SMC Networks LECSB2-T Series User manual

Doc No. DOC1015792
NN57170400
PRODUCT NAME
AC Servo Motor Driver
(Pulse input type/Positioning type)
MODEL / Series / Product Number
LECSB2-T□Series
(Simplified Edition)
This product can be used by adding "MR Configurator2 dedicated file for LECSB-T"
to Setup software (MR Configurator2TM :LEC-MRC2□).
This is an additional file that is absolutely necessary when setting the LECSB-T with MR Configurator2TM.
Please download the dedicated file from SMC website.
When connecting LECSB-T with MR Configurator2TM, select MR-J4-A-S099(□) as the model.
For SMC products and SMC purchased products, please contact the SMC sales office.

- 1 -
Contents
Contents..................................................................................................... 1
Introduction ............................................................................................... 6
Terms ......................................................................................................... 6
1. Configuration......................................................................................... 7
2. Pre-Operation Procedure...................................................................... 8
2.1 Flow chart ...........................................................................................................8
3. Wiring..................................................................................................... 9
3.1 Power Supply Wiring..........................................................................................9
3.2 Connection of I/O signals................................................................................10
3.2.1 Position control mode (sink input/output interface)...............................................10
3.2.2 Speed control mode (sink input/output interface)..................................................13
3.2.3 Torque control mode (sink input/output interface).................................................14
3.2.4 Positioning Mode (Sink I/O Interface).......................................................................15
4. Parameter List for each Mode .............................................................16
4.1 Common to each mode ...................................................................................16
4.2 Position control mode .....................................................................................16
4.3 Speed control mode.........................................................................................17
4.4 Torque control mode........................................................................................17
4.5 Positioning mode .............................................................................................18
5. Parameter setting from setup software (MR Configurator2TM)..........19
5.1 Setup software (MR Configurator 2TM)............................................................19
5.1.1 Installation Method.....................................................................................................19
5.2 Driver basic settings for first commissioning ...............................................19
5.2.1 Starting the setup software .......................................................................................20
5.2.2 System Settings..........................................................................................................21
5.2.3 Model Selection...........................................................................................................21
5.2.4 Driver ON LINE Check................................................................................................22
5.2.5 Help Function..............................................................................................................22
5.3 Parameter setting (Driver side).......................................................................23
5.3.1 Change Parameter Block ...........................................................................................24
5.3.2 Reading parameters ...................................................................................................24
5.3.3 How to set parameters (Example: Operation mode change).................................25
5.3.4 Recommended Parameter Values by Actuator........................................................26
5.3.5 Absolute position detection system.........................................................................26
5.3.6 Electronic Gears .........................................................................................................27
5.3.7 Control mode selection...........................................................................................28
5.3.8 Set the parameter of command pulse input form (position control mode (pulse
input) only)................................................................................................................29
5.3.9 Verify of parameters ...................................................................................................32
5.3.10 Parameter initialization ............................................................................................33
5.4 JOG operation by setup software...................................................................34
5.4.1 JOG operation.............................................................................................................35
5.5 How to change the allocation of I/O signals ..................................................36
5.5.1 Set input signal automatic ON selection parameter...............................................36

