Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the user
manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information: www.smeg.com/services/customer-service

EN
5
1 Your cooler/freezer 6
2 Safety and Environment
Instructions 7
General Safety...................................7
Intended Use.....................................9
Child Safety .....................................10
Compliance with WEEE Directive and
Disposing of the Waste Product.......10
Compliance with RoHS Directive .....10
Package Information........................10
3 Installation 11
Points to be paid attention to when the
relocation of the refrigerator .............11
Electrical connection........................11
Disposing of the packaging .............12
Disposing of your old refrigerator .....12
Placing and Installation ....................12
Adjusting the legs ............................13
Changing the illumination lamp .......13
Changing the door opening direction13
Door Open Warning.........................13
4 Preparation 14
Hints and Tips .................................15
5 Using your cooler/freezer 16
Icematic and ice storage container ..18
How to Freeze Fresh Foods ..........18
Recommendations for Preservation of
Frozen Foods ..................................20
Defrosting........................................20
Deep Freezer Information.................20
Defrosting the frozen foods..............20
Recommended Temperature
Settings...........................................21
6 Maintenance and cleaning 24
Protection of plastic surfaces ..........24
7 Troubleshooting 25
CONTENTS

EN
6
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your cooler/freezer
1. Control Panel
2. Flap (Fast-Freeze compartment)
3. Ice cube tray & Ice bank
4. Drawers
5. Adjustable front feet
1
2
3
5
4

EN
7
2Safety and Environment Instructions
This section provides the safety
instructions necessary to prevent the
risk of injury and material damage.
Failure to observe these instructions will
invalidate all types of product warranty.
Intended use
A
WARNING:
Keep ventilation openings,
in the appliance enclosure or
in the built-instructure, clear
of obstruction.
A
WARNING:
Do not use mechanical
devices or other
means to accelerate the
defrostingprocess, other than
those recommended by the
manufacturer.
A
WARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments of the
appliance, unless they are of
the type recommended by
the manufacturer.
A
WARNING:
Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
This appliance is intended to be used
in household and similar applications
such as
– staff kitchen areas in shops, offices
and other working environments;
– farm houses and by clients in hotels,
motels and other residential type
environments;
–bed andbreakfasttype environments;
– catering and similar non-retail
applications.
General Safety
• This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person
responsible for their safety. Children
should not be allowed to play with
this device.
• In case of malfunction, unplug the
device.
• After unplugging, wait at least 5
minutes before plugging in again.
• Unplug the product when not in use.
• Do not touch the plug with wet
hands! Do not pull the cable to plug
off, always hold the plug.
• Do not plug in the refrigerator if the
socket is loose.
• Unplug the product during
installation, maintenance, cleaning
and repair.
• If the product will not be used for
a while, unplug the product and
remove any food inside.
• Do not use the product when the
compartment with circuit cards
located on the upper back part of the
product (electrical card box cover) (1)
is open.

EN
8
1
1
• Do not use steam or steamed
cleaning materials for cleaning the
refrigerator and melting the ice inside.
Steam may contact the electrified
areas and cause short circuit or
electric shock!
• Do not wash the product by spraying
or pouring water on it! Danger of
electric shock!
• In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorized service
before doing anything.
• Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
• If the product has LED type lighting,
contact the authorized service for
replacing or in case of any problem.
• Do not touch frozen food with wet
hands! It may adhere to your hands!
• Do not place liquids in bottles and
cans into the freezer compartment.
They may burst out!
• Place liquids in upright position after
tightly closing the lid.
• Do not spray flammable substances
near the product, as it may burn or
explode.
• Do not keep flammable materials and
products with flammable gas (sprays,
etc.) in the refrigerator.
• Do not place containers holding
liquids on top of the product.
Splashing water on an electrified part
may cause electric shock and risk of
fire.
• Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product,
do not pull by holding the door
handle. The handle may come off.
• Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
• Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the
product to fall down and cause
damage to the parts.
• Take care not to trap the power
cable.
• When positioning the appliance,
ensure the supply cord is not trapped
or damaged.
• Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the appliance.
• Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.

