SmartBidet SB-100R User manual

Warranty (22~23)
User Manual
“Important safeguards/general cautions ” are information that can protect the user from safety hazards and also prevent
losses. Please be sure to read the manual correctly for proper usage.
• Please read the manual carefully before installation and utilization.
• This product is made for the US and Canada.
• The function and design of the product may be changed for quality improvements.
SB-100R
SB-100R Electronic Bidet
TM

2 3
ContentsImportant Functions
Preparation
Others
0peration
&
Cleaning
IMPORTANT SAFEGUARDS
General cautions
Product structure and designations
(Product components)
Control designations
Troubleshooting
Specications
Warranty
20
21
22-23
4
6
8
9
Installation and cautions
Initial operation
Separation of the unit from toilet bowl
Basic operation
Detailed operation
Maintenance
Draining water
Winter usage
10
12
13
14
15
18
19
19
Simply Clean. Stainless Nozzle.
Simplemente Limpia. Tout Simplement Propre.
Inoxidable Boquilla. Inoxydable Buse.
3-in-1 Improved Hygienic Functions
3-en-1 Funciones Mejoradas de Higiene
3-in-1 Amélioration des Fonctions D'hygiène
Revolutionary Heated Seat & Warm Air Dryer
Asiento Térmico Revolucionario y Secador de Aire Caliente
Sièges Chauffants Révolutionnaire et Sécheuse Air Chaud
Soft Closing
Fermeture en douceur
Cierre suave
Heated Seat
Siege chauffant Asiento
calefaccionado
Heated Water
Eau chaude
Agua caliente
Adjustable Nozzle
Bec reglable
Boquilla ajustable
Replaceable Nozzle A
buse remplaçable A
boquilla reemplazable A
SB-100R
Distributed by Hitrons Solutions Inc
Easy to Use
Facile a utilizer
Facil de Usar
Stable seat
Asiento estable
Siège stable
DIY Easy Installation
Instalación fácil de DIY
Installation facile de bricolage
Distri
b
ute
d
b
y
Hitrons So
l
utions In
c
c

4 5
1
IMPORTANT SAFEGUARDS
2
Cautions Before Installation
•READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
DANGER - To reduce the risk of electrocution:
WARNING - To reduce the risk of burns, electrocution, re, or injury to persons.
1. Do not place or store product where it can fall or be pulled into a tub or sink.
2. Do not place in or drop into water or other liquid.
3. Do not reach for a product that has fallen into water.
If this happens unplug the unit and then remove item from water immediately.
1. Close supervision is necessary when this product is used by, on, or near children or invalids.
2. Use this product only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug or if it is not working properly,
if it has been dropped or damaged, or dropped into water. Return the product to a service center for
examination and repair.
4. Keep the cord away from heated surfaces.
5. Never block the air openings of the product or place it on a soft surface, such as a bed or couch,
where the air openings may be blocked. Keep the air openings free of lint, hair, and the like.
6. Do not use the unit if you are sleeping or tired to the point of being drowsy.
7. Never drop or insert any object into any opening or hose.
8. Do not use outdoors or operate where aerosol (spray) products are being used or when oxidated products
are being administered.
9. Unplug this product before lling. Fill (reservoir) with water. Do not overll (or specify lling instructions)
SAVE THESE INSTRUCTIONS
THIS PRODUCT MUST BE PLUGGED into a regular voltage Grounded GFCI outlet (North America
120V AC, 60Hz). The rated power consumption is 660W / 600-700W. In locations where only a
standard two-prong outlet is available, it is the responsibility of the user to install a grounded
three-prong outlet. Using higher voltage is dangerous and may result in a re or other accident.
This product is not responsible for damage resulting from the use of it on other than specied
voltage, or operating it without proper grounding.
• Instruction and caution statements for cleaning, user maintenance, operations recommended by the manufacturer,
such as lubrication or nonlubrication, and a warning to the user that any other servicing should be performed by
an authorized service representative or that the product has no user serviceable parts.
This product has to be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This product is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
Danger - Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to either at blade terminal.
Consult with a licensed electrician if you have concerns about whether the product is properly grounded.
This product is for use on a normal 120 V circuit, and has a grounding plug that looks like the plug illustrated in sketch A
in Figure 1. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be used to connect this
plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available. The temporary adapter
should be plugged into a properly grounded outlet (sketch A) and should be installed by a licensed electrician.
The green colored rigid ear, lug, and the ike extending from the adapter must be connected to a permanent ground such
as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by the screw.
WIRING REQUIREMENT
WIRING REQUIREMENT
GROUND INSTRUCTIONS
WARNING
DANGER
This Product must be on a separated circuit. No other appliance should share
the circuit with this product.
Sharing a circuit could cause the branch circuit fuse to blow
or the circuit breaker to trip. Continuous usage under these conditions may
result in re or property damage.
IMPROPER GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK.
Electric wiring has to be done in accordance with all local codes,
or in the absence of local codes, with National Electrical Codes.
GROUNDING PIN
ADAPTER ADAPTER
METAL SCREW
TAB for
Grounding Screw
GROUNDED
OUTLET
- Figure 1-
GROUNDED
OUTLET BOX
Preferred Connection Temporary Connection
The use of an extension cord is not recommended or advised. If it is necessary to use an extension cord, use only a three-prong
extension cord (one to one), and a three slot built-in GFCI receptacle that will accept the plug on this product. The marked rating
of the extension cord should be equal to or greater than the electrical rating of the unit (10amp). Consult a licensed electrician if
you are not sure whether the unit is properly grounded.
This appliance has to be grounded.

