will only supply
energy to the rack in which it is located and, with the jumper cut off, it will not supply energy to the
previous racks. All modules must have the CH1 jumper (power supply) set in the Eposition.
Redundant Mode:
In redundant mode, the power supply modules must be placed in the first and third slots of rack
DF1A or first and second slots of rack DF78. In both, the CH1 jumper (power supply) must be set in
the Rposition. In this condition, the power supply modules will split the power. This topology is
called “split power mode”.

DF56 – Power Supply for Backplane 20 – 30 Vdc
5
smar
+5VDC
DF56
+24VDC
DC LINE
See
manual
DC Power Supply for Backplane
1B
2B
3B
4B
5B
6B
7B
FUSE
2.5A
20-30VDC
Max. 42W
6W
30VDC Max.
200mAMax.
OUTPUT
24VDC
300mA
DC Power Supply for Backplane
DC-R/56
Air convection
do not obstruct
air flow!
Fail
V
BRN04
Operating Range
-10ºC 60ºC
14ºF 140ºF
to
to
DC Power Supply: DF56
Technical Specifications
INPUTS
DC 20 to 30 Vdc
Inrush Current < 20.6 A @ 30 Vdc [ ΔT < 430 us]
Maximum Consumption 42 W
Indicator DC LINE (Green LED)
OUTPUTS
a) Output1 (Internal Use) 5.2 Vdc +/- 2%
Current 3 A Maximum
Ripple 100 mVpp Maximum
Indicator +5 Vdc (Green LED)
Hold up Time > 47 ms @ 24 Vdc [Full Load]
b) Output 2 (External Use) 24 Vdc +/- 10%
Current 300 mA Maximum
Ripple 200 mVpp Maximum
Indicator +24 Vdc (Green LED)
Short Circuit Current 700 mA
ISOLATION
Input signal, internal outputs and the external output are isolated between them.
Between Outputs and Ground 500 Vrms
Between Input and Output 1500 Vrms
FAILURE RELAY
Type of Output Solid state relay, normally closed (NC), isolated
Limits 6 W, 30 Vdc Max, 200 mA Max
Maximum Initial Contact Resistance <13 Ω
Overload Protection Should be provided externally.
Operation Time 5 ms maximum

DF56 – User’s Manual
6
TEMPERATURE
Operation -10 ºC to 60 ºC (14 ºF to 140 ºF)
DIMENSIONS AND WEIGHT
Dimensions (W x H x D) 39.9 x 137.0 x 141.5 mm
(1.57 x 5.39 x 5.57 in)
Weight 0.450 kg
CABLES
One Wire 14 AWG (2 mm2)
Two Wires 20 AWG (0.5 mm2)
NOTES
1. If the power consumption exceeds the power supplied, the DFI302 system may operate in an
unpredictable manner that may causes damages to the equipment or risk of personal injury.
Therefore, the power consumption must be calculated correctly and a detailed analysis should
be performed to define the installation of extra power supply modules.
2. The hardware revisions which are GLL1279 Rev1 and previous revisions do not support
redundancy feature.
3. To meet the EMC standards requirements, the wires’ length to the failure relay must be less
than 30 meters. The power supply of activated load by the failure relay must not be from
external network.
Calculating the Power Consumption
Since the power available in the power supply is limited, it is important to calculate the power
consumption of modules in use. The user can create a worksheet to summarize all supplied and
required current from each module and associated equipment (such as operator interface).
Example of worksheet with the module’s consumption, and some power supplies’ specification.
DFI302 Power Budget
Module Description Qty. Consumption Unit Power (mA) Total Power (mA) Supply Unit Power (mA) Total Power (mA)
@24 V @5 V @24 V @5 V @24 V @5 V @24 V @5 V
DF51 Controller 1 0 950 0 950
DF62 Controller 0 550 0 0
DF63 Controller 0 550 0 0
DF73 Controller 0 650 0 0
DF75 Controller 0 550 0 0
DF11 2*8 DI 24 Vdc 0 80 0 0
DF12 2*8 DI 48 Vdc 0 80 0 0
DF13 2*8 DI 60 Vdc 0 80 0 0
DF14 2*8 DI 125 Vdc 0 80 0 0
DF15 2*8 DI 24 Vdc (sink) 0 80 0 0
DF16 2*4 DI 120 Vac 0 50 0 0
DF17 2*4 DI 240 Vac 0 50 0 0
DF18 2*8 DI 120 Vac 0 87 0 0
DF19 2*8 DI 240 Vac 2 0 87 0 174
DF20 8 switches 0 45 0 0
DF44 8 AI 0 320 0 0
DF57 8 AI 0 320 0 0