- 2-
5.5.2 Signals required for operation within the input signal automatic ON selectable
range..........................................................................................................................37
5.5.3 Initial allocation of I/O signals...................................................................................41
5.5.4 Signal Allocation using Setup Software...................................................................43
5.5.5 Allocation Examples for Position Control Mode (Pulse Input)..............................44
5.5.6 Setting example when changing the number of point tables in positioning (point
table)..........................................................................................................................46
5.5.7 I/O Signal Allocation Check.......................................................................................49
5.5.8 How to change the allocation from Digital I/O –Basic Tab....................................50
5.6 Positioning Operation using Setup Software ................................................52
5.6.1 Positioning Operation ................................................................................................53
5.6.2 Motor Speed Setting...................................................................................................54
5.6.3 Acceleration/deceleration Time Constant Setting...................................................55
5.6.4 Movement Amount Setting and Operation...............................................................56
5.7 Positioning Operation (Point Table) using Setup Software..........................57
5.7.1 Point Table List.........................................................................................................57
5.7.2 Point Table Data..........................................................................................................58
5.7.3 Point Table (Target Position) Setting........................................................................59
5.7.4 Point Table (Rotation Speed) Setting........................................................................62
5.7.5 Point Table (Acceleration Time Constant and Deceleration Time Constant) Setting
63
5.7.6 Positioning (Pushing Operation) Setting.................................................................63
5.7.7 1 Step Feed.................................................................................................................64
5.8 Saving / Loading Parameters..........................................................................65
5.8.1 Saving Parameters......................................................................................................65
5.8.2 Loading Parameters ...................................................................................................66
5.9 Saving / Loading Project..................................................................................67
5.9.1 Saving Project.............................................................................................................67
5.9.2 Loading Project...........................................................................................................68
5.10 Saving / Loading Point Table.........................................................................69
5.10.1 Saving Point Table....................................................................................................69
5.10.2 Loading Point Table..................................................................................................70
5.11 Acquisition of Motion Waveform by Graph Monitor ....................................71
5.11.1 Setting Items to display Graph................................................................................72
5.11.2 Trigger Wait................................................................................................................75
5.11.3 Operation Instruction................................................................................................76
5.11.4 Saving Waveform......................................................................................................77
5.12 Display All Monitor List..................................................................................78
6. Home Position Return Method ............................................................79
6.1 Position Control Mode (Pulse Input)...............................................................79
6.2 Positioning mode (Point table)........................................................................79
6.2.1 Pushing Type Home Position Return Method..........................................................80
7. Operation Method of each Mode.........................................................83
7.1 Position Control Mode (Pulse Input)...............................................................83
7.1.1 Operating Instruction .................................................................................................83
7.2 Speed Control Mode ........................................................................................84
7.2.1 Operating Instruction .................................................................................................84
7.3 Torque Control Mode .......................................................................................86
7.3.1 Operating Instruction .................................................................................................86
7.4 Positioning Mode (Point Table).......................................................................87
7.4.1 Operating Instruction of Point Table.........................................................................87
7.5 Positioning Mode (Programimg Method) .......................................................89

- 3-
7.5.1 How to Set....................................................................................................................89
7.5.2 Commands in Program Method ................................................................................90
7.5.3 Program-based Operation Instruction Method........................................................91
7.6 Positioning Mode (Pushing Operation)..........................................................92
7.6.1 How to Set....................................................................................................................92
7.6.2 Point Table-based Operation Instruction Method ...................................................93
7.6.3 Timing Chart................................................................................................................94
7.6.4 Point Table Data List...................................................................................................95
8. Troubleshooting ...................................................................................97
8.1 Alarm and Warning...........................................................................................97
8.2 Alarm Display....................................................................................................97

- 4-
LECSB2-T□Series / Driver
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions
indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger”. They are all important notes for
safety and must be followed in addition to International Standards (ISO/IEC), Japan Industrial Standards (JIS) *1.) and
other safety regulations*2.).
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems
ISO 4413: Hydraulic fluid power -- General rules relating to systems
IEC 60204-1: Safety of machinery -- Electrical equipment of machines (Part 1: General requirements)
ISO 10218: Manipulating industrial robots -- Safety
*2) Labor Safety and Sanitation Law, etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result in minor or
moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could result in death
or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result in death or
serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based
on necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person
who has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when
configuring the equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is confirmed.
The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
When the product is to be removed, confirm that the safety measures as mentioned above are
implemented and the power from any appropriate source is cut, and read and understand the specific
product precautions of all relevant products carefully.
Before machinery/equipment is restarted, take measures to prevent unexpected operation and
malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1) Conditions and environments outside of the given specifications, or use outdoors or in a place
exposed to direct sunlight.
2) Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and lock circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3) An application which could have negative effects on people, property, or animals requiring special
safety analysis.
4) Use in an interlock circuit, which requires the provision of double interlock for possible failure by using
a mechanical protective function, and periodical checks to confirm proper operation.
Note that the CAUTION level may lead to a serious consequence according to conditions. Please follow the
instructions of both levels because they are important to personnel safety.