EN
9
• To avoid contamination of food,
please respect the following
instructions:
• – Opening the door for long periods
can cause a significant increase of
the temperature in the compartments
of the appliance.
• – Clean regularly surfaces that can
come in contact with food and
accessible drainage systems.
• – Clean water tanks if they have not
been used for 48 h; flush the water
system connected to a water supply
if water has not been drawn for 5
days.
• – Store raw meat and fish in suitable
containers in the refrigerator, so that
it is not in contact with or drip onto
other food.
• – Two-star frozen-food
compartments are suitable for storing
pre-frozen food, storing or making
icecream and making ice cubes.
• – One-, two- and three-star
compartments are not suitable for the
freezing of fresh food.
• – If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the door
open to prevent mould developing
within the appliance.
1.1.1 HC Warning
If the product comprises a cooling
system using R600a gas, take care
to avoid damaging the cooling system
and its pipe while using and moving the
product. This gas is flammable. If the
cooling system is damaged, keep the
product away from sources of fire and
ventilate the room immediately.
C
The label on the inner left
side indicates the type of gas
used in the product.
1.1.2 For Models with
Water Dispenser
• Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar). If
your water pressure exceeds 80
psi (5.5 bar), use a pressure limiting
valve in your mains system. If you
do not know how to check your
water pressure, ask for the help of a
professional plumber.
• If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in
your installation. Consult Professional
plumbers if you are not sure that
there is no water hammer effect in
your installation.
• Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
Intended Use
• This product is designed for home
use. It is not intended for commercial
use.
• The product should be used to store
food and beverages only.
• Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.

EN
10
• Original spare parts will be provided
for 10 years, following the product
purchasing date.
Child Safety
• Keep packaging materials out of
children’s reach.
• Do not allow the children to play with
the product.
• If the product’s door comprises a
lock, keep the key out of children’s
reach.
Compliance with WEEE
Directive and Disposing of
the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU). This
product bears a classification symbol
for waste electrical and electronic
equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Do not dispose of the
waste product with normal
domestic and other wastes at the end
of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn about
these collection centers.
Compliance with RoHS
Directive
• This product complies with EU WEEE
Directive (2011/65/EU). It does
not contain harmful and prohibited
materials specified in the Directive.
Package Information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or
nonprofessional repair can have
safety consequences and might void
the guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets.
Please note that some of these spare
parts are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Door gaskets will be available for
10 years after the model has been
discontinued.

EN
11
3Installation
BIn case the information which are
given in the user manual are not
taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged,
shelves, accessories, crisper, etc.
inside your refrigerator should be
fixed with adhesive tape and secured
against impacts. Package should
be bound with a thick tape or sound
ropes and the transportation rules
on the package should be strictly
observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the refrigerator,
Check the following before you
start to use your refrigerator:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges are
intended to keep the distance which
will ensure the air circulation between
your refrigerator and the wall. (The
picture is drawn up as a representation
and it is not identical with your
product.)
2. Clean the interior of the
refrigerator as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the
refrigerator to the wall socket. When
the fridge door is opened, fridge
internal lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
5. Front edges of the refrigerator
may feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.

EN
12
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the doors
of your refrigerator and pass it sideways
through the door.
1. Install your refrigerator to a
place that allows ease of use.
2. Keep your refrigerator away
from heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do not
place your product on the materials
such as rug or carpet.
4. Place your refrigerator on an
even floor surface to prevent jolts.
5. Your product requires adequate
air circulation to function efficiently. If
the product will be placed in an alcove,
remember to leave at least 5 cm
clearance between the product and
the ceiling, rear wall and the side walls.
6. If the product will be placed in
an alcove, remember to leave at least
5 cm clearance between the product
and the ceiling, rear wall and the side
walls. Check if the rear wall clearance
protection component is present at its
location (if provided with the product).
If the component is not available, or if
it is lost or fallen, position the product
so that at least 5 cm clearance shall
be left between the rear surface of the
product and the wall of the room. The
clearance at the rear is important for
efficient operation of the product.

EN
13
Adjusting the legs
If your cooler/freezer is unbalanced;
You can balance your cooler/freezer
by turning its front legs as illustrated
in the figure. The corner where the leg
exists is lowered when you turn in the
direction of black arrow and raised
when you turn in the opposite direction.
Taking help from someone to slightly
lift the cooler/freezer will facilitate this
process.
Changing the door opening
direction
Door opening direction of your
refrigerator can be changed according
to the place you are using it. If this is
necessary, please call your nearest
Authorized Service.
Door Open Warning
(This feature is optional)
An audio warning signal will be given
when the door of your product is left
open for at least 1 minute. This warning
will be muted when the door is closed
or any of the display buttons (if any) are
pressed.
Positioning
This appliance should be installed in a
dry, well ventilated indoor position.
This appliance is intended to be used
at ambient temperature ranging from
10°C to 43°C.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in
a safe and comfortable way.The lamps
used in this appliance have to withstand
extreme physical conditions such as
temperatures below -20 °C.
(only chest and upright freezer)
This product is equipped with a
lighting source of the "G" energy
class.
The lighting source in this product
shall only be replaced by professional
repairers.

