Smeg UD516DUK User manual

1
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
SUMMARY
1PRODUCT IDENTIFICATION.................................................................................................................................. 3
1.1 APPLICATION, GENERAL FUNCTIONS ANDINTENDED USE............................................................................. 3
1.2 NAME AND ADDRESSOF MANUFACTURER ORDISTRIBUTOR........................................................................ 3
SMEG S.P.A. ............................................................................................................................................................ 3
1.3 DECLARATION OFCONFORMITY TO PRODUCT STANDARDS.......................................................................... 3
1.4 DESCRIPTION OF THE APPLIANCE................................................................................................................. 4
2SYMBOLS USED IN THE MANUAL ........................................................................................................................ 5
3SAFETY PRECAUTIONS AND INSTRUCTIONS........................................................................................................ 6
3.1 CORRECT INSTALLATION.............................................................................................................................. 6
3.2 SAFE USE...................................................................................................................................................... 7
3.3 CORRECT MAINTENANCE............................................................................................................................. 8
4PRODUCT CHARACTERISTICS............................................................................................................................... 9
4.1 OVERALL DIMENSIONS FOR BUILT-UNDER INSTALLATION............................................................................. 9
4.2 TECHNICAL CHARACTERISTICS.....................................................................................................................11
5PREPARING THE APPLIANCE FORUSE.................................................................................................................12
5.1 POSITIONING AND INSTALLATION...............................................................................................................12
5.2 CONNECTION TO THE WATER SUPPLY.........................................................................................................14
5.3 DRAINCONNECTION...................................................................................................................................14
5.4 CONNECTION TO THEELECTRICITY SUPPLY..................................................................................................15
6FIRST START-UP..................................................................................................................................................16
6.1 FIRST START-UP ..........................................................................................................................................16
6.2 PREPARING FOR USE ( IMPORTANT )..........................................................................................................16
6.3 USING THE WATER SOFTENER (ON MODELS WITH THIS FEATURE ONLY)......................................................16
7CONTROL PANEL................................................................................................................................................17
7.1 SET-UP (AUTHORISED STAFFONLY)............................................................................................................18
7.2 MODIFIABLE PARAMETERS..........................................................................................................................19
7.3 STARTING THE PERISTALTIC PUMPS – RAPID FILLING OF DETERGENT AND RINSE AID DELIVERY CIRCUIT......22
8MALFUNCTIONS SHOWN ON THE DISPLAY (FOR THE TECHNICIAN)....................................................................23
9INSTRUCTIONS FOR THE USER............................................................................................................................25
9.1 BEFORE WASHING.......................................................................................................................................26
9.2 FIRST USE EACHDAY (TANK AND BOILEREMPTY)........................................................................................27
9.3 OPERATING ANOMALIES.............................................................................................................................28
9.4 PROGRAM CHANGE ....................................................................................................................................29
10 CHOSING THE PROGRAM ...............................................................................................................................30
11 BASKETS PROVIDED .......................................................................................................................................31
12 MAINTENANCE AN CLEANING........................................................................................................................32
12.1 CLEANING THE FILTER DURING THE DAY......................................................................................................33
12.2 TOTAL PUMP-OUTAT THE END OF THE DAY................................................................................................33
12.3 TOPPING UP WITH REGENERATING SALT (FOR MODELS WITH SOFTENER)...................................................34
12.4 ROUTINEINSPECTIONOF THE SPRAY ARM (ONCE AWEEK )........................................................................34
12.5 LENGTHY PERIODS OUT OF USE...................................................................................................................34
13 TROUBLESHOOTING.......................................................................................................................................35
14 MALFUNCTIONS SHOWN ON THE DISPLAY (FOR THE USER)...........................................................................37

2
SMEG thanks you for choosing one of its products.
Thismanual is an integral part of the appliance. Take good care of it andkeep it to hand throughout
the appliance’s life cycle, since it contains important information about assembly, safety, use and
maintenance.
In the event that the appliance is sold on, consign this manual to the new owner.
Before putting the applianceinto operation,read all theinstructions inthismanual carefully tobecome familiar with
the rightconditions for theproperuse ofyourprofessionaldishwasher.