- 5-
LECSB2-T□Series / Driver
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries; consult SMC beforehand and exchange specifications
or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
The warranty period of the product is 1 year in service or 1.5 years after the product is delivered,
whichever is first.*3)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
Prior to using SMC products, please read and understand the warranty terms and disclaimers noted
in the specified catalog for the particular products.
*3.) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or
failure due
to the deterioration of rubber material are not covered by the limited warranty.
Compliance Requirements
When the product is exported, strictly follow the laws required by the Ministry of Economy, Trade and
Industry (Foreign Exchange and Foreign Trade Control Law).

- 6-
Introduction
When using the LECSB2-T□, prepare the "LECSB2-T□Operation Manual" and use it together.
For the handling and details of equipment other than this driver, please refer to the manual of the equipment you
are using.
Check that the main circuit power supply (AC200V) and control power supply (AC200V) are wired. .
For wiring, refer to " LECSB2-T□Operation Manual, Chapter 3.1" and " LECSB2-T□Operation Manual
(Simplified Edition) , Chapter 3 ".
Check the EM2 (forced stop 2) wiring or parameter to release EM2 (operable).
EM2 can be forcibly set to automatic ON with a parameter only for the positioning mode .
Other than positioning mode, EM2 can not be forcibly set to automatic ON with parameters.
Sure to set the EM2 wiring to the ON : EM2 release (operable) state.
When setup software (MR Configurator 2TM ) is used, it is necessary to select the LECSB2-T□ model.
Select "MR-J4-A-S099(□)" *1) through Project (P) - "New (N)" - "Model".
*1) This product can be used by adding "MR Configurator2 dedicated file for LECSB-T" to Setup software(MR
Configurator2TM:LEC-MRC2□).
Please download the dedicated file from SMC website.
"LECSB2-T□ Operation Manual, section 17.1 " for how to add and operate dedicated files.
Terms
Position control mode (pulse input)
Positioning is performed by controlling the rotation speed and direction
of the motor with a pulse train.
Speed control mode
Runs at the set rotation speed using parameters or analog input
commands.
Torque control mode
Operation is executed with the set output torque by the analog input
command.
Positioning mode (point table)
Position data, rotation speed, acceleration/deceleration time constant,
etc. are set in the point table of the driver, and I/O signal ON/OFF
control positioning operation is executed. (Up to 255 points can be
used in the point table.)
Positioning mode (program method)
Multiple operation method settings are preset in the driver as steps
with program, and I/O signal ON/OFF control positioning operation is
executed. (The maximum number of steps is 640.)
Positioning mode (equally divided
indexing method) (Note)
Presetting the number of equal divisions of 360 degrees for one
rotation of the machine end, and I/O signal ON/OFF control positioning
operation is executed. (Maximum number of divisions: 255 divisions)
Positioning mode
(pushing operation)
A series of operations from positioning to pushing operation is
executed using the positioning mode of point table.
Note) The positioning mode (equally divided indexing method) is not described in this Operation Manual
(Simplified Edition).
When using the positioning mode (equally divided indexing method), refer to ``LECS B2 -T□ Operation
Manual, Chapter 16.17 ''.