DF56 – Power Supply for Backplane 20 – 30 Vdc
7
DFI302 Power Budget
Module Description Qty. Consumption Unit Power (mA) Total Power (mA) Supply Unit Power (mA) Total Power (mA)
@24 V @5 V @24 V @5 V @24 V @5 V @24 V @5 V
DF45 8 Temperature inputs 0 55 0 0
DF21 16 DO (transistor) 65 70 0 0
DF22 2*8 DO (transistor) 65 70 0 0
DF23 8 DO (triac) 0 70 0 0
DF24 2*8 DO (triac) 0 115 0 0
DF25 2*4 DO (relay) 134 20 0 0
DF26 2*4 DO (relay) 134 20 0 0
DF27 2*4 DO (relay) 134 20 0 0
DF28 2*8 DO (relay) 180 30 0 0
DF29 2*4 DO (relay) 134 20 0 0
DF30 2*4 DO (relay) 134 20 0 0
DF31 2*4 DO (relay) 134 20 0 0
DF46 4 AO 180 20 0 0
DF32 8 DI 24 Vdc, 4 DO (relay) 67 60 0 0
DF33 8 DI 48 Vdc, 4 DO (relay) 67 60 0 0
DF34 8 DI 60 Vdc, 4 DO (relay) 67 60 0 0
DF35 8 DI 24 Vdc, 4 DO (relay) 67 60 0 0
DF36 8 DI 48 Vdc, 4 DO (relay) 67 60 0 0
DF37 8 DI 60 Vdc, 4 DO (relay) 67 60 0 0
DF38 8 DI 24 Vdc, 4 DO (relay) 67 60 0 0
DF39 8 DI 48 Vdc, 4 DO (relay) 67 60 0 0
DF40 8 DI 60 Vdc, 4 DO (relay) 67 60 0 0
DF49 2 Fieldbus Power Impedance 750 0 0 0
DF53 4 Fieldbus Power
Impedance
1 1500 0 1500 0
TOTAL 4 1500 1074
DF50 1 300 3000 300 3000
DF52 1 1500 0 1500 0
TOTAL 6 1800 3000
Power supplies positioning
For systems based on DF92 and DF93 racks with DF90 and DF91
A power supply connected to a rack, in a system, provides current to the racks row that are
horizontally interconnected to it by their terminals of lateral connections, and vertically through DF90
cables, thus forming a group of rows of racks that use the same power supply.
The system can have only one power supply (or pair of redundant power supplies) or it can be
subdivided in several of these groups1, each one powered by a power supply (or pair of redundant
power supplies).
The recommended way to distribute the power is to divide the system in groups of horizontal rows of
racks. In this scheme, each power supply must be positioned on the top left of the group of rows of
racks that it powers. The rack were is the power supply must be the W1 jumper cut and the DF90
cable must not be connected to the rows powered by other power supplies (top rows). See in the
following figure an example of system powered by two power supplies, each one powers a part of
rows represented in green and blue.
1Maximum 8 groups allowed when the DF56 power supplies are used.

