SMART D-C5 User manual

Installation and Operation Manual
For TCP/IP Digital System

Remark
Please follow the user manual for correct installation and testing, if
there is any doubt please call our tech-supporting and customer
center.
Our company applies ourselves to reformation and innovation of
our products. No extra informing for any change. The illustration
shown here only used for reference, if there is any difference
please take the actual product as standard product.

CATALOG
Product Picture ........................................................1
Basic Functions........................................................2
Technology Parameters ...........................................2
Package Content......................................................2
Operations................................................................3
System Setting .........................................................4
System Connection..................................................9
Installation..............................................................13
Care and Maintenance...........................................14

Model:D-C5 (With glass surface)
Camera
Call Button
Speaker
Infrared LEDs
Microphone
Light Sensor
Model:D-C5 (With metal surface )
Microphone
Camera
Call Button
Infrared LEDs Light Sensor
Speaker
-1-

Technology Parameter
1. Working voltage DC 12V/ POE optional
2. Rated power 5W
3.
. Operating temperature -40℃～+70℃
5. Relative humidity: 20% 93%
6. IP Rating: IP55
7. CPU: 350MHz
8. RAM:
:
:
Standby power consumption: 2.5W
4 :
～
DDR2 1Gbit X 2
9. Flash: 16Gbit
Check the package content:
Technology Parameter
1. Call indoor monitor or management center.
2. Video intercom with indoor monitor or management center.
3. Support SIP protocol to communicate with IP phone.
Basic Functions
Waterproof jacket 1 Waterproof jacket 2
Cable cover
Waterproof jacket 3
Installation screws
-2-
Package Content
Screw wrench

Operation
In standby mode, when the visitors press the call button, the corresponding
indoor monitor will ring.
When it is set as help station, press the call button, the management center
will ring.
Calling
IP address View
same LAN. Install “700 Upgrade Tool” in PC, and press “search” button to view the
IP address of the outdoor panel.
Connect outdoor panel and PC in the network switch and make them in the
-3-

-4-
System Setting
Connect outdoor panel and PC in the network switch and make them in the
same LAN. Input IP address of outdoor panel in the web browser of PC, then input
the user name and password(the default user name is admin, the password is
123456) to enter into the following interface:
1. LAN setting:
Click “LAN” icon on the interface to enter into the following interface:
IP: IP address should be unique in the same LAN.
Mask: The default Mask is 255.255.255.0.
Gateway: It depends on IP address.
DNS: It depends on LAN.
Server IP: It is the same as the IP address of management PC.
NTP: It refers to network time protocol.
Usually, the communication among management center, indoor monitor and
outdoor panel will be available in the same LAN; if they are not in the same LAN,

you need to set SIP server to support the communication.
Press “Submit” button to confirm settings.
-5-
2. Device setting:
Click “Device” icon on the interface to enter into the following interface:
The settings of build and Unit No. should be the same as that of
corresponding indoor monitor.
No.: It is unique number for the outdoor panel. You can have max.9 outdoor
panels in one house, and you need to distinguish their numbers from 1 to 9.
Sys password: You can change the login password as you like (the default
password is 123456).
Panel mode: unit panel, wall panel and personal panel for option.
Unit panel: It is reserved;
Wall panel: It is used to call the management center in the guard center.
Person panel: It is used to call the indoor monitor in single house or
building.
You can choose different ring back tone for the outdoor panel.
Press “Submit” button to confirm settings.
1
2
3
3. Access setting:
Click “Access” icon on the interface to enter into the following interface:

Unlock timeout: 1~9 seconds, the door lock is open.
Unlock delay: .
Unlock password: It is reserved.
Elev refer:
After
The door lock is open for 0~9 seconds
It is reserved.
Admin Card: It is reserved.
Press “Submit” button to confirm settings.
4. VOIP
Click “VOIP” icon on the interface to enter into the following interface:
Input the relevant information if you have SIP server.
5. Forward :(Call transfer)
Click “Forward” icon on the interface to enter into the following interface:
-6-

1.Call indoor monitor
The indoor monitor can be bound with IP phone No.. When someone calls it,
and there is no answer within 25 seconds, the calling will transfer to the IP phone
automatically. Please refer to the following steps:
Input room No. of indoor monitor, then input the Account No. you want to
bind;If want to delete the Account No., input the room No. firstly, then select
“Remove” in the frame;
Press “Submit” button to confirm settings.
When the outdoor panel calls the indoor monitor, it will transfer to IP phone,
and you can make communication with IP phone accordingly.
2.Call management center
Input the room No. of outdoor panel; then input the Account No. you want
to bind (the account No. refers to management center No.);
If want to delete the Account No., input the room No. firstly, then select
“Remove” in the frame;
Press “Submit” button to confirm settings.
Remark:
The feature is available when you have SIP server.
One outdoor panel can be connected with one IP phone only.
6. ExModule
It is reserved.
7. Advanced
It is reserved.
8. Default
It is reserved.
-7-

9. Logout
Click “Logout” icon on the interface to enter into the following interface:
Click “Submit” icon to logout the system.
-8-

CAT-5e
6.LOCK26.LOCK2
1.+12V1.+12V
2.GND2.GND
4.CTRL4.CTRL
5.LOCK1 5.LOCK1
SETSET
NONO
NCNC
GNDGND
V+V+
485+485+
485-485-
RVV4*0.5
Electric lock
Reserved 485
data interface
Optional 1:
If you use the same power supply for outdoor panel and lock, please find the
system diagram as follows:
Connect with electric lock:
+12V+12V GNDGND
LOCK+ LOCK
-9-
System Connection
Power(DC12V)

Connect with magnetic lock:
CAT-5e
GNDGND
V+V+
485+485+
485-485-
RVV4*0.5
Reserved 485
data interface
+12V
GND
CTRL
LOCK
GND
GND
+12V
Magnetic lock
LOCK+
LOCK
Power(DC12V)
-10-

If your lock needs a seperate power supply, please find the system
diagram as follows:
Optional 2:
CAT-5e
GNDGND
V+V+
485+485+
485-485-
RVV4*0.5
Reserved 485
data interface
GND
+12V
Lock
DC
Power
Supply
+12V
GND
+18V
CTRL
LOCK1
LOCK2
NO
COM
NC
-11-
Power(DC12V)

Power on Ethernet:
Compatible with IEEE 802.3af, 48V PoE standard.
GND
+12V
+12V
GND
+18V
CTRL
LOCK1
LOCK2
PoE Switch
CAT-5e
-12-
Lock
DC
Power
Supply
NO
COM
NC
Power(DC12V)(optional)

Build-in box
Hole
l
Drain hole
Break through the cord hole on
the bottom of the build-in box
firstly for water draining.
Please don’t cover the drain hold
with the glass cement.
-13-
Installation

Care and Maintenance
