INSTRUCTION MANUAL
G
GU UI ID DE E F FO OR R U US SI IN NG G T TH HE E D DI IS SH HW WA AS SH HE ER R A AN ND D T TH HE E W WA AS SH HI IN NG G P PR RO OG GR RA AM MS S

Contents
15
1. Description of the controls________________________________16
2. Troubleshooting _______________________________________25
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
This user-friendly manual will provide answers to all your questions
about use of the dishwasher.
For any other information about use and maintenance of the dishwasher,
read the enclosed manual carefully.
USER INSTRUCTIONS: useful information is provided for the use of the
washing programs and all the dishwasher's functions.

User instructions
16
1. Description of the controls
1.1 Front panel
All the dishwasher control are grouped on the front panel. Programming
and option selection are only possible with the door closed.
1ON/OFF BUTTON
2START/PAUSE BUTTON
3SELECTION PROGRAMS BUTTON
4PROGRAMS LIGHTS
5"3/1" OPTION BUTTON (on some models only)
6"3/1" OPTION LIGHT (on some models only)
7DELAY PROGRAM BUTTON (on some models only)
8DELAY PROGRAM LIGHTS (on some models only)
9NO SALT LIGHT
68910 11 4
157 32
10 NO RINSE AID LIGHT
11 RECESSED DOOR HANDLE

User instructions
17
SETTING THE WASHING PROGRAM
To select the most suitable program for the dishes to be washed refer to
the table below, which indicates the most appropriate program according
to dish type and degree of soiling.
DURATION CONSUMPTION
PROGRAM SELECTION TYPE AND GRADE DIRT PROGRESS
PROGRAM MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
SOAK
PANS AND DISHES
IN WAITING OF
COMPLETING
THE LOAD
Cold prewash 15' 60,03
LIGHT DISHES
NOT VERY DIRTY
Wash at 45°C
Cold rinse
Rinse at 68°C
Dry
70' 15 1,15
BIO
(*) Bio
PANS AND DISHES
NOT VERY DIRTY BUT
WITH DRY RESIDUALS
Cold prewash
Wash at 50°C
Rinse at 62°C
Dry
180' 171,05
NORMAL
PANS AND DISHES
DIRTY AND WITH
DRY RESIDUALS
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 64°C
Dry
110' 20 1,40
EXTRA
HYGIENE
(**)
PANS AND DISHES
VERY DIRTY AND
WITH DRY RESIDUALS
Prewash at 45°C
Wash at 70°C
2 cold rinses
Rinse at 70°C
Dry
125' 24 1,77
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
Only run the soak program with half loads.
The "3/1" option (5)is available for all programs except the soak program.
(*) Reference program as per EN 50242 standard.
(**) The "EXTRA HYGIENE" program terminates with an anti-bacteria rinse that ensures a further
reduction in the bacteria level. If the temperature falls during this stage of the program (e.g.
because the door is opened or due to a power blackout), the program lights (4)flash to warn
that the anti-bacteria effect is not guaranteed.
(1) Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and room
temperatures, and the type and amount of dishes.

User instructions
18
1.2 Washing programs
The dishwasher is equipped with a control panel, described in chapter
"1. Description of the controls", from which it is possible to carry out all
the power switch-on, switch-off and programming operations.
Before starting a washing program make sure that:
•The water supply tap is open.
•The correct amount of detergent has been added to the
dispenser.
•The baskets have been correctly loaded.
•The spray arms are able to rotate freely and without
obstruction.
•The dishwasher door is securely closed.
SWITCHING ON
When the ON/OFF button (1) is pressed, the dishwasher switches on.
The indicator lights will display the dishwasher's "status".
68910 11 4
157 32