6 7
3
General Caution
Warning
Cautions
Disassembling
remodeling prohibited
Unplugging the
power cord
Observe at all times
Do not spray water
Grounding
Wet hands prohibited
Observe at all times
Use of fire prohibited
Prohibited
Prohibited
Prohibited
Prohibited Prohibited
Prohibited Prohibited
Prohibited Prohibited
Observe at all times Observe at all times
Prohibited
Do not separate, disassemble, repair or remodel the unit,
or allow foreign substances inside the unit.
• This can cause a re or electric shock.
• Only qualied service personnel should repair this product.
For safety purposes, unplug the power cord either when cleaning
the product or detaching the unit from the toilet bowl.
• Failure to do so can cause an electric shock.
• Children, elderly, patients and those who are physically limited should us the low temperature setting for
the seat, water and dryer.
• After using the unit at high temperatures, the temperature should be readjusted to ‘low’ for the elderly,
children and for those with sensitive skin.
• Those who cannot adjust the temperature or those who have sensitive skin should take special precautions.
Do not use a damaged power cord or a loosely tted electric outlet.
• This can cause an electric shock.
When cleaning, do not use cleaning detergents (oxidized products, sink products, toilet cleaning
products, and any types of stain removers) on the external surface of the electronic toilet seat,
do not spray air fresheners or aromatic products onto seat in attempts to eliminate odors.
• Using cleaning detergents or air fresheners can change the color of the external surface and
can also cause problems with the seats functioning
Do not splash water on the main unit or power cord, and do not utilize it in areas of high
levels of humidity.
• This can cause a re or electric shock.
This product must be grounded before usage and
plugged into an AC 120V/60Hz power outlet.
• If grounding is not done, it can cause re or electric shock .
Do not stand on top of the seat
cover, seat or main body unit. This
can damage or break the unit.
• Do not use a broken product.
• As the unit is a bathroom appliance,
do not use it for any other purposes.
Do not slam or close the seat or
seat cover forcefully.
Prevent children from putting foreign
substances or inserting their hands
into the dryer outlet or onto the nozzle.
Do not pull the connecting
hose forcefully or bend it.
Never put the product
in water.
Do not let urine contact the dryer
outlet or nozzle area.
When cleaning or not using
the product over a long period
of time, be sure to unplug the
unit. (refer to page 19)
Do not touch the power cord with wet hands.
• Do not plug or unplug the power cord with wet hands as it can
cause electric shock or bodily injury.
Do not supply electrical power to the product until it is installed on the toilet and the water
supply hose is properly connected.
• This can cause a re or damage the product.
Do not connect several power cords into one outlet.
• This unit uses 120V power outlet.
• Can cause overheating or re hazards.
• Plug in the power cord properly into the power outlet.
Please use public water supply.
Please do not connect the unit to industrial water or greywater.
• This can cause skin infections or urinary tract infections and also damage the unit.
Keep the cord away from cigarettes or ammable substances.
• This can cause electric shock or bodily injury.
When the following people sit down on the seat, a guardian should pay extra attention so that they will not fall when sitting
on the toilet seat or standing up from it.
- Children, elderly, or those who cannot independently sit or stand on the seat.