EN
14
4Preparation
• Your cooler/freezer should be
installed at least 30 cm away from
heat sources such as hobs, ovens,
central heater and stoves and at least
5 cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of the room
where you install your cooler/freezer
should at least be 10°C. Operating
your cooler/freezer under cooler
conditions is not recommended with
regard to its efficiency.
• Please make sure that the interior
of your cooler/freezer is cleaned
thoroughly.
• If two cooler/freezers are to be
installed side by side, there should be
at least 2 cm distance between them.
• When you operate your cooler/freezer
for the first time, please observe the
following instructions during the initial
six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• Due to temperature change as a
result of opening/closing the product
door during operation, condensation
on the door/body shelves and the
glass containers is normal.
• Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. Functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy under
these circumstances.
• For a freestanding appliance; ‘this
refrigerating appliance is not intended
to be used as a built-in appliance’.

EN
15
Hints and Tips
Hints for energy saving
• Most efficient use of energy is
ensured in the configuration with
the drawers in the bottom part of
the appliance and shelves evenly
distributed. Position of the door bins
does not affect energy consumption.
• Do not open the door frequently or
leave it open longer than necessary.
• Do not set too high temperature to
save energy unless it is required by
the characteristics of the food.
• If the ambient temperature is high
and the temperature control is set to
low temperature and the appliance
is fully loaded, the compressor may
run continuously, causing frost or ice
formation on the evaporator. In this
case, set the temperature control
toward higher temperature to allow
automatic defrosting and to save
energy this way.
• Ensure a good ventilation. Do not
cover the ventilation grilles or holes.
Hints for fresh food refrigeration
• Good temperature setting that
ensures preservation of fresh food is
a temperature less than or equal to
+4°C.
• Higher temperature setting inside the
appliance may lead to shorter shelf
life of food.
• Cover the food with packaging to
preserve its freshness and aroma.
• Always use closed containers for
liquids and for food, to avoid flavours
or odours in the compartment.
• To avoid the cross-contamination
between cooked and raw food, cover
the cooked food and separate it from
the raw one.
• It is recommended to defrost the
food inside the fridge.
• Do not insert hot food inside the
appliance. Make sure it has cooled
down at room temperature before
inserting it.
• To prevent food waste the new stock
of food should always be placed
behind the old one.
Hints for food refrigeration
• Meat (all types): wrap in a suitable
packaging and place it on the glass
shelf above the vegetable drawer.
Store meat for at most 1 -2 days.

EN
16
5Using your cooler/freezer
2
1
4
3
8
11
12
7
6
5
9
10
Indicator Panel
1. Quick Freeze Function:
Quick Freeze indicator turns on when
the Quick Freeze function is on. Press
QuickFreeze button again to cancel this
function. QuickFreeze indicator will turn
off and normal settings will be resumed.
QuickFreeze function will be cancelled
automatically 50 hours later if you do not
cancel it manually. If you want to freeze
plenty amount of fresh food, press
QuickFreeze button before you place
the food into the freezer compartment.
If you press the QuickFreeze button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
2. Quick Freeze Indicator
This icon flashes in an animated
style when the QuickFreeze function is
active.

EN
17
3. Freezer Set Function:
This function allows you to make
the freezer compartment temperature
setting. Press this button to set the
temperature of the freezer compartment
to -18, -20, -22 and -24 respectively.
4- Freezer Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Freezer Compartment.
5. Eco-Fuzzy (Special Economic
Usage) Function:
Press Eco-Fuzzy button to activate the
Eco Fuzzy Function. Cooler/freezer
will
start operating in the most economic
mode at least 6 hours later if the door
is not opened and any buton is not
pressed.The
economic usage indicator will turn
on when the function is active. Press
Eco Fuzzy button again to activate the
Eco-Fuzzy function.
6. Eco-Fuzzy (Special Economic
Usage) Indicator:
This icon lights up when the Eco-
Fuzzy Function is active.
7. High Temperature/Error Warning
Indicator:
This light comes on during high
temperature failures and error warnings.
8. Economic Usage Indicator:
Economic Usage Indicator turns on
when the Freezer Compartment is set
to -18°C. It turns off when the qfreeze
function is on.
9-Energy Saving Function
When you press this button, Energy
saving icon will light up and Energy
Saving Function will be activated. If
energy saving function is active, all
icons on the display other than energy
saving icon will turn off. When the
Energy Saving Function is active, if
any button is pressed or the door is
opened, Energy Saving Function will
be exited and the icons on display will
return to normal.If you press this buton
again, Energy Saving icon will turn off
and Energy Saving Function will not be
active.
10-Energy Saving Indicator
This icon lights up when the Energy
Saving Function is selected
11-Key Lock Mode
Press Key Lock button concurrently
for 3 seconds. Key lock icon will light
up and key lock mode will be activated.
Buttons will not function if the Key Lock
mode is active.
Press Key Lock button
concurrently for 3 seconds again. Key
lock icon will turn off and the key lock
mode will be exited.
12-Key Lock Indicator
This icon light up when the Key Lock
mode is activated.