DF56 – User’s Manual
8
System powered by two power supplies
Note that this system, for greater efficiency, is optimized for power distribution by groups of rows of
racks. Thus, a power supply powers a whole number of rows it supports. However, in rare cases,
with long rows or many modules with great consumption in the same row, there is the option to add
power supplies in the middle of the row, dividing the power within this row. In this case, the power
supply added powers only the modules positioned on the right in the same row, up to the end, or
even where there is another power supply added. In the rack where the power supply was added, in
this scheme, the W1 jumper must be cut and left lateral connection terminal (+5 Vdc) must be
disconnected (collapsed).
In this system, the DF56 modules must be their CH1 jumper always configured in R, even if they are
not in redundant pairs.
ATTENTION
A mixture of these power supplies with the CH1 configured in Rand in Ein any
DFI302 system, is not allowed!
On DF92, the pair of redundant power supplies must be installed in the first and second slots.
On DF93 is recommended the placement of the redundant pair in the first and second slots, but it
can be installed in any slots if necessary.
The system has diagnostic for voltage level distributed to racks. It also supports modules with great
power consumption in any place on the bus. Nevertheless, is recommended to place those modules
close to the power supplies, to avoid unnecessary power transmission.
For systems based on DF78 and DF1A Racks
1. Observe the maximum current values from the power supply module specification. The limit for
DF56 is 3 A.

DF56 – Power Supply for Backplane 20 – 30 Vdc
9
2. After the connection with long cables (DF4A, DF5A, DF6A and/or DF7A) you have to put another
power supply module in the first slot of the first rack.
3. Use up to 6 modules DF44/DF57 per power supply; always place consecutively the DF44/DF57
and close to the power supply. Because of the high current consumption of the modules
DF44/DF57, a not desired voltage drop in the bus can occur if these modules are placed after other
modules.
4. When is necessary to add interface modules, such as HI302, MB700, DF58, in the same bus
which is used by output and input modules, is recommended that these modules are placed close to
the power supply, because in the same way as described in the previous item, a not desired voltage
drop in the bus can occur if these modules are placed after other modules.
5. Adding a new power supply module
•Determine the rack where the new power supply will be installed.
•Cut the jumper W1 of the rack.
•Plug the new power supply at the first slot of the rack (slot 0).
•In this case, the CH1 jumper of all modules DF56 must be set in Eposition.

DF56 – User’s Manual
10
Installing Modules in the Rack
Follow the steps below to install a module in the rack.
Attach the top of the module (with a 45oinclination) to the
module support located on the upper part of the rack.
Mounting detail.
Push the module fixing it to the module connector.
Next, fix the module to the rack using a screwdriver, and
fasten the fixation screw at the bottom of the module.

Appendix A
A.1
SRF – SERVICE REQUEST FORM
DFI302 – Fieldbus Universal Bridge
Proposal Nº:
COMPANY INFORMATION
Company:
_____________________________________________________________________________________________________
Unit: ________________________________________________________________________________________________________
Invoice: _______________________________________________________________________________________________________
COMMERCIAL CONTACT
Full Name:
____________________________________________________________________________________________________
Phone: _________ _________________________ _________ _________________________ Fax: _______________________
E-mail:
_______________________________________________________________________________________________________
TECHNICAL CONTACT
Full Name: ________________________________________________________________________________________________
Phone: _________ _________________________ _________ _________________________ Extension: ____________________
E-mail:
_______________________________________________________________________________________________________
EQUIPMENT DATA
Model:
______________________________________________________________________________________________________
Serial Number: ________________________________________________________________________________________________
PROCESS DATA
Process Type (Ex. boiler control): __________________________________________________________________________
Operation Time: ____________________________________________________________________________________________
Failure Date: __________________________________________________________________________________________________
FAILURE DESCRIPTON
(Please, describe the failure. Can the error be reproduced? Is it repetitive?)
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
OBSERVATIONS
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
______________________________________________________________________________________________________________
USER INFORMATION
Company: _____________________________________________________________________________________________________
Contact: _______________________________________________________________________________________________________
Section: _______________________________________________________________________________________________________
Title: ________________________________________________ Signature:_______________________________________________
Phone: _________ _________________________ _________ _________________________ Extension: ___________________
E-mail: ________________________________________________________________________ Date: ______/ ______/ _________
For warranty or non-warranty repair, please contact your representative.
Further information about address and contacts can be found on www.smar.com/contactus.asp