8 9
STOP Stop
TURBO For His Back Wasah
FEMININE For Her Front Wash
POSTERIOR For Her Back Wash
OSCILLATE
During a wash, if you press on this button, the nozzle
will oscillate back and forth for a wider wash. Pressing
it once more will stop the oscillation.
ENERGY
SAVER
Pressing this button On or O with activate or
deactivate the Energy Saving mode.
WATER
PRESSURE
The water pressure can be adjusted up to 5 levels.
NOZZLE
POSITION
The oscillating mode and nozzle position can be
adjusted up to 5 levels.
WATER The water temperature can be adjusted up to 4 levels.
SEAT The seat’s temperature can be adjusted up to 4 levels.
4
Product structure and designations
Main unit Remote Control
Product components
T-Valve & packing
Conversion Nut
(3/8” Compression
(With Packing)
Water supply hose
(for electrical toilet seat)
Cone packing
(2pcs)
Mounting bolts
(2pcs)
Base Plate
(1pcs)
Nuts
(2pcs)
Bolt Case
(2pcs)
User manual
Water supply hose
(for toilet flush water tank)
For plumbing For product xation Installation instructions
• Always sit on the middle of the unit and do not sit on the side of the seat.
(The basic functions will not work if the skin sensor is not active.)
• When operating For POSTERIOR/FEMININE/TURBO, if the water temperature is low and
cold water comes out after using it for a period of time, pause and wait for 3 minutes for warm water to be provided.
Sitting on the heated seat or using the dryer for an extended period of time can potentially cause low degre burning.
Special precautions should be taken for children, those who cannot adjust the temperature, and those who have sensitive skin.
Caution
If the remote control is not used for 10 seconds, the LED light will
turn off automatically to protect its battery life.
Remote control
1.5V AAA type
Battery (2pcs)
For remote control
Remote control holder
Posterior
Turbo
Feminine
Simple Control
Dierent types
of wash sprays
(refer above)
Drain button
Skin sensor is
embedded in seat
Unit Separation
Button
Heated seat
Lid
Caution label

10 11
5
Installation
Caution
• This product requires 120V usage.
• Please do not plug in the electrical cord prior to installation.
• Please consult with a licensed electrician if electrical work is needed. In case a grounded outlet
is not available, grounding should be done in order to prevent short circuits or electric shock.
Check the water valve
Installation steps
Check the water valve in the bathroom. You may need to consider purchasing additional components.
For the following case, the T-valve alone is sucient for connection.
Shut water supply by turning it to the right.
Place the bolt into the bolt case and align it with
the top of the base plate. Insert the bolt with bolt
case onto the base plate. After this is done, hold the
bolts, gently slide it into the bottom of the unit until
it clicks in place. You will hear a click sound. Please
do NOT use force.
Once the base plate is attached to the unit, align the
unit and toilet fixture facing front, and then insert
the mounting bolts to the toilet mounting holes.
Please do not over tighten the nut.
Install the main unit and insert the mounting
bolts to the toilet mounting holes.
Connect the exible tube from side of
T-valve to the unit. Turn the water
valve to the left to allow water to ow.
※Customers should use the new hose set provided
with the product. Do not use used set again.
Disconnect existing hose from water tank.
Connect the T-valve to the water tank.
Connect the water supply hose to the
assembled T-valve.
Remove existing seat and lid.
• Water supply valve
Minus home Handle Inner bolt for water valve
• Inner bolt water valve
• Release the bolts on both
sides of the existing toilet
seat to remove the seat
and lid.
• Store the removed seat,
nut and water hose in a
safe area in case you
move or it needs to be
reinstalled.
Water supply hose
Installed bolt case
Cone Packing
Cone Packing
Back
Bolt
Water supply hose
Water supply valve
Nut
Nut
Base plate
Bolt
• Professional engineering is needed for plumbing work
on specialized water pipes and ush valve pipes.
• Please consult with a qualied specialist.
• Please put the unused water hose in a secure area.
󱎲
󱎶
󱎸
󱎷
󱎹
󱎳
󱎴 󱎵
Exisiting toilet
seat
Toilet
body
Nut
T-valve
(with packing)
Water Tank
Shut off Valve

