SmartLearn IB-82T User manual

Interactive Whiteboard
InstallationGuide

User Guide
1
Installation Guide
This Installation Guide provides basic installation and configuration procedures
for the Interactive Whiteboard.
Mounting the Whiteboard
To mount the Whiteboard on a wall:
Installation Method 1:
1. Locate the hardware and installation tools included in the package. Note the
differences between the front and back of the Whiteboard.
x4 x6 x4 (optional)
Penholder x1
x4
Required installation tools :
BACK
FRONT

User Guide
2
2. Positioning and drill holes for the brackets which will hold the top frame
of Whiteboard.
3. To fix the top brackets onto the wall.
4. Slide the holding screws into the top frame and bottom frame of Whiteboard
via the slots on the frame.
1
2
Positioning and drill holes.
4x
1
2
4x
1
2
BACK
3
4

User Guide
3
5. Install the penholder(optional).
6. Hang the Whiteboard onto wall by fixing the top brackets with Whiteboard.
Lift up
7. Mount the Whiteboard on the wall.
Move up and positioning
Positioning and drill holes
1
2
2x
BACK
3
Bottom side
4
Penholder
4x
1
2
FRONT
3
4
BACK
IWB Frame
IWB Frame
IWB
slot
Wall
Installed
1
Installed
2
Installed
FRONT
3
4

User Guide
4
8. To fix the bottom brackets onto the wall.
9. Hold the bottom frame of Whiteboard by fixing the bottom brackets with
Whiteboard.
10. Whiteboardmountedonthewall.
1
Installed
2
Installed
FRONT
4x
3
4
OR
IWB keep up
1
Installed
2
Installed
IWB Frame
IWB Frame
FRONT
BACK
BACK
2x
3
4
IWB keep up
FRONT

User Guide
5
Installation Method 2:
1. Locate the hardware and installation tools included in the package. Note the
differences between the front and back of the Whiteboard.
x4 x6 x4 (optional)
Penholder x1
x4
Required installation tools :
2. Install the four wall-mount brackets.
3. Install the penholder.
4x
BACK
2x
BACK
Bottom side
Penholder
BACK
FRONT

User Guide
6
4. Mount the Whiteboard on the wall.
Handling the Whiteboard
When using or moving the Whiteboard, do not hit or scratch the Whiteboard’s
surface, do not drop the Whiteboard, and do not pull on cables connected to the
Whiteboard.
Warning
4x
FRONT
4x
OR

User Guide
7
Connecting the USB lable with Whiteboard
Remark :This part is only for some models of infraredWhiteboards.
How to connect:
1. Plug the USB lable to the USB port (A Type or B Type) at the back of Whiteboard.
connect
①
If with A Type USB port ATypeUSBlable
② connect
If with B Type USB port B Type USB lable
2. Fasten the USB lable to the lable Fastenner to ensure the USB lable is fixed.
①A Type USB lable Fastening method: ②B Type USB lable Fastening method:
(USB port) (lable port)
BACK
BACK
BACK