EN
18
Icematic and ice storage
container
*optional
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating to
take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do not
put water in it. Otherwise, it will break.
How to Freeze Fresh Foods
• Foods to be frozen must be divided
into portions according to a size to
be consumed, and frozen in separate
packages. In this way, all the food
should be prevented from being re-
frozen by thawing.
• In order to protect the nutritional
value, the aroma and the color of
the foods as much as possible,
vegetables should be boiled for a
short period of time before freezing.
(Boiling is not necessary for foods
such as cucumber, parsley.) Cooking
time of the vegetables frozen in this
way is shortened by 1/3 than that of
the fresh vegetables.
• To extend the storage times of frozen
foods, boiled vegetables must first
be filtered and then hermetically
packaged as in the all types of foods.
• Foods should not be placed in
the freezer compartment without
package.
• The packaging material of the food
to be stored should be air-tight, thick
and durable and should not deform
with cold and humidity. Otherwise,
the food that is hardened by freezing
might pierce the package. Sealing
the package well is also important in
terms of securely storing the food.
The following packaging types are
suitable for use to freeze the food:
Polyethylene bag, aluminum foil,
plastic foil, vacuum bags and cold-
resistant storage containers with caps.
The use of the following types of
packaging is not recommended to
freeze the food;
Packaging paper, parchment paper,
cellophane (gelatin paper), garbage
bag, used bags and shopping bags.

EN
19
• Hot foods should not be placed in the
freezer compartment without cooling.
• When placing unfrozen fresh foods in
the freezer compartment, please note
that it does not contact with frozen
foods. Cool-pack (PCM) can be
placed to the rack immediately below
the quick freezer rack for preventing
them from being getting warm.
• During the freezing time (24 hours) do
not place other food to the freezer.
• Place your foods to the freezing
shelves or racks by spreading them
so that they will not be cramped (it
is recommended that the packaging
does not come into contact with
each other).
• Frozen foods must be immediately
consumed in a short period of time
after defrosting and must never be
frozen again.
• Do not block the ventilation holes by
putting your frozen foods in front of
the ventilation holes located on the
back surface.
• We recommend you to attach a label
onto the package and write the name
of the foods in the package and the
freezing time.
Foods suitable for freezing:
Fish and seafood, red and white meat,
poultry, vegetables, fruit, herbaceous
spices, dairy products (such as cheese,
butter and strained yoghurt), pastries,
ready or cooked meals, potato dishes,
souffle and desserts.
Foods not suitable for freezing:
Yoghurt, sour milk, cream,
mayonnaise, leaved salad, red radish,
grapes, all fruits (such as apple, pears
and peaches).
• For foods to be frozen quickly and
thoroughly, the following specified
amounts per package should not be
exceeded.
-Fruits and vegetables, 0.5-1 kg
-Meat, 1-1.5 kg
• A small amount of foods (maximum
2 kg) can also be frozen without the
use of the quick freezing function.
To obtain the best result, apply the
following instructions:
1. Activate the quick freezing
function 30 hours before placing your
fresh foods.
2. 30 hours after pressing the
button, firstly place your food that
you want to freeze to the third drawer
from the bottom with higher freezing
capacity. If you have food remained,
place them in front of the second
drawer from the bottom.
3. The quick freezing function will
be automatically inactivated after 50
hours.
4. Do not try to freeze a large
quantity of food at a time. Within 24
hours, this product can freeze the
maximum food quantity specified as
«Freezing Capacity … kg/24 hours»
on its type label. It is not convenient to
put more unfrozen/fresh foods to the
freezer compartment than the quantity
specified on the label.
• You can review the Meat and Fish,
Vegetables and Fruits, Dairy Products
tables for placing and storing your
foods in the deep-freezer.