DF56 – User’s Manual
A.2

Appendix B
B.1
SMAR WARRANTY CERTIFICATE
1. SMAR guarantees its products for a period of 24 (twenty four) months, starting on the day of
issuance of the invoice. The guarantee is valid regardless of the day that the product was
installed.
2. SMAR products are guaranteed against any defect originating from manufacturing, mounting,
whether of a material or manpower nature, provided that the technical analysis reveals the
existence of a quality failure liable to be classified under the meaning of the word, duly verified
by the technical team within the warranty terms.
3. Exceptions are proven cases of inappropriate use, wrong handling or lack of basic maintenance
compliant to the equipment manual provisions. SMAR does not guarantee any defect or
damage caused by an uncontrolled situation, including but not limited to negligence, user
imprudence or negligence, natural forces, wars or civil unrest, accidents, inadequate
transportation or packaging due to the user’s responsibility, defects caused by fire, theft or stray
shipment, improper electric voltage or power source connection, electric surges, violations,
modifications not described on the instructions manual, and/or if the serial number was altered
or removed, substitution of parts, adjustments or repairs carried out by non-authorized
personnel; inappropriate product use and/or application that cause corrosion, risks or
deformation on the product, damages on parts or components, inadequate cleaning with
incompatible chemical products, solvent and abrasive products incompatible with construction
materials, chemical or electrolytic influences, parts and components susceptible to decay from
regular use, use of equipment beyond operational limits (temperature, humidity, etc.) according
to the instructions manual. In addition, this Warranty Certificate excludes expenses with
transportation, freight, insurance, all of which are the customer’s responsibility.
4. For warranty or non-warranty repair, please contact your representative.
Further information about address and contacts can be found on www.smar.com/contactus.asp
5. In cases needing technical assistance at the customer’s facilities during the warranty period,
the hours effectively worked will not be billed, although SMAR shall be reimbursed from the
service technician’s transportation, meals and lodging expenses, as well dismounting/mounting
costs, if any.
6. The repair and/or substitution of defective parts do not extend, under any circumstance, the
original warranty term, unless this extension is granted and communicated in writing by SMAR.
7. No Collaborator, Representative or any third party has the right, on SMAR’s behalf, to grant
warranty or assume some responsibility for SMAR products. If any warranty would be granted
or assumed without SMAR’s written consent, it will be declared void beforehand.
8. Cases of Extended Warranty acquisition must be negotiated with and documented by SMAR.
9. If necessary to return the equipment or product for repair or analysis, contact us.
See item 4.
10. In cases of repair or analysis, the customer must fill out the Revision Requisition Form (FSR)
included in the instructions manual, which contains details on the failure observed on the field,
the circumstances it occurred, in addition to information on the installation site and process
conditions. Equipments and products excluded from the warranty clauses must be approved by
the client prior to the service execution.
11. In cases of repairs, the client shall be responsible for the proper product packaging and SMAR
will not cover any damage occurred in shipment.

DF56 – User’s Manual
B.2
12. In cases of repairs under warranty, recall or outside warranty, the client is responsible for the
correct packaging and packing and SMAR shall not cover any damage caused during
transportation. Service expenses or any costs related to installing and uninstalling the product
are the client´s sole responsibility and SMAR does not assume any accountability before the
buyer.
13. It is the customer’s responsibility to clean and decontaminate products and accessories prior to
shipping them for repair, and SMAR and its dealer reserve themselves the right to refuse the
service in cases not compliant to those conditions. It is the customer’s responsibility to tell
SMAR and its dealer when the product was utilized in applications that contaminate the
equipment with harmful products during its handling and repair. Any other damages,
consequences, indemnity claims, expenses and other costs caused by the lack of
decontamination will be attributed to the client. Kindly, fill out the Declaration of
Decontamination prior to shipping products to SMAR or its dealers, which can be accessed at
www.smar.com/doc/declarationofcontamination.pdf and include in the packaging.
14. This warranty certificate is valid only when accompanying the purchase invoice.
