Thank you for purchasing our product.
This manual applies to:
Type
Model
1.3 Megapixel
H20IPEBIR1F, H20IPEBIR1VF, H20IPVDIR1F
3 Megapixel
H20IPEBIR3F, H20IPEBIR3VF, H20IPVDIR3F
This manual is subject to change without notice. Any updates will be added to the
new version of this manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability
of the security or signaling aspects of this product. UL has only tested for fire, shock
or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the security or signaling
aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF
ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

SmartWatch® IP Network Camera User Manual
44
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the limits
for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the Low Voltage
Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery information.
The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling,
return the battery to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.

SmartWatch® IP Network Camera User Manual
55
Table of Contents
CHAPTER 1 SYSTEM REQUIREMENT..............................................................................................7
CHAPTER 2 NETWORK CONNECTION ............................................................................................8
2.1 SETTING THE IP NETWORK CAMERA OVER LAN...................................................................................8
2.1.1 Wiring over LAN ..................................................................................................................8
2.1.2 Detecting and Changing the IP Address...............................................................................9
2.2 SETTING THE IP NETWORK CAMERA OVER WAN ...............................................................................10
2.2.1 Static IP Connection ...........................................................................................................10
2.2.2 Dynamic IP Connection ......................................................................................................11
CHAPTER 3 ACCESS TO THE IP NETWORK CAMERA ..................................................................... 13
3.1 ACCESSING BY WEB BROWSERS .....................................................................................................13
3.2 ACCESSING BY CLIENT SOFTWARE...................................................................................................15
3.2.1 Accessing by System Manager Software............................................................................15
3.2.2 Accessing by SmartWatch® Viewer Software ....................................................................16
CHAPTER 4 LIVE VIEW ................................................................................................................ 17
4.1 LIVE VIEW SCREEN ......................................................................................................................17
4.2 STARTING LIVE VIEW ...................................................................................................................18
4.3 RECORDING AND CAPTURING IMAGES MANUALLY .............................................................................19
4.4 OPERATING PTZ CONTROL ...........................................................................................................19
4.4.1 PTZ Control Panel...............................................................................................................19
4.4.2 Setting / Calling a Preset....................................................................................................20
4.5 CONFIGURING LIVE VIEW PARAMETERS ...........................................................................................21
CHAPTER 5 IP NETWORK CAMERA CONFIGURATION .................................................................. 22
5.1 CONFIGURING LOCAL PARAMETERS ................................................................................................22
5.2 CONFIGURING TIME SETTINGS.......................................................................................................23
5.3 CONFIGURING NETWORK SETTINGS................................................................................................25
5.3.1 Configuring TCP/IP Settings ...............................................................................................25
5.3.2 Configuring Port Settings ...................................................................................................26
5.3.3 Configuring PPPoE Settings................................................................................................ 27
5.3.4 Configuring DDNS Settings ................................................................................................28
5.3.5 Configuring SNMP Settings................................................................................................30
5.3.6 Configuring 802.1X Settings...............................................................................................32
5.3.7 Configuring QoS Settings ...................................................................................................33
5.3.8 Configuring FTP Settings....................................................................................................33
5.3.9 Configuring UPnP™ Settings ..............................................................................................35
5.4 CONFIGURING VIDEO AND AUDIO SETTINGS.....................................................................................36
5.4.1 Configuring Video Settings ................................................................................................36
5.4.2 Configuring Audio Settings ................................................................................................37
5.5 CONFIGURING IMAGE PARAMETERS................................................................................................37
5.5.1 Configuring Display Settings ..............................................................................................37

