Smart Chef HWB-1S User manual

INSTALLATION, OPERATION AND
CARE MANUAL
WAFFLE BAKER
Imported and distributed by

READ THE INSTRUCTION MANUAL
CAREFULLY BEFORE USING THE PRODUCT.
2. Transport and storage
Please handle with care while transporting the product, to prevent severe
vibration and damage. Products in long-term storage should be stored the correct
way up, in a dry, well ventilated area.
INDEX
1. Technicalspecications
2. Transport and storage
3. Installation
4. Operating Procedure
5. Cleaning and Maintenance
6. Circuit Diagram
1. Technical specications
MODEL DIMENSIONS VOLTAGE POWER
HWB-1S 282 x 380 x 230mm 220~240V / 50~60Hz 1.6kW
HWB-2S 570 x 380 x 230mm 220~240V / 50~60Hz 3.2kW
HWB-1 250 x 350 x 260mm 220~240V / 50~60Hz 1.2kW
HWB-2 500 x 350 x 260mm 220~240V / 50~60Hz 2.4kW
HX-2208 330 x 365 x 235mm 220~240V / 50~60Hz 1.8kW
This manual is applicable for the following models:
DESCRIPTION MODEL PRODUCT CODE
1Platewa󰀪ebaker(Belgian) HWB-1S WBS0001
2platewa󰀪ebaker(Belgian) HWB-2S WBS0002
1Platewa󰀪ebaker(Round) HWB-1 WBS1001
2Platewa󰀪ebaker(Round) HWB-2 WBS1002
Lollywa󰀪ebaker HX-2208 WBS2001

3. Installation
• The product should be places on a stable, non-combustible surface. A
clearance area of at least 10cm on the left and should be maintained. The
backshouldbefromnon-combustiblematerial(suchasbrickwalls,etc.)with
a clearance area of 20cm or more.
• Connect the product to the main socket ensuring that the voltage is the same
as found on the rating plate which is found on the back of the unit.
• Make sure the unit is safely grounded before switching on.
• To replace the power cord, ensure that the same type of cable is used. This
must be done by a professional technician.
• The installation and the maintenance of electrical connections, should be
donebyaprofessionalcertiedtechnician.
4. Operating Procedure
• Ensure that the thermostat is set to 0 before switching on.
• Turn on the unit by pressing the power switch.
• Rotatethethermostatknobclockwisetothedesiredtemperature.The
orange heat indicating light will light up and the unit will start heating. When
the desired temperature is reached, the heat indicating light goes out and unit
switcheso󰀨.Whenthetemperaturedecreasedslightly,theunitwillswitchon
automatically. This cycle will continue until the thermostat setting is changed.
• When the desired temperature is reached, generously oil plates. The unit is
now ready for use.
• Addthewa󰀪emixtothebottomplate.Forbestresults,pourthemixfromthe
outside inward to ensure even browning. Close the lid and set the timer to
the desired time.
• Thetimerwillsoundwhentimeisuptoremindyoutoremovewa󰀪es.
• Alwaysswitcho󰀨theunitwhennishedbakingbyturningthethermostatto0
andswitchingo󰀨thepowerbutton.
Do not touch hot food, liquid or heating surfaces while equipment is
heating or operating. Allow the hot surface to cool before handling
WARNING

6. Circuit Diagram
• R1 & R2 - Heating pipe
• D - Heating Light
• WK1 - Thermostat
~220V
R1
WK1
D1
R2
5. Cleaning and Maintenance
• Always ensure that the unit is disconnected from the main power supply
before cleaning.
• This appliance should not be cleaned with a water jet or immersed in water.
Onlyuseadampclothorspongedippedinsoapywater.Failuretoobserve
this instruction might damage the unit and will void the warranty.
• Wipeo󰀨theappliancewithadryclothandwaitatleast30minutesbeforere-
connecting to the main power outlet.
• TheplatesareTEFLONcoatedandshouldonlybecleanedwithadamp
cloth. Under no circumstances should the plates be cleaned with abrasive
wool as this will void the warranty.