- 7-
1. Configuration
Equipment and wiring needed to get started.
1
Driver
LECSB2-T*
2
Motor cable
LE-CSM-***
3
Encoder cable
LE-CSE-***
4
I/O connector
LE-CSNB
I/O cable
LEC-CSNB-1
5
USB cable
LEC-MR-J3USB
6
Setup software (MR Configurator2TM)
LEC-MRC2*
7
Main circuit power supply connector
CNP1 (Accessory)
8
Control circuit power supply connector
CNP2 (Accessory)
9
Motor connector
CNP3 (Accessory)
10
Absolute battery
LEC-MR-BAT6V1SET (included)
Not required if used in an incremental system
11
STO cable
LEC-MR-D05UDL3M
Note) The optional lock cable is not shown in this drawing.
For details, refer to the "LECSB2-T□ Operation Manual".
1
3
2
U
V
W
4
PC
5
6
7
8
9
10
11
Ｌ1
Ｌ2
Ｌ3
N(-)
Ｐ3
Ｐ4
C
D
Ｌ11
Ｌ21
Ｐ(+)
Provided by customer
Provided by customer
200 V AC
Provided by
customer
Electric Actuators
Ex) LEF

- 8-
2. Pre-Operation Procedure
2.1 Flow chart
Wiring
See “3. Wiring”
Parameter setting
See “4. List of Parameters for each Mode”
Signal Assignment Configuration
See “5.5 Changing I/O Signal Allocation”
Parameter Settings using the Setup Software (MR
Configurator2TM)
See “5. Parameter Settings using the Setup Software (MR
Configurator2TM)”
Home position
return Method
See ”6. Home
position return
Method”
Home position
return Method
See “6．Home
position return
Method”
“Position Control
Mode” Configuration
See “7.1 Position
Control Mode (Pulse
input)”
“Positioning mode”
Configuration
See “7.4 Positioning
mode (Point table
method)”
See “7.5 Positioning
mode (Program
method)”
See “7.6 Positioning
mode (Pushing
operation)”
“Speed control
mode” Configuration
See “7.2 Speed control
mode”
“Torque control mode”
Configuration
See “7.3 Torque control
mode”
Position control
using pulse train
input
Speed control though
specifying the internal
set speed using I/O
signals
Thrust control through
specifying the internal set
torque using I/O signals
Simple positioning mode
which is operable using
I/O signals
-Point table method
-Program method
- Pushing operation

- 9-
3. Wiring
3.1 Power Supply Wiring
Connect the actuator and driver power supply. This wiring diagram is common for each mode.
(1) LECSB2-T□(Absolute encoder)
Example) When the power supply voltage is AC200V single-phase/sink input/output interface
[1] Power supply input terminals: Supply specified power (single -phaseAC200to 240V) to L1and L3.
[2] - Connect the power input terminals (U, V, W ) of the motor to the power terminals (U, V, W ) of the
driver.
- Connect the ground terminal of the motor to the ground terminal of the driver.
- Connect the encoder cable.
[3] Connect the single -phaseAC200to 240V external power supply to the power supply for control circuit.
[4] Connect the DC24V power supply to the interface power supply.
Refer to "LECSB2-T□ Operation Manual, Chapter 3" when the power supply voltage is 3-phase AC200V or
source I/O interface.
Note 1.
P3 and P4 are already connected at the time of shipment.
2.
Always connect between P+ and D. (Wiring is completed at the time of shipment.)
4.
This is for the sink I/O interface.
6.
Use a magnetic contactor with an operation delay time (the time from when current flows through the operation coil until the
contact closes) of 80 ms or less. Depending on the voltage of the main circuit and the operation pattern, the bus voltage may
drop and the deceleration may shift to dynamic brake deceleration during forced stop deceleration. If you do not want dynamic
brake deceleration, delay the time to turn off the magnetic contactor.
7.
To prevent an unexpected restart of the driver, configure a circuit that turns off EM2 when the main circuit power is turned off.
8.
When not using the STO function, attach the short-circuit connector that comes with the driver.
9.
If the wire used for L11 and L21 is thinner than the wire used for L1 and L3, use a no-fuse circuit breaker.
10..
Do not connect the servo motor of the wrong axis to U, V, W and CN2 of the driver as it may cause malfunction.
11.
For convenience, the DC24 V power supplies for input signals and output signals are shown separately, but they can be
configured with a single unit.

