Smart Cabling & Transmission TPP016VPD User manual

1
16 Channel Video, Power CCTV Hub with AC Power Supply in 1U
Rack Mounting Hub
ITEM NO.: TPP016VPD, TTP111VP, TTP111VP3, TTP111VPC, TTP111VPD-RJ45
TTP111HDP, TTP111HDP-L, TTP111HDPD-RJ45, PC500,PC1A
The 16-channel TPP016VPD CCTV hub is using standard CAT5e & RJ45 structured building wiring
to carry video, power and data for simplifying short range installation by centralizing power and
reducing installation labor costs. The built in 10AMP AC24V power supply could support
at-distance camera loads up to 500mA per channel. Each port built in switch to set the unit to
power 2 pairs or 3 pairs. To use with TTP111VP3/ TTP111VPC/TTP111VPD-RJ45 at regular
analog camera side or using with TTP11HDP/TTP111HDP-L/TTP111HDPD-RJ45 at
HD-TVI/AHD/HDCVI camera side to send video, power or data for cable runs 300 meters (max.)
TPP016VPD 16 Channel Passive Video, Power, Data CCTV Hub
with AC Power Supply in 1U Rack Mounting Hub
TPP016VPD CCTV hub Integrate and send video and power, data over a single 4 pairs
CAT5 cable up to 300 meters.
Video support: Composite Video, HD-TVI, AHD, HDCVI.
Built in switch at each port to set unit for “2 pair power + 1 pair data” mode or “3 pairs
power” mode.
Power cameras via 2 or 3 pairs UTP cable for variety distances (please refer to below
power distance chart).
Use with video& power Balun TTP111HDP/TTP111HDP-L(AC24V camera) or add model no:
PC500/PC1A power converter (AC24V to DC12V regulated) at DC12V camera side, to
send video and power only.
Use with TTP111HDPD-RJ45 video, power, data combiner at the camera side, to send
video, power and data.
10 Amp AC24V power, each port output current up to 1.1Amp for camera, max up to
10Amp.
Built in “no fuse breaker” to avoid current overload.
Built in PTC (positive temperature coefficient) for short protection and auto rework on
each port.
Perfect cable management solution from the camera to the wiring station, control room.
Optional Model: Work with Regular Analog Camera
TTP111VP Video & Power Transceiver for AC24V Camera (2 pairs)
Video (one pair) and remote power (2pairs) transmission over one 4pairs CAT5 cable.
Transmission range up to 300 meters (max.)
BNC for video, power cord for power, RJ45 female output for video and power.
Eliminates costly coaxial cables and minimize installation time.
Use with TPP016VPD for 16 channel video, power over professional CAT5 RJ45 connection.

2
TTP111VP3 Video & Power Transceiver for AC24V Camera (3 pairs)
Identical to TTP111VP, but remote power go through via “3 pairs” to instead of 2 pairs for longer
range.
TTP111VPC Video & Power Transceiver for DC12V Camera
Video (one pair) and remote power (2 or 3 pairs) transmission over one 4pairs CAT5 cable.
Built in AC to DC12V regulated power converter, 1000mA max. .
Built in switch to set unit for “2 pair power through” or “3 pairs power through” mode.
For DC12V camera use, the power sources convert from TPP016VPD AC24V power for professional
CCTV Industry Installation.
Transmission range up to 300 meters (max.)
BNC for video, power cord for power, RJ45 female output for video and power.
Eliminates costly coaxial cables and minimize installation time.
Use with TPP016VPD for 16 channel video, power over professional CAT5 RJ45 connection.
TTP111VPD-RJ45 Video, Power, Data Transceiver
Video, low voltage camera power, Data (RS422, 485) transmission over one standard CAT 5 cable.
Male BNC with 2 mini-coax pigtail to RJ45 connector.
Built in PTC fuse for short protection.
Transmission range up to 300 meters (max.)
Use with TPP016VPD at camera side, 16 channel video, power, data over professional CAT 5 RJ45
connection.
Optional Model: Work with HDTVI/AHD//HDCVI Analog Camera
TTP111HDP HD-TVI/AHD/HDCVI HD Video & Power Balun______
Transmit HD-TVI/AHD/HDCVI video and power over one CAT5e cable.
Video (one pair) and remote power (3pairs) transmission over one 4pairs CAT5 cable.