3
1PRODUCT IDENTIFICATION
1.1 Application, general functions and intended use
This dishwasher is intended for professional use in the restaurant and institutional catering sector
and complies with the relevant safety regulations. However, misuse may cause injury and/or
damage, and therefore the dishwasher must only be used by suitably trained staff.
This dishwasher is designed for use innon-mobile premises and is intended only forwashing cutlery
and dishes (plates, ovenware, cups, glasses, bowls, etc.) stable at the temperature and humidity
generated by the appliance. Any other type of use is not permitted and may be dangerous.
Persons whose physical, sensory or mental capabilities, inexperience or lack of knowledge render
them unable to use the dishwasher safely must not use it without the supervision and guidance of
a responsible person.
The manufacturer is not liable for any injury or damage caused by failure to comply with the
instructions given in this manual, misuse, tampering with even a single part of the appliance, or the
use of non-genuine spare parts.
1.2 Name and address of manufacturer or distributor
Smeg S.p.A.
Via Leonardo da Vinci, 4 - 42016 Guastalla (RE) Tel. [phone] - Fax + 39 0522 821453
Internet: www.smegfoodservice.com, email: [e-mail]
Our Sales Department staff will be able to provide you with information about prices and special
offers.
Our After-Sales Department will be able to provide you with guidance about keeping your device
functioning correctly and put you in touch with your nearest authorised Service Centre. Our entire
product offering can be viewed at our website.
1.3 Declaration of conformity to product standards
This appliance complies with the relevant safety regulations and conforms to the requirements of
directives 2006/42/EC and 2004/108/EC.
The dishwasher is also marked in compliance with European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
For information on the treatment, recovery and recycling of this product, contact the
local authority, domestic waste collection service, or your Smeg reseller.
Make sure that this product is scrapped correctly to safeguard the environment and
health.

4
1.4 Description of the appliance (according to the model)
U COVER (TOP)
D DISPLAY AND CONTROL PANEL
A FRONT LOADING/UNLOADING DOOR
V SERVICE COMPARTMENT
F ADJUSTABLE FEET

5
2SYMBOLS USED IN THE MANUAL
This symbol instructs the user to read the instructions in the manual with care.
This symbol appears next to information important for the safety of people and the
appliance.
This symbol is applied to some parts which contain live electrical components and
indicates the risk of electric shock.
This symbol is applied close to the terminal used to earth the appliance's electrical
system.
This symbol appears next to important information. Read the instructionsprovided
with care and comply with the procedures and rules described.
This symbol appears next to information and technical instructions intended for the
qualified staff who are to install, commission and test the appliance and carry out
any repairs.
This symbol indicates that at the end of its working life, the appliance must be
consigned to a disposal plant for recovery and recycling in accordance with the
relevant legislation in the country of installation. Contact a specialist centre for
disposal.

6
3SAFETY PRECAUTIONS AND INSTRUCTIONS
The precautions and instructions below contain important information and must be read with care.
The manufacturer does not accept responsibility for damage caused byfailure to comply with the
safety precautions and instructions.
3.1 Correct installation
The dishwasher must be installed by an authorised technician.
When handling andinstalling the dishwasher, always wear the most suitable personal
protection equipment (PPE) for the task in hand.
Do not install a dishwasher which has been damaged during transport. If in doubt,
consult your dealer.
If the power supply cable is damaged, do not run the dishwasher.
Do not install the dishwasher in areas subject to freezing temperatures or in
atmospheres with explosion risk (ATEX).
Any accessories may only be installed on the appliance if authorised by the
manufacturer.
Do not install the dishwasher next to appliances which irradiate strong heat (e.g. gas
burners, stoves, etc.) since they could cause damage.
If the dishwasher is installed above the ground, make sure that the stand and
dishwasher are secured properly and do not constitute a hazard.
Electrical safety is only ensured if the dishwasher is connected to an earth conductor
compliant with the relevant electrical regulations. If in doubt, have the system
inspected by a qualified electrician.
A circuit breaker and overcurrent protection device (magnetothermal switch or fuses)
must be installed in an easily accessible position on the dishwasher's power supply
line. This device must only serve the dishwasher and must be suitable for its rated
electrical characteristics.
Do not connect the dishwasher to the electrical mains by means of adapters or
extensions, since they do not guarantee the safety required.
If the dishwasher is connected to the electrical mains by means of a plug, it must be
of the same type as the power socket, suitable for the appliance's rated electrical
characteristics and compliant with the relevant national regulations on electrical
systems. The power plug must be easily accessible after the appliance has been
installed.
Only use new hoses for connection to the water supply. Old hoses or hoses salvaged
from previous installations must not be used.
The drain connection must be made in accordance with the relevant national
regulations. Substandard connections may cause flowback and in some cases
pollution.