- 10 -
3.2 Connection of I/O signals
An example of connecting the input/output signals of the driver is shown.
3.2.1 Position control mode (sink input/output interface)
(1) Connection example
An example of connection in position control mode is shown below.
For the source I/O interface, please refer to "LECSB2-T□ Operation Manual Chapter 3.2.1 (2)".
For notes and wiring details, please refer to "LECSB2-T□ Operation Manual Chapter 3.2.1 (1)".
For input/output signals, refer to "LECSB2-T□ Operation Manual (Simplified Edition), Chapter 3.2.1 (2), (3)". For
details, refer to "LECSB2-T□ Operation Manual Chapter 3.5".
This connection example is for use with Mitsubishi Electric Corporation's PLC/positioning unit
(RD75D/LD75D/QD75D) when used in position control mode.
When connecting with other PLCs/positioning units, please check the "LECSB2-T□instruction
manual" and the technical data/manuals of the PLC and positioning unit you are using.

- 11 -
(2) Input signal
Position control mode: P, Speed control mode: S, Torque control mode: T,
Positioning mode (Point table method): CP, Positioning mode (Program method): CL
●: Automatic ON can be set ○: Initial setting △: Assignment is available with parameter －: Assignment is not available
Symbol
Device name
Automatic
ON
P
S
T
CP/
CL
Function
PP
Forward rotation
pulse train
(Sink)
-
○
-
-
-
1) For open collector method
Maximum input frequency is 200 kpulses /s.
For A-phase and B-phase pulse trains, 200
kpulses /s is the frequency after
multiplication by 4.
a) For sink input interface
Input a forward pulse train between PP
and DOCOM.
Input a reverse pulse train between NP
and DOCOM.
b) For source input interface
Input a forward rotation pulse train
between PP2 and PG.
Input reverse pulse train between NP2
and NG.
2) For differential receiver method
Maximum input frequency is 4 Mpulses /s.
For A-phase and B-phase pulse trains,
4 Mpulses /s is the frequency after
multiplication by 4.
Input a forward pulse train between PG and
PP.
Input a reverse pulse train between NG and
NP.
NP
Reverse rotation
pulse train
(Sink)
-
○
-
-
-
PP2
Forward rotation
pulse train
(Source)
-
○
-
-
-
NP2
Reverse rotation
pulse train
(Source)
-
○
-
-
-
PG
Differential
forward rotation
pulse train
-
○
-
-
-
NG
Differential
reverse rotation
pulse train
-
○
-
-
-
EM2
Forced stop 2
-/●
Note)
○
○
○
○
Forced stop state can be canceled by turning
ON EM2.
EM1 is an exclusive function, EM2/EM1 are the
same connector pins.
EM1
Forced stop 1
-
△
△
△
△
Unlike EM2, it does not decelerate and forcibly
stops.
SON
Servo-on
●
○
○
○
○
When SON is turned ON, operation becomes
possible.
RES
Reset
-
○
○
○
△
Alarm can be reset.
LSP
Forward rotation
stroke end
●
○
○
△
○
Turn this signal on before operation. When this
signal turns off, the product is stopped suddenly
and servo lock is enabled.
LSN
Reverse rotation
stroke end
●
○
○
△
○
Turn this signal on before operation. When this
signal turns off, the product is stopped suddenly
and servo lock is enabled.
TL1
Internal torque
limit selection
-
△
△
△
△
When this signal turns on, the torque will be
lower than the set parameter torque.
ST1
Forward rotation
start
-
-
○
-
○
Start the servo motor.
ST2
Reverse rotation
start
-
-
○
-
○
Start the servo motor.
RS1
Forward rotation
selection
-
-
-
○
-
Servo motor torque generating direction is
selected.
RS2
Reverse rotation
selection
-
-
-
○
-
Servo motor torque generating direction is
selected.
SP1
Speed selection 1
-
-
○
○
-
The command rotation speed during operation is
selected.
SP2
Speed selection 2
-
-
○
○
-
SP3
Speed selection 3
-
-
△
△
-
CR
Clear
-
○
-
-
△
When turned ON, the droop pulse is erased.