SmartWatch® IP Network Camera User Manual
66
5.5.2 Configuring OSD Settings...................................................................................................39
5.5.3 Configuring Text Overlay Settings ......................................................................................41
5.5.4 Configuring Privacy Mask ..................................................................................................41
5.6 CONFIGURING AND HANDLING ALARMS ..........................................................................................42
5.6.1 Configuring Motion Detection ...........................................................................................43
5.6.2 Configuring Tamper-proof Alarm.......................................................................................46
5.6.3 Configuring External Alarm Input ...................................................................................... 47
5.6.4 Configuring Alarm Output .................................................................................................49
5.6.5 Handling Exception ............................................................................................................50
5.6.6 Email Sending Triggered by Alarm.....................................................................................51
5.6.7 Configuring Snapshot Settings...........................................................................................52
CHAPTER 6 STORAGE SETTINGS ..................................................................................................54
6.1 CONFIGURING NAS SETTINGS .......................................................................................................54
6.2 CONFIGURING RECORDING SCHEDULE.............................................................................................55
CHAPTER 7 PLAYBACK ................................................................................................................59
CHAPTER 8 LOG SEARCHING .......................................................................................................61
CHAPTER 9 OTHERS ....................................................................................................................63
9.1 MANAGING USER ACCOUNTS........................................................................................................63
9.2 CONFIGURING RTSP AUTHENTICATION ...........................................................................................65
9.3 ANONYMOUS VISIT .....................................................................................................................65
9.4 IP ADDRESS FILTER......................................................................................................................66
9.5 VIEWING DEVICE INFORMATION ....................................................................................................68
9.6 MAINTENANCE...........................................................................................................................69
9.6.1 Rebooting the Camera .......................................................................................................69
9.6.2 Restoring Default Settings .................................................................................................69
9.6.3 Exporting/ Importing Configuration File............................................................................70
9.6.4 Upgrading the System........................................................................................................70

SmartWatch® IP Network Camera User Manual
7
Chapter 1 System Requirement
Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 /
Server 2003 / Server 2008 32bits
CPU: Intel Pentium IV 3.0 GHz or higher
RAM: 1G or higher
Display: 1024×768 resolution or higher
Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above
version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above
versions.

SmartWatch® IP Network Camera User Manual
8
Chapter 2 Network Connection
Before you start:
If you want to set the IP network camera via a LAN (Local Area Network), please
refer to Section 2.1 Setting the IP network camera over the LAN.
If you want to set the IP network camera via a WAN (Wide Area Network), please
refer to Section 2.2 Setting the IP network camera over the WAN.
2.1 Setting the IP network camera over LAN
To view and configure the camera via a LAN, you need to connect the IP network
camera in the same subnet as your computer. Install the SmartWatch® System
Manager software to search and change the IP of the IP network camera.
2.1.1 Wiring over LAN
The following diagrams show the two ways of connecting an IP network camera to
computer:
To test the IP network camera, you can directly connect the IP network camera
to the computer with a network cable as shown in Figure 2-1.
Refer to the Figure 2-2 to set the IP network camera up over LAN via a
switch/router.
Figure 2-1 Connecting Directly
Figure 2-2 Connecting via a Switch or a Router

SmartWatch® IP Network Camera User Manual
99
2.1.2 Detecting and Changing the IP Address
You need the IP address to connect to the IP network camera.
Steps:
1. To get the IP address, install the System Manager client software. This will
display a list of online devices. Please refer to the user manual of System
Manager client software for more detailed information.
2. Change the IP address and subnet mask to the same range as that of your
computer.
3. Enter the IP address of the IP network camera in the address field of the web
browser to view the live video.
The default IP address is 192.0.0.64 and the port number is 8000. The default user name
is admin, and password is 12345.
For accessing the IP network camera from different subnets, please set the gateway for
the IP network camera after logging in. For more detailed information, please refer to
Section 5.3.1 Configuring TCP/IP Settings.
Figure 2-3 System Manager Interface