7
3.2 Safe use
The staff assigned to use the dishwasher must be suitably trained and instructed.
The appliance is not suitable for use by juveniles or persons with reduced physical,
sensorial or mental capacities, or those without the necessary knowledge and
experience. Such persons may only use the appliance under the supervision of a
person responsible for their safety.
Do not leave the dishwasher door open. Risk of tripping or injury against the edges
of the door.
Do not sit or lean on the open door. This may tip over or damage the appliance.
The water inside the dishwasher is not drinkable.
Do not use the dishwasher for washing or soaking foods.
Do not use the water inside the dishwasher for defrosting foods, even if they are in
airtight containers.
When using the dishwasher, remember that the plates are very hot at the end of a
wash cycle.
Knives and pointed kitchen equipment must be placed in the basket with their tips
downwards, or horizontally, taking care not to allow them to protrude from the basket
The dishwasher is only intended for use with water and detergents suitable for
washing in professional dishwashers. The use of other products may damage both
the dishes and the appliance.
Do not operate the dishwasher with organic solvents or flammable liquids. Never load
dishes dirty with ash, wax or paint.
When handling detergents comply strictly with the instructions provided by the
detergent producer.
Always keep the detergent safety datasheets within reach so that the operator can
consult them easily if necessary.
Swallowing or inhaling detergents may cause serious injury to the nose, mouth and
throat. If detergent has been inhaled or swallowed, seek medical advice
immediately.

8
3.3 Correct maintenance
Do not clean the machine with a water jet machine, high-pressure or steam cleaners.
Before performing any maintenance procedure on the appliance disconnect it from
the mains electricity supply. Touching live electrical components, even accidentally,
may be very dangerous.
Never open the dishwasher's case. Electric shock hazard. Only the authorised
technician may access the internal parts of the dishwasher.
The dishwasher may only be repaired by the authorised service organisation.
Substandard repairs may cause damage or danger for the user.
No alterations or changes of any kind to the appliance's electrical circuits or
mechanical structure are permitted. The manufacturer declines all responsibility for
damage arising from unauthorised alterations.
Replace any faulty parts only with genuine spare parts. The manufacturer declines
all liability for damage resulting from the use of non-genuine spare parts.
The power supply cable, if fitted, must be replaced by the manufacturer or an
authorised service centre in accordance with the technical data specified on the
wiring diagram supplied with the appliance, to prevent all risks.

9
4PRODUCT CHARACTERISTICS
4.1 Overall dimensions
R LOWER BACK PANEL E ELECTRICITY SUPPLY CABLE
C FILLER HOSE P PERISTALTIC HOSES
Q EARTH TERMINAL S DRAIN HOSE
T EXTERNAL DISPENSER POWER CABLE ENTRY POINT

10
4.2 Overall dimensions
R LOWER BACK PANEL
C FILLER HOSE
Q EARTH TERMINAL
E ELECTRICITY SUPPLY CABLE
P PERISTALTIC HOSES
S DRAIN HOSE
T EXTERNAL DISPENSER POWER CABLE ENTRY POINT