EN
20
Recommendations for
Preservation of Frozen
Foods
• While purchasing your frozen foods,
make sure that they are frozen at
appropriate temperatures and their
packages are not broken.
• Put the packages on the freezer
compartment as soon as possible
after purchasing them.
• Make sure that the expiration
date indicated on the packaging
is not expired before consuming
the packaged ready meals that
you remove from the freezer
compartment.
Defrosting
The ice in the freezer compartments is
automatically thawed.
Deep Freezer Information
The EN 62552 standard requires
(according to specific measurement
conditions) that at least 4.5 kg of
food for each 100 liter of freezer
compartment volume can be frozen
at a room temperature of 25°C in 24
hours.
Defrosting the frozen foods
Depending on the food diversity and
the purpose of use, a selection can be
made between the following options for
defrosting:
• At room temperature (it is not very
suitable to defrost the food by leaving
it at room temperature for a long
time in terms of maintaining the food
quality)
• In the refrigerator
• In the electrical oven (in models with
or without fan)
• In the microwave oven
CAUTION:
• Never put acidic beverages in glass
bottles and cans into your freezer due
to the risk of explosion.
• If there is moisture and abnormal
swelling in the packaging of frozen
foods, it is likely that they were
previously stored in an improper
storage condition and their contents
deteriorated. Do not consume these
foods without checking.
• Since some spices in cooked
meals may change their taste when
exposed to long-term storage
conditions, your frozen foods should
be less seasoned or the desired
spices should be added to the foods
after the thawing process.

EN
21
Recommended Temperature Settings
Freezer
compartment
setting
Remarks
-20 °C This is the default recommended
temperature setting.
-21,-22,-23 or -24
oC
These settings are recommended when
the ambient temperature is higher than 30°C
or when you think the refrigerator is not cool
enough due to frequent opening and closing
of the door.
Quick freeze (Quick) Use when you want to freeze your food in a
short time.It is recommended to be applied
to preserve the quality of your fresh food.
You do not need to use the quick freezing
function when putting your frozen food.
You do not need to use the quick freezing
function to freeze a small amount of fresh
food, up to 2 kg per day.

EN
22
Meat and Fish Preparation
Longest
storage
time
(month)
M e a t
products
Veal
Steak By cutting them 2 cm thick and placing foil between them or wrapping
tightly with stretch
6 – 8
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
6 – 8
Cubes In small pieces 6 – 8
Schnitzel,
chops
By placing foil between cut slices or wrapping individually with stretch 6 – 8
Mutton
Chops By placing foil between meat pieces or wrapping individually with
stretch
4 - 8
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
4 - 8
Cubes By packing the shredded meats in a refrigerator bag or wrapping them
tightly with stretch
4 - 8
Beef
Roast By packing the pieces of meat in a refrigerator bag or wrapping them
tightly with stretch
8 - 12
Steak By cutting them 2 cm thick and placing foil between them or wrapping
tightly with stretch
8 - 12
Cubes In small pieces 8 - 12
Boiled meat By packaging in small pieces in a refrigerator bag 8 - 12
Mince Without seasoning, in flat bags 1 - 3
Offal (piece) In pieces 1 - 3
Fermented sausage -
Salami
It should be packaged even if it has casing. 1 - 2
Jambon By placing foil between cut slices 2 - 3
Poultry
a n d
hunting
animals
Chicken and Turkey By wrapping in foil 4 – 6
Goose By wrapping in foil (portions should not exceed 2.5 kg) 4 – 6
Duck By wrapping in foil (portions should not exceed 2.5 kg) 4 – 6
Deer, Rabbit, Roe Deer By wrapping in foil (portions should not exceed 2.5 kg, and their bones
should be separated)
6 – 8
Fish
a n d
seafood
Freshwater fish (Trout,
Carp, Crane, Catfish)
After thoroughly cleaning the inside and scales, it should be washed
and dried, and the tail and head parts should be cut when necessary.
2
Lean fish (Sea bass,
Turbot, Sole)
4-6
Fatty fish (Bonito,
Mackerel, Bluefish, Red
Mullet, Anchovy)
2 - 4
Shellfish Cleaned and in bags 4 - 6
Caviar In its packaging, in an aluminum or plastic container 2 - 3