SmartWatch® IP Network Camera User Manual
1010
2.2 Setting the IP network camera over WAN
This section explains how to connect to the IP network camera via WAN with a static
IP or a dynamic IP.
2.2.1 Static IP Connection
Before you start:
Please apply for a static IP from an ISP (Internet Service Provider). With the static IP
address, you can connect the IP network camera via a router.
Connecting the IP network camera via a router
Steps:
1. Connect the IP network camera to the router.
2. Assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2
Detecting and Changing the IP Address for detailed IP address configuration of
the camera.
3. Save the static IP address in the router.
4. Set port mapping, e.g., 80, 8000, 8200 and 554 ports. Port mapping will vary
depending on what router you have. Please refer to the router manufacturer.
5. Connect to the IP network camera through a web browser or the client software
over the internet.
Figure 2-4 Accessing the Camera through Router with Static IP
Connecting the IP network camera with static IP directly
You can also save the static IP address in the camera and directly connect it to the
internet without using a router. Refer to Section 2.1.2 Detecting and Changing the IP
Address for detailed IP address configuration of the camera.
Figure 2-5 Accessing the Camera with Static IP Directly

SmartWatch® IP Network Camera User Manual
1111
2.2.2 Dynamic IP Connection
Before you start:
If you have a dynamic IP from an ISP, you can connect the IP network camera to a
modem or a router.
Connecting the IP network camera via a router
Steps:
1. Connect the IP network camera to the router.
2. In the camera, assign a LAN IP address, the subnet mask and the gateway. Refer
to Section 2.1.2 Detecting and Changing the IP Address for detailed LAN
configuration.
3. In the router, set the PPPoE user name, password and confirm the password.
4. Set port mapping. E.g. 80, 8000, 8200 and 554 ports. The steps for port mapping
may vary depending on the router.
5. Apply a domain name from a domain name provider.
6. Configure the DDNS settings in the router.
7. Connect to the camera via the applied domain name.
Connecting the IP network camera via a modem
This camera supports the PPPoE auto dial-up function. The camera automatically gets
a public IP address by ADSL dial-up after the camera is connected to a modem. You
need to configure the PPPoE parameters of the IP network camera. Refer to Section
5.3.3 Configuring PPPoE Settings for detailed configuration.
Figure 2-6 Accessing the Camera with Dynamic IP
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
after rebooting the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (E.g. DynDns.com). Please follow below steps for
normal domain name resolution and private domain name resolution to solve the problem.
Normal Domain Name Resolution

SmartWatch® IP Network Camera User Manual
1212
Figure 2-7 Normal Domain Name Resolution
Steps:
1. Apply a domain name from a domain name provider.
2. Configure the DDNS settings in the DDNS Settings interface of the IP network
camera. Refer to Section 5.3.4 Configuring DDNS Settings for detailed
configuration.
3. Connect to the camera via the applied domain name.
Private Domain Name Resolution
Figure 2-8 Private Domain Name Resolution
Steps:
1. Install and run the IP Server software in a computer with a static IP.
2. Access the IP network camera through the LAN with a web browser or the client
software.
3. Enable DDNS and select IP Server as the protocol type. Refer to Section 5.3.4
Configuring DDNS Settings for more detailed configuration.

SmartWatch® IP Network Camera User Manual
13
Chapter 3 Access to the IP network
camera
3.1 Accessing by Web Browsers
Steps:
1. Open the web browser.
2. In the address bar, input the IP address of the IP network camera, e.g.,
192.0.0.64 and hit the enter key to enter the login interface.
3. Input the user name and password and click .
The default user name is admin, password is 12345.
Figure 3-1 Login Interface
4. Install the plug-in before viewing the live video and operating the camera.
Please follow the installation prompts to install the plug-in.

SmartWatch® IP Network Camera User Manual
1414
Figure 3-2 Download and Install Plug-in
Figure 3-3 Install Plug-in (1)
Figure 3-4 Install Plug-in (2)

SmartWatch® IP Network Camera User Manual
1515
Figure 3-5 Install Plug-in (3)
Figure 3-6
You may have to close the web browser to install the plug-in. Please reopen the web
browser and log back in again after installing the plug-in.
3.2 Accessing by Client Software
3.2.1 Accessing by System Manager Software
The product CD contains the System Manager client software (Client or PCNVR). You
can view the live video and manage the camera with the client software.
Follow the installation prompts to install the software. The control panel and live
view interface of System Manager are displayed below.
Figure 3-7 System Manager Live View

SmartWatch® IP Network Camera User Manual
1616
Figure 3-8 System Manager Configuration Panel
For detailed information about System Manager client software, please refer to the user
manual of the System Manager software.
3.2.2 Accessing by SmartWatch® Viewer Software
To view the camera with a mobile phone, install the SmartWatch® Viewer software
on your mobile phone.
For detailed information about SmartWatch® Viewer software, please refer to the user
manual of the SmartWatch® Viewer software.