12 13
6
Initial Operation 7 Separation of unit from the toilet bowl
Turn the water supply valve to the left and see if there is any water leaking from the hose.(1~5)
Disconnect the power plug
Shut the water supply valve
Push and hold the button on the right side of the unit to completely
drain the water from the water tank.
Disconnect the T-valve from the water tank.
Unit separation button
Connect the water hose to the toilet which was disassembled while installing the electronic toilet seat,
and turn the water valve to the left to open it. See if there is any leaking from the water hose connection.
Re-install the toilet seat and lid that was separated when installing the electronic toilet seat.
• As explained above, steps 1~4 are instructions for separation of the unit for basic cleaning purposes,
and steps 5~7 are instructions for separation when moving, etc.
Loosen the nut on the hose that is connected to the unit, and
then separate the electronic toilet seat from the toilet in the
following order as illustrated.
• While pushing the button (area shown as an arrow) push the electronic toilet seat slightly toward to the front
and then the body unit will begin to slide out.
Next, lightly pull the unit toward the front and it will detach from the toilet.
Please follow the instructions below when moving or separating the unit from the toilet for cleaning purposes
Connect the power cord to the 120V electric outlet.
Water supply valve
If you press or button, the water will begin to enter the heated water tank.
Function Check
• If the tank is full, then a low beeping sound will occur which indicates that
preparation is complete.
• In order to check whether the functions work, you will rst need to touch the seat or sit on it to
activate the skin sensor.
• Please be aware that water will come out. This product can only operate when the user sits on the
electronic toilet seat.
󱎲
󱎲
󱎳
󱎴
󱎶
󱎷
󱎸
󱎵
󱎳
󱎴
󱎵
󱃦
󱃧
󱃨
󱃩
󱃪
Do not turn the seat upside-down. This can cause damage to the unit as well as re hazard.
Drain button

14 15
ᆞWhen pressing button the display light( ) will change to allow the adjustment
of the water temperature to the desired level.
ᆞWhen pressing button display light( ) will change.
Temperature can be adjusted to the desired level.
ᆞTo increase water pressure press (high) on the remote.
ᆞTo decrease water pressure press (low) on the remote.
ᆞAs the water pressure increases the LED lights will illuminate the levels(see above illustration).
Caution
8
Operation (Basic) 9 Operation (Instructions to operate each function)
Cautions
Please press the‘o’ or ‘low’ button for seat temperature when the following persons use it.
Special precautions should be taken for children, those who cannot adjust the temperature, and
those who have sensitive skin.
• Sit on the toilet seat so that the skin sensor can fully be activated.
Sit on the seat.
• Do not press the control buttons harder than needed. This can cause damage.
• The skin sensor of the seat is only activated with bodily contact,
please be sure to pull down your clothes amply and do not cover the seat
with any clothing items, as it can prevent the seat from activating.
Warning
Low - High
Low - High
Room temperature
Room temperature
Low - High
Low - High
Low
Low
Low - High
Low - High
Normal
Normal
Low - High
Low - High
High
High
Low - High
Low - High
Water temperature
Seat temperature
• To Stop POSTERIOR, FEMININE, TURBO Wash.
Press
• Wash is available Posterior, Feminine and Turbo.
• The selected function can be used for up to 1 minute.
Please press or ,
• The wash functions will automatically stop after one minute.
If you want to use it continuously press the button again.
Warning
ᆞAverage maintenance time for warm water: This product can maintain the warm water
level for up to 50 seconds during a 1 minute wash session.
ᆞPress (high), (low) for the Water (Water pressure can be adjusted 1~5 levels.)
ᆞIt is recommended that the water lter (strainer) is cleaned periodically, as water pressure
can be weakened if foreign substances cling onto the water lter (strainer).
High
I
Low
High
I
Low
ᆞLED level
Water pressure
Water temperature adjustment
Seat temperature
Skin sensor