11
4.3 Technical characteristics
Electricity supply - See technical data
plate and
electrical wiring
diagram supplied
with the
appliance
Intake water pressure -
Intake water temperature -
Use - Indoor
Max. working altitude m 2000
Working ambient temperature °C 10 - 35
Relative humidity 80% for
temperatures up
to 25°C with
linear decrease to
50% at the
temperature of
35°C
Intake water hardness
(models with softener) °f ≤ 60
Intake water hardness
(models without softener) °f ≤ 15
Water intake flow rate
(models with rinsing pump) L/min min 6
Water intake flow rate
(models without rinsing pump) L/min min 12
Intake hose connection - threaded 3/4 “
Drain minimum diameter mm 25
Drain height (above appliance installation surface) mm max 600
Rinse cycle water consumption L 3.2
Boiler capacity L 6
Tank capacity L 11
Noise level LpA < 60 dB(A)
Degree of protection IPX 4
Net weight kg ˜ 60/85
Power supply cable type ◄HAR►H07RN-F

12
5PREPARING THE APPLIANCE FOR USE
Convey the dishwasher to the installation site, remove the packaging and check the appliance and
components for damage; any damage found must be reported to the transporter in writing. The
packagingcomponents(plasticbags,expandedpolystyrene,nails,etc.)mustnotbe leftwithinreach
of children and pets since they are potentially dangerous. All packaging materials used are
environment-friendly. They can be kept without constituting any hazard, or may be disposed of at
a specialist waste disposal centre. The plastic components suitable for recycling are marked as
follows:
PE -polyethylene: externalpackaging film, bag containing the instructions, protective bags.
PP - polypropylene: straps used to close the packaging.
PS -expanded polystyrene: cornerguards, top of packaging.
Wooden and cardboard components can be disposed of in accordance with the local regulations.
5.1 Positioning and installation
Place the dishwasher in the chosen point and remove the protective film. Level the dishwasher
(with the aid of a spirit level) on its four feet, adjusting them to ensure that it is stable. If the
dishwasher is installed above the ground, make sure that the stand and dishwasher are secured
properly and do not constitute a hazard.
All operations described in this section must be carried out and/or checked by the
qualified staff who install and commission the dishwasher.
The systems and premises in which the dishwasher is installed must comply with the
relevant regulations.
If the dishwasher is installed next to another appliance, also check the
recommendations provided by the manufacturer of the adjacent appliance.
Installations other than those described must first be approved by the manufacturer.
Use only professional furnishings and units in the vicinity of the dishwasher. Any
other types of furnishing may be damaged.

13

14
5.2 Connection to the water supply
Check that the intake water pressure, flow rate and temperature are as stated in the dishwasher's
technical characteristics. If the dynamic pressure exceeds the limit stated in
the technical characteristics, a pressure reducer must be installed. If the
pressure is lower, it might be necessary to fit a special pump to ensure
optimal performance. Connect the water intake hose to a connector with ¾”
gas threaded fitting, inserting the filter "A" provided. The tap must be easily
accessible after installation of the appliance.
5.3 Drain connection
The dishwasher is fitted with a drain pump and can operate with drain connections on the floor or
wall. Before connecting the hose, check that the diameter and height of the wall drain connection
are as stated in the dishwasher's technical characteristics. When connecting the dishwasher's
drain hose, take care to avoid kinks, sharp bends orcrushing. Since the drain water temperature
can be very high, the end of the drain hose must be fixed to the drain connection using the hose
clamps provided.
Only use new hoses for connection to the water supply. Old hoses or hoses salvaged
from previous installations must not be used.
If the water supply system has been unused for a long time or if work has been done
on it, before connecting the appliance's intake hose run the water to flush the air
and dirt from the pipes.
FOR MODELS WITH A WATER SOFTENER
An “approved” double check valve or some other noless effective device providing
backflow prevention protection to at least fluid category two shall be fitted at the
point of connection between the water supply and the fitting or appliance.
FOR MODELS WITHOUT A WATER SOFTENER
An “approved” single check valve or some other no less effective device providing
backflow prevention protection to at least fluid category two shall be fitted at the
point of connection between the water supply and the fitting or appliance.
The drain connection must be made in accordance with the relevant national
regulations. Substandard connections may cause flowback and in some cases
pollution.
No extensions must be added to the drain hose supplied with the appliance. Any
extensions might cause drainage problems.