3
TTP111HDP-L HD-TVI/AHD/HDCVI HD Video & Power Balun_
Identical to TTP111HDP, but with 10cm mini coax cable for easy mounting.
TTP111HDPD-RJ45 HD-TVI/AHD/HDCVI Video Power Data Balun
HD-TVI/AHD/HDCVI video, low voltage camera power, Data (RS485) transmission over one Cat5e cable.
PC500 AC to DC 12V Power Converter 500mA
AC to DC12V Power Converter with DC plug cable 500mA Max.
Input power: AC15~26V; DC15~28V.
Output Power: DC12V regulated.
For DC type camera or video power sources convert using AC24V for professional CCTV Industry
Installation.
PC1A AC to DC 12V Power Converter 1Amp
Identical to PC500, but with 1000mA max.

4
Product Overview:
TPP016VPD
Switch setting:
3 pairs power -------------work with TTP111VP3/TTP111HDP/TTP111HDP-L or TTP111VPC
2 pairs power & data-----work with TTP111VPD-RJ45/TTP111HDPD-RJ45
2 pairs power-------------work with TTP111VP
TTP111VP/ TTP111VP3/TTP111HDP
Front Rear
TTP111VPJ-RJ45/TTP111HDPD-RJ45
Front Rear
TTP111VPC
Rack Mount Installation:
Package includes the two mounting brackets and eight screws.
Place the mounting brackets unto the side of the left and right side of rack enclosure. Use two
screws to secure mounting brackets.

5
Installation View:
Caution: to avoid any damage, TPP016VPD cabling is not able to connect any Ethernet or
PoE network with outside plant routing.
HD-TVI/AHD/HDCVI Twisted Pair Transmission Distance Chart
Transmitter
Receiver
HD-TVI
AHD
HDCVI
CVBS
TTP111HDP
TTP111HDP-L
TTP111HDPD-RJ45
TPP016VPD
1080P
250M
1080P
300M
1080P
300M
300M
AC24V Power Distance Chart over UTP CAT5 cable:
CAT5 Cable (24AWG)
Actual Voltage camera at 21V
Power
2 Pairs/AC24V
3 Pairs/AC24V
100 mA
300 Meters
300 Meters
300 mA
100 Meters
225 Meters
1 Amp
30 Meters
45 Meters
Specification:
ITEM NO.
TPP016VPD
Video, Power, Input
16 x RJ45 connector for 16 Port
RJ45 with LED indication
Yellow LED on: power go though, Green LED: no function
Data Input Port
1 Port (Terminal Block)
Video Output (BNC Connector)
16 Port, 1Vp-p, 75 ohms
Power
10AMP, AC120V/230V to AC24V
Each port output current 1.1A (Max.)
Recommend Cable
CAT 5 Cable 4 Pairs (24 AWG)
Storage Temperature
-30℃~70℃
Operation Temperature
-10℃~45℃
Weight g
5700 g
Dimension W x H x D mm
482x290X44 (1U)
Material
Metal Black