16 17
• When pressing the energy saver light on the electronic toilet seat will turn on.
• Energy saver mode automatically maintains a water and seat temperature of 89.6.
• If you want to turn o the energy saver function,
press the button again and the display light will turn o.
• While the energy saving mode is on, if you increase or decrease the water and seat temperature, the Energy Saving
mode will automatically turn o. If you stand up from the bidet seat, the Energy Saving mode will automatically
turn back on.
9
Operation (Instructions to operate each function)
In order to save energy, please abide by the following instructions:
• Keep seat cover closed when not in use to prevent heat from being lost.
• Keep temperature set to low.
• Unplug the power cord if you do not plan to use it for a long period of time.
Other energy saving tips
ᆞBefore and after using FEMININE,
POSTERIOR, TURBO the nozzle will
automatically clean itself.
ᆞAfter pressing one of the wash functions: FEMININE / POSTERIOR / TURBO, pressing it
a second time will activate the oscillating nozzle, covering a wider area of washing.
ᆞPress the button once more to stop the oscillation.
ᆞWhen using the wash functions use ▲(front), ▼(back) buttons to adjust the nozzle to t to your body.
ᆞLED level
Front
I
Back
Front
I
Back
Nozzle position adjustment
Oscillate
Automatic self cleaning nozzle
During a power outage, the water or seat heating temperature could appear to be lower than
the actual temperature setting.
· Always purchase the correct size and grade of battery most suitable for the intended use.
· Clean the battery contracts and also those of the device prior to battery installationj.
· Remove batteries frome equipment which is not to be used for an extended period of time.
· Remove and replace all batteries.
ᆞSelect a convenient spot near the toilet to attach the remote control holder
ᆞMake sure that the selected spot will not be exposed to water and
the area where you intend to ax the holder is clean and dry
ᆞRemove lm from the double sided tape locaed on the back of the
remote control holder and place the holder in the selected area.
ᆞOn remote control insert the two(2) batterries (1.5V AAA) ensuring that the
poles on the batteries correspond to the diretions on the remote control.
Energy saver
Setting up and using the remote control
Double
sided
tape
Two (2) batteries
( + , - please consider the right polarity) Remote control
holder

18 19
10
Maintenance 11 Draining water from tank
12
Maintenance for winter season
Cleaning the body unit
Cleaning the water lter (strainer)
• Beware to not use any bathroom cleaning detergents such as benzene acid
chemical detergent on the seat exterior.
- Using any type of chemical products or rough scrubbers on the electronic toilet seat surface,
which is made out of plastic material can either damage or change its color.
• Do not spray water directly or use a shower hose on the main body unit.
- Can cause fire or damage to the unit.
• When cleaning, the power cord must be unplugged from the power outlet,
and make sure water does not contact the cord and/or outlet.
• After cleaning, use a soft cloth to dry the unit.
1) Close the water shut off valve.
2) Flush the toilet to empty the water reservoir.
3) Unscrew the water hose nut.
Water supply valve
Water filter
(Strainer)
Do not use cleaning products nor chemical detergent. We recommend to mix baking powder and
vinegar to clean the unit.
4) Clean the strainer with a small brush or water
5) Re-screw the water hose nut.
6) Open the water shut off valve.
Disconnect the power plug.
󱎲
Check if the power cord is plugged in securely.
󱎲
Adjust the button to "low" to prevent water from freezing.
󱎳
If the product is not used for a long period of time,especially in cold regions or
environments, please disconnect the power cord and drain the water from the
internal unit.
󱎴
Please do not keep this product outdoors during the winter
as the cold temperature may damage the product.
󱎵
Shut the valve by turning it to the right.
󱎳
Press the drain lever until the water is completely drained from water tank.
󱎴
To re-supply water after draining, open the water shut o valve.
󱎵
Do not drink the drained water.
Do not insert finger into the drain hole.
Before draining, unplug the power cord and wait 30 minutes until the unit has cooled down.
Drain button
ᆞPlease perform the actions below without sitting on the toilet seat
- On Remote controller press and hold the‘POSTERIOR’button for three (3) seconds and the water nozzle will extend.
- To clean use a soft bristled brush(tooth brush) or a soft cloth. Upon completion press and hold the‘STOP’
button and the nozzle will retract back to its original position and will perform it’s self-cleaning function.
- Upon completion of these two steps the toilet seat can be used.
Cleaning the nozzle