15
5.4 Connection to the electricity supply
The dishwasher must be connected to the electrical system by authorised, skilled staff, in
accordance with the relevant regulations. Also comply with the technical instructions for the
connection provided with the appliance. The dishwasher's rated electrical characteristics are
provided on its technical data plate. A circuit breaker with contact gap rated for category II
overvoltage and an overcurrent protection device (magnetothermal switch or fuses) must be
installed in an easily accessible position on the dishwasher's power supply line. These devices must
only serve the dishwasher and must be suitable for its rated electrical characteristics. The
electrical protection devices must undergo a functional test before the dishwasher is put into
operation. If the dishwasher is connected to the electrical mains by means of a plug, it must be of
the same type as the power socket, suitable for the appliance's rated electrical characteristics and
compliant with the relevant national regulations. The power plug must be easily accessible after
the appliance has been installed.
Electrical safety is only ensured if the dishwasher is connected to an earth conductor
compliant with the relevant electrical regulations. If in doubt, have the system
inspected by a qualified electrician.
Donot connect the dishwasher tothe electrical mains by means of adapters or
extensions,since they may cause dangerous overheating.
Connect the appliance to the earth system. The earth connection terminal is low
down on the back of the appliance and is marked with the symbol.
The dishwasher is always powered up unless the master switch is turned off or, on
appliances with power plug, the plug is disconnected.

16
6FIRST START-UP
6.1 First start-up
The electrical protection system must undergo a functional test before the appliance is put into
operation.
The appliance must be installed and/or inspected by qualified staff, who will start it up for the first
time and provide the relevant operating instructions.
6.2 Preparing for use ( Important )
The rinse aid dispenser is fitted onall models, the detergent dispenser only on some.
If both dispensers are present put the external detergent and rinse aid containers in place and
insert the respective intake hoses on the rear of the appliance into them. Red hose: detergent,
blue hose: rinse aid.
Before inserting the hoses into the containers, fit the weights (needed to
ensure that they always draw in liquid from the bottoms of the containers)
and thefilters onto their ends as shown. If the detergent dispenser is not
factory-fitted, it can be retrofitted after ordering the relative kit.
6.3 Using the water softener (on models with this feature only)
The quantity of lime in the water (which indicates its hardness) causes
whitish marks on dry dishes and dishes alsotend to lose their shine over
time. The dishwasher is equipped with an automatic water softener which
removes the substances that cause hardness from the water with the aid of
regenerating salt.
The first time the dishwasher is used, a litre of water must be poured into the
tank with the salt. Whenever the tank is filled, always take care to ensure that
the cap is firmly closed. The mixture of water and detergent must not get into
the salt tank, as this would impair operation of the regeneration system. In
this case warranty cover will be forfeited.
IMPORTANT:
Wheneverthetypeofdetergentorrinseaidis changed,itisABSOLUTELYESSENTIALtoflushout
the peristaltic pumps by placing the external intake pipes in water for a few cycles. Always use
only products specifically recommended for use in a professionaldishwasher. Failure to comply
with this recommendation leads to forfeiture of the warranty entitlement on the appliance’s
watersystem.Replacementoftheinternal tubeofthe detergentandrinseaidperistalticpumps
is recommended every 12 months or 15.000 wash cycles, by the After-Sales Service.

