Smarti IDP4301 User manual

Manual SMART-i ™
Note (Please Read before Use)
Smart-i Incorporation reserves the rights of interpretation to this "instruction manual ".
λAll GPS map data and license(s) attached in the device are solely for Navigational purposes.
Please DO NOT attempt to alter and/or duplicate the GPS data and license(s).
λUsers are to read the operation instructions carefully before use to avoid mishandling and/or misuse
of product.
λThe Portable GPS system shall be fitted in a position that DOES NOT visually affects the driver.
λPlease note in certain countries, it is NOT LEGAL to access multimedia programs while driving. The
company WILL NOT be responsible for any user breaching the rules and regulations set by relevant
Traffic Authorities of respective countries.

MANUAL SMART-i ™
Contents
1. BASIC USE 4
2. MAIN FUNCTIONS AND OPERATIONS 5
2.1. FLASH PLAYING 5
2.2. VIDEO PLAYING 5
2.3. MUSIC PLAYING 6
2.4. BLUETOOTH 6
2.5. PICTURE 8
3. TOOLS 9
3.1. CALCULATOR 9
3.2. WINDOWS 9
3.3. FM 9
4. SYSTEM SETTINGS 10
4.1. BACKLIGHT SETTING 10
4.2. POWER SETTING 10
4.3. SOUND 10
4.4. SYSTEM INFO 10
4.5. CALIBRATE TOUCH SCREEN 10
4.6. UPDATE LOGO 10
4.7. FILE MANAGEMENT 10
4.8. AV IN SET 10
4.9. GPS PATH 10
5. QUICK TROUBLESHOOTING 11
6. DISCLAIMER 12
7. IMPORTANT MESSAGES 12
8. TECHNICAL SUPPORT 12

MANUAL SMART-i ™
______________________________________________
Road Runner Series 41
Model IDP4301
_____________________________________________
USER MANUAL

MANUAL SMART-i ™
4
1. Basic use
Battery
Battery status icon：
【Attention】Please charge the battery if the status is low.
Power charging
Attention：
1. The new battery may not be charged initially
2. 8 to 16 hours is needed for the first three times of charging
3. Ensure subsequent charging of 2 to 4 hours when using a DC adapter.
【Attention】
1. In the event that the unit has been idle for over 60 days, charge the unit for a minimum of 6 hours prior to
use.
2. Discharge the battery if the device is not being used for a period longer than 90 days.
Powering On & Off：
Press and hold the “Power” button to power the equipment on / off.
Sleeping mode (Activate by pressing the “Power” button once):
While in sleeping mode, all programs stop working, and resume operation mode after starting up.
The device could toggle to sleeping mode automatically or manually by the 2 methods below:
1. Press “Power” button once to activate sleeping mode.
2. The device will change to sleeping mode when there is no operation for a period preset by the user.
Starting up while in sleeping mode:
Press and hold power key to resume operation mode.
Shutdown
The device will automatically shut down after full consumption of the internally built battery.
Internal Flash Drive
The internal flash drive of the device contains the map software, GPS Navigation data and map license.
Users can store their multimedia files to the internal flash drive.
Note: For USA customers, there will be an internal flash of 2Gigbyte. Navigation software and date will utilize
approximately 1.4 Gigabyte. Users can make use of the remaining 500Megabyte of free space for multimedia storage.
.

MANUAL SMART-i ™
5
2. Main functions & operations
2.1 Flash Multimedia Files.
From the device’s main menu, tap 「Flash] icon to enter into flash folder.
Tap to search your favorite, tap to exit；tap to play the selected file.
Control buttons in playing mode:
Play Play
Pause Click to pause playing
Stop Click to stop playing
Forward Click for forwarding
Backward Click for reversing
Full screen Click for full screen playing mode
Return Click to return to main interface when playing
【Attention】In full screen playing mode, the tool bar is hidden. Simply tap the screen for the tool bar to appear.
2.2 Video playing
Support video files in AVI, MPEG, MPG, MOV, DAT, ASF, RM. RMVB and WMV formats.
In main menu, tap「Video」icon to enter into video folder:
Tap to search your favorite, tap to exit；tap to play the selected file.
Control button in playing mode:
Play Next
Pause Last
Stop Full screen playing
Close
【Attention】In full screen playing mode, the tool bar is hidden. Simply tap the screen for tool bar to appear.

MANUAL SMART-i ™
6
2.3 Music playing
Support MP3, WMA formats.
In main menu, tap 「Music」icon to enter into music folder.
Tap to search your favorite, tap to exit, tap to play the selected file.
Soft keys information:
pause,
play
stop
next
previous
play in sequence.
volume on/off
return to the system main interface
2.4 Bluetooth（Optional）
Tap 「Bluetooth」for Bluetooth menu.
Control button：
Close Close the current dialog box
Phone keyboard Dial-up directly
Call history Display call history
The last call Display the last call
Pairing Pairing with a Mobile Phone or other Bluetooth device
Bluetooth Setting Setting Bluetooth parameters
Pairing equipment
management To manage all the paired equipments.
Phone keyboard
Tap“Photo keypad”for the interface
Control button：
Close Close the current dialog box
Back Click to delete the last character
Dial up To make a call
Phonebook Call history