20 21
• The design and function of this product could be changed without notice for the improvement of its quality.
13
Troubleshooting 14 Specications
• Please be sure to check the following aspects before asking for help.
Troubleshooting Factors to check
The water does not spray
• Check if the water tank is lled.
• See if the water valve is closed.
• Check if the water lter (strainer) is clogged.
The unit is not operating
• Check if the power cord is connected.
• See if the power is turned o from the main unit.
• See if you are correctly sitting on the seat so that
the skin sensor switch will function properly.
(Make sure that the Skin sensor on the seat touches your skin when you sit on the seat.)
Water is leaking • After checking if the plumbing is correctly connected, if water is leaking
from the main unit disconnect and contact service personnel.
Water pressure is weak • Check if the water pressure is set at “low”.
• Check if the water lter (strainer) is clogged.
Seat, water is not warm
• See if the water temperature is set to “low”.
When the nozzle doesn’t
come out
• See if the skin sensor on the seat is touching the skin.
When water is cold or warm
• Adjust the temperature to (mid, high).
• If someone has already used the wash function, wait about 3 minutes to use it.
• Sit on the seat for approximately 3 minutes and then use it.
Body unit shakes • Tighten the bolt (do not over-tighten)
Specication SB-100R
Power rating 120V / 60Hz / 670W
Water inlet
type
Type Direct Inlet Flow Type
Water inlet pressure 0.07 ~ 0.74MPa
Wash
device
Posterior Max. 700cc ± 100cc / min.
Feminine Max. 700cc ± 100cc / min.
Turbo Max. 700cc ± 100cc / min.
Water pressure
adjustments 5 levels
Warm water temperature
control Room Temp. ~ Low, Normal, High
Heater 600W
Safety device Thermal fuse, Thermal switch, Float switch
Heated
seat
Temperature control Room Temp. ~ Low, Normal, High
Heater 55 W
Safety device Thermal fuse
Inlet water temperature 37.4 °F ~ 95°F (3°C ~ 35°C)
Ambient temperature 37.4 °F ~ 104°F (3°C ~ 40°C)
Dimensions
Elongated
W : 15.4 inch (392mm)
L : 20 inch (508mm)
H : 6.06 inch (154mm)
Weight (Ibs) 9.4 lbs (Packed : 12.3 lbs)

22 23
Information to the user
Warranty
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio commu-
nications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the
following measures:
General Limited Warranty Covered Hitrons Solutions Inc will warrant to the original retail byuer only, which
falls in normal user and within the applicable periods specified below. Hitrons Solutions Inc replacements will
be warranted to the original purchaser of the products only.
The Parts Warrnty if the parts fail within Twelve(12)months after original purchase from authorized retailer,
following the installation manual and normal operation, Hitrons Solutions Inc will furnish replacement part(s)
agter warranty registration.
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modications not expressly approved by the manufacturer could void the
users authority to operate the equipment and limited warranty.
WARNING
• This Warranty does not cover the following
Hitrons Solutions Inc.
Limited Warranty
1. Defects and/or malfunctions from failure to properly install, operate and/or maintain the unit in
accordance with the installation manual.
2. Damage from abuse, fire, flood, freeze, and any other acts of Nature.
3. Damage resulting from unauthorized alterations, attachments and/or repairs.
4. If the product was not installed properly.
5. Damage to the unit by animals, mice or insects.
6. Damage caused by excess moisture or from water clogging the bathroom or restroom.
7. Damage from not being installed in accordance with all applicable local codes, ordinances and
good trade practices.
8. Color fading due to use in wrong environment.
9. Damage from chemials.
10. The warranty will not be covered without providing the date of purchase with original receipt.
*The serial number is located in the lid of the unit.
PLEASE
SEND
TO
WARRANTY REGISTRATION
Purchaser
Dealer(Company)
To ensure your warranty protection, please complete and return this registration with
a copy of the original sales receipt to [e-mail] or via mail within 15 days after
data of purchase to validate your warranty. If you choose to send through email, in the
Subject link, please write "Warranty Information: Your SmartBidet Serial number "
Company
City Country
Dealer Code
Address
Address
Model * Serial Number #
Service Department
Hitrons Solutions Inc.
Inquiries and Support
Email : [email protected]
Phone : [phone]
Attn: Warranty Dept.
Hitrons Solutions Inc.
[email protected]om

Service Department
Hitrons Solutions Inc.
Inquiries and Support
Email : [email protected]om
88 Portland Avenue, Suite M,
Bergeneld, NJ 07621
Phone : [phone]
Electronic Bidet Seat
TM
2018 JUN 0.0