SmartWatch® IP Network Camera User Manual
17
Chapter 4 Live View
4.1 Live View Screen
The live video page allows you to view live video, capture images, PTZ control,
set/call presets and configure video parameters.
Log in to the IP network camera to enter the live view page.
Descriptions of the live view page:
Figure 4-1 Live View Page
Menu Bar:
Click each tab to enter Live View, Playback, Log and Configuration page respectively.
Live View Window:
Display the live video.
Toolbar:
Operations on the live view page, e.g., live view, capture, record, audio on/off,
two-way audio, etc.
PTZ Control:
Panning, tilting and zooming actions of the PTZ camera and the lighter and wiper
control (if it supports PTZ function or an external pan/tilt unit has been installed).
Preset Setting/Calling:
Set and call the preset for the camera (if supports PTZ function or an external
pan/tilt unit has been installed).

SmartWatch® IP Network Camera User Manual
1818
Live View Parameters:
Configure the image size and stream type of the live video.
4.2 Starting Live View
In the live view window as shown in Figure 4-2, click on the toolbar to start the
live view of the camera.
Figure 4-2 Live View Toolbar
Table 4-1 Descriptions of the Toolbar
Icon
Description
/
Start/Stop live view
Manually capture images displayed in live view and save them
as a JPEG file.
/
Manually start/stop recording.
Audio on and adjust volume /Mute.
/
Enable/Disable two-way audio.
/
Enable/Disable PTZ.
Before using the two-way audio function or recording with audio, please set the Stream Type
to Video & Audio (please refer to Section 5.4).
Full-screen Mode
You can double-click on the live video screen to switch the current live view into
full-screen or return back to normal mode from the full-screen.
Please refer to the following sections for more information:
Configuring remote recording in Section 6.2 Configuring Recording Schedule.
Setting the image quality of the live video in Section 5.1 Configuring Local
Parameters and Section 5.4.1 Configuring Video Settings.
Setting the OSD text on live video in Section 5.5.2 Configuring OSD Settings.

SmartWatch® IP Network Camera User Manual
1919
4.3 Recording and Capturing Images Manually
In the live view screen, click on the toolbar to capture the live images or click
to record the live video. The location that the images and video recordings can
can be set in the Configuration > Local Configuration page.
Please note that the captured image will be saved as a JPEG file in your computer.
4.4 Operating PTZ Control
In the live view screen, you can use the PTZ control buttons to control the camera (if
PTZ camera connected).
Before you start:
Please configure the PTZ parameters on RS-485 Settings page referring to Section
10.6 RS-485 Settings.
4.4.1 PTZ Control Panel
On the live view screen, click to show the PTZ control panel / click to
hide it.
Click the direction buttons to control the pan/tilt direction.
Figure 4-3 PTZ Control Panel
Click the zoom/iris/focus buttons for lens control.

SmartWatch® IP Network Camera User Manual
2020
There are 8 direction arrows ( , , , , , , , ) in the live view window.
For the cameras that support lens control only, the direction buttons will be invalid.
Table 4-2 Descriptions of PTZ Control Panel
Button
Description
Zoom in/out
Focus near/far
Iris open/close
Light on/off
Wiper on/off
One-touch focus
Initialize lens
Adjust speed of pan/tilt
movements
4.4.2 Setting / Calling a Preset
Setting a Preset:
1. In the PTZ control panel, select a preset number from the preset list.
Figure 4-4 Setting a Preset
2. Use the PTZ control buttons to move the lens to the desired position.
• Pan the camera to the right or left.
• Tilt the camera up or down.
• Zoom in or out.
• Refocus the lens.
3. Click to save the setting of the current preset.
4. Click to delete the preset.