- 12 -
●: Automatic ON can be set ○: Initial setting △: Assignment is available with parameter －: Assignment is not available
Symbol
Device name
Automatic
ON
P
S
T
CP/
CL
Function
DI0
Point table No/
Program No.
selection 1
●
-
-
-
○
Select point table, program and return to home
position mode with DI0 to DI7.
DI1
Point table No/
Program No
selection 2
●
-
-
-
○
DI2
Point table No/
Program No
selection 3
●
-
-
-
○
DI3
Point table No/
Program No
selection 4
●
-
-
-
○
DI4
Point table No/
Program No
selection 5
●
-
-
-
△
DI5
Point table No/
Program No
selection 6
●
-
-
-
△
DI6
Point table No/
Program No
selection 7
●
-
-
-
△
DI7
Point table No/
Program No
selection 8
●
-
-
-
△
MD0
Automatic/manual
selection
●
-
-
-
○
When this signal turns on, automatic operation
mode is activated. When this signal turns off,
manual operation mode is activated.
Note) In other than positioning mode, EM2 (Forced stop 2) cannot be forcibly set to automatic ON.
Be sure to set the EM2 wiring to the ON: EM2 release (operable) state.
(3) Output signal
Position control mode: P, Speed control mode: S, Torque control mode: T,
Positioning mode (Point table method): CP, Positioning mode (Program method): CL
○: Initial setting △: Assignment is available with parameter －: Assignment is not available
Symbol
Device name
P
S
T
CP/
CL
Function
ALM
Malfunction
○
○
○
○
This signal turns off while alarm is generated.
RD
Ready
○
○
○
○
When servo-on turns on and operation is available, this
signal turns on.
INP
In-position
○
-
-
○
This signal turns on when the droop pulse is within the
setting range.
SA
Speed
command
reached
-
○
-
△
When the servo motor rotation speed reaches the set
speed, this signal turns on.
VLC
Limiting speed
-
-
○
-
This signal turns on when reaching the speed restricted by
parameter.
TLC
Limiting torque
○
○
-
○
This signal turns on when reaching the torque set by
parameter while torque is generated. .
ZSP
Zero speed
detection
○
○
○
○
When the servo motor rotation speed is lower than the
speed set by parameter, this signal turns on.
MBR
Electromagnetic
brake interlock
△
△
△
△
This signal turns off in case of servo off or when alarm is
generated.

- 13 -
3.2.2 Speed control mode (sink input/output interface)
(1) Connection example
An example of a connection for the speed control mode is shown below. Connect wires as necessary.
For the source I/O interface, refer to "LECSB2-T□Operation Manual Chapter 3.2.2 (2)".
For notes and wiring details, refer to "LECSB2-T□Operation Manual Chapter 3.2.2".
For input/output signals, refer to "LECSB2-T Operation manual (simplified version), chapter 3.2.1 (2), (3)".
For details, refer to "LECSB2-T□Operation Manual Chapter 3.5".

- 14 -
3.2.3 Torque control mode (sink input/output interface)
(1) Connection example
An example of a connection for the torque control mode is shown below. Connect wires as necessary.
For the source I/O interface, please refer to "LECSB2-T□Operation Manual Chapter 3.2.3 (2)".
For notes and wiring details, refer to "LECSB2-T□Operation Manual Chapter 3.2.3".
For input/output signals, refer to "LECSB2-T Operation manual (simplified version), chapter 3.2.1 (2), (3)".
For details, refer to "LECSB2-T□Operation Manual Chapter 3.5".