17
7CONTROL PANEL
On-off button
Program selection button
Start CONFIRM/PAUSE button
Total emptying button (tank and boiler)
Additional function selection button
L1 Mains power on light
L2 Light indicating dishwasher in operation, cycle running, FILL running…. (blue), ready
(green), malfunction (red)
L3 Pump-out in progress light
No rinse-aid symbol (if a system for monitoring outside the dishwasher is provided)
Tank heating element on symbol
Nosalt symbol (if softener is fitted)
Boiler element on symbol
No detergent symbol (if a system for monitoring outside the dishwasher is provided)
Light L2
Green light: dishwasher ready
Blue light: dishwasher in operation (washing in progress, FILL in progress ....)
Red light: indicates a malfunction
The instructions apply to "undercounter" and hood-type dishwashers, so some sections of the
manual may describe procedures referring to one or the other type, depending on the model
purchased (e.g. open the door/lift the hood....).

18
When the display control panel is switched on, the
display shows the type of dishwasher (PRF 400,
PRF 500, CAPOTE…….), followed by the firmware
version and update installed.
If the dishwasher is already powered up, press the
on/off button for direct display of the firmware
version and update installed.
7.1 SET-UP (Authorised staff only)
Dishwasher parameter modification procedure
With the tank empty
1- Switch the appliance on; the display will show
“FILL” and filling will start.
2- Open the door/lift the hood (depending on the
model); "CLOSE"will appear on the display
3- Press the button and hold it down for 5/7
seconds. When -------- appears on the display, release
the button and press it again to access the main PCB
setup menu.
With the tank full/the hood open
1 - Press the button and hold it down for 5/7
seconds. When -------- appears on the display, release
the button and press it again to access the main
PCB setup menu.
All the modifiable parameters can now be displayed,scrolling through them with the button.
Press the button to select the value required for each parameter.
To confirm the value required simply quit the menu or move on to the next parameter by pressing
.
Quitting the setup menu automatically: wait about 3 minutes without using the controls.
Quitting the setup menu in manual mode: hold the ON/OFF button until the beep sounds; the
dishwasher switches off.
Set-up
During first start-up, the functions/parameters listed below must be set or adjusted:

19
7.2 Modifiable parameters
The illustrations are purely guideline. The minimum and maximum temperatures
available depend on the model (glass washer, dishwasher, undercounter or hood-
type model, ..).
Rinsing temperature
(boiler temperature)
Washing temperature
(tank temperature)
Warning: The tank and boiler temperatures shown on the display may bedifferent from the
actual temperatures by a few degrees, especially in transient phases (just after theFILL is
completed, just after the end of the cycle, etc.) due to the inertia of the measurement probe.
Adjusting rinse aid dispensing (optional if installed)
Every time is pressed, the
value increases of 0,1 g/l up
to a max. of 2 g/l.
Default: 1,2 g/l.
Adjusting detergent dispensing (optional if installed)
Every time is pressed, the
value increases of 0,2 g/l up
to a max. of 10 g/l.
Default: 2,6 g/l.
Autostart function
Set at “on” to start the cycle when the hood/door is closed.
Set at “off” to start the cycle after confirmation with the
start button .

20
Regeneration frequency setup (models with softener)
* (Default value: H03; modify the parameter to suit the mains water hardness.
At first use, the salt tank has to be filled. It is subsequently sufficient simply to fill up with
regenerating salt when necessary.
Mains water hardness setting table
Ppm-
mg/l
Hardness
°d German
degrees
Hardness
°f French
degrees
Setting
level
Regeneration off
H00
150
8,5
15
H01
200
11
20
H02
300
17
30
* H03
With values over 60°f an external water
treatment device must be used and the
regeneration frequency must be set on H00.
400
22,5
40
H04
500
28
50
H05
600 33,5 60 H06
Important:
During normal operation, the dishwasher will performa number of washing cycles while
regeneration is in progress. During this time (5-6 cycles) the intake water will not be treated, but
this will not affect the washing quality.
Extra rinse
Rinsing is 10” longer than the standard in each washing
cycle.
On: enabled – OFF: disabled.
"Clean water" cycle
Whenthis option is activated, theappliance pumps out all
the water from the tank and then refills it with clean water
at every wash cycle. How long this operation takes depends
on the washing water temperature.
On: enabled – OFF: disabled.
N.B.: prolonged use of this option leads to higher detergent
and rinse aid consumption.