6
ITEM NO.
TTP111VP / TTP111VP3
Video (BNC Connector)
1 (1V p-p, 75 Ohms)
Transmission Interface
RJ45
Transmission Distance
600M(B/W), 300M(COLOR)
Cable
Twisted Pair CAT5 (AWG24)
Power
V
Storage Temperature
-30℃~70℃
Operation Temperature
-10℃~45℃
Weight
70 g
Dimension W x H x D mm
69x25x22
Material
PVC Black
ITEM NO.
TTP111VPC
Video (BNC Connector)
1 (1V p-p, 75 Ohms)
Power
V
Transmission Interface
RJ45
Transmission Distance
600M(B/W), 300M(COLOR)
Cable
Twisted Pair CAT5 (AWG24)
Input Power
AC20~28V; DC16~30V
Output Power
DC12V Regulated
Output Current
1000mA (MAX)
Material
Metal
Storage Temperature
-30℃~70℃
Operation Temperature
-10℃~45℃
Weight
200 g
Dimension W x H x D mm
87x67x27
Material
Metal
ITEM NO.
TTP111VPD-RJ45
VIDEO (BNC Connector)
1 (1V p-p, 75 Ohms)
TRANSMISSION INTERFACE
RJ45
TRANSMISSION DISTANCE
600M(B/W), 300M(COLOR)
DATA Connector
1
CABLE
Twisted Pair CAT5 (AWG24)
POWER
V
DIMENSIONS W x H x D mm
69x25x20.5 with 25cm cable
ITEM NO.
TTP111HDP
Video Input / Output Terminals
BNC x 1 (1 Vp-p，75 Ohm)
Video Input / Output Terminals
RJ45 x 1 ( 100 Ohm )
Power
DC-PLUG
Bandwidth
50Hz ~ 60MHz ( -3dB )
Transmission Distance
HDCVI/AHD: 300M, HD-TVI: 250M
ESD protection
30 KV(Air)，15 KV (Contact) ; IEC 61000-4-2 compliant
EFT protection
40A(5/50ns) ; IEC 61000-4-4 compliant
Lightning protection
2A (8/20μs) ; IEC 61000-4-5 compliant
Surge Protection Attack Time
< 1 nS
Environmental Specifications
Operation: 0 to 55℃, Storage: -20 to 85℃, Humidity: up to 95%
Dimension mm
69 x 25 x 20.7 + 140mm power cord
Weight g
37 g

7
ITEM NO.
TTP111HDP-L
Video Input / Output Terminals
BNC x 1 (1 Vp-p，75 Ohm)
Video Input / Output Terminals
RJ45 x 1 ( 100 Ohm )
Power
DC-PLUG
Bandwidth
50Hz ~ 60MHz ( -3dB )
Transmission Distance
HDCVI/AHD: 300M, HD-TVI: 250M
ESD protection
30 KV(Air)，15 KV (Contact) ; IEC 61000-4-2 compliant
EFT protection
40A(5/50ns) ; IEC 61000-4-4 compliant
Lightning protection
2A (8/20μs) ; IEC 61000-4-5 compliant
Surge Protection Attack Time
< 1 nS
Environmental Specifications
Operation: 0 to 55℃, Storage: -20 to 85℃, Humidity: up to 95%
Dimension mm
69 x 25 x 20.7 + 120mm pigtail cable
Weight g
45
ITEM NO.
TTP111HDPD-RJ45
Video Input / Output Terminals
BNC x 1 (1 Vp-p，75 Ohm)
Video Input / Output Terminals
RJ45 x 1 ( 100 Ohm )
Power
DC-PLUG
Data
Data cable
Bandwidth
50Hz ~ 60MHz ( -3dB )
Transmission Distance
HDCVI/AHD: 300M, HD-TVI: 250M
ESD protection
30 KV(Air)，15 KV (Contact) ; IEC 61000-4-2 compliant
EFT protection
40A(5/50ns) ; IEC 61000-4-4 compliant
Lightning protection
2A (8/20μs) ; IEC 61000-4-5 compliant
Surge Protection Attack Time
< 1 nS
Environmental Specifications
Operation: 0 to 55℃, Storage: -20 to 85℃, Humidity: up to 95%
Dimension mm
69 x 25 x 20.7 + 120mm pigtail cable
Weight g
45
ITEM NO.
PC500
INPUT POWER
AC15~26V; DC15~28V
OUTPUT POWER
DC12V Regulated
OUTPUT CURRENT
500mA
MATERIAL
ABS PLASTIC
CABLE
Input side: 15cm, 22AWG, 2 Pin Terminal Block
Output side: 15cm, 22AWG, DC Plug
DIMENSIONS mm
63X29X25 (Do not include cable and connecter)
WEIGHT g
35
ITEM NO.
PC1A
INPUT POWER
AC18~26V; DC18~28V
OUTPUT POWER
DC12V Regulated
OUTPUT CURRENT
1000mA (MAX)
MATERIAL
Metal
DIMENSIONS mm
102.8X25.4X25.4
WEIGHT g
80