- 15 -
3.2.4 Positioning Mode (Sink I/O Interface)
(1) Connection example
An example of a connection for the positioning mode (point table) is shown below. Connect wires as necessary.
For the source input/output interface, refer to "LECSB2-T□Operation Manual Chapter 3.9".
For notes and wiring details, refer to "LECSB2-T□Operation Manual Chapter 16.2.1 (1)".
For programming method, please refer to "LECSB2-T□Operation Manual Chapter 16.2.1 (2)".
For the equal division indexing method, please refer to "LECSB2-T□Operation Manual Chapter 16.2.1 (3)".
For the pushing operation, refer to "LECSB2-T□Operation Manual Chapter 17.2".
For input/output signals, refer to "LECSB2-T Operation manual (simplified version), chapter 3.2.1 (2), (3)".
For details, refer to "LECSB2-T□Operation Manual Chapter 16.2.3".

- 16 -
4. Parameter List for each Mode
This is a parameter that needs to be set in each control mode. Set as necessary.
For details, refer to "LECSB2-T□ Operation Manual, Chapter 5" and "LECSB2-T□ Operation Manual (Simplified
Edition), Chapter 5.3". For parameters other than this item, refer to "LECSB2-T □ Operation Manual, Chapter 5 ".
Setup software (MR Configurator2 TM: L EC-MRC2*) is always required to set parameters.
*1 Setup software 1.52E or higher is required.
*2 Prepare the setup software (MR Configurator2TM : LEC-MRC2*) separately.
*3 Prepare the USB cable (LEC-MR-J3USB) separately.
4.1Common to each mode
(1) [Basic setting parameter (No.PA□□)]
№
Abbreviation
name
initial value
unit
PA01
*STY
driving mode
1000h
PA02
* REG
Regeneration option
0000h
(2) [Input /output setting parameter (No. PD□□)]
This parameter is set when changing the allocation of input/output signals and when selecting automatic ON of
input signals.
For details, refer to "LECSB2-T□ Operation Manual, Section 5.1.4" and "LECSB2-T□ Operation Manual
(Simplified Edition), Section 5.5".
4.2 Position control mode
(1) [Basic setting parameter (No. PA□□)]
№
Abbreviation
name
initial value
unit
PA03
*ABS
Absolute position detection system
0000h
PA06
CMX
Electronic gear numerator (command input pulse magnification numerator)
1
PA07
CDV
Electronic gear denominator (command input pulse magnification
denominator)
1
PA08
ATU
Auto tuning mode
0001h
PA09
RSP
Auto tuning responsiveness
16
PA10
INP
In-position range
100
pulse
PA13
*PLSS
Command pulse input form
0100h
PA14
*POL
Rotation direction selection
0
PA21
*AOP3
Function selectionA-3
0001h

- 17 -
4.3 Speed control mode
(1) [Basic setting parameter (No. PA□□)]
№
Abbreviation
name
initial value
unit
PA08
ATU
Auto tuning mode
0001h
PA09
RSP
Auto tuning responsiveness
16
(2) [Extended setting parameter (No. PC□□)]
№
Abbreviation
name
initial value
unit
PC01
STAs
Velocity acceleration time constant
0
Ms.
PC02
STBs
speed deceleration time constant
0
Ms.
PC05
SC1
Internal speed command 1
100
r/min
PC06
SC2
Internal speed command 2
500
r/min
PC07
SC3
Internal speed command 3
1000
r/min
PC08
SC4
Internal speed command 4
200
r/min
PC 09
SC5
Internal speed command 5
300
r/min
PC10
SC6
Internal speed command 6
500
r/min
PC11
SC7
Internal speed command 7
800
r/min
PC12
VCM
Analog speed command Maximum rotation speed
0
r/min
4.4 Torque control mode
(1) [Extended setting parameter (No. PC□□)]
№
Abbreviation
name
initial value
unit
PC01
STAs
Velocity acceleration time constant
0
Ms.
PC02
STBs
speed deceleration time constant
0
Ms.
PC05
SC1
Internal speed limit 1
100
r/min
PC06
SC2
Internal speed limit 2
500
r/min
PC07
SC3
Internal speed limit 3
1000
r/min
PC08
SC4
Internal speed limit 4
200
r/min
PC 09
SC5
internal speed limit 5
300
r/min
PC10
SC6
internal speed limit 6
500
r/min
PC11
SC7
internal speed limit 7
800
r/min
PC13
TLC
Analog torque command maximum output
100.0
%