MANUAL SMART-i ™
7
Call History
Tap“call record”for call history information.
Control button：
Close Close the current interface ；
Outgoing Display all the outgoing calls lately
Incoming calls Display all the incoming calls lately
Missed calls Display all the missed calls lately
Last Display the last content
Next Display the next content
Delete one Delete the selected
Delete all Delete all the phone information
Calling Dial-up the selected phone
Paring interface
Control button：
Close Close the current dialog box；
Count down Automatic count down from the beginning of paring
Bluetooth setting
Tap“Bluetooth setting”for the menu.
Control button：
Close Close the current dialog box
Reset pin code Resetting pin code
Ring-Tone You can select one ring tone
Turning On/Off Bluetooth
function Turning On/Off Bluetooth function
Pin code setting interface:
Close Close the current dialog box
Display zone Display the inputted characters. Pin code is“8888”
Number keyboard Help you input the No.
Back Back space

MANUAL SMART-i ™
8
Confirm Confirm your setting
Paring setting
Control button：
Close Close the current dialog box
Last Display the last content
Next Display the next content
Connect Paring
Turn off Turn off the current connection
Delete Delete all paring history
2.5 Picture
Support JPG, JPEG, BMP formats in SD card.
Tap「Picture」to browse picture folder.
Tap to search for file. Tap to exit. Tap to open the selected file.
Soft keys information:
or browse up and down.
or zoom in/out
full screen on
photo rotating.
size
exit.

MANUAL SMART-i ™
9
3. Tools
3.1 Calculator
Tap [Calculator」in the system main menu to use calculator.
Tap to exit.
3.2 Windows
Tap「Win Desk」in the system main menu to enter into Windows platform.
In Windows platform CE6.0, you can view your Microsoft Words, Excel, Power Point, PDF etc…
Windows Media Player is also available for multimedia files.
To exit from Windows CE 6.0, press on the [GPS_MAIN] to exit to the system main menu.
3.3 FM
With this function, IDP4301 can connect with auto video/audio system.
1. Tap「FM」for FM transmission menu.
2. Tap or to adjust the FM frequency according to the FM radio frequency in your car.

MANUAL SMART-i ™
10
4. System Settings
Tap「System Set」icon to customize the system settings such as backlight brightness, volume, and language… to your
own preferred settings
Language setting:
Tap the corresponding national flag to select the language you need and save automatically.
4.1 Backlight Setting
Setting up of the duration of backlight and screen saver.
4.2 Power setting
To indicate battery current level and to set up Auto Sleep mode.
4.3 Sound
Tap “Sound”to set volume.
4.4 System info
To check on the information of the device.
4.5 Calibrate touch screen
You can calibrate the touch screen if it is not responding accurately to your stylus taps.
Tap on the calibration as indicated on the screen. Tap and hold at the center of the target. When the target moves to
another position, tap and hold at the center of the new target. Repeat each time to complete the calibration process.
When the process is completed, tap screen to return to the Settings screen.
4.6 Update Logo
This function serves as the upgrading program for the device.
4.7 File management
This function is used for managing the files in SD card
4.8 AV IN Set
To toggle to reverse camera view if the system is fitted with reverse camera.
4.9 GPS Path
Use for configuration of GPS path for the device to detect the link to GPS map folder.

MANUAL SMART-i ™
11
5. Quick Troubleshooting
Power
Cannot startup Insufficient battery. Please connect the adapter and restart the system.
Screen
No screen displayed If the system does not respond after powering up,
try the following:
1. Connect an adapter, restart system.
2. Reset the system.
Display speed is too slow 1. Check if the battery is low on power.
2. Reset the system.
Screen has no response Reset the system.
Navigation GPS cannot display current location Make sure your current location is not obstructed
by buildings or other interferences.

MANUAL SMART-i ™
12
6. Disclaimer
Smart-i Incorporation takes no responsibility for any use of this product that may result in law violation and/or
accidents leading to personal injuries and/or property damage. It is the user’s own responsibility to operate the product
in a prudent manner that will comply with the law. Smart-i will take no responsibility for the consequences caused by
inaccurate satellite transmissions.
7. Important Messages
•Warning: Do not operate Smart-i Navigator and a vehicle simultaneously as this is very dangerous. The vehicle
must be parked prior to operating Smart-i. It is your sole responsibility to operate Smart-i and the vehicle in a
prudent manner. Misusing Smart-i may result in accidents and may lead to injuries and/or property damage. Only
a passenger, not the driver should operate Smart-i while the vehicle is in motion.
•Caution: Do not use Smart-i as a medium to generate precise readings of altitude, direction, distance, location or
topography. Smart-i must only be used as a navigational aid. Any information generated from Smart-i must only
be used as reference.
•Caution: Although every attempt has been made to ensure the accuracy of the maps and the data used by
Smart-i, the location of points of interest, transportation networks, etc may change over time without notice
therefore rendering the data obsolete. Therefore it is essential that you check the actual surroundings with
Smart-i’s maps in order to confirm that you are at the exact destination.
•Caution: Smart-i cannot guarantee that any parts of the planned route will be safe, closed to traffic, or restricted
to certain types of vehicles or if traffic is congested. Therefore it is your responsibility to determine the safety of
the suggested route and to ignore any illegal or unsafe routes.
8. Technical Support
Kindly refer to product origin’s websites for service and support details;
EMAIL : [email protected]
WEB : www.smart-i.us
We thank you for purchasing SMART-i product and Services.