- 18 -
4.5 Positioning mode
(1) [Basic setting parameter (No. PA□□)]
№
Abbreviation
name
initial value
unit
PA03
*ABS
Absolute position detection system
0000h
PA06
CMX
Electronic gear numerator (command input pulse magnification numerator)
1
PA07
CDV
Electronic gear denominator (command input pulse magnification
denominator)
1
PA08
ATU
Auto tuning mode
0001h
PA09
RSP
Auto tuning responsiveness
16
PA10
INP
In-position range
100
pulse
PA14
*POL
Rotation direction selection
0
PA21
*AOP3
Function selectionA-3
0001h
(2) [Positioning setting parameter (No. PT□□)]
№
Abbreviation
name
initial value
unit
PT01
*CTY
Command mode selection
0000h
PT03
*FTY
Feed function selection
0000h
PT04
*ZTY
Origin return type
0010h
PT05
ZRF
Origin return speed
100
r/min
PT07
ZSTMore
Origin shift amount
0
µm _
PT08
*ZPS
Origin return position data
0
× 10 STM μm _
PT13
JOG
JOG speed
100
r/min
PT15
LMPL
Software limit +
0
× 10 STM μm _
PT16
LMPH
PT17
*LMNL
Software limit -
0
× 10 STM μm _
PT18
*LMNH
(3) [ I /O setting parameter (No. PD□□)]
A) Point table
This parameter is set when changing the allocation of input/output signals and when using the point table
with a maximum of 255 points.
For details, refer to "LECSB2-T Operation Manual (Simplified Edition), Section 5.5" and "LECSB2-T□
Operation Manual, Section 16.4.4".
B) Program method
This parameter is set when changing the assignment of input/output signals.
For details, refer to "LECSB2-T Operation Manual (Simplified Edition), section 5.5" and "LECSB2-T□
Operation Manual, Section 16.10.4 ".
C) Pushing operation
This parameter is set when changing the allocation of input/output signals and when using the point table
with a maximum of 255 points.
For details, refer to "LECSB2-T Operation Manual (Simplified Edition), section 5.5", "LECSB2-T□ Operation
Manual, section 17.7.2 ", and "LECSB2-T□ Operation Manual, section 17.9".

- 19 -
5. Parameter setting from setup software (MR Configurator2TM)
The procedure for setting typical parameters from the setup software (MR Configurator2 TM: LEC-MRC2*) is
explained. For details of parameters, refer to "LECSB2-T Operation Manual, Chapter 5 ".
5.1 Setup software (MR Configurator 2TM)
*1 Setup software version 1.52E or higher is required.
*2 Prepare the setup software (MR Configurator2TM: LEC-MRC2*) separately.
*3 Prepare the USB cable (LEC-MR-J3USB) separately.
5.1.1 Installation Method
" MR Configurator2TM Operation Manual" in the " Setup Software (MR Configurator2TM) " CD
("Manual¥ ib0300160 *.pdf ") to install the " setup software (MR Configurator2TM) ".
After the installation is completed, a software called “MR Configurator2” will be added to your PC.
5.2 Driver basic settings for first commissioning
Turn on the main circuit power supply (AC 200V) and control power supply (AC 200V) of the LECSB2-T.
the driver display is as shown below, set the EM2 (forced stop 2 ) wiring to ON : Forced stop canceled
(operable).
Refer to "LECSB2-T□ Operation Manual, Chapter 4 " when turning on the power for the first time.
This product can be used by adding the "MR Configurator2 dedicated file for LECSB-T" to the setup software
(MRConfigurator2TM: LEC-MRC2□).
Please download the dedicated file from our website.
